面向深度神經網絡加速芯片的高效硬件優化策略

張萌; 張經緯; 李國慶; 吳瑞霞; 曾曉洋

doi:10.11999/JEIT210002

面向深度神經網絡加速芯片的高效硬件優化策略

doi: 10.11999/JEIT210002

1.
東南大學電子學院國家專用集成電路系統工程技術研究中心南京 210096
2.
復旦大學專用集成電路與系統國家重點實驗室上海 200433

基金項目: 國家重點研發計劃(2018YFB2202703)，江蘇省自然科學基金(BK20201145)

詳細信息

作者簡介:
張萌：男，1964年生，研究員，研究方向?yàn)閿?shù)字信號處理、深度學習算法及硬件加速

張經緯：男，1997年生，碩士生，研究方向?yàn)樯疃葘W(xué)習硬件加速器設計

李國慶：男，1991年生，博士生，研究方向?yàn)橛?jì)算機視覺和深度學習硬件加速器設計

吳瑞霞：女，1996年生，碩士生，研究方向?yàn)樯疃葘W(xué)習算法

曾曉洋：男，1972年生，教授，研究方向?yàn)楦吣苄到y(tǒng)芯片(SoC)

通訊作者:
張經緯　zhangjingwei@seu.edu.cn

中圖分類號: TN79.1
計量
- 文章訪問數: 1494
- HTML全文瀏覽量: 544
- PDF下載量: 198
- 被引次數: 0
出版歷程
- 收稿日期: 2021-01-04
- 修回日期: 2021-04-21
- 網絡出版日期: 2021-04-29
- 刊出日期: 2021-06-18

Efficient Hardware Optimization Strategies for Deep Neural Networks Acceleration Chip

1.
National ASIC Engineering Center, School of Electronic Sci. and Eng., Southeast University, Nanjing 210096, China
2.
National ASIC Key Laboratory, Fudan University, Shanghai 200433, China

Funds: The National Key R&D Program of China(2018YFB2202703), Jiangsu Province of Natural Science and Technology(BK20201145)

摘要

摘要: 輕量級神經網絡部署在低功耗平臺上的解決方案可有效用于無人機(UAV)檢測、自動駕駛等人工智能(AI)、物聯網(IOT)領域，但在資源有限情況下，同時兼顧高精度和低延時來構建深度神經網絡(DNN)加速器是非常有挑戰性的。該文針對此問題提出一系列高效的硬件優化策略，包括構建可堆疊共享計算引擎(PE)以平衡不同卷積中數據重用和內存訪問模式的不一致；提出了可調的循環次數和通道增強方法，有效擴展加速器與外部存儲器之間的訪問帶寬，提高DNN淺層網絡計算效率；優化了預加載工作流，從整體上提高了異構系統的并行度。經Xilinx Ultra96 V2板卡驗證，該文的硬件優化策略有效地改進了iSmart3-SkyNet和SkrSkr-SkyNet類的DNN加速芯片設計。結果顯示，優化后的加速器每秒處理78.576幀圖像，每幅圖像的功耗為0.068 J。
- 深度神經網絡 /
- 目標檢測 /
- 神經網絡加速器 /
- 低功耗 /
- 硬件優化
Abstract: Lightweight neural networks deployed on low-power platforms have proven to be effective solutions for Artificial Intelligence (AI) and Internet Of Things (IOT) domains such as Unmanned Aerial Vehicle (UAV) detection and unmanned driving. However, in the case of limited resources, it is very challenging to build Deep Neural Networks (DNN) accelerator with both high precision and low delay. In this paper, a series of efficient hardware optimization strategies are proposed, including stackable shared Processing Engine (PE) to balance the inconsistency of data reuse and memory access patterns in different convolutions; Regulable loop parallelism and channel augmentation are proposed to increase effectively the access bandwidth between accelerator and external memory. It also improve the efficiency of DNN shallow layers computing; Pre-Workflow is applied to improve the overall parallelism of heterogeneous systems. Verified by Xilinx Ultra96 V2 board, the hardware optimization strategies in this paper improve effectively the design of DNN acceleration chips like iSmart3-SkyNet and SkrSkr-SkyNet. The results show that the optimized accelerator processes 78.576 frames per second, and the power consumption of each picture is 0.068 Joules.
- Deep Neural Networks (DNN) /
- Object detection /
- Neural network accelerator /
- Low power consumption /
- Hardware optimization

HTML全文

圖 1 iSmart3-SkyNet加速器上的SkyNet Roofline模型分析

下載: 全尺寸圖片幻燈片

圖 2 系統-計算模塊-線性緩沖區結構示意圖

下載: 全尺寸圖片幻燈片

圖 3 通道增強流程說明圖

下載: 全尺寸圖片幻燈片

圖 4 3種工作流比較圖

下載: 全尺寸圖片幻燈片

圖 5 優化后加速器上的SkyNet Roofline模型分析

下載: 全尺寸圖片幻燈片

圖 6 iSmart3和Skrskr加速優化前后性能對比

下載: 全尺寸圖片幻燈片

表 1 SkyNet的體系結構和每個捆綁包的推理速度表格

捆綁包	層數	輸入尺寸	操作類型	計算量、計算量占比(%)	延遲占比(%)
#1	1	3×160×320	DW-Conv3	119.61M, 20.6	33.90
	2	3×160×320	PW-Conv1
	3	48×160×320	POOLING
#2	4	48×80×160	DW-Conv3	86.02M, 14.42	16.54
	5	48×80×160	PW-Conv1
	6	96×80×160	POOLING
#3	7	96×40×80	DW-Conv3	61.75M, 10.36	6.23
	8	96×40×80	PW-Conv1
	9	192×40×80	POOLING
#4	10	192×20×40	DW-Conv3	60.36M, 10.13	4.92
#4	11	192×20×40	PW-Conv1	60.36M, 10.13	4.92
#5	12	384×20×40	DW-Conv3	160.05M, 26.85	12.43
#5	13	384×20×40	PW-Conv1	160.05M, 26.85	12.43
#6	–	合并第9層輸出		107.52M, 18.04	20.08
	14	1280×20×40	[旁路] DW-Conv3
	15	1280×20×40	PW-Conv1
#7	16	96×20×40	PW-Conv1	0.77M, 0.14	0.10
–	17	10×20×40	計算回歸框		0.16
CPU	–	–	–	–	5.64

下載: 導出CSV

表 2 優化策略效果對比

加速器	iSmart3 ^[9]	SEUer A	Skrskr ^[10]	SEUer B
網絡模型	SkyNet	SkyNet	SkyNet	SkyNet
量化精度	A9/W11	A9/W11	A8/W6	A8/W6
硬件平臺	Ultra96V2	Ultra96V2	Ultra96V2	Ultra96V2
準確率(DJI)	0.716	0.724	0.731	0.731
時鐘頻率(MHz)	215	215	300	300
DSP數量	329	287	360	360
LUT數量	54	54	56	46
FF數量	60	70	68	51
幀率	25.05	37.393	52.429	78.576
GOPS/W	3.21	5.95	7.22	11.19
Energy/Pic.(J)	0.289	0.135	0.129	0.068

下載: 導出CSV
