雙鑒別器盲超分重建方法研究

盧迪; 于國梁

doi:10.11999/JEIT221502

雙鑒別器盲超分重建方法研究

doi: 10.11999/JEIT221502

盧迪^,,
于國梁

哈爾濱理工大學 哈爾濱 150080

詳細信息

作者簡介:
盧迪：女，教授，博士，研究方向?yàn)閿?shù)據融合、圖像處理

于國梁：男，碩士生，研究方向?yàn)閳D像處理、超分辨率重建

通訊作者:
盧迪　ludizeng@hrbust.edu.cn

中圖分類號: TN911.73; TP391
計量
- 文章訪問數: 443
- HTML全文瀏覽量: 472
- PDF下載量: 54
- 被引次數: 0
出版歷程
- 收稿日期: 2022-12-02
- 修回日期: 2023-09-13
- 網絡出版日期: 2023-09-15
- 刊出日期: 2024-01-17

Research on Blind Super-resolution Reconstruction with Double Discriminator

LU Di^,,
YU Guoliang

Harbin University of Science and Technology, Harbin 150080, China

摘要

摘要: 圖像超分變率重建方法在公共安全檢測、衛星成像、醫學和照片恢復等方面有著十分重要的用途。該文對基于生成對抗網絡的超分辨率重建方法進行研究，提出一種基于純合成數據訓練的真實世界盲超分算法(Real-ESRGAN)的UNet3+雙鑒別器Real-ESRGAN方法(Double Unet3+ Real-ESRGAN, DU3-Real-ESRGAN)。首先，在鑒別器中引入U(xiǎn)Net3+結構，從全尺度捕捉細粒度的細節和粗粒度的語義。其次，采用雙鑒別器結構，一個鑒別器學習圖像紋理細節，另一個鑒別器關注圖像邊緣，實現圖像信息互補。在Set5, Set14, BSD100和Urban100數據集上，與多種基于生成對抗網絡的超分重建方法相比，除Set5數據集外，DU3-Real-ESRGAN方法在峰值信噪比(PSNR)、結構相似性(SSIM)和無參圖像考評價指標(NIQE)都優于其他方法，產生了更直觀逼真的高分辨率圖像。
- 超分辨率重建 /
- 純合成數據訓練的真實世界盲超分算法 /
- UNet3+ /
- 雙鑒別器
Abstract: Image super-resolution reconstruction methods have very important uses in public safety detection, satellite imaging, medicine and photo restoration. In this paper, super-resolution reconstruction methods based on generative adversarial networks are investigated, from the training Real-world blind Enhanced Super-Resolution Generative Adversarial Networks pure synthetic data (Real-ESRGAN) method, a double UNet3+ discriminators Real-ESRGAN (DU3-Real-ESRGAN) method is proposed. Firstly, a UNet3+ structure is introduced in the discriminator to capture fine-grained details and coarse-grained semantics from the full scale. Secondly, a dual discriminator structure is adopted, with one discriminator learning image texture details and the other focusing on image edges to achieve complementary image information. Compared with several methods based on generative adversarial networks on Set5, Set14, BSD100 and Urban100 data sets, except for Set5, the Peak Signal to Noise Ration (PSNR), Structure SIMilarity (SSIM) and Natural Image Quality Evaluator (NIQE) values of the DU3-Real-ESRGAN method are superior to those of other methods to produce more intuitive and realistic high-resolution images.
- Image super-resolution reconstruction /
- Real-world blind Enhanced Super-Resolution Generative Adversarial Networks (Real-ESRGAN) /
- UNet3+ /
- Dual discriminators

HTML全文

圖 1 Real-ESRGAN生成器網絡結構

下載: 全尺寸圖片幻燈片

圖 2 Real-ESRGAN鑒別器網絡結構

下載: 全尺寸圖片幻燈片

圖 3 UNet++和UNet3+網絡結構

下載: 全尺寸圖片幻燈片

圖 4 UNet3+網絡decoder結構圖

下載: 全尺寸圖片幻燈片

圖 5 DU3-Real-ESRGAN網絡結構

下載: 全尺寸圖片幻燈片

圖 6 DIV2K數據集HR圖像與LR圖像對比圖

下載: 全尺寸圖片幻燈片

圖 7 Set5數據集對比圖

下載: 全尺寸圖片幻燈片

圖 8 BSD100數據集對比圖

下載: 全尺寸圖片幻燈片

圖 9 Set14數據集不同算法對比

下載: 全尺寸圖片幻燈片

圖 10 Urban100數據集不同算法對比

下載: 全尺寸圖片幻燈片

表 1 PSNR/SSIM值對比

數據集	算法
數據集	SRGAN	EDSR	ESRGAN	Real-ESRGAN	U3-RealESRGAN	DU3-Real-ESRGAN
Set5	28.99/0.791	28.80/0.787	28.81/0.7868	30.52/0.878	30.01/0.868	30.24/0.870
Set14	27.03/0.815	26.64/0.803	27.13/0.741	28.71/0.830	28.55/0.845	29.57/0.847
BSD100	27.85/0.745	28.34/0.827	27.33/0.808	29.14/0.855	29.25/0.851	30.19/0.859
Urban100	27.45/0.825	27.71/0.7420	27.29/0.836	28.82/0.850	29.15/0.795	30.05/0.857

下載: 導出CSV

表 2 NIQE值對比

數據集	算法
數據集	SRGAN	EDSR	ESRGAN	Real-ESRGAN	U3-RealESRGN	DU3-Real-ESRGAN
Set5	5.671 2	5.137 2	4.580 6	3.506 4	3.602 1	3.840 0
Set14	7.559 3	5.158 8	4.409 6	3.541 3	3.533 2	3.516 8
BSD100	7.341 3	6.271 5	3.817 2	3.691 6	3.267 5	3.247 4
Urban100	7.108 9	6.563 2	4.199 6	3.929 0	3.454 3	3.399 3

下載: 導出CSV

參考文獻(20)

[1]	陶狀, 廖曉東, 沈江紅. 雙路徑反饋網絡的圖像超分辨重建算法[J]. 計算機系統應用, 2020, 29(4): 181–186. doi: 10.15888/j.cnki.csa.007344 TAO Zhuang, LIAO Xiaodong, and SHEN Jianghong. Dual stream feedback network for image super-resolution reconstruction[J]. Computer Systems &Applications, 2020, 29(4): 181–186. doi: 10.15888/j.cnki.csa.007344
[2]	陳棟. 單幅圖像超分辨率重建算法研究[D]. [碩士論文], 華南理工大學, 2020. CHEN Dong. Research on single image super-resolution reconstruction algorithm[D]. [Master dissertation], South China University of Technology, 2020.
[3]	KAPPELER A, YOO S, DAI Qiqin, et al. Video super-resolution with convolutional neural networks[J]. IEEE Transactions on Computational Imaging, 2016, 2(2): 109–122. doi: 10.1109/TCI.2016.2532323
[4]	JADERBERG M, SIMONYAN K, ZISSERMAN A, et al. Spatial transformer networks[C]. The 28th International Conference on Neural Information Processing Systems, Montreal, Canada, 2015: 2017–2025.
[5]	IRANI M and PELEG S. Super resolution from image sequences[C]. [1990] Proceedings. 10th International Conference on Pattern Recognition, Atlantic City, USA, 1990: 115–120.
[6]	STARK H and OSKOUI P. High-resolution image recovery from image-plane arrays, using convex projections[J]. Journal of the Optical Society of America A, 1989, 6(11): 1715–1726. doi: 10.1364/JOSAA.6.001715
[7]	DONG Chao, LOY C C, HE Kaiming, et al. Learning a deep convolutional network for image super-resolution[C]. 13th European Conference on Computer Vision, Zurich, Switzerland, 2014: 184–199.
[8]	DONG Chao, LOY C C, and TANG Xiaoou. Accelerating the super-resolution convolutional neural network[C]. 14th European Conference on Computer Vision. Amsterdam, The Netherlands, 2016: 391–407.
[9]	PARK S J, SON H, CHO S, et al. SRFeat: Single image super-resolution with feature discrimination[C]. The 15th European Conference on Computer Vision, Munich, Germany, 2018: 455–471.
[10]	ZHANG Yulun, LI Kunpeng, LI Kai, et al. Image super-resolution using very deep residual channel attention networks[C]. The 15th European Conference on Computer Vision, Munich, Germany, 2018: 294–310.
[11]	LEDIG C, THEIS L, HUSZÁR F, et al. Photo-realistic single image super-resolution using a generative adversarial network[C]. 2017 IEEE Conference on Computer Vision and Pattern Recognition, Honolulu, USA, 2017: 105–114.
[12]	LIM B, SON S, KIM H, et al. Enhanced deep residual networks for single image super-resolution[C]. 2017 IEEE Conference on Computer Vision and Pattern Recognition Workshops (CVPRW), Honolulu, USA, 2017: 1132–1140.
[13]	WANG Xintao, YU Ke, WU Shixiang, et al. ESRGAN: Enhanced super-resolution generative adversarial networks[C]. European Conference on Computer Vision, Munich, Germany, 2018: 63–79.
[14]	SOH J W, PARK G Y, JO J, et al. Natural and realistic single image super-resolution with explicit natural manifold discrimination[C]. The 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Long Beach, USA, 2019: 8114-8123.
[15]	WANG Xintao, XIE Liangbin, DONG Chao, et al. Real-ESRGAN: Training real-world blind super-resolution with pure synthetic data[C]. 2021 IEEE/CVF International Conference on Computer Vision Workshops, Montreal, Canada, 2021: 1905–1914.
[16]	SAJJADI M S M, SCHÖLKOPF B, and HIRSCH M. EnhanceNet: Single image super-resolution through automated texture synthesis[C]. 2017 IEEE International Conference on Computer Vision (ICCV), Venice, Italy, 2017: 4501–4510.
[17]	ZHANG Kai, LI Yawei, ZUO Wangmeng, et al. Plug-and-play image restoration with deep denoiser prior[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2022, 44(10): 6360–6376. doi: 10.1109/TPAMI.2021.3088914
[18]	HUANG Huimin, LIN Lanfen, TONG Ruofeng, et al. UNet 3+: A full-scale connected UNet for medical image segmentation[C]. ICASSP 2020 - 2020 IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP), Barcelona, Spain, 2020: 1055–1059.
[19]	ZHOU Zongwei, SIDDIQUEE M M R, TAJBAKHSH N, et al. Unet++: A nested U-Net architecture for medical image segmentation[M]. Stoyanov D, Taylor Z, Carneiro G, et al. Deep Learning in Medical Image Analysis and Multimodal Learning for Clinical Decision Support. Cham: Springer, 2018: 3–11.
[20]	MITTAL A, SOUNDARARAJAN R, and BOVIK A C. Making a “Completely Blind” image quality analyzer[J]. IEEE Signal Processing Letters, 2013, 20(3): 209–212. doi: 10.1109/LSP.2012.2227726
