基于DT-LIF神經元與SSD的脈沖神經網絡目標檢測方法

周雅; 栗心怡; 武喜艷; 趙宇飛; 宋勇

doi:10.11999/JEIT221367

基于DT-LIF神經元與SSD的脈沖神經網絡目標檢測方法

doi: 10.11999/JEIT221367

北京理工大學光電學院北京 100081

基金項目: 國家自然科學基金(82272130, U22A20103)

詳細信息

作者簡介:
周雅：女，副教授，研究方向為智能光電信息處理

栗心怡：女，碩士生，研究方向為類腦計算

武喜艷：女，博士生，研究方向為脈沖神經網絡及其應用

趙宇飛：男，博士后，研究方向為面向計算機視覺的類腦計算

宋勇：男，教授，研究方向為類腦計算、智能交互等

通訊作者:
宋勇　yongsong@bit.edu.cn

中圖分類號: TN911.73; TP391.41
計量
- 文章訪問數: 1060
- HTML全文瀏覽量: 482
- PDF下載量: 190
- 被引次數: 0
出版歷程
- 收稿日期: 2022-11-01
- 修回日期: 2023-05-11
- 網絡出版日期: 2023-05-20
- 刊出日期: 2023-08-21

Object Detection Method with Spiking Neural Network Based on DT-LIF Neuron and SSD

School of Optics and Photonics, Beijing Institute of Technology, Beijing 100081, China

Funds: The National Natural Science Foundation of China (82272130, U22A20103)

摘要

摘要: 相對于傳統人工神經網絡(ANN)，脈沖神經網絡(SNN)具有生物可解釋性、計算效率高等優勢。然而，對于目標檢測任務，SNN存在訓練難度大、精度低等問題。針對上述問題，該文提出一種基于動態閾值LIF神經元(DT-LIF)與單鏡頭多盒檢測器(SSD)的SNN目標檢測方法。首先，設計了一種DT-LIF神經元模型，該模型可根據累積的膜電位動態調整神經元的閾值，以驅動深層網絡的脈沖活動，提高推理速度。同時，以DT-LIF神經元為基元，構建了一種基于SSD的混合SNN。該網絡以脈沖視覺幾何群網絡(Spiking VGG)和脈沖密集連接卷積網絡(Spiking DenseNet)為主干(Backbone)，具有由批處理歸一化(BN)層、脈沖卷積(SC)層與DT-LIF神經元構成的3個額外層和SSD預測框頭(Head)。實驗結果表明，相對于LIF神經元網絡，DT-LIF神經元網絡在Prophesee GEN1數據集上的目標檢測精度提高了25.2%。對比AsyNet算法，所提方法的目標檢測精度提高了17.9%。
- 計算機視覺 /
- 目標檢測 /
- 脈沖神經網絡 /
- 神經元
Abstract: Compared with traditional Artificial Neural Network (ANN), the Spiking Neural Network (SNN) has advantages of bioligical reliability and high computational efficiency. However, for object detection task, SNN has problems such as high training difficulty and low accuracy. In response to the above problems, an object detection method with SNN based on Dynamic Threshold Leaky Integrate-and-Fire (DT-LIF) neuron and Single Shot multibox Detector (SSD) is proposed. First, a DT-LIF neuron is designed, which can dynamically adjust the threshold of neuron according to the cumulative membrane potential to drive spike activity of the deep network and imporve the inferance speed. Meanwhile, using DT-LIF neuron as primitive, a hybrid SNN based on SSD is constructed. The network uses Spiking Visual Geometry Group (Spiking VGG) and Spiking Densely Connected Convolutional Network (Spiking DenseNet) as the backbone, and combines with SSD prediction head and three additional layers composed of Batch Normalization (BN) layer , Spiking Convolution (SC) layer, and DT-LIF neuron. Experimental results show that compared with LIF neuron network, the object detection accuracy of DT-LIF neuron network on the Prophesee GEN1 dataset is improved by 25.2%. Compared with the AsyNet algorithm, the object detection accuracy of the proposed method is improved by 17.9%.
- Computer vision /
- Object detection /
- Spiking Neural Network (SNN) /
- Neuron

HTML全文

圖 1 LIF神經元模型等效電路

下載: 全尺寸圖片幻燈片

圖 2 基于DT-LIF神經元與SSD的目標檢測算法的結構

下載: 全尺寸圖片幻燈片

圖 3 DT-LIF神經元模型示意圖

下載: 全尺寸圖片幻燈片

圖 4 Spiking VGG網絡結構圖(以VGG11為例)

下載: 全尺寸圖片幻燈片

圖 5 Spiking DenseNet網絡結構圖(以DenseNet121為例)

下載: 全尺寸圖片幻燈片

圖 6 Prophesee GEN1數據集示例

下載: 全尺寸圖片幻燈片

圖 7 訓練損失(Loss)曲線圖

下載: 全尺寸圖片幻燈片

算法1 DT-LIF發射脈沖過程
參數：θ, p, q, V_th, τ_m
(1) θ = V_th = 1; V = 0; V_reset = 0 // 初始化
(2) for t = 1 to timesteps do
(3) 　for l = 2 to L do
(4) 　　for i = 1 to neurons do
(5) 　　　$ H_{i,t}^l $ = $ V_{i,t-1}^l $ + ($ X_{i,t}^l $ – ($ V_{i,t-1}^l $ – V_reset)) * tau // $ X_{i,t}^l $ 　　　　　是正向傳遞的輸入
(6) 　　　delta = $ H_{i,t}^l $ – $ V_{i,t-1}^l $
(7) 　　　$\theta_{i,t}^l $ = p + q exp (–delta / c)
(8) 　　　if $ H_{i,t}^l $ ≥ $\theta_{i,t}^l $ then
(9)　　　　 $ S_{i,t}^l $ = 1
(10) 　　　 $ V_{i,t}^l $ = V_reset
(11) 　　 end for
(12) 　 end for
(13) end for

下載: 導出CSV

表 1 Prophesee GEN1數據集上的對比實驗結果

方法	mAP(0.5:0.95)
Spiking VGG11+LIF	0.127
Spiking VGG11+DT-LIF	0.159
Spiking DenseNet+LIF	0.148
Spiking DenseNet+DT-LIF	0.165
AsyNet^[31]	0.140

下載: 導出CSV
