面向可見光通信的硅基InGaN/GaN多量子阱多口分路器光子集成芯片

李欣; 王徐; 李蕓; 沙源清; 蔣成偉; 王永進

doi:10.11999/JEIT210953

面向可見光通信的硅基InGaN/GaN多量子阱多口分路器光子集成芯片

doi: 10.11999/JEIT210953

李欣^{1, 2, ,},
王徐¹,
李蕓¹,
沙源清¹,
蔣成偉¹,
王永進¹

1.
南京郵電大學通信與信息工程學院南京 210003
2.
南京郵電大學寬帶無線通信與傳感網技術教育部重點實驗室南京 210003

基金項目: 中國博士后基金 (2018M640508)，南京郵電大學1311人才計劃(1311)，南京郵電大學寬帶無線通信與傳感網技術教育部重點實驗室開放研究基金(JZNY202109)

詳細信息

作者簡介:
李欣：女，1984年生，副教授，研究方向?yàn)榭梢?jiàn)光通信及氮化鎵光電子器件

王徐：女，1998年生，碩士生，研究方向?yàn)榭梢?jiàn)光通信及氮化物光電子器件

李蕓：女，1998年生，碩士生，研究方向?yàn)榭梢?jiàn)光通信及氮化物光電子器件

沙源清：男，1997年生，碩士生，研究方向?yàn)榭梢?jiàn)光通信及氮化物光電子器件

蔣成偉：男，1997年生，碩士生，研究方向?yàn)榭梢?jiàn)光通信及氮化物光電子器件

王永進：男，1977年生，教授，研究方向?yàn)橄乱淮鸁o(wú)線通信、新型光電子器件、信息功能材料及物聯網

通訊作者:
李欣　lixin1984@njupt.edu.cn

中圖分類號: TN256; TN929.1
計量
- 文章訪問數: 998
- HTML全文瀏覽量: 736
- PDF下載量: 70
- 被引次數: 0
出版歷程
- 收稿日期: 2021-09-08
- 修回日期: 2022-04-22
- 網絡出版日期: 2022-04-28
- 刊出日期: 2022-08-17

Silicon-based InGaN/GaN Multi-quantum Wells Multi-port Splitter Photonic Integrated Chip for Visible Light Communication

1.
College of Telecommunications and Information, Nanjing University of Posts and Telecommunications, Nanjing 210003, China
2.
Key Laboratory of Broadband Wireless Communication and Sensor Network Technology, Nanjing University of Posts and Telecommunications, Ministry of Education, Nanjing 210003, China

Funds: China Postdoctoral Science Foundation Funded Project (2018M640508), The Talent Program of Nanjing University of Posts and Telecommunications (1311), The Open Research Fund of Key Laboratory of Broadband Wireless Communication and Sensor Network Technology (Nanjing University of Posts and Telecommunications), Ministry of Education (JZNY202109)

摘要

摘要: 為研究面向可見光通信的多功能光子集成芯片，實現可見光信號發射、探測、傳輸和功率分配的一體化的復合功能，該文提出一種基于硅基InGaN/GaN多量子阱材料的微型發光二極管(LED)多口分路器結構的光子集成芯片，對集成芯片進行了形貌、光電特性和可見光通信測試等多方面表征，實現了對可見光信號的有效傳輸和不同比例的多口功率分路，并對分路器不同端口的出射光強進行量化處理，最后，利用信號發生器在微型LED光源發射端加載300 kHz的矩形波電信號，收集分路器末端發射的調制可見光信號，輸入/接收信號的波形變化趨勢一致，說明該光子集成芯片可實現有效的可見光通信。該研究的主要目的是嘗試性將可見光波段的光源和光電探測器集成在氮化物晶圓上，為可見光通信的全光網絡的可見光信號片上集成式處理提供新的研究思路和方案，為發展面向可見光通信網絡需求的復合功能光子集成芯片終端提供了更多可能性。
- 光子集成芯片 /
- 可見光通信 /
- 氮化鎵 /
- 發光二極管 /
- 多口分路器
Abstract: In order to study the multi-functional photon integrated chip for visible light communication and realize the integrated function of visible light signal emission, detection, transmission and power distribution, a miniature Light Emitting Diode(LED) with splitter structure based on silicon-based InGaN/GaN multiple quantum well material is proposed in this paper. The photon integrated chip is characterized in many aspects, such as morphology, optoelectronic characteristics and visible light communication test. The effective transmission of visible light signal and different proportion of multi-port power shunt are realized, and the output light intensity of different ports of the splitter is quantified. Finally, the rectangular wave signal of 300 kHz is loaded at the emitter end of the miniature LED light source by the signal generator, and the modulated visible light signal emitted at the end of the splitter is collected. The waveform change trend of the input / receive signal is the same. It shows that the photonic integrated chip can achieve effective visible light communication. The main purpose of this study is to try to integrate visible light sources and photodetectors on nitride wafers, so as to provide new research ideas and schemes for on-chip integrated processing of visible light signals in all-optical networks of visible light communications. It provides more possibilities for the development of multi-function photon integrated chip terminals for visible light communication networks.
- Photonics integrated chips /
- Visible light communication /
- Gallium nitride /
- Light Emitting Diodes(LED) /
- Multi-port splitters

HTML全文

圖 1 可見光信號在分路器結構中傳輸情況的仿真模型及仿真分析結果

下載: 全尺寸圖片幻燈片

圖 2 硅基InGaN/GaN多量子阱多口分路器光子集成芯片示意圖

下載: 全尺寸圖片幻燈片

圖 3 硅基InGaN/GaN多量子阱多口分路器光子集成芯片加工工藝流程圖

下載: 全尺寸圖片幻燈片

圖 4 硅基InGaN/GaN多量子阱多口分路器光子集成芯片的光學顯微鏡圖

下載: 全尺寸圖片幻燈片

圖 5 多口分路器的掃描電子顯微鏡圖

下載: 全尺寸圖片幻燈片

圖 6 多口分路器關鍵結構的原子力顯微鏡圖

下載: 全尺寸圖片幻燈片

圖 7 發光器件的電致發光總光強

下載: 全尺寸圖片幻燈片

圖 8 硅基InGaN/GaN多量子阱多口分路器光子集成芯片在1～10 mA注入電流下的工作狀態

下載: 全尺寸圖片幻燈片

圖 9 隨注入電流變化的分路器不同端口的出射光強曲線

下載: 全尺寸圖片幻燈片

圖 10 光子集成芯片可見光通信測試的輸入輸出信號波形圖

下載: 全尺寸圖片幻燈片

表 1 本研究與部分已發表光子集成芯片指標對比

包含器件	功能	光信號波長	年份
無源光子器件	光功率分配	近紅外光	2021^[13], 2018^[22]
無源光子器件	光信號傳輸	1550 nm	2021^[16], 2019^[17]
無源光子器件	光信號傳輸	633 nm	2016^[20]
微型LED光源	光信號發射	450 nm	2014^[8]
有源無源光子器件	發射、探測、傳輸、功率分配	445 nm	2022(本文)

下載: 導出CSV

表 2 分路器不同端口的出射光強

	電流(mA)
	3	4	5	6	7	8	9	10
1號端口光強(a.u.)	1854.1	4065.9	4580.9	6455.0	9363.0	12213.1	13929.8	14582.0
2號端口光強(a.u.)	330.1	922.0	797.9	1102.0	1964.0	2873.0	3021.0	3383.0
3號端口光強(a.u.)	147.1	481.0	215.1	795.9	1944.0	1684.0	2025.0	1776.0

下載: 導出CSV
