免調度非正交多址接入上行鏈路的非2冪次長度二元擴頻序列

李玉博; 王亞會; 于麗欣; 劉凱

doi:10.11999/JEIT210293

免調度非正交多址接入上行鏈路的非2冪次長度二元擴頻序列

doi: 10.11999/JEIT210293

燕山大學信息科學與工程學院秦皇島 066004

基金項目: 河北省自然科學基金(F2020203043, F2021203040)，河北省高等學?？茖W(xué)技術研究項目(ZD2020179, ZD2021105)

詳細信息

作者簡介:
李玉博：男，1985年生，副教授，碩士生導師，研究方向?yàn)閴嚎s感知技術，序列設計與編碼理論

王亞會：女，1999年生，碩士生，研究方向?yàn)槊庹{(diào)度NOMA擴頻序列設計

于麗欣：女，1998年生，碩士生，研究方向?yàn)閿U(kuò)頻序列設計

劉凱：女，1977年生，副教授，碩士生導師，研究方向?yàn)閿U(kuò)頻序列設計

通訊作者:
李玉博　liyubo6316@ysu.edu.cn

中圖分類號: TN914.42
計量
- 文章訪問數: 1344
- HTML全文瀏覽量: 532
- PDF下載量: 107
- 被引次數: 0
出版歷程
- 收稿日期: 2021-04-09
- 修回日期: 2021-08-24
- 網絡出版日期: 2021-09-08
- 刊出日期: 2022-04-18

Binary Spreading Sequences of Lengths Non-Power-of-Two for Uplink Grant-Free Non-Orthogonal Multiple Access

School of Information Science & Engineering, Yanshan University, Qinhuangdao 066004, China

Funds: The Natural Science Foundation of Hebei Province(F2020203043, F2021203040), The Science and Technology Research Project of Colleges and Universities in Hebei Province (ZD2020179, ZD2021105)

摘要

摘要: 為了解決5G大規模機器類通信場景下大規模接入和如何提高頻譜效率的問題，該文針對免調度非正交多址接入(NOMA)系統上行鏈路，通過采用插入函數在2元Golay序列上插入元素的方法，提出具有低峰均功率比(PAPR)且長度為非2冪次的2元擴頻序列集。仿真結果表明，得到的序列集具有低相干性，這為基于壓縮感知的活躍用戶檢測提供了可靠的性能。同傳統的Zadoff-Chu序列相比，新型2元序列集具有更小的字符集，便于實現。此外，所構造的序列PAPR最大為4，低于高斯隨機序列和Zadoff-Chu序列，因此可以有效解決時域信號峰均功率比過高的問題。
- 大規模機器類通信 /
- 非正交多址接入 /
- 壓縮感知 /
- 擴頻序列集
Abstract: In order to solve the problem of mass access and how to improve spectrum efficiency in 5G massive Machine-Type Communication (mMTC) scenario, for the uplink grant-free Non-Orthogonal Multi-Access(NOMA) system, new sets of non-orthogonal binary spreading sequences with low Peak Average Power Ratio(PAPR) and lengths non-power-of-two is proposed by inserting elements into binary Golay sequences using insertion function. Simulation results confirm that the resulting sequence sets has low coherence, which provides reliable performance for active user detection based on Compressed Sensing (CS). Compared with the traditional Zadoff-chu sequences, the new binary sequence sets has a smaller alphabet set, which is easy to implement. Moreover, the resultanted sequences exhibit the PAPR of at most 4, which is lower than those for Gaussian and Zadoff-Chu sequences. Therefore, the problem of high peak-to-power ratio in time domain can be solved effectively.
- Massive machine-type communications /
- Non-Orthogonal Multiple Access (NOMA) /
- Compressed Sensing (CS) /
- Sets of spreading sequences

HTML全文

圖 1 上行免調度NOMA的系統模型^[21]

下載: 全尺寸圖片幻燈片

圖 2 $ M{\text{ = }}129 $時(${M_{{\rm{zc}}}} = 127$)每個設備的SNR上的基于CS的CE和MUD的性能

下載: 全尺寸圖片幻燈片

圖 3 $ M{\text{ = }}130 $時(${M_{{\rm{zc}}}} = 131$)每個設備的SNR上的基于CS的CE和MUD的性能

下載: 全尺寸圖片幻燈片

圖 4 $ M{\text{ = }}129 $時(${M_{{\rm{zc}}}} = 127$)用戶過載因子L上的基于CS的CE和MUD的性能

下載: 全尺寸圖片幻燈片

圖 5 $ M{\text{ = }}130 $時(${M_{{\rm{zc}}}} = 131$)用戶過載因子L上的基于CS的CE和MUD的性能

下載: 全尺寸圖片幻燈片

圖 6 $ M{\text{ = }}129 $時(${M_{{\rm{zc}}}} = 127$)活躍概率P_a上的基于CS的CE和MUD的性能

下載: 全尺寸圖片幻燈片

圖 7 $ M{\text{ = 130}} $時(${M_{{\rm{zc}}}} = 131$)活躍概率P_a上的基于CS的CE和MUD的性能

下載: 全尺寸圖片幻燈片

表 1 使${{\boldsymbol{\varPhi}} '}$達到最優的置換集

$ {M'}{\text{ = }}{{\text{2}}^m} $	用戶過載因子	相干值	置換集$\varGamma$
32	$ 2 \le L \le 8 $	0.25	$(5,4,3,2,1),(3,4,2,5,1),(4,2,5,3,1),(4,3,5,1,2),(4,5,1,3,2),(5,3,1,4,2),(5,4,2,1,3),(4,1,2,5,3)$
64	$ 2 \le L \le 5 $	0.125	$(3,4,5,2,6,1),(6,3,2,4,1,5),(4,1,6,5,2,3),(6,5,3,1,2,4),(5,3,2,1,6,4)$
128	$ 2 \le L \le 8 $	0.125	$\begin{array}{l} {\text{(4,5,1,3,6,7,2),(4,2,5,1,6,7,3),(6,7,1,2,3,5,4),(5,3,6,4,1,7,2),(6,4,7,3,1,5,2),(4,3,6,7,5,2,1),} } \\ {\text{(6,1,3,2,7,4,5),(6,7,5,1,4,3,2)} } \\ \end{array}$
256	$ 2 \le L \le 5 $	0.0625	${\text{(4,5,6,1,3,7,8,2),(7,6,8,2,3,1,4,5),(7,1,8,6,4,3,5,2),(6,7,2,3,8,4,1,5),(8,3,1,5,2,7,4,6)} }$
512	$ 2 \le L \le 8 $	0.0625	$\begin{array}{l} {\text{(8,3,7,4,9,2,5,1,6),(8,4,3,7,2,6,1,9,5),(9,5,4,1,6,8,3,7,2),(6,5,8,7,9,3,4,2,1),} } \\ {\text{(4,1,7,6,8,9,2,5,3),(4,8,2,6,9,7,5,3,1),(5,3,7,8,2,1,6,9,4),(5,6,9,3,7,1,8,2,4)} } \\ \end{array}$
1024	$ 2 \le L \le 5 $	0.03125	$\begin{array}{l} {\text{(9,1,6,3,2,8,5,4,10,7),(5,1,9,8,2,10,6,3,7,4),(6,3,8,10,9,7,1,5,4,2),(7,6,8,1,3,2,10,9,4,5),} } \\ {\text{(9,5,3,2,4,8,6,10,7,1)} } \\ \end{array}$

下載: 導出CSV

表 2 擴頻矩陣相干值$\mu ({\boldsymbol{\varPhi}} )$

擴頻矩陣	序列長度	$\mu ({\boldsymbol{\varPhi} } )$	擴頻矩陣	序列長度	$\mu ({\boldsymbol{\varPhi} } )$	擴頻矩陣	序列長度	$\mu ({\boldsymbol{\varPhi } })$	擴頻矩陣	序列長度	$\mu ({\boldsymbol{\varPhi } })$
本文	33	0.2727	本文	34	0.2941	文獻[16]	32	0.2500	基于ZC序列	31	0.1796
	65	0.1385		66	0.1515		64	0.1250		61	0.1280
	129	0.1318		130	0.1385		128	0.1250		127	0.0887
	257	0.0661		258	0.0698		256	0.0625		257	0.0624
	513	0.0643		514	0.0661		512	0.0625		509	0.0443
	1025	0.0322		1026	0.0331		1024	0.03125		1021	0.0313

下載: 導出CSV

表 3 擴頻矩陣?yán)镄蛄械淖畲驪APR

擴頻矩陣	序列長度	PAPR	擴頻矩陣	序列長度	PAPR	擴頻矩陣	序列長度	PAPR	擴頻矩陣	序列長度	PAPR
本文	33	2.4545	本文	34	2.9412	文獻[16]	32	2.0000	基于ZC序列	31	4.4066
	65	2.2825		66	2.6172		64	1.9928		61	4.0922
	129	2.2403		130	2.4923		128	2.0000		127	4.3376
	257	2.1699		258	2.3265		256	1.9978		257	4.7396
	513	2.1228		514	2.2490		512	2.0000		509	4.8785
	1025	2.0834		1026	2.1713		1024	1.9993		1021	5.2751

下載: 導出CSV

表 4 幾種確定性擴頻矩陣的參數

擴頻矩陣	擴頻序列長度$ M $	$\mu ({\boldsymbol{\varPhi} } )$	PAPR上界	字符集大小
文獻[16]	$ {2^m} $	$\sqrt{{1}/{ {2}^{m\text{-1} } } },\;\;m{\text{為奇數} }$ $\sqrt{{1}/{ {2}^{m} } },\;m{\text{為偶數} }$	2	2
基于ZC序列	$ {M_{{\text{zc}}}} $為任意素?cái)?shù)	$\sqrt {{1}/{ { {M_{ {\text{zc} } } } } } }$	>4	$ {M_{{\text{zc}}}} $
本文	$ {2^m}{\text{ + }}1 $	$\dfrac{\sqrt{ {2}^{m+1} }+1}{ {2}^{m}+1},\;m{\text{為奇數} }$ $\dfrac{\sqrt{ {2}^{m} }+1}{ {2}^{m}+1},\;m{\text{為偶數} }$	4	2
本文	$ {2^m}{\text{ + 2}} $	$ \dfrac{\sqrt{{2}^{m+1}}+2}{{2}^{m}+2},m{\text{為奇數}} $，$ \dfrac{\sqrt{{2}^{m}}+2}{{2}^{m}+2},m{\text{為偶數}} $	4	2

下載: 導出CSV
