面向 6G 的多維擴展通感一體化研究綜述
doi: 10.11999/JEIT231045
-
1.
大連理工大學信息與通信工程學院 大連 116024
-
2.
中國通信企業協會 北京 100846
-
3.
哈爾濱工業大學(威海)信息科學與工程學院 威海 264209
基金項目: 國家重點研發計劃 (2020YFB1807002)，國家自然科學基金(62371087, 62101091), 遼寧省應用基礎研究計劃 (2023TH2/101300197)
An Overview on Multi-dimensional Expanded Integrated Sensing and Communication for 6G
-
1.
School of Information and Communication Engineering, Dalian University of Technology, Dalian 116024, China
-
2.
China Association of Communications Enterprises, Beijing 100846, China
-
3.
School of Information Science and Engineering, Harbin Institute of Technology at Weihai, Weihai 264209, China
Funds: The National Key R&D Program of China (2020YFB1807002), The National Natural Science Foundation of China (62371087, 62101091), The Application and Fundamental Research Planning Project in Liaoning Province (2023TH2/101300197)
-
摘要: 面對第6代移動通信(6G)網絡立體覆蓋的互聯感知需求和無線設備廣泛接入造成的頻譜稀缺問題，基于無人機(UAV)的機動性和智能反射面(IRS)重構無線傳播環境特性的多維擴展通感一體化可實現立體網絡空間中通信和感知功能的相互協同，有效提升頻譜效率和硬件資源的利用率，滿足6G萬物智聯的無線網絡愿景。該文針對6G多維擴展通感一體化網絡架構展開綜述。首先，概述了 6G網絡愿景和通感一體化的理論基礎，并討論基于UAV和IRS多維擴展通感一體化的應用場景、發展趨勢和性能指標。然后，探討了超大規模多輸入多輸出天線、太赫茲、無線攜能通信、人工智能、隱蔽通信和有源反射面等6G關鍵前沿技術在基于無人機和智能反射面多維擴展通感一體化網絡中的潛在應用。最后，展望了未來6G多維擴展通感一體化的發展方向及關鍵技術挑戰。Abstract: Facing the demand for interconnectivity sensing of three-dimensional coverage for the sixth-Generation mobile communication (6G) networks and the spectrum scarcity issue caused by the widespread access of wireless devices, the multi-dimensional expanded Integrated Sensing and Communication (ISAC), based on Unmanned Aerial Vehicles (UAV) and Intelligent Reflecting Surfaces (IRS), is capable of achieving synergistic communication and sensing functions in the three-dimensional network space. This can effectively enhance spectrum efficiency, hardware resource utilization, and align with the wireless network vision of 6G Internet of Everything. This paper provides an overview of the architecture for the 6G multi-dimensional expanded ISAC. Firstly, it summarizes the theoretical foundations of the 6G network vision and ISAC networks, and the application scenarios, development trends, and performance indicators of multi-dimensional expanded ISAC based on UAV and IRS are discussed. Then, it investigates the potential applications of 6G key technologies, such as ultra-massive multiple-input and multiple-output antenna, terahertz, simultaneous wireless information and power transfer, artificial intelligence, covert communication, and active IRS, in multi-dimensional expanded ISAC networks based on UAV and IRS. Finally, the future development direction and key technical challenges of 6G multi-dimensional expanded ISAC sre prospected.
-
表 1 基于UAV和IRS多維擴展的通感一體化網絡應用場景
場景/應用分類 同步成像與環境重構 高精度定位與跟蹤 增強人類感官 動作和表情識別 智慧工廠 區域檢測和環境感知 設備定位和安裝 自動化測量和控制 產品質量檢測 垂直行業 智慧農業 作物生理監測和生產 自動化收取和存儲 種植環境檢測 作物質量監管 智慧交通 3D道路成像 無人駕駛與輔助駕駛 雨霧天氣路況監測 安全駕駛 環境監測 無人機集群管理 水利水文監測 污染與空氣質量檢測 殘障保障服務 公共服務 公共安全 災害應急管理和疏散 交通運輸安全 無接觸安全檢測 突發事件預測 城市管理 城市環境監督 城市文明監察 建筑安全風險檢測 全時段監控 災難救援 災情評估與災后重建 人員定位與物資投送 災區環境檢測 人員搜救 極端場景 戰場支援 實時情報獲取 精確打擊支持 敵對目標監視和偵測 敵情偵測與分析 應用 太空探測 地球和大氣監測 太空垃圾探測 星際空間探測 航天員健康檢測 海洋勘探 海洋資源勘探 海上巡邏與航行安全 海洋氣象和氣候監測 海洋生態監測
下載: 導出CSV
表 2 現有ISAC和波形設計簡要總結
參考文獻 ISAC波形設計 技術原理 優點 缺點 文獻[26, 27] 以感知為基礎的設計 將通信信號調制或引入感知系統中，在不影響
感知功能情況下實現通信功能與感知系統高度兼容 低數據速率 文獻[28, 29] 以通信為基礎的設計 利用通信波形、協議和架構進行感知，
通過目標回波提取感知信息與通信系統高度兼容 感知性能差 文獻 [30–32] 通感一體聯合優
化設計兼顧通信和感知的需求和性能指標 高性能感知和通信 設計復雜度高
下載: 導出CSV
表 3 基于UAV和IRS的多維擴展通感一體化網絡性能指標
性能分類 性能指標 具體要求 通信性能 帶寬和速率
穩定性傳輸數據的速度和容量，較大的帶寬能夠支持高分辨率圖像、視頻等大數據傳輸
保障UAV在高速運動和復雜環境中通信連接的可靠性，防止干擾和信號丟失感知性能 感知范圍
感知精度感知功能的有效覆蓋區域，UAV和IRS可提供更廣泛的環境信息
感知系統識別目標和獲取環境信息的準確度和可靠性，影響系統的決策能力多源數據
融合性能數據融合精度
傳輸時延不同傳感器數據融合后的信息準確性，能夠提供更全面、準確的環境認知
確保感知數據的快速獲取和信息交互效率，提高系統的實時決策能力數據質量
和準確性魯棒性
隱私和安全性在干擾和突發情況下，UAV的移動性和IRS環境重構能力保障系統功能的彈性設計
提供安全的數據傳輸和存儲機制，保障敏感信息的安全傳輸網絡協
同性能自適應性
能耗和計算資源基于IRS-UAV的無線網絡需實現空地網絡的相互協同，適應環境和任務需求的變化
保持低能耗，確保感知和數據處理和計算不過度消耗電力，提高UAV的續航能力
下載: 導出CSV
-
[1] 易芝玲, 王森, 韓雙鋒, 等. 從5G到6G的思考: 需求、挑戰與技術發展趨勢[J]. 北京郵電大學學報, 2020, 43(2): 1–9. doi: 10.13190/j.jbupt.2020-024.YI Zhiling, WANG Sen, HAN Shuangfeng, et al. From 5G to 6G: Requirements, challenges and technical trends[J]. Journal of Beijing University of Posts and Telecommunications, 2020, 43(2): 1–9. doi: 10.13190/j.jbupt.2020-024. [2] LIU Guangyi, HUANG Yuhong, LI Na, et al. Vision, requirements and network architecture of 6G mobile network beyond 2030[J]. China Communications, 2020, 17(9): 92–104. doi: 10.23919/JCC.2020.09.008. [3] ZHANG Shunqing, XIANG Chenlu, and XU Shugong. 6G: Connecting everything by 1000 times price reduction[J]. IEEE Open Journal of Vehicular Technology, 2020, 1: 107–115. doi: 10.1109/OJVT.2020.2980003. [4] HAN Chong, WANG Yiqin, LI Yuanbo, et al. Terahertz wireless channels: A holistic survey on measurement, modeling, and analysis[J]. IEEE Communications Surveys & Tutorials, 2022, 24(3): 1670–1707. doi: 10.1109/COMST.2022.3182539. [5] 趙亞軍, 郁光輝, 徐漢青. 6G移動通信網絡: 愿景、挑戰與關鍵技術[J]. 中國科學: 信息科學, 2019, 49(8): 963–987. doi: 10.1360/N112019-00033.ZHAO Yajun, YU Guanghui, and XU Hanqing. 6G mobile communication networks: Vision, challenges, and key technologies[J]. SCIENTIA SINICA Informationis, 2019, 49(8): 963–987. doi: 10.1360/N112019-00033. [6] AKAN O B and ARIK M. Internet of radars: Sensing versus sending with joint radar-communications[J]. IEEE Communications Magazine, 2020, 58(9): 13–19. doi: 10.1109/MCOM.001.1900550. [7] LIU Rang, LI Ming, LUO Honghao, et al. Integrated sensing and communication with reconfigurable intelligent surfaces: Opportunities, applications, and future directions[J]. IEEE Wireless Communications, 2023, 30(1): 50–57. doi: 10.1109/MWC.002.2200206. [8] 張嘉慧, 王新奕, 費澤松, 等. 6G通感融合網絡中的物理層安全: 機遇與挑戰[J]. 移動通信, 2023, 47(3): 55–61. doi: 10.3969/j.issn.1006-1010.20230204-0002.ZHANG Jiahui, WANG Xinyi, FEI Zesong, et al. Physical layer security in 6G integrated sensing and communication systems: Opportunities and challenges[J]. Mobile Communications, 2023, 47(3): 55–61. doi: 10.3969/j.issn.1006-1010.20230204-0002. [9] 陳新穎, 盛敏, 李博, 等. 面向6G的無人機通信綜述[J]. 電子與信息學報, 2022, 44(3): 781–789. doi: 10.11999/JEIT210789.CHEN Xinying, SHENG Min, LI Bo, et al. Survey on unmanned aerial vehicle communications for 6G[J]. Journal of Electronics & Information Technology, 2022, 44(3): 781–789. doi: 10.11999/JEIT210789. [10] 朱政宇, 王梓晅, 徐金雷, 等. 智能反射面輔助的未來無線通信: 現狀與展望[J]. 航空學報, 2022, 43(2): 025014. doi: 10.7527/s1000-6893.2021.25014.ZHU Zhengyu, WANG Zixuan, XU Jinlei, et al. Future wireless communication assisted by intelligent reflecting surface: State of art and prospects[J]. Acta Aeronautica et Astronautica Sinica, 2022, 43(2): 025014. doi: 10.7527/s1000-6893.2021.25014. [11] 朱政宇, 徐金雷, 孫鋼燦, 等. 基于IRS輔助的SWIPT物聯網系統安全波束成形設計[J]. 通信學報, 2021, 42(4): 185–193. doi: 10.11959/j.issn.1000?436x.2021060.ZHU Zhengyu, XU Jinlei, SUN Gangcan, et al. Secure beamforming design for IRS-assisted SWIPT internet of things system[J]. Journal on Communications, 2021, 42(4): 185–193. doi: 10.11959/j.issn.1000?436x.2021060. [12] PANG Xiaowei, SHENG Min, ZHAO Nan, et al. When UAV meets IRS: Expanding air-ground networks via passive reflection[J]. IEEE Wireless Communications, 2021, 28(5): 164–170. doi: 10.1109/MWC.010.2000528. [13] HE Yinghui, CAI Yunlong, MAO Hao, et al. RIS-assisted communication radar coexistence: Joint beamforming design and analysis[J]. IEEE Journal on Selected Areas in Communications, 2022, 40(7): 2131–2145. doi: 10.1109/JSAC.2022.3155507. [14] SU Yuhua, PANG Xiaowei, CHEN Shanzhi, et al. Spectrum and energy efficiency optimization in IRS-assisted UAV networks[J]. IEEE Transactions on Communications, 2022, 70(10): 6489–6502. doi: 10.1109/TCOMM.2022.3201122. [15] LIU Fan, CUI Yuanhao, MASOUROS C, et al. Integrated sensing and communications: Toward dual-functional wireless networks for 6G and beyond[J]. IEEE Journal on Selected Areas in Communications, 2022, 40(6): 1728–1767. doi: 10.1109/JSAC.2022.3156632. [16] 伍光新, 姚元, 祁琳琳. 雷達通信波形一體化發展綜述[J]. 現代雷達, 2021, 43(9): 37–45. doi: 10.16592/j.cnki.1004-7859.2021.09.007.WU Guangxin, YAO Yuan, and QI Linlin. An overview on radar-communication integration of waveform[J]. Modern Radar, 2021, 43(9): 37–45. doi: 10.16592/j.cnki.1004-7859.2021.09.007. [17] IMT-2030(6G)推進組. 6G網絡架構愿景與關鍵技術展望白皮書[R]. 2021.IMT-2030 (6G) Promotion Group. 6G Network Architecture Vision and Key Technology Outlook White Paper[R]. 2021. [18] CUI Yanpeng, FENG Zhiyong, ZHANG Qixun, et al. Toward trusted and swift UAV communication: ISAC-enabled dual identity mapping[J]. IEEE Wireless Communications, 2023, 30(1): 58–66. doi: 10.1109/MWC.003.2200207. [19] MENG Kaitao, WU Qingqing, MA Shaodan, et al. Throughput maximization for UAV-enabled integrated periodic sensing and communication[J]. IEEE Transactions on Wireless Communications, 2023, 22(1): 671–687. doi: 10.1109/TWC.2022.3197623. [20] SHAO Xiaodan, YOU Changsheng, MA Wenyan, et al. Target sensing with intelligent reflecting surface: Architecture and performance[J]. IEEE Journal on Selected Areas in Communications, 2022, 40(7): 2070–2084. doi: 10.1109/JSAC.2022.3155546. [21] YOU Changsheng, KANG Zhenyu, ZENG Yong, et al. Enabling smart reflection in integrated air-ground wireless network: IRS meets UAV[J]. IEEE Wireless Communications, 2021, 28(6): 138–144. doi: 10.1109/MWC.001.2100148. [22] PANG Xiaowei, ZHAO Nan, TANG Jie, et al. IRS-assisted secure UAV transmission via joint trajectory and beamforming design[J]. IEEE Transactions on Communications, 2022, 70(2): 1140–1152. doi: 10.1109/TCOMM.2021.3136563. [23] 李國琳, 郭文彬. 雷達通信一體化波形設計綜述[J]. 移動通信, 2022, 46(5): 38–44. doi: 10.3969/j.issn.1006-1010.2022.05.006.LI Guolin and GUO Wenbin. Waveform design for integrated radar and communication: A survey[J]. Mobile Communications, 2022, 46(5): 38–44. doi: 10.3969/j.issn.1006-1010.2022.05.006. [24] BAYESTEH A, 何佳, 陳雁, 等. 通信感知一體化——從概念到實踐[EB/OL].https://www.huawei.com/cn/huaweitech/future-technologies/integrated-sensing-communication-concept-practice, 2022.BAYESTEH A, HE Jia, CHEN Yan, et al. Integration of communication and perception-from concept to practice[EB/OL].https://www.huawei.com/cn/huaweitech/future-technologies/integrated-sensing-communication-concept-practice, 2022. [25] XIAO Zhiqiang and ZENG Yong, Waveform design and performance analysis for full-duplex integrated sensing and communication [J] IEEE Journal on Selected Areas in Communications, 2022, 40(6):1823–1837. doi: 10.1109/JSAC.2022.3155509. [26] HUANG Tianyao, SHLEZINGER N, XU Xingyu, et al. MAJoRCom: A dual-function radar communication system using index modulation[J]. IEEE Transactions on Signal Processing, 2020, 68: 3423–3438. doi: 10.1109/TSP.2020.2994394. [27] NOWAK M, WICKS M, ZHANG Zhiping, et al. Co-designed radar-communication using linear frequency modulation waveform[J]. IEEE Aerospace and Electronic Systems Magazine, 2016, 31(10): 28–35. doi: 10.1109/MAES.2016.150236. [28] KUMARI P, MYERS N J, and HEATH R W. Adaptive and fast combined waveform-beamforming design for mmWave automotive joint communication-radar[J]. IEEE Journal of Selected Topics in Signal Processing, 2021, 15(4): 996–1012. doi: 10.1109/JSTSP.2021.3071592. [29] LIU Yongjun, LIAO Guisheng, and YANG Zhiwei. Robust OFDM integrated radar and communications waveform design based on information theory[J]. Signal Processing, 2019, 162: 317–329. doi: 10.1016/j.sigpro.2019.05.001. [30] LIU Fan, ZHOU Longfei, MASOUROS C, et al. Toward dual-functional radar-communication systems: Optimal waveform design[J]. IEEE Transactions on Signal Processing, 2018, 66(16): 4264–4279. doi: 10.1109/TSP.2018.2847648. [31] XIAO Zhiqiang and ZENG Yong. Waveform design and performance analysis for full-duplex integrated sensing and communication[J]. IEEE Journal on Selected Areas in Communications, 2022, 40(6): 1823–1837. doi: 10.1109/JSAC.2022.3155509. [32] BAXTER W, ABOUTANIOS E, and HASSANIEN A. Joint radar and communications for frequency-hopped MIMO systems[J]. IEEE Transactions on Signal Processing, 2022, 70: 729–742. doi: 10.1109/TSP.2022.3142909. [33] CUI Yuanhao, LIU Fan, JING Xiaojun, et al,Integrating sensing and communications for ubiquitous IoT: Applications, trends,and challenges[J]. IEEE Network, 2021, 35(5):158–167. doi: 10.1109/MNET.010.2100152. [34] XU Yu, ZHANG Tiankui, LIU Yuanwei, et al. UAV-enabled integrated sensing, computing, and communication: A fundamental trade-off[J]. IEEE Wireless Communications Letters, 2023, 12(5): 843–847. doi: 10.1109/LWC.2023.3245728. [35] 中國通信學會. 通感算一體化網絡前沿報告(2021年)[R]. 中國通信學會, 2021.China Communications Society. Frontier Report on the Integrated Sensing, Communication and Computing Network[R]. China Communications Society, 2021. [36] ZHANG Zhengquan, XIAO Yue, MA Zheng, et al. 6G wireless networks: Vision, requirements, architecture, and key technologies[J]. IEEE Vehicular Technology Magazine, 2019, 14(3): 28–41. doi: 10.1109/MVT.2019.2921208. [37] CHEN Zhi, MA Xinying, ZHANG Bo, et al. A survey on terahertz communications[J]. China Communications, 2019, 16(2): 1–35. doi: 10.12676/j.cc.2019.02.001. [38] IMT-2030(6G)推進組. 太赫茲通信技術研究報告[R]. 2022.IMT-2030 (6G) Promotion Group. Terahertz Communication Technology Research Report[R]. 2022. [39] CLERCKX B, ZHANG Rui, SCHOBER R, et al. Fundamentals of wireless information and power transfer: From RF energy harvester models to signal and system designs[J]. IEEE Journal on Selected Areas in Communications, 2019, 37(1): 4–33. doi: 10.1109/JSAC.2018.2872615. [40] WANG Jiadai, LIU Jiajia, LI Jingyi, et al. Artificial intelligence-assisted network slicing: Network assurance and service provisioning in 6G[J]. IEEE Vehicular Technology Magazine, 2023, 18(1): 49–58. doi: 10.1109/MVT.2022.3228399. [41] LIU Peng, FEI Zesong, WANG Xinyi, et al. Outage constrained robust secure beamforming in integrated sensing and communication systems[J]. IEEE Wireless Communications Letters, 2022, 11(11): 2260–2264. doi: 10.1109/LWC.2022.3198683. [42] 王超, 安建平, 邢成文, 等. 面向空間信息網絡的隱蔽通信技術綜述[J]. 中國科學: 信息科學, 2023. doi: 10.1360/SSI-2023-0101.WANG Chao, AN Jianping, XING Chengwen, et al. A review of covert communication technologies for space information networks[J]. SCIENTIA SINICA Informationis, 2023. doi: 10.1360/SSI-2023-0101. [43] ZHANG Zijian, DAI Linglong, CHEN Xibi, et al. Active RIS vs. passive RIS: Which will prevail in 6G?[J]. IEEE Transactions on Communications, 2023, 71(3): 1707–1725. doi: 10.1109/TCOMM.2022.3231893. -
