DR-GAN：一種無監督學習的探地雷達雜波抑制方法

雷文太; 毛凌青; 龐澤邦; 任強; 王成浩; 隋浩; 辛常樂

doi:10.11999/JEIT221072

DR-GAN：一種無監督學習的探地雷達雜波抑制方法

doi: 10.11999/JEIT221072

1.
中南大學計算機學院長沙 410083
2.
中國電波傳播研究所青島 266107

基金項目: 中國電波傳播研究所穩定支持科研經費(A131903W13)

詳細信息

作者簡介:
雷文太：男，教授，研究方向?yàn)樘降乩走_(dá)信號處理技術

毛凌青：男，碩士生，研究方向?yàn)樘降乩走_(dá)信號處理技術

龐澤邦：男，博士生，研究方向?yàn)榛谏疃葘W(xué)習的探地雷達智能數據處理

任強：男，高級工程師，研究方向?yàn)樘降乩走_(dá)系統集成技術

王成浩：男，高級工程師，研究方向?yàn)樘降乩走_(dá)信息處理

隋浩：男，碩士生，研究方向?yàn)樘降乩走_(dá)信號處理技術

辛常樂：男，碩士生，研究方向?yàn)樘降乩走_(dá)信號處理技術

通訊作者:
龐澤邦　pangzebang@csu.edu.cn

中圖分類號: TN957.52
計量
- 文章訪問數: 1179
- HTML全文瀏覽量: 563
- PDF下載量: 196
- 被引次數: 0
出版歷程
- 收稿日期: 2022-08-15
- 修回日期: 2023-02-16
- 網絡出版日期: 2023-02-22
- 刊出日期: 2023-10-31

DR-GAN: An Unsupervised Learning Approach to Clutter Suppression for Ground Penetrating Radar

1.
School of Computer Science, Central South University, Changsha 410083, China
2.
China Research Institute of Radiowave Propagation, Qingdao 266107, China

Funds: The Stable-Support Scientific Project of China Research Institute of Radiowave Propagation (A131903W13)

摘要

摘要: 探地雷達(GPR)是一種基于電磁波的地下無損探測技術，廣泛應用于市政工程、交通、軍事等領域。在數據采集過程中，由于發射天線和接收天線之間的耦合、起伏地面的散射以及地下隨機媒質的復雜性等原因，采集得到的GPR B-scan回波中通常存在雜波，雜波嚴重影響了地下目標的檢測和特征提取。該文提出一種用于GPR B-scan圖像雜波抑制的解糾纏表示生成對抗網絡(DR-GAN)，設計了目標特征編碼器和雜波特征編碼器用來提取GPR B-scan圖像中的目標特征和雜波特征，設計了雜波抑制生成器用來獲取雜波抑制后的GPR B-scan圖像。與現有的基于監督學習的GPR雜波抑制方法相比，該方法在網絡訓練時不需要成對的匹配數據，可以更好地應用于實測GPR圖像的雜波抑制。在仿真和實測GPR數據上的實驗結果表明，DR-GAN這一無監督學習網絡具有更好的雜波抑制性能。對石英砂中埋設的鋼筋進行數據采集，運用DR-GAN對含雜波的實測數據進行處理，處理結果的改善系數(IF)指標較現有的魯棒非負矩陣分解(RNMF)方法提高了17.85 dB。
- 探地雷達 /
- 雜波抑制 /
- 無監督學習 /
- 解糾纏表示 /
- 生成對抗網絡
Abstract: Ground Penetrating Radar (GPR) is an underground nondestructive detection technology based on electromagnetic wave, which is widely used in municipal engineering, transportation, military and other fields. In the process of data acquisition, due to the coupling between transmitting antenna and receiving antenna, scattering from undulating ground and the complexity of underground random media, there is usually clutter in the GPR B-scan, which affects seriously the detection and feature extraction of underground targets. A Disentanglement Representation Generative Adversarial network (DR-GAN) for clutter suppression in GPR B-scan images is proposed. A target feature encoder and a clutter feature encoder are designed to extract target features and clutter features in GPR B-scan images. A clutter suppression generator is designed to obtain the GPR B-scan image after clutter suppression. Compared with the existing GPR clutter suppression methods based on supervised learning, the proposed method does not need pairwise matching data during network training, and can be better applied to the clutter suppression of measured GPR images. Experimental results on simulated and measured GPR data show that DR-GAN is an unsupervised learning network with better clutter suppression performance. The data of reinforcement embedded in quartz sand are collected, and the measured data containing clutter are processed by DR-GAN. The Improvement Factor (IF) index of the processing results is 17.85 dB higher than that of the existing Robust Nonnegative Matrix Factorization (RNMF) method.
- Ground Penetrating Radar (GPR) /
- Clutter suppression /
- Unsupervised learning /
- Disentangled Representations (DR) /
- Generative Adversarial Networks (GAN)

HTML全文

圖 1 DR-GAN的網絡框架

下載: 全尺寸圖片幻燈片

圖 2 GPR圖像的雜波抑制流程

下載: 全尺寸圖片幻燈片

圖 3 DR-GAN的編碼器與生成器的網絡結構

下載: 全尺寸圖片幻燈片

圖 4 DR-GAN的判別器網絡結構

下載: 全尺寸圖片幻燈片

圖 5 仿真場景模型

下載: 全尺寸圖片幻燈片

圖 6 DR-GAN在仿真數據上的雜波抑制效果

下載: 全尺寸圖片幻燈片

圖 7 不同方法對仿真數據的雜波抑制效果

下載: 全尺寸圖片幻燈片

圖 8 實測場景

下載: 全尺寸圖片幻燈片

圖 9 實測雜波數據的制作

下載: 全尺寸圖片幻燈片

圖 10 DR-GAN在實測數據上的雜波抑制效果

下載: 全尺寸圖片幻燈片

圖 11 不同方法對實測數據的雜波抑制效果

下載: 全尺寸圖片幻燈片

表 1 仿真場景參數

模型參數		掃描場景參數
模型尺寸	1.8 m×0.002 m×0.45 m	發射源波形	瑞克子波
單元格大小	0.002 m×0.002 m×0.002 m	發射中心頻率	2 GHz
土壤沙子重量百分比	50%	仿真時窗	10 ns
土壤粘土重量百分比	50%	發射天線起點	(0.1 m,0.002 m,0.4 m)
土壤的容重	2.0 g/cm³	接收天線起點	(0.2 m,0.002 m,0.4 m)
土壤的沙粒密度	2.66 g/cm³	每次掃描天線移動距離	0.01 m
土壤體積含水率范圍	0.001～0.150	目標形狀	圓柱、方柱
土壤材料種類	50種	圓柱半徑	0.03～0.05 m
土壤厚度	0.4 m	方柱邊長	0.04～0.06 m
土壤表面高度起伏范圍	0.38～0.41 m	目標高度	0.2～0.3 m
		目標水平位置	0.35～1.45 m

下載: 導出CSV

表 2 各種雜波抑制算法的平均PSNR(dB)/平均SSIM

目標類型	MS	SVD	NMF	RPCA	RNMF	RAE	本文DR-GAN
PVC圓柱體	0.85/0.014	22.38/0.365	22.23/0.305	23.54/0.259	22.72/0.205	22.56/0.154	36.66/0.965
空洞圓柱體	6.62/0.060	22.96/0.420	22.96/0.398	25.94/0.470	24.35/0.338	22.99/0.363	42.73/0.989
金屬圓柱體	12.58/0.126	25.26/0.588	25.18/0.562	27.59/0.612	25.86/0.471	25.92/0.432	44.70/0.992
PVC方柱體	6.41/0.021	23.09/0.357	24.06/0.365	27.11/0.437	25.84/0.351	25.22/0.287	43.65/0.980
空洞方柱體	12.45/0.072	25.79/0.535	25.38/0.494	28.78/0.597	26.43/0.444	25.80/0.369	47.92/0.993
金屬方柱體	16.97/0.181	25.97/0.538	25.39/0.504	29.15/0.652	27.45/0.538	26.72/0.458	48.00/0.993

下載: 導出CSV

表 3 各種雜波抑制方法的平均用時(s)

	MS	SVD	NMF	RPCA	RNMF	RAE	DR-GAN(GPU)
時間	0.002 9	0.010 2	0.013 6	2.083 9	6.063 6	3.872 6	0.103 0

下載: 導出CSV

表 4 實測數據雜波抑制的平均IF(dB)

目標類型	MS	SVD	NMF	RPCA	RNMF	RAE	本文DR-GAN
空心PVC管	10.49	24.19	24.59	20.68	24.74	12.01	41.34
空心塑料瓶	13.26	24.50	23.82	23.18	24.67	18.40	45.79
鋼筋	13.19	26.07	25.96	26.28	28.16	26.65	46.01

下載: 導出CSV
