高性能YOLOv5：面向嵌入式平臺高性能目標檢測算法研究

劉喬壽; 趙志源; 王均成; 皮勝文

doi:10.11999/JEIT220413

高性能YOLOv5：面向嵌入式平臺高性能目標檢測算法研究

doi: 10.11999/JEIT220413

1.
重慶郵電大學通信與信息工程學院重慶 400065
2.
先進網絡與智能互聯技術重慶市高校重點實驗室重慶 400065
3.
泛在感知與互聯重慶市重點實驗室重慶 400065

詳細信息

作者簡介:
劉喬壽：男，副教授，博士，研究方向?yàn)?G超密集網絡干擾協調、云邊協同智能計算、FPGA智能算法加速、物聯網系統及終端設備開發

趙志源：男，碩士生，研究方向?yàn)槟繕?biāo)檢測和云邊協同智能計算

王均成：男，碩士生，研究方向?yàn)槟繕?biāo)檢測和圖像處理

皮勝文：男，碩士生，研究方向?yàn)榉植际缴疃葘W(xué)習與通算融合

通訊作者:
趙志源　804311347@qq.com

中圖分類號: TN911.73
計量
- 文章訪問數: 2136
- HTML全文瀏覽量: 2019
- PDF下載量: 445
- 被引次數: 0
出版歷程
- 收稿日期: 2022-04-07
- 修回日期: 2022-07-07
- 網絡出版日期: 2022-07-08
- 刊出日期: 2023-06-10

High Performance YOLOv5: Research on High Performance Target Detection Algorithm for Embedded Platform

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Advanced Network and Intelligent Connection Technology Key Laboratory of Chongqing Education Commission of China, Chongqing 400065, China
3.
Chongqing Key Laboratory of Ubiquitous Sensing and Networking, Chongqing 400065, China

摘要

摘要: 針對目前深度學習單階段檢測算法綜合性能不平衡以及在嵌入式設備難以部署等問題，該文提出一種面向嵌入式平臺的高性能目標檢測算法?；谥豢?次5代 (YOLOv5)網絡，改進算法首先在主干網絡部分采用設計的空間頸塊代替原有的焦點模塊，結合改進的混洗網絡2代替換原有的跨級局部暗網絡，減小空間金字塔池化 (SPP)的內核尺寸，實現了主干網絡的輕量化。其次，頸部采用了基于路徑聚合網絡 (PAN)設計的增強型路徑聚合網絡 (EPAN)，增加了P6大目標輸出層，提高了網絡的特征提取能力。然后，檢測頭部分采用以自適應空間特征融合 (ASFF)為基礎設計的自適應空洞空間特征融合 (A-ASFF)來替代原有的檢測頭，解決了物體尺度變化問題，在少量增加額外開銷情況下大幅提升檢測精度。最后，函數部分采用高效交并比 (EIoU)代替完整交并比 (CIoU)損失函數，采用S型加權線性單元 (SiLU)代替HardSwish激活函數，提升了模型的綜合性能。實驗結果表明，與YOLOv5-S相比，該文提出的同版本算法在mAP@.5，mAP@.5:.95上分別提高了4.6%和6.3%，參數量降低了43.5%，計算復雜度降低了12.0%，在Jetson Nano平臺上使用原模型和TensorRT加速模型進行速度評估，分別減少了8.1%和9.8%的推理延遲。該文所提算法的綜合指標超越了眾多優秀的目標檢測網絡，對嵌入式平臺更為友好，具有實際應用意義。
- 目標檢測 /
- YOLOv5 /
- 混洗網絡2代 /
- 自適應空間特征融合 /
- 嵌入式設備 /
- TensorRT加速
Abstract: Considering the problems of imbalanced comprehensive performance of the current deep learning single-stage detection algorithms and difficult deployment in embedded devices, one High-Performance object detection algorithm for embedded platforms is proposed in this paper. Based on the You Only Look Once v5 (YOLOv5) network, in the backbone network part of the improved algorithm firstly, the original focus module and original Cross Stage Partial Darknet are replaced by a designed space stem block and an improved ShuffleNetv2, respectively. The kernel size of Space Pyramid Pooling (SPP) is reduced to lighten the backbone network. Secondly, in the neck, an Enhanced Path Aggregation Network (EPAN) based on Path Aggregation Network (PAN) design is adopted, a P6 large target output layer is added, and the feature extraction ability of the network is improved. And then, in the head, an Adaptive-Atrous Spatial Feature Fusion (A-ASFF) based on Adaptive Spatial Feature Fusion (ASFF) is used to replace the original detection head, the object scale change problem is solved, and the detection accuracy is greatly improved with a small amount of additional overhead. Finally, in the function section, a Complete Intersection over Union (CIoU) loss function is replaced by the Efficient Intersection over Union (EIoU), a HardSwish activation function is replaced by a Sigmoid weighted Linear Unit (SiLU), and model synthesis ability has been improved. The experimental results show that compared to YOLOv5-S, the mAP@.5 and mAP@.5:95 of the same version of the algorithm proposed in this paper are increased by 4.6% and 6.3% while the number of parameters and the computational complexity are reduced by 43.5% and 12.0%, respectively. Using the original model and the TensorRT accelerated model for speed evaluation on the Jetson Nano platform, the inference latency is reduced by 8.1% and 9.8%, respectively. The comprehensive indicators of many excellent object detection networks and their friendliness to embedded platforms are surpassed by the algorithm proposed in this paper and the practical meaning is generated.
- Object detection /
- YOLOv5 /
- ShuffleNetv2 /
- Adaptive Spatial Feature Fusion (ASFF) /
- Embedded device /
- TensorRT acceleration

HTML全文

圖 1 YOLOv5整體架構圖

下載: 全尺寸圖片幻燈片

圖 2 Space Stem架構圖

下載: 全尺寸圖片幻燈片

圖 3 Shuffle Block和IS Block的模塊對比圖

下載: 全尺寸圖片幻燈片

圖 4 PAN與EPAN的模塊對比圖

下載: 全尺寸圖片幻燈片

圖 6 A-ASFF Head結構

下載: 全尺寸圖片幻燈片

圖 5 HP-YOLOv5整體架構圖

下載: 全尺寸圖片幻燈片

圖 7 YOLOv5-S和 HP-YOLOv5-S的平均精度和召回率對比圖

下載: 全尺寸圖片幻燈片

圖 8 YOLOv5-S不同場景檢測效果圖

下載: 全尺寸圖片幻燈片

圖 9 HP-YOLOv5-S不同場景檢測效果圖

下載: 全尺寸圖片幻燈片

表 1 網絡疊加優化研究結果

方法	mAP@.5(%)	mAP@.5:.95(%)	Params(M)	FLOPs(G)	Latency (ms)
YOLOv5	69.7	42.1	7.3	8.3	11.2
替換SiLU	70.2(+0.5)	42.4(+0.3)	7.3	8.3	10.8(–0.4)
修改SPP(3,5,9)	70.2	42.4	7.3	8.3	10.3(–0.5)
替換Space Stem	71.5(+1.3)	44.1(+1.7)	7.3	8.4	10.5(+0.2)
替換IS Block	70.8(–0.7)	43.2(–0.9)	3.8	7.0	8.3(–2.2)
替換EPAN	71.8(+1.0)	44.0(+0.8)	3.9	7.1	8.7(+0.4)
增添P6 Block	73.0(+1.2)	45.5(+1.5)	4.0	7.1	8.9(+0.2)
替換A-ASFF/ASFF	74.1/74.3(+1.1/+1.3)	47.6/47.7(+2.1/+2.2)	4.1/6.6	7.3/10.1	10.1/11.7(+1.2/2.8)
替換EIoU	74.3(+0.2)	48.4(+0.8)	4.1	7.3	10.1

下載: 導出CSV

表 2 本文方法與基線各模塊的對比實驗結果

原始方法/本文方法	Params(修改前/后)	MFLOPs(修改前/后)	mAP@.5(修改前/后)(%)
SPP(5,9,13) / SPP(3,5,9)	656896.0/656896.0	257.8/257.8	69.7/69.7
Focus / Space Stem	44032.0/67968.0(+54.0%)	1643.0/2497.0(+51.9%)	69.7/71.3(+1.6)
CSP Block / IS Block	986112.0/882432.0(–10.5%)	1549.0/71.3(–95.4%)	69.7/69.4(–0.3)
PAN / EPAN	193654200.0/200566200.0(+3.6%)	5838.6/5841.4(+0.1%)	69.7/70.8(+1.1)
Head / A-ASFF Head	158300900.0/175772300.0(+11.0%)	1442.7/1719.3(+19.2%)	69.7/71.6(+1.9)

下載: 導出CSV

表 3 本文方法與基線消融對比實驗結果

SiLU	Space Stem	IS Block	SPP (3,5,9)	EPAN	P6	A-ASFF	EIOU	mAP@.5(%)	mAP@.5:.95(%)	Params(M)	FLOPs(G)	Latency (ms)
								69.7	42.1	7.3	8.3	11.2
√								70.2↑	42.4↑	7.3	8.3	10.8↑
	√							71.3↑	43.9↑	7.3	8.4↓	11.5↓
		√						69.4↓	41.3↓	3.8↑	6.9↑	8.9↑
			√					69.7	42.1	7.3	8.3	10.7↑
				√				70.8↑	43.3↑	7.4↓	8.4↓	11.6↓
					√			71.6↑	44.9↑	7.5↓	8.4↓	11.4↓
						√		71.6↑	45.3↑	7.6↓	8.7↓	12.5↓
							√	70.0↑	42.9↑	7.3	8.3	11.2
	√		√					71.3↑	43.9↑	7.3	8.4↓	11.1↑
		√	√					69.4↓	41.3↓	3.8↑	6.9↑	8.4↑
	√	√						70.8↑	43.2↑	3.8↑	7.0↑	9.1↑
	√	√	√					70.8↑	43.2↑	3.8↑	7.0↑	8.6↑
				√	√			72.5↑	45.7↑	7.6↓	8.4↓	11.7↓
√	√	√	√	√	√	√	√	74.3↑	48.4↑	4.1↑	7.3↑	10.1↑

下載: 導出CSV

表 4 在PASCAL VOC 2012數據集上不同算法性能比較

算法	Params(M)	FLOPs(G)	mAP@.5(%)	mAP@.5:.95(%)	Latency/(ms)			模型大小 (MB)
算法	Params(M)	FLOPs(G)	mAP@.5(%)	mAP@.5:.95(%)	PC	Nano	TRT	模型大小 (MB)
YOLOv3-Tiny	8.7	6.4	47.9	21.5	–	–	–	33.1
YOLOv4-Tiny	5.9	8.0	54.8	25.6	–	–	–	23.7
NanoDet	0.9	1.4	54.4	25.2	8.5	–	–	1.7
NanoDet-Plus	1.2	1.8	57.1	29.3	9.0	–	–	2.3
YOLOv5-N	1.9	2.2	61.9	34.2	9.2	115.2	25.8	4.0
YOLOv5-S	7.3	8.3	69.7	42.1	11.3	152.8	45.7	14.9
YOLOv5-M	21.6	25.3	75.1	49.8	13.2	315.6	97.4	43.5
HP-YOLOv5-N	1.1	1.9	67.2	39.6	8.9	108.4	23.9	3.1
HP-YOLOv5-S	4.1	7.3	74.3	48.4	10.1	140.4	41.2	11.4
HP-YOLOv5-M	11.0	19.1	76.7	52.7	12.5	284.5	86.1	35.6

下載: 導出CSV
