基于二值和三值憶阻器模型構建的混沌系統的特性分析

王曉媛,  田遠澤,  程知群

王曉媛, 田遠澤, 程知群. 基于二值和三值憶阻器模型構建的混沌系統的特性分析[J]. 電子與信息學報, 2023, 45(12): 4556-4565. doi: 10.11999/JEIT221083
引用本文: 王曉媛, 田遠澤, 程知群. 基于二值和三值憶阻器模型構建的混沌系統的特性分析[J]. 電子與信息學報, 2023, 45(12): 4556-4565. doi: 10.11999/JEIT221083
WANG Xiaoyuan, TIAN Yuanze, CHENG Zhiqun. Characteristic Analysis of Chaotic System Based on Binary-valued and Tri-valued Memristor Models[J]. Journal of Electronics & Information Technology, 2023, 45(12): 4556-4565. doi: 10.11999/JEIT221083
Citation: WANG Xiaoyuan, TIAN Yuanze, CHENG Zhiqun. Characteristic Analysis of Chaotic System Based on Binary-valued and Tri-valued Memristor Models[J]. Journal of Electronics & Information Technology, 2023, 45(12): 4556-4565. doi: 10.11999/JEIT221083

基于二值和三值憶阻器模型構建的混沌系統的特性分析

doi: 10.11999/JEIT221083

  • 杭州電子科技大學電子信息學院 杭州 310000

基金項目: 國家自然科學基金(61871429)，浙江省自然科學基金(LY18F010012)，科技部基地平臺項目(D20011)
詳細信息
    作者簡介:

    王曉媛：女，教授，研究方向?yàn)樾滦陀洃浽?憶阻器、憶容器和憶感器)理論及應用，非線性電路系統設計和信息加密算法

    田遠澤：男，碩士生，研究方向?yàn)榛煦缦到y(tǒng)與圖像加密算法

    程知群：男，教授，研究方向?yàn)樯漕l集成電路設計、毫米波高速通信系統

    通訊作者:

    王曉媛　youyuan-0213@163.com

  • 中圖分類號: TN918.1

Characteristic Analysis of Chaotic System Based on Binary-valued and Tri-valued Memristor Models

  • School of Electronic Information, Hangzhou Dianzi University, Hangzhou 310000, China

Funds: The National Natural Science Foundation of China (61871429), The Natural Science Foundation of Zhejiang Province (LY18F010012), The Project of Ministry of Science and Technology of China (D20011)
  • 摘要: 近年來，基于憶阻器的非線性動力學問題備受關注。該文以二值和三值憶阻器為例分析了二值和多值憶阻器對于混沌系統動力特性的影響。首先，將二值憶阻器引入Chen系統，構建了一個4維的基于二值憶阻器的混沌系統(BMCS)。其次，使用三值憶阻器替換上述系統中的二值憶阻器，構建一個4維的基于三值憶阻器的混沌系統(TMCS)。通過理論分析與數值仿真，從多個角度對比了兩個混沌系統之間的動力學特性差異，如Lyapunov指數、分岔圖、系統的平衡點、系統穩定性、對初值的敏感性以及系統的復雜度分析等。結果表明，兩個基于憶阻器的混沌系統都具有無窮多個平衡點，二者產生的吸引子均為隱藏吸引子，且都存在的暫態混沌現象，但三值憶阻混沌系統具有超混沌特性，且相比二值憶阻混沌系統具有更強的初值敏感性以及更大的參數取值區間。分析得出基于三值憶阻器構建的混沌系統比基于二值憶阻器的混沌系統能夠產生更為復雜的動力學特性，混沌信號也更為復雜。
    Abstract: In recent years, nonlinear dynamics problems based on memristors have received much attention. In this paper, binary-valued and tri-valued memristors are used as examples to analyze the influence of binary-valued and multi-value memristors on the dynamic characteristics of chaotic systems. Firstly, the binary-valued memristor is introduced into the Chen system, and a four-dimensional Binary-valued Memristor-based Chaotic System(BMCS) is constructed. Secondly, a tri-valued memristor is used to replace the binary-valued memristor in the above system, and a four-dimensional Tri-valued Memristor-based Chaotic System(TMCS) is constructed. Through theoretical analysis and numerical simulation, the differences of dynamic characteristics between the two chaotic systems are compared from multiple perspectives, such as Lyapunov exponent, bifurcation diagram, equilibrium point of the system, system stability, sensitivity to initial value and system complexity analysis, etc. The results show that the two memristor-based chaotic systems have infinite equilibrium points, the attractors generated by both are hidden attractors, and both have transient chaotic phenomena, but the Tri-valued memristor chaotic system has Hyper-chaos, and has stronger initial value sensitivity than Binary-valued memristor chaotic system. Further, the Tri-valued memristor chaotic system has a larger parameter value interval than the Binary-valued memristor chaotic system to obtain chaotic sequences with sufficiently high complexity. Through analysis, it is concluded that the chaotic system based on Tri-valued memristor can generate more complex dynamic characteristics and more complex chaotic signal than the chaotic system based on binary-valued memristor.
