運動意圖的頭皮腦電編解碼及其腦-機接口研究進展

陳龍; 張定澤; 王坤; 許敏鵬; 明東

doi:10.11999/JEIT221449

運動意圖的頭皮腦電編解碼及其腦-機接口研究進展

doi: 10.11999/JEIT221449

陳龍¹,
張定澤¹,
王坤^1, ,,
許敏鵬^{1, 2},
明東^{1, 2}

1.
天津大學醫學工程與轉化醫學研究院天津 300072
2.
天津大學精密儀器與光電子工程學院天津 300072

基金項目: 國家重點研發計劃(2021YFF0602902)，國家自然科學基金(82001939, 62122059, 81925020, 62206198)

詳細信息

作者簡介:
陳龍：男，副教授，研究方向?yàn)槟X機接口、神經調控與康復

張定澤：男，碩士生，研究方向?yàn)檫\(yùn)動意圖腦電編解碼

王坤：女，講師，研究方向?yàn)檫\(yùn)動意圖腦電信號特征提取及其腦-機接口設計

許敏鵬：男，教授，研究方向?yàn)槟X-機接口及其應用轉化

明東：男，教授，研究方向?yàn)樯窠?jīng)工程

通訊作者:
王坤　flora_wk@tju.edu.cn

中圖分類號: TN911.7; TP391
計量
- 文章訪問數: 1008
- HTML全文瀏覽量: 932
- PDF下載量: 321
- 被引次數: 0
出版歷程
- 收稿日期: 2022-11-17
- 修回日期: 2023-04-12
- 網絡出版日期: 2023-04-24
- 刊出日期: 2023-10-31

Research Progress on the Coding and Decoding of Scalp Electroencephalogram Induced by Movement Intention and Brain-Computer Interface

CHEN Long¹,
ZHANG Dingze¹,
WANG Kun^{1
, ,},
XU Minpeng^{1, 2},
MING Dong^{1, 2}

1.
Academy of Medical Engineering and Translational Medicine, Tianjin University, Tianjin 300072, China
2.
School of Precision Instrument and Opto-Electronics Engineering, Tianjin University, Tianjin 200072, China

Funds: The National Key Research and Development Program of China (2021YFF0602902), The National Natural Science Foundation of China (82001939, 62122059, 81925020, 62206198)

摘要

摘要: 基于運動意圖的腦-機接口(BCI)對人體運動功能增強、替代和康復具有重要研究意義與應用價值。其中，運動想象(MI)是最常用的表征運動意圖的BCI范式。然而，傳統MI-BCI通常僅實現不同肢體部位運動意圖解碼，且識別正確率較低，制約著精細運動控制與康復效果。針對上述問題，近年來研究者在單一肢體特定部位、運動學與動力學意圖誘發頭皮腦電編解碼以及運動意圖錯誤相關電位檢測3個方面開展了一系列有意義的探索，并在高自由度的運動指令控制和面向卒中患者的臨床康復應用方面取得了較大的研究成果。該文從運動意圖的頭皮腦電(EEG)編解碼相關范式及其BCI應用兩個方面綜述了本領域研究進展，并探討當前研究存在的問題和可能的解決方案，以期促進運動意圖BCI技術的深入研究及開發應用。
- 腦-機接口 /
- 腦電 /
- 運動意圖 /
- 精細運動控制 /
- 臨床康復
Abstract: Movement intention based Brain-Computer Interfaces (BCIs) have important research significance and application value in motor enhancement, replacement and rehabilitation. Among them, Motor Imagery (MI) is the most commonly used BCI paradigm to represent motor intention. However, traditional MI-BCIs usually focus on the recognition of the intention of different limbs, and the classification accuracies are relatively low, which restricts fine motor control and rehabilitation. To solve the above problems, in recent years, researchers have carried out a series of meaningful explorations in coding and decoding of scalp ElectroEncephaloGram (EEG) from three aspects: specific parts of a single limb movement intention, kinematic and kinetics intention, and mismatch between movement and expectation. On the basis of the above research, some typical applications to high freedom motor control and stroke rehabilitation have been developed. The research progress in this field from the related paradigms of scalp EEG coding and decoding of motor intention and its BCI application is reviewed. Besides, the existing challenges and possible solutions are discussed, considering to promote the in-depth research and application of motor intention based BCIs.
- Brain-Computer Interface (BCI) /
- ElectroEncephaloGram (EEG) /
- Movement intention /
- Fine motor control /
- Clinical rehabilitation
