邊緣計算網絡中區塊鏈賦能的異步聯邦學習算法

黃曉舸; 鄧雪松; 陳前斌; 張杰

doi:10.11999/JEIT221517

邊緣計算網絡中區塊鏈賦能的異步聯邦學習算法

doi: 10.11999/JEIT221517

重慶郵電大學通信與信息工程學院重慶 400065

基金項目: 國家自然科學基金(61831002)，重慶市科委重慶市基礎研究與前沿探索項目(cstc2018jcyjAx0383)

詳細信息

作者簡介:
黃曉舸：女，教授，博士，研究方向?yàn)橐苿?dòng)通信技術、區塊鏈、聯邦學習、資源分配相關技術

鄧雪松：男，碩士生，研究方向?yàn)橐苿?dòng)通信技術、聯邦學習相關技術

陳前斌：男，教授，博士生導師，研究方向?yàn)樾乱淮苿?dòng)通信網絡、未來網絡、LTE-Advanced異構小蜂窩網絡

張杰：男，教授，博士，研究方向?yàn)橐苿?dòng)通信、IoT等

通訊作者:
黃曉舸　huangxg@cqupt.edu.cn

中圖分類號: TN92
計量
- 文章訪問數: 765
- HTML全文瀏覽量: 538
- PDF下載量: 136
- 被引次數: 0
出版歷程
- 收稿日期: 2022-12-06
- 修回日期: 2023-05-17
- 網絡出版日期: 2023-05-24
- 刊出日期: 2024-01-17

Asynchronous Federated Learning via Blockchain in Edge Computing Networks

College of Communication and Information Technology, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (61831002), Innovation Project of the Common Key Technology of Chongqing Science and Technology Industry (cstc2018jcyjAx0383)

摘要

摘要: 由于數據量激增而引起的信息爆炸使得傳統集中式云計算不堪重負，邊緣計算網絡(ECN)被提出以減輕云服務器的負擔。此外，在ECN中啟用聯邦學習(FL)，可以實現數據本地化處理，從而有效解決協同學習中邊緣節點(ENs)的數據安全問題。然而在傳統FL架構中，中央服務器容易受到單點攻擊，導致系統性能下降，甚至任務失敗。本文在ECN場景下，提出基于區塊鏈技術的異步FL算法(AFLChain)，該算法基于ENs算力動態分配訓練任務，以提高學習效率。此外，基于ENs算力、模型訓練進度以及歷史信譽值，引入熵權信譽機制評估ENs積極性并對其分級，淘汰低質EN以進一步提高AFLChain的性能。最后，提出基于次梯度的最優資源分配(SORA)算法，通過聯合優化傳輸功率和計算資源分配以最小化整體網絡延遲。仿真結果展示了AFLChain的模型訓練效率以及SORA算法的收斂情況，證明了所提算法的有效性。
- 異步聯邦學習 /
- 區塊鏈 /
- 資源分配 /
- 邊緣計算網絡
Abstract: Because of the information explosion caused by the surge of data, traditional centralized cloud computing is overwhelmed, Edge Computing Network (ECN) is proposed to alleviate the burden on cloud servers. In contrast, by permitting Federated Learning (FL) in the ECN, data localization processing could be realized to successfully address the data security problem of Edge Nodes (ENs) in collaborative learning. However, traditional FL exposes the central server to single-point attacks, resulting in system performance degradation or even task failure. In this paper, we propose Asynchronous Federated Learning based on Blockchain technology (AFLChain) in the ECN that can dynamically assign learning tasks to ENs based on their computing capabilities to boost learning efficiency. In addition, based on the computing capability of ENs, model training progress and historical reputation, the entropy weight reputation mechanism is implemented to assess and rank the enthusiasm of ENs, eliminating low quality ENs to further improve the performance of the AFLChain. Finally, the Subgradient based Optimal Resource Allocation (SORA) algorithm is proposed to reduce network latency by optimizing transmission power and computing resource allocation simultaneously. The simulation results demonstrate the model training efficiency of the AFLChain and the convergence of the SORA algorithm and the efficacy of the proposed algorithms.
- Asynchronous federated learning /
- Blockchain /
- Resource allocation /
- Edge Computing Network (ECN)

HTML全文

圖 1 網絡結構圖

下載: 全尺寸圖片幻燈片

圖 2 一個epoch的工作流程

下載: 全尺寸圖片幻燈片

圖 3 異步FL概述

① SN下載全局模型；② SNs本地訓練；③ SNs獲取下一動作；④ 領導者收集SNs模型并上傳至區塊鏈；⑤⑥ PN下載SNs模型進行聚合；⑦ PN上傳全局模型至區塊鏈

下載: 全尺寸圖片幻燈片

圖 4 不同算法準確率與全局epoch的關系

下載: 全尺寸圖片幻燈片

圖 5 不同F(xiàn)L算法在不同數據集上的性能表現

下載: 全尺寸圖片幻燈片

圖 6 AFLChain在不同SN數量下的性能表現

下載: 全尺寸圖片幻燈片

圖 7 AFLChain在不同算力比時的性能表現

下載: 全尺寸圖片幻燈片

圖 8 AFLChain在不同掉隊者比例下的性能表現

下載: 全尺寸圖片幻燈片

圖 9 不同算法在不同場景下的時間開銷

下載: 全尺寸圖片幻燈片

圖 10 SNs信譽值的變化

下載: 全尺寸圖片幻燈片

圖 11 不同信譽機制對準確率的影響

下載: 全尺寸圖片幻燈片

圖 12 SORA算法在不同最大算力時約束的收斂情況

下載: 全尺寸圖片幻燈片

圖 13 不同資源分配算法的網絡時延對比

下載: 全尺寸圖片幻燈片

算法1　狀態數據庫決策流程
輸入：SN $k$狀態信息，狀態表　　　　${[(k,{h_\kappa },{r_\kappa },T_\kappa ^{{\text{cmp}}},T_k^{{\text{qry}}},{T_\kappa },{a_\kappa })]_{\forall k \in [1,K]}}$
輸出：下一動作${a_k}$
更新狀態表中SN $k$的狀態信息
通過式(8)找到最低算力SN
情況1：SN $k$剛進入一輪本地訓練，或SN $\xi $還未完成訓練。
if ${r_k} = 1$ or ${h_k} > {h_\xi }$
${r_k} \leftarrow {r_k} + 1$
返回${a_k} = 1$
end if
${ {{t} }_c}{\text{ = CurrentTime} }$
情況2：SN $\xi $已完成訓練，或剩余等待時間不夠完成一輪訓練。
if $k = \xi $ or ${a_\xi } = 0$ or 式(10)不成立
更新狀態表動作信息
返回${a_k} = 0$
end if
情況3：剩余等待時間足以SN $k$完成一輪本地訓練。
${r_k} \leftarrow {r_k} + 1$
返回${a_k} = 1$

下載: 導出CSV

算法2 基于次梯度的最優資源分配算法(SORA)
輸入：拉格朗日乘子更新步長$ ({\epsilon}_{1},{\epsilon}_{2}) $，拉格朗日乘子初始值　　　　$(\pi _1^0,\pi _2^0)$，最大容忍閾值$ {\epsilon}_{3} $，$t = 0$，迭代因子上限${t_{\max }}$
輸出：最優資源分配$(f{_k^{ {\text{cmp} }* } },f{_k^{b}},{p_k}^)$
while $t < {t_{\max }}$ do
由式(36)和式(42) 分別得到$f{_k^{ {\text{cmp} }* }}$和$f{_k^{b*}}$
由式(39)和式(40) 分別更新拉格朗日乘子${\pi _1}$和${\pi _2}$ 　　　if $ \left\|{\pi }_{1}^{t+1}-{\pi }_{1}^{t}\right\| < {\epsilon}_{3} $ and $ \left\|{\pi }_{2}^{t+1}-{\pi }_{2}^{t}\right\| < {\epsilon}_{3} $
break
else
$t = t + 1$
end if
end while
由式(44)得到${p_k}^*$

下載: 導出CSV

表 1 仿真參數設置

參數	描述	數值
$K$	SN個數	30
$H$	epoch數量	30
$B$	帶寬	1 MHz
$ {\delta _b} $	塊大小	8 MB
$ {n_0} $	噪聲功率	–174 dBm/Hz
$\lambda $	全局學習率	1
$ \eta $	本地學習率	0.001
$ b $	數據抽樣大小	32
$ D $	訓練樣本大小	3 MB
$ {c_k} $	SN $ k $完成訓練所需頻率	20 cycles/bit
$ f_k^{\max } $	SN $ k $最大算力	0.2～1 GHz
$ {p_k} $	SN $ k $傳輸功率	40 W
${\text{t} }{ {\text{h} }_{\rm{upper}}}$	信譽值上分位點	50
${\text{t} }{ {\text{h} }_{\rm{low}}}$	信譽值下分位點	18

下載: 導出CSV
