一種面向多任務的無人機輔助的通信網絡資源分配與軌跡優化研究

裴二榮; 婁宇涵; 李永剛; 黎偉

doi:10.11999/JEIT230974

一種面向多任務的無人機輔助的通信網絡資源分配與軌跡優化研究

doi: 10.11999/JEIT230974

1.
重慶郵電大學通信與信息工程學院重慶 400065
2.
重慶金美通信有限公司重慶 400035

基金項目: 國家自然科學基金(62071077)，重慶成渝科技創新項目(KJCXZD2020026)

詳細信息

作者簡介:
裴二榮：男，教授，研究方向為無線移動通信

婁宇涵：男，碩士生，研究方向為無人機通信、移動邊緣計算

李永剛：男，副教授，研究方向為無線移動通信

黎偉：男，博士，研究方向為無線移動通信

通訊作者:
婁宇涵　1162961114@qq.com

中圖分類號: TN929.5
計量
- 文章訪問數: 825
- HTML全文瀏覽量: 246
- PDF下載量: 108
- 被引次數: 0
出版歷程
- 收稿日期: 2023-09-06
- 修回日期: 2024-01-25
- 網絡出版日期: 2024-02-27
- 刊出日期: 2024-07-29

Research on Resource Allocation and Trajectory Optimization of a Multitask Unmanned Aerial Vehicles Assisted Communication Network

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Chongqing Jinmei Communication Co., Ltd., Chongqing 400035, China

Funds: The National Natural Science Foundation of China (62071077), Chongqing Chengyu Science and Technology Innovation Project (KJCXZD2020026)

摘要

摘要: 裝載各種有效荷載的無人機(UAV)能夠?qū)崿F(xiàn)傳感、通信和計算等多任務，因而常被部署到數據采集(DA)和輔助計算等領域。但是到目前為止，絕大多數研究僅專注于單一功能的無人機輔助的通信網絡資源分配與軌跡優化，對于面向多任務的資源分配和軌跡優化問題還未解決。為此，該文提出一種綜合考慮無人機數據采集、數據廣播以及計算任務卸載的無人機輔助的通信網絡資源優化的分配策略，旨在通過聯合優化傳輸占空比、用戶發射功率與無人機軌跡，在滿足目標位置采集數據實時廣播的前提下，最大化用戶卸載量。為了解決多變量耦合優化問題，提出了基于塊坐標下降(BCD)和連續凸逼近(SCA)的高效迭代優化算法，將耦合優化問題分解為3個子問題進行迭代優化。最后，大量仿真結果表明，該算法在公平性和總卸載計算量方面都優于其他測試方案。
- 無人機通信 /
- 移動邊緣計算 /
- 數據采集 /
- 凸優化
Abstract: Unmanned Aerial Vehicles (UAV) loaded with various payloads can achieve multiple tasks such as sensing, communication, and computing, and are often deployed in fields such as Data Acquisition (DA) and auxiliary computing. However, so far, the vast majority of research has only focused on single function drone resource allocation and trajectory optimization, and the problem of multi task oriented drone resource allocation and trajectory optimization has not been solved yet. Therefore, an allocation strategy for optimizing drone communication network resources is proposed that comprehensively considers drone data acquisition, data broadcasting, and computing task offloading. The aim is to maximize user offloading by jointly optimizing transmission duty cycle, user transmission power, and drone trajectory, while meeting the real-time broadcast of target location data collection. In order to solve the problem of multivariable coupled optimization, an efficient iterative optimization algorithm based on Block Coordinate Descent (BCD) and Successive Convex Approximate (SCA) is proposed. The coupled optimization problem is decomposed into three sub problems for iterative optimization. Finally, a large number of simulation results show that the algorithm outperforms other testing schemes in terms of fairness and total offloading computation.
- Unmanned Aerial Vehicle (UAV) communication /
- Mobile Edge Computing (MEC) /
- Data acquisition /
- Convex optimization

HTML全文

圖 1 系統模型

下載: 全尺寸圖片幻燈片

圖 2 無人機時隙分配策略

下載: 全尺寸圖片幻燈片

圖 3 6種方案在每個時隙的總卸載吞吐量

下載: 全尺寸圖片幻燈片

圖 4 6種方案的收斂性

下載: 全尺寸圖片幻燈片

圖 5 無人機采集數據下行吞吐量

下載: 全尺寸圖片幻燈片

圖 6 無人機飛行高度H對系統性能的影響

下載: 全尺寸圖片幻燈片

圖 7 用戶傳輸能量對系統性能的影響

下載: 全尺寸圖片幻燈片

圖 8 不同的$ {D_k} $和$ {d_{{\text{set}}}} $對系統性能的影響

下載: 全尺寸圖片幻燈片

1 面向多任務的無人機軌跡和資源迭代優化算法

(1) 初始化最大誤差 $ \varepsilon $ 、總量吐量迭代值obj、最大迭代次數 $ \alpha $ 與　 $ {{{D}}^i}\left( n \right) = \left\{ {{\boldsymbol{A}}_n^i,{\boldsymbol{Q}}_n^i,{\boldsymbol{P}}_{m,n}^i} \right\} $
(2) $ {\bf{while}} $ $ i \lt \alpha $ $ {\bf{do}} $
(3) 　 $ i = i + 1, $
(4) 　給定 $ \left\{ {{\boldsymbol{Q}}_n^i,{\boldsymbol{P}}_{m,n}^i} \right\} $ ，求解占空比子問題P1，得到最優情況　　　 $ \left\{ {{\boldsymbol{A}}_n^{i + 1},{\boldsymbol{Q}}_n^i,{\boldsymbol{P}}_{m,n}^i} \right\} $ ;
(5) 　給定 $ \left\{ {{\boldsymbol{A}}_n^{i + 1},{\boldsymbol{Q}}_n^i} \right\} $ ，求解功率子問題P2，得到最優情況　　　 $ \left\{ {{\boldsymbol{A}}_n^{i + 1},{\boldsymbol{Q}}_n^i,{\boldsymbol{P}}_{m,n}^{i + 1}} \right\} $ ;
(6) 　給定 $ \left\{ {{\boldsymbol{A}}_n^{i + 1},{\boldsymbol{P}}_{m,n}^{i + 1}} \right\} $ ，求解軌跡子問題P3.1，得到最優情　　　況 $ \left\{ {{\boldsymbol{A}}_n^{i + 1},{\boldsymbol{Q}}_n^{i + 1},{\boldsymbol{P}}_{m,n}^{i + 1}} \right\} $ ;
(7) 　將 $ \left\{ {{\boldsymbol{A}}_n^{i + 1},{\boldsymbol{Q}}_n^{i + 1},{\boldsymbol{P}}_{m,n}^{i + 1}} \right\} $ 帶入目標函數中計算當前總吞吐　　　量迭代值objnew;
(8) 　 $ {\bf{if }}{\text{ abs}}\left( {{\text{objnew}} - {\text{obj}}} \right) \le \varepsilon {\text{ }}{\bf{then}} $ break
(9) 　else $ {\text{obj}} = {\text{objnew}} $ ;
(10) end while
(11) 輸出最優參數值 $ \left\{ {{\boldsymbol{A}}_n^,{\boldsymbol{Q}}_n^,{\boldsymbol{P}}_{m,n}^} \right\} = \left\{ {{\boldsymbol{A}}_n^i,{\boldsymbol{Q}}_n^i,{\boldsymbol{P}}_{m,n}^i} \right\} $ ，　　　計算獲得當前最大的總吞吐量為 $ {\text{ob}}{{\text{j}}^} = {\text{objnew}} $ ;

下載: 導出CSV

表 1 關鍵的仿真參數

參數	取值	參數	取值
飛行高度$ H $	100 m	最大傳輸能量$ {E_{\max }} $	0.4 J
飛行時隙$ N $	60	最小傳輸速率$ {R_{\min }} $	4×10⁴ bit/s
飛行周期$ T $	60 s	最大平均功率$ {P_{\max }} $	500 mW
信道帶寬$ B $	1 MHz	目標區域半徑$ {d_{{\text{set}}}} $	10 m
最大速度$ {V_{\max }} $	20 m/s	功率譜密度$ {N_0} $	–90 dBm/Hz
信道功率增益$ {\beta _0} $	–60 dB	目標位置數據量$ {D_k} $	7×10⁶ bit

下載: 導出CSV
