面向可見光通信的硅基InGaN/GaN多量子阱波導定向耦合器光子集成芯片

李欣; 李蕓; 王徐; 沙源清; 蔣成偉; 王永進

doi:10.11999/JEIT210758

面向可見光通信的硅基InGaN/GaN多量子阱波導定向耦合器光子集成芯片

doi: 10.11999/JEIT210758

李欣^{1, 2, ,},
李蕓¹,
王徐¹,
沙源清¹,
蔣成偉¹,
王永進¹

1.
南京郵電大學通信與信息工程學院南京 210003
2.
南京郵電大學寬帶無線通信與傳感網技術教育部重點實驗室南京 210003

基金項目: 中國博士后基金 (2018M640508)，南京郵電大學1311人才計劃，南京郵電大學寬帶無線通信與傳感網技術教育部重點實驗室開放研究基金

詳細信息

作者簡介:
李欣：女，1984年生，副教授，研究方向?yàn)榭梢姽馔ㄐ偶暗壒怆娮悠骷?/p>
李蕓：女，1998年生，碩士生，研究方向?yàn)榭梢姽馔ㄐ偶暗锕怆娮悠骷?/p>
王徐：女，1998年生，碩士生，研究方向?yàn)榭梢姽馔ㄐ偶暗锕怆娮悠骷?/p>
沙源清：男，1997年生，碩士生，研究方向?yàn)榭梢姽馔ㄐ偶暗锕怆娮悠骷?/p>
蔣成偉：男，1997年生，碩士生，研究方向?yàn)榭梢姽馔ㄐ偶暗锕怆娮悠骷?/p>

通訊作者:
李欣　lixin1984@njupt.edu.cn

中圖分類號: TN929.1; TN256
計量
- 文章訪問數: 1166
- HTML全文瀏覽量: 399
- PDF下載量: 100
- 被引次數: 0
出版歷程
- 收稿日期: 2021-07-30
- 修回日期: 2022-03-22
- 網絡出版日期: 2022-03-31
- 刊出日期: 2022-08-17

Silicon-based InGaN/GaN Multiple Quantum Well Waveguide Directional Coupler Photonic Integrated Chip for Visible Light Communication

1.
College of Telecommunications and Information, Nanjing University of Posts and Telecommunications, Nanjing 210003, China
2.
Key Laboratory of Broadband Wireless Communication and Sensor Network Technology, Ministry of Education, Nanjing University of Posts and Telecommunications, Nanjing 210003, China

Funds: China Postdoctoral Science Foundation (2018M640508), Talent Program of Nanjing University of Posts and Telecommunications, Open research fund of Key Lab of Broadband Wireless Communication and Sensor Network Technology (Nanjing University of Posts and Telecommunications), Ministry of Education

摘要

摘要: 利用可見光信號作為新型信息載體的光通信技術近些年來得到長足發展，為了開發新一代光子集成芯片作為可見光通信網絡的終端器件，滿足可見光信號發射、接收、傳輸與處理的復合需求，該文基于硅基InGaN/GaN多量子阱材料，設計了一種集成可見光波段微型發光二極管(LED)光源、波導定向耦合器、微型光電探測器于一體的光子集成芯片。該芯片利用InGaN/GaN多量子阱材料的發光探測共存現象，實現了上述復合功能。微型LED光源作為發射端，可以發射出藍色波段的可見光信號，其發光強度受到注入電流的線性調制，可實現調幅可見光通信，適合作為可見光通信的發射端。微型LED光源發射的可見光信號傳輸進入波導定向耦合器，實現了片內有效傳輸耦合和光功率平均分配。經過耦合傳輸?shù)目梢姽庑盘?hào)進入微型光電探測器，可以監測到與耦合傳輸?shù)墓庑盘?hào)強度相匹配的光電流。最后，可見光通信測試也表明該芯片可實現有效的可見光通信。該研究為發展面向可見光通信網絡需求的復合功能光子集成芯片終端提供了更多可能性。
- 可見光通信 /
- 氮化鎵 /
- 發光二極管 /
- 定向耦合器 /
- 光子集成
Abstract: Optical communication technology using visible optical signal as a new information carrier is greatly developed in recent years. In order to develop a new generation of photonic integrated chip as a terminal device of the visible optical communication network, to meet the composite requirements of the visible optical signal transmission,reception, transmission and processing. Based on the silicon-based InGaN/GaN multi-quantum well material, a composite photon integrated chip integrating visible band micro Light-Emitting Diode (LED) light source, waveguide directional coupler and micro photodetector is designed. A luminescence detection coexistence phenomenon of a InGaN/GaN multi-quantum well material is used in this chip to achieve the above composite function. As the transmitting end, the micro LED light source can emit the blue band visible light signal. Its luminous intensity is linear modulated by the injection current, which can realize the amplitude modulation visible light communication, which is suitable for the transmitting end of visible light communication. The visible light signal transmitted by the micro LED light source is transmitted into the waveguide directional coupler, which realizes the effective in-chip transmission coupling and the average optical power distribution of the chip. After the visible light signal passed through the coupled transmission enters the microphotodetector, a photocurrent matching the intensity of the coupled transmitted light signal can be monitored. Finally, effective visible light communication of this chip is also confirmed by visible light communication testing. It provides more possibilities for developing composite functional photon integrated chip terminals facing the needs of visible optical communication networks through this reserach.
- Visible light communication /
- Gallium Nitride /
- Light-Emitting Diode(LED) /
- Directional coupler /
- Photonic integration

HTML全文

圖 1 光子集成芯片的結構與制備圖

下載: 全尺寸圖片幻燈片

圖 2 硅基InGaN/GaN多量子阱波導定向耦合器光子集成芯片的光學顯微鏡圖

下載: 全尺寸圖片幻燈片

圖 3 波導定向耦合器的掃描電子顯微鏡圖

下載: 全尺寸圖片幻燈片

圖 4 波導定向耦合器的原子力顯微鏡圖片

下載: 全尺寸圖片幻燈片

圖 5 微型LED光源的電學特性圖

下載: 全尺寸圖片幻燈片

圖 6 微型LED光源的電致發光特性圖

下載: 全尺寸圖片幻燈片

圖 7 不同注入電流下光子集成芯片的工作圖片

下載: 全尺寸圖片幻燈片

圖 8 不同注入電流下驅動微型LED光源時光電探測器接收到的光電流曲線

下載: 全尺寸圖片幻燈片

圖 9 波導定向耦合器仿真模型與分析

下載: 全尺寸圖片幻燈片

圖 10 微型LED光源的可見光通信測試圖

下載: 全尺寸圖片幻燈片

參考文獻(22)

[1]	MARET L, LAGRANGE A, and DUPRé L. Ultra-high speed optical wireless communications with gallium-nitride microLED[J]. The SPIE, 2021, 11706, 0O.
[2]	FERREIRA R X G, XIE Enyuan, MCKENDRY J J D, et al. High bandwidth GaN-based micro-LEDs for multi-Gb/s visible light communications[J]. IEEE Photonics Technology Letters, 2016, 28(19): 2023–2026. doi: 10.1109/LPT.2016.2581318
[3]	CHEN S W H, HUANG Yuming, CHANG Yunhan, et al. High-bandwidth green semipolar (20–21) InGaN/GaN micro light-emitting diodes for visible light communication[J]. ACS Photonics, 2020, 7(8): 2228–2235. doi: 10.1021/acsphotonics.0c00764
[4]	李榮玲, 商慧亮, 雷雨, 等. 高速可見光通信中關鍵使能技術研究[J]. 激光與光電子學進展, 2013, 50(5): 050003. LI Rongling, SHANG Huiliang, LEI Yu, et al. Research of key enabling technologies for high-speed visible-light communication[J]. Laser &Optoelectronics Progress, 2013, 50(5): 050003.
[5]	AMIRI I S, PALAI G, ALZUBI J A, et al. Chip to chip communication through the photonic integrated circuit: A new paradigm to optical VLSI[J]. Optik, 2020, 202: 163588. doi: 10.1016/j.ijleo.2019.163588
[6]	TANG Yuling and CHEN Jun. High responsivity of Gr/ n-Si Schottky junction near-infrared photodetector[J]. Superlattices and Microstructures, 2021, 150: 106803. doi: 10.1016/J.SPMI.2021.106803
[7]	HE Xiangyu, XIE Enyuan, ISLIM M S, et al. 1 Gbps free-space deep-ultraviolet communications based on III-nitride micro-LEDs emitting at 262 nm[J]. Photonics Research, 2019, 7(7): B41–B47. doi: 10.1364/PRJ.7.000B41
[8]	LIU Xinyu, LIU Dajian, and DAI Daoxin. Silicon polarization beam splitter at the 2 μm wavelength band by using a bent directional coupler assisted with a nano-slot waveguide[J]. Optics Express, 2020, 29(2): 2720–2726. doi: 10.1364/OE.403932
[9]	BAYAL I and MAHAPATRA P K. Simulation of quantum coherence dynamics in macroscopic domain using a three-waveguide directional coupler[J]. Journal of Modern Optics, 2020, 67(10): 869–879. doi: 10.1080/09500340.2020.1780641
[10]	葛義蓉. 定向耦合器在微波傳輸系統中的應用[J]. 航空計測技術, 2001, 21(1): 31–32,38. doi: 10.3969/j.issn.1674-5795.2001.01.009 GE Yirong. Application of directional coupler to microwave transmission system[J]. Aviation Metrology &Measurement Technology, 2001, 21(1): 31–32,38. doi: 10.3969/j.issn.1674-5795.2001.01.009
[11]	蔣平英. 脊波導定向耦合器的設計與研究[D]. [碩士論文], 電子科技大學, 2007. JIANG Pingying. Design and research of ridge waveguide directional coupler[D]. [Master dissertation], University of Electronic Science and Technology, 2007.
[12]	TUGENDHAFT I, BORNSTEIN A, WEISSMAN Y, et al. Coupling efficiency of directional fiber couplers in the mid-infrared[J]. Applied Spectroscopy, 1996, 50(7): 906–909. doi: 10.1366/0003702963905420
[13]	JANG H S, PARK K N, and LEE K S. Characterization of tunable photonic crystal fiber directional couplers[J]. Applied Optics, 2007, 46(18): 3688–3693. doi: 10.1364/AO.46.003688
[14]	MALKA D, DANAN Y, RAMON Y, et al. A photonic 1 × 4 power splitter based on multimode interference in silicon–gallium-nitride slot waveguide structures[J]. Materials, 2016, 9(7): 516. doi: 10.3390/ma9070516
[15]	HAMIDAH M and PURNAMANINGSIH R W. An S-bend based optical directional coupler using GaN semiconductor[C]. 2019 IEEE International Conference on Innovative Research and Development (ICIRD), Jakarta, Indonesia, 2019: 1–4.
[16]	PURNAMANINGSIH R W, HAMIDAH M, FITHRIATY D, et al. A GaN/sapphire 1 × 4 optical power splitter using five rectangular waveguide for underwater application[C]. 2018 IEEE 5th International Conference on Engineering Technologies and Applied Sciences (ICETAS), Bangkok, Thailand, 2018: 1–5.
[17]	ZHANG Yanfeng, MCKNIGHT L, WATSON I M, et al. Compact large-cross-section GaN directional couplers[C]. IEEE Photonic Society 24th Annual Meeting, Arlington, USA, 2011: 407–408.
[18]	THUBTHIMTHONG B, SASAKI T, and HANE K. Photonic-crystal-waveguide-assisted directional couplers for hybrid Si/GaN nanophotonics[C]. 2014 International Conference on Optical MEMS and Nanophotonics, Glasgow, UK, 2014: 201–202.
[19]	ENGIN E, O'BRIEN J L, and CRYAN M J. Design and analysis of a gallium nitride-on-sapphire tunable photonic crystal directional coupler[J]. Journal of the Optical Society of America B, 2012, 29(6): 1157–1164. doi: 10.1364/JOSAB.29.001157
[20]	YUAN Jialei, GAO Xumin, YANG Yongchao, et al. GaN directional couplers for on-chip optical interconnect[J]. Semiconductor Science and Technology, 2017, 32(4): 045001. doi: 10.1088/1361-6641/aa59ef
[21]	PARK J Y, LEE J H, JUNG S, et al. InGaN/GaN-based green-light-emitting diodes with an inserted InGaN/GaN-graded superlattice layer[J]. Physica Status Solidi (a) , 2016, 213(6): 1610–1614. doi: 10.1002/pssa.201533092
[22]	DAS D, AIELLO A, GUO Wei, et al. InGaN/GaN quantum dots on silicon with coalesced nanowire buffer layers: A potential technology for visible silicon photonics[J]. IEEE Transactions on Nanotechnology, 2020, 19: 571–574. doi: 10.1109/TNANO.2020.3007732
