面向遙感圖像場景分類的雙知識蒸餾模型

李大湘; 南藝璇; 劉穎

doi:10.11999/JEIT221017

面向遙感圖像場景分類的雙知識蒸餾模型

doi: 10.11999/JEIT221017

西安郵電大學通信與信息工程學院西安 710121

基金項目: 國家自然科學基金(62071379)，陜西省自然科學基金(2017KW-013), 西安郵電大學創新基金(CXJJYL2021055, YJGJ201902)

詳細信息

作者簡介:
李大湘：男，博士，副教授，研究方向?yàn)檫b感圖像分類、目標檢測與跟蹤、醫學圖像識別、多實例學習與深度學習等

南藝璇：女，碩士生，研究方向?yàn)檫b感圖像分類、圖像分割、圖像檢索、機器學習與模式識別

劉穎：女，博士，高級工程師，研究方向?yàn)閳D像識別與機器學習等

通訊作者:
南藝璇　1010367243@qq.com

中圖分類號: TN911.73; TP751
計量
- 文章訪問數: 621
- HTML全文瀏覽量: 442
- PDF下載量: 124
- 被引次數: 0
出版歷程
- 收稿日期: 2022-08-03
- 修回日期: 2023-01-15
- 網絡出版日期: 2023-02-22
- 刊出日期: 2023-10-31

A Double Knowledge Distillation Model for Remote Sensing Image Scene Classification

School of Telecommunication and Information Engineering, Xi’an University of Posts and Telecommunications, Xi’an 710121, China

Funds: The National Natural Science Foundation of China (62071379), The Natural Science Foundation of Shaanxi Province (2017KW-013), The Innovation Foundation of Xi’an University of Posts and Telecommunications (CXJJYL2021055, YJGJ201902)

摘要

摘要: 為了提高輕型卷積神經網絡(CNN)在遙感圖像(RSI)場景分類任務中的精度，該文設計一個雙注意力(DA)與空間結構(SS)相融合的雙知識蒸餾(DKD)模型。首先，構造新的DA模塊，將其嵌入到ResNet101與設計的輕型CNN，分別作為教師與學生網絡；然后，構造DA蒸餾損失函數，將教師網絡中的DA知識遷移到學生網絡之中，從而增強其對RSI的局部特征提取能力；最后，構造SS蒸餾損失函數，將教師網絡中的語義提取能力以空間結構的形式遷移到學生網絡，以增強其對RSI的高層語義表示能力。基于兩個標準數據集AID和NWPU-45的對比實驗結果表明，在訓練比例為20%的情況下，經知識蒸餾之后的學生網絡性能分別提高了7.69%和7.39%，且在參量更少的情況下性能也優于其他方法。
- 遙感圖像分類 /
- 知識蒸餾 /
- 雙注意力 /
- 空間結構
Abstract: In order to improve the accuracy of light-weight Convolutional Neural Networks (CNN) in the classification task of Remote Sensing Images (RSI) scene, a Double Knowledge Distillation (DKD) model combined with Dual-Attention (DA) and Spatial Structure (SS) is designed in this paper. First, new DA and SS modules are constructed and introduced into ResNet101 and lightweight CNN designed as teacher and student networks respectively. Then, a DA distillation loss function is constructed to transfer DA knowledge from teacher network to student network, so as to enhance their ability to extract local features from RSI. Finally, constructing a SS distillation loss function, migrating the semantic extraction ability in the teacher network to the student network in the form of a spatial structure to enhance its ability to express the high -level semantics of the RSI. The experimental results based on two standard data sets AID and NWPU-45 show that the performance of the student network after knowledge distillation is improved by 7.57% and 7.28% respectively under the condition of 20% training proportion, and the performance is still better than other methods under the condition of fewer parameters.
- Remote sensing image classification /
- Knowledge distillation /
- Dual Attention (DA) /
- Spatial Structure (SS)

HTML全文

圖 1 設計的DKD模型框架結構示意圖

下載: 全尺寸圖片幻燈片

圖 2 雙注意力(DA)模塊架構示意圖

下載: 全尺寸圖片幻燈片

圖 3 教師網絡訓練3元孿生框架示意圖

下載: 全尺寸圖片幻燈片

圖 4 SS知識蒸餾

下載: 全尺寸圖片幻燈片

圖 5 AID數據集訓練比例為20%時的混淆矩陣

下載: 全尺寸圖片幻燈片

圖 6 NWPU-45數據集訓練比例為20%時的混淆矩陣

下載: 全尺寸圖片幻燈片

圖 7 使用Grad-CAM進行可視化對比

下載: 全尺寸圖片幻燈片

表 1 學生網絡具體參數設計

網絡層名	輸出尺寸	計算方法
Conv1	112×112	7×7，64，stride=2
DA	112×112	DA模塊
Conv2_x	56×56	3×3 max pool, stride=2
Conv2_x	56×56	[3×3, 64; 3×3,64]
Conv3_x	28×28	[3×3, 128; 3×3,64]
Conv4_x	14×14	[3×3, 256; 3×3,64]
Conv5_x	7×7	[3×3, 512; 3×3,64]
	1×1	average pool,45-d fc, softmax

下載: 導出CSV

算法1 雙知識蒸餾(DKD)學生網絡訓練及測試
輸入：訓練圖像$ D = \{ ({\text{IM}}{{\text{G}}_n},{y_n}):n = 1,2, \cdots ,N\} $，網絡超參　　　　(Epoches, BS與lr)，測試圖像　　　　$ {\text{Tst}} = \{ ({\text{IM}}{{\text{G}}_m},{y_m}):m = 1,2, \cdots ,M\} $
輸出：學生網絡參數${\varOmega _{\text{S} } }$及測試圖像分類精度
準備：將D中的訓練圖像組成3元組，采用圖3所示孿生框架訓練　　　　教師網絡${\varOmega ^{ {\text{TE} } } }$；
For epoch in Epoches:
(1) 根據批大小BS，對D中的訓練圖像進行分批；
(2) 每批圖像送入教師網絡${\varOmega ^{ {\text{TE} } } }$，得到的高層語義特征　　　　 ${\text{Tb}} = \{ {t_i}\|i = 1,2, \cdots ,{\text{BS}}\} $；
(3) 每批圖像送入學生網絡${\varOmega _{\text{S} } }$，得到的高層語義特征　　　　 ${\text{Sb}} = \{ {s_i}\|i = 1,2, \cdots ,{\text{BS}}\} $及預測標簽$\{ {\tilde y_i}\} _{i = 1}^{{\text{BS}}}$；
(4) 用式(15)計算${L_{{\text{HTL}}}}$，優化器通過反向傳播更新學生網絡 　　　　參數${\varOmega _{\text{S} } }$;
(5) 采用余弦衰減策略更新學習率lr。
End for
(6) 對 $ \forall {\text{IM}}{{\text{G}}_m} \in {\text{Tst}} $，將${\text{IM}}{{\text{G}}_m}$輸入學生網絡${\varOmega _{\text{S} } }$，得到其　　　　類別預測結果${ { {\tilde y} }_{{m} } }$；
(7) 根據$ \{ ({\bar y_m},{y_m}):m = 1,2, \cdots ,M\} $，統計分類精度且輸出。

下載: 導出CSV

表 2 不同訓練比例下消融實驗的OA值(%)

	AID訓練比例(%)		NWPU-45訓練比例(%)
	20	50	10	20
基線	87.52	89.43	86.27	88.48
+DA	93.08	94.36	91.68	93.65
+SS	93.92	94.63	92.91	94.12
+DKD	95.21	97.04	93.88	95.87
教師	95.93	97.63	94.47	96.52

下載: 導出CSV

表 3 教師與學生網絡性能比較(以AID數據集(50%)為例)

Model	Parameters (MB)	AvgTime (ms)	Accuracy (%)
教師	42.56	14.8	97.63
學生(DKD)	4.92	4.37	97.04
ResNet50^[9]	25.56	8.53	95.49
VGG-16^[17]	138.36	16.43	92.63
SCViT^[18]	85.61	20.1	89.23

下載: 導出CSV

表 4 基于AID與NWPU-45數據集的綜合對比實驗結果(%)

方法	AID訓練比例(%)		NWPU-45訓練比例(%)
方法	20	50	10	20
VGG16+MSCP^[22]	91.52	94.42	88.32	91.56
ARCNet-VGG^[19]	88.75	93.10	85.60	90.87
CNN-CapsNet^[23]	93.79	96.32	89.03	89.03
SCCov^[24]	93.12	96.10	89.30	92.10
GBNet^[25]	92.20	95.48	90.03	92.35
MF2Net^[26]	93.82	95.93	90.17	92.73
MobileNet^[20]	88.53	90.91	80.32	83.26
ViT-B-16^[21]	93.81	95.90	90.96	93.36
XU et al.^[27]	94.17	96.19	90.23	93.25
DKD (本文)	95.21	97.04	93.88	95.87

下載: 導出CSV
