基于階梯結構的U-Net結腸息肉分割算法

時永剛; 李祎; 周治國; 張?jiān)?/>
	<meta name=

doi:10.11999/JEIT210916

基于階梯結構的U-Net結腸息肉分割算法

doi: 10.11999/JEIT210916

夏卓巖

北京理工大學信息與電子學院北京 100081

基金項目: 國家自然科學基金(60971133, 61271112)

詳細信息

作者簡介:
時永剛：男，1969年生，副教授，研究方向?yàn)獒t(yī)學圖像分割、目標檢測識別、目標分類、圖像復原和超分辨率重建

李祎：女，1996年生，碩士生，研究方向?yàn)獒t(yī)學圖像分割

周治國：男，1977年生，副教授，研究方向?yàn)橹悄芨兄c導航

張?jiān)溃耗校?996年生，碩士生，研究方向?yàn)獒t(yī)學圖像處理、深度學習

夏卓巖：男，1997年生，碩士生，研究方向?yàn)閳D像分割、目標檢測與分類、目標識別

通訊作者:
時永剛　ygshi@bit.edu.cn

中圖分類號: TN911.73; R735.34
計量
- 文章訪問數: 1152
- HTML全文瀏覽量: 677
- PDF下載量: 200
- 被引次數: 0
出版歷程
- 收稿日期: 2021-09-01
- 修回日期: 2021-12-21
- 錄用日期: 2021-12-21
- 網絡出版日期: 2021-12-27
- 刊出日期: 2022-01-10

Polyp Segmentation Using Stair-structured U-Net

School of Information and Electronics, Beijing Institute of Technology, Beijing 100081, China

Funds: The National Natural Science Foundation of China (60971133, 61271112)

摘要

摘要: 結腸息肉的精確分割對結直腸癌的診斷和治療具有重要意義，目前的分割方法普遍存在有偽影、分割精度低等問題。該文提出一種基于階梯結構的U-Net結腸息肉分割算法(SU-Net)，使用U-Net的U型結構，利用Kronecker乘積來擴展標準空洞卷積核，構成Kronecker空洞卷積下采樣有效擴大感受野，彌補傳統空洞卷積容易丟失的細節特征；應用具有階梯結構的融合模塊，遵循擴展和堆疊原則形成階梯狀的分層結構，有效捕獲上下文信息并從多個尺度聚合特征；在解碼器引入卷積重構上采樣模塊生成密集的像素級預測圖，捕獲雙線性插值上采樣中缺少的精細信息。在Kvasir-SEG數據集和CVC-EndoSceneStill數據集上對模型進行了測試，相似系數(Dice)指標和交并比(IoU)指標分別達到了87.51%, 88.75%和82.30%, 85.64%。實驗結果表明，該文所提方法改善了因過度曝光、低對比度引起的分割精度低的問題，同時消除了邊界外部的圖像偽影和圖像內部不連貫的現象，優于其他息肉分割方法。
- 圖像分割 /
- 結腸息肉圖像 /
- 空洞卷積 /
- U-Net
Abstract: The precise segmentation of colon polyps plays a significant role in the diagnosis and treatment of colorectal cancer. The existing segmentation methods have generally artifacts and low segmentation accuracy. In this paper, Stair-structured U-Net (SU-Net) is proposed to segment polyp, using U-shaped structure. The Kronecker product is used to extend the standard atrous convolution kernel to keep more detail structrural features that are easily ignored. Stair-structured fusion module is applied to encompass effectively multi-scale features. The decoder introduces a convolutional reshaped upsampling module to generate pixel-level predictions. Experiments are performed on the Kvasir-SEG dataset and the CVC-EndoSceneStill dataset. The results show that the method proposed in this paper outperforms other polyp segmentation methods in Dice and Intersection-over-Union(IoU).
- Image segmentation /
- Colorectal polyp image /
- Atrous convolution /
- U-Net

HTML全文

圖 1 SU-Net整體框架

下載: 全尺寸圖片幻燈片

圖 2 不同類型卷積核和KACD模塊

下載: 全尺寸圖片幻燈片

圖 3 階梯結構的融合模塊

下載: 全尺寸圖片幻燈片

圖 4 卷積重構上采樣模塊

下載: 全尺寸圖片幻燈片

圖 5 SU-Net與其他分割模型在EndoSceneStill數據集上的分割結果

下載: 全尺寸圖片幻燈片

圖 6 SU-Net與其他分割模型在Kvasir-SEG數據集上的分割結果

下載: 全尺寸圖片幻燈片

表 1 SU-Net消融實驗列表

序號	實驗描述
1	基線
2	僅將基線里的空洞卷積替換為Kronecker空洞卷積
3	將實驗2中下采樣替換為Kronecker空洞卷積下采樣
4	在實驗3中的編碼器解碼器之間加入階梯結構的融合模塊
5	SU-Net

下載: 導出CSV

表 2 在EndoSceneStill數據集上各實驗的量化結果

評估標準	消融實驗編號
評估標準	1	2	3	4	5
召回率	0.7819	0.8195	0.8028	0.8027	0.8237
特異性	0.9931	0.9908	0.9946	0.9947	0.9929
精確率	0.9185	0.8747	0.9179	0.9119	0.9007
F₁	0.7899	0.7994	0.8088	0.8174	0.8230
F₂	0.7791	0.8025	0.7980	0.8046	0.8175
IoU	0.7194	0.7214	0.7360	0.7450	0.7499
IoU_B	0.9601	0.9599	0.9269	0.9627	0.9630
IoU_M	0.8397	0.8407	0.8494	0.8538	0.8564
Dice	0.7899	0.7994	0.8088	0.8174	0.8230

下載: 導出CSV

表 3 在Kvasir-SEG數據集上各實驗的量化結果

評估標準	消融實驗編號
評估標準	1	2	3	4	5
召回率	0.8664	0.8631	0.8636	0.8750	0.8752
特異性	0.9840	0.9854	0.9844	0.9858	0.9866
精確率	0.8921	0.9006	0.9163	0.9021	0.9207
F₁	0.8560	0.8607	0.8654	0.8689	0.8751
F₂	0.8574	0.8673	0.8602	0.8681	0.8718
IoU	0.7866	0.7920	0.7957	0.8032	0.8173
IoU_B	0.9534	0.9539	0.9520	0.9532	0.9577
IoU_M	0.8700	0.8730	0.8738	0.8782	0.8875
Dice	0.8560	0.8607	0.8654	0.8689	0.8751

下載: 導出CSV

表 4 不同模型在EndoSceneStill數據集中的量化評估結果

模型	召回率	特異性	精確率	F₁	F₂	IoU	IoU_B	IoU_M	Dice
U-Net	0.6839	0.9954	0.9222	0.7113	0.6910	0.6314	0.9515	0.7914	0.7113
Attention unet	0.6744	0.9962	0.9373	0.7084	0.6833	0.6260	0.9504	0.7882	0.7084
TKCN	0.8110	0.9866	0.8565	0.7819	0.7875	0.7023	0.9536	0.8280	0.7819
Xception	0.8017	0.9920	0.8964	0.7940	0.7906	0.7220	0.9575	0.8398	0.7940
DeepLabV3+	0.7611	0.9919	0.8543	0.7542	0.7505	0.6833	0.9545	0.8189	0.7542
PraNet	0.7973	0.9937	0.9215	0.8016	0.7945	0.7349	0.9610	0.8480	0.8016
SU-Net	0.8237	0.9929	0.9007	0.8230	0.8175	0.7499	0.9630	0.8564	0.8230

下載: 導出CSV

表 5 不同模型在Kvasir-SEG數據集中的量化評估結果

模型	召回率	特異性	精確率	F₁	F₂	IoU	IoU_B	IoU_M	Dice
U-Net	0.8408	0.9707	0.8315	0.8017	0.8161	0.7099	0.9331	0.8215	0.8017
Attention unet	0.8576	0.9682	0.8317	0.8105	0.8283	0.7249	0.9340	0.8294	0.8105
TKCN	0.8651	0.9826	0.8989	0.8552	0.8567	0.7811	0.9473	0.8642	0.8552
Xception	0.8702	0.9831	0.9041	0.8662	0.8639	0.7982	0.9504	0.8743	0.8662
DeepLabV3+	0.8879	0.9812	0.8938	0.8725	0.8770	0.8110	0.9550	0.8830	0.8725
PraNet	0.8763	0.9859	0.9154	0.8743	0.8718	0.8110	0.9557	0.8833	0.8743
SU-Net	0.8752	0.9866	0.9207	0.8751	0.8718	0.8173	0.9577	0.8875	0.8751

下載: 導出CSV

參考文獻(22)

[1]	GSCHWANTLER M, KRIWANEK S, LANGNER E, et al. High-grade dysplasia and invasive carcinoma in colorectal adenomas: A multivariate analysis of the impact of adenoma and patient characteristics[J]. European Journal of Gastroenterology & Hepatology, 2002, 14(2): 183–188. doi: 10.1097/00042737-200202000-00013
[2]	ARNOLD M, SIERRA M S, LAVERSANNE M, et al. Global patterns and trends in colorectal cancer incidence and mortality[J]. Gut, 2017, 66(4): 683–691. doi: 10.1136/gutjnl-2015-310912
[3]	PUYAL J G B, BHATIA K K, BRANDAO P, et al. Endoscopic polyp segmentation using a hybrid 2D/3D CNN[C]. 23rd International Conference on Medical Image Computing and Computer-Assisted Intervention, Lima, Peru, 2020: 295–305.
[4]	TASHK A, HERP J, and NADIMI E. Fully automatic polyp detection based on a novel u-net architecture and morphological post-process[C]. 2019 IEEE International Conference on Control, Artificial Intelligence, Robotics & Optimization, Athens, Greece, 2019: 37–41.
[5]	WANG Pu, XIAO Xiao, BROWN J R G, et al. Development and validation of a deep-learning algorithm for the detection of polyps during colonoscopy[J]. Nature Biomedical Engineering, 2018, 2(10): 741–748. doi: 10.1038/s41551-018-0301-3
[6]	SORNAPUDI S, MENG F, and YI S. Region-based automated localization of colonoscopy and wireless capsule endoscopy polyps[J]. Applied Sciences, 2019, 9(12): 2404. doi: 10.3390/app9122404
[7]	FAN Dengping, JI Gepeng, ZHOU Tao, et al. PraNet: Parallel reverse attention network for polyp segmentation[C]. 23rd International Conference on Medical Image Computing and Computer-Assisted Intervention, Lima, Peru, 2020: 263–273.
[8]	FENG Ruiwei, LEI Biwen, WANG Wenzhe, et al. SSN: A stair-shape network for real-time polyp segmentation in colonoscopy images[C]. 2020 IEEE 17th International Symposium on Biomedical Imaging (ISBI), Iowa City, USA, 2020: 225–229.
[9]	JI Gepeng, CHOU Yucheng, FAN Dengping, et al. Progressively normalized self-attention network for video polyp segmentation[J]. arXiv: 2105.08468, 2021.
[10]	LIN Ailiang, CHEN Bingzhi, XU Jiayu, et al. DS-TransUNet: Dual swin transformer U-Net for medical image segmentation[J]. arXiv: 2106.06716, 2021.
[11]	ZHANG Yundong, LIU Huiye, and HU Qiang. TransFuse: Fusing transformers and CNNs for medical image segmentation[J]. arXiv: 2102.08005, 2021.
[12]	JHA D, SMEDSRUD P H, RIEGLER M A, et al. Kvasir-SEG: A segmented polyp dataset[C]. 26th International Conference on Multimedia Modeling, Daejeon, Korea, 2020: 451–462.
[13]	VáZQUEZ D, BERNAL J, SáNCHEZ F J, et al. A benchmark for endoluminal scene segmentation of colonoscopy images[J]. Journal of Healthcare Engineering, 2017, 2017: 4037190. doi: 10.1155/2017/4037190
[14]	RONNEBERGER O, FISCHER P, and BROX T. U-Net: Convolutional networks for biomedical image segmentation[C]. 18th International Conference on Medical Image Computing and Computer-Assisted Intervention, Munich, Germany, 2015: 234–241.
[15]	LONG J, SHELHAMER E, and DARRELL T. Fully convolutional networks for semantic segmentation[C]. Proceedings of the IEEE Conference on Computer Vision and Pattern Recognition (CVPR), Boston, USA, 2015: 3431–3440.
[16]	WU Tianyi, TANG Sheng, ZHANG Rui, et al. Tree-structured kronecker convolutional network for semantic segmentation[C]. 2019 IEEE International Conference on Multimedia and Expo (ICME), Shanghai, China, 2019: 940–945.
[17]	CHOLLET F. Xception: Deep learning with depthwise separable convolutions[C]. The 2017 IEEE Conference on Computer Vision and Pattern Recognition (CVPR), Honolulu, USA, 2017: 1800–1807.
[18]	HE Kaiming, ZHANG Xiangyu, REN Shaoqing, et al. Deep residual learning for image recognition[C]. The 2016 IEEE Conference on Computer Vision and Pattern Recognition (CVPR), Las Vegas, USA, 2016: 770–778.
[19]	SHI Wenzhe, CABALLERO J, HUSZáR F, et al. Real-time single image and video super-resolution using an efficient sub-pixel convolutional neural network[C]. The 2016 IEEE Conference on Computer Vision and Pattern Recognition (CVPR), Las Vegas, USA, 2016: 1874–1883.
[20]	KINGMA D P and BA J. Adam: A method for stochastic optimization[J]. arXiv: 1412.6980, 2017.
[21]	OKTAY O, SCHLEMPER J, LE FOLGOC L, et al. Attention U-Net: Learning where to look for the pancreas[J]. arXiv: 1804.03999v3, 2018.
[22]	CHEN L C, ZHU Yukun, PAPANDREOU G, et al. Encoder-decoder with Atrous separable convolution for semantic image segmentation[C]. The 15th European Conference on Computer Vision (ECCV), Munich, Germany, 2018: 833–851.
