上下文信息融合與分支交互的SAR圖像艦船無錨框檢測

曲海成; 高健康; 劉萬軍; 王曉娜

doi:10.11999/JEIT201059

上下文信息融合與分支交互的SAR圖像艦船無錨框檢測

doi: 10.11999/JEIT201059

遼寧工程技術大學軟件學院葫蘆島 125105

基金項目: 國家自然科學基金青年基金(41701479)，遼寧省教育廳基金(LJ2019JL010)，遼寧工程技術大學學科創新團隊(LNTU20TD-23)

詳細信息

作者簡介:
曲海成：男，1981年生，副教授，研究方向?yàn)檫b感影像高性能計算、視覺信息計算、目標檢測與識別

高健康：男，1996年生，碩士生，研究方向?yàn)檫b感圖像目標檢測

劉萬軍：男，1959年生，教授，研究方向?yàn)閿?shù)字圖像處理、運動目標檢測與跟蹤

王曉娜：女，1994年生，碩士生，研究方向?yàn)閿?shù)字圖像處理

通訊作者:
高健康　gjk_0825@163.com

¹⁾ SSDD數據集下載鏈接：https://zhuanlan.zhihu.com/p/143794468²⁾ SAR-Ship-Dataset數據集下載：https://pan.baidu.com/s/1PhSMkXVcuRM8M8xL15iBIQ
中圖分類號: TN911.73; TP751
計量
- 文章訪問數: 1031
- HTML全文瀏覽量: 442
- PDF下載量: 100
- 被引次數: 0
出版歷程
- 收稿日期: 2020-12-16
- 修回日期: 2021-05-27
- 網絡出版日期: 2021-08-27
- 刊出日期: 2022-01-10

An Anchor-free Method Based on Context Information Fusion and Interacting Branch for Ship Detection in SAR Images

School of Software, Liaoning Technical University, Huludao 125105, China

Funds: The Young Scientists Fund of National Natural Science Foundation of China (41701479), The Department of Education Fund Item (LJ2019JL010) of Liaoning Province, The Discipline Innovation Team of Liaoning Technical University (LNTU20TD-23)

摘要

摘要: SAR圖像中艦船目標稀疏分布、錨框的設計，對現有基于錨框的SAR圖像目標檢測方法的精度和泛化性有較大影響，因此該文提出一種上下文信息融合與分支交互的SAR圖像艦船目標無錨框檢測方法，命名為CI-Net。考慮到SAR圖中艦船尺度的多樣性，在特征提取階段設計上下文融合模塊，以自底向上的方式融合高低層信息，結合目標上下文信息，細化提取到的待檢測特征；其次，針對復雜場景中目標定位準確性不足的問題，提出分支交互模塊，在檢測階段利用分類分支優化回歸分支的檢測框，改善目標定位框的精準性，同時將新增的IOU分支作用于分類分支，提高檢測網絡分類置信度，抑制低質量的檢測框。實驗結果表明：在公開的SSDD和SAR-Ship-Dataset數據集上，該文方法均取得了較好的檢測效果，平均精度(AP)分別達到92.56%和88.32%，與其他SAR圖艦船檢測方法相比，該文方法不僅在精度上表現優異，在摒棄了與錨框有關的復雜計算后，較快的檢測速度，對SAR圖像實時目標檢測也有一定的現實意義。
- 合成孔徑雷達 /
- 艦船檢測 /
- 無錨框 /
- 上下文信息 /
- 自注意力
Abstract: Ship targets are sparsely distributed in Synthetic Aperture Radar (SAR) images, and the design of anchor frame has a great impact on the accuracy and generalization of existing SAR image target detection method based on anchor. Therefore, an anchor-free method based on context information fusion and interacting branch for ship detection in SAR images (named as CI-Net) is proposed. Considering the diversity of ship scale in SAR images, a context fusion module is designed in the feature extraction stage, integrate high and low levels of information in a bottom-up manner and refine the extracted features to be detected by combining with the target context information. Secondly, aiming at the problem of complex targets in the scene is not accurate, interacting branch module is put forward. In the detection phase, use classification branches optimization regression testing box is used, to improve the target frame’s precision. At the same time, the new Intersection over Union (IOU) is used on branches of the classification to improve detection network classification confidence, to inhibit detection box of low quality. Experimental results show that the proposed method achieves good detection results on both SSDD and SAR-Ship-Dataset, with Average Precision (AP) reaching 92.56% and 88.32%, respectively. Compared with other ship detection methods in SAR image, the proposed method not only has excellent performance in accuracy, but also has a faster detection speed after abandoning the complex calculation related to anchor frame. It also has a certain practical significance for real-time target detection in SAR image.
- Synthetic Aperture Radar (SAR) /
- Ship detection /
- Anchor-free /
- Context information /
- Self-attention
¹⁾ SSDD數據集下載鏈接：https://zhuanlan.zhihu.com/p/143794468²⁾ SAR-Ship-Dataset數據集下載：https://pan.baidu.com/s/1PhSMkXVcuRM8M8xL15iBIQ

HTML全文

圖 1 無錨框的檢測模型

下載: 全尺寸圖片幻燈片

圖 2 CI-Net檢測模型框架

下載: 全尺寸圖片幻燈片

圖 3 上下文融合模塊

下載: 全尺寸圖片幻燈片

圖 4 GCNet結構

下載: 全尺寸圖片幻燈片

圖 5 自注意力模塊

下載: 全尺寸圖片幻燈片

圖 6 檢測結果對比圖

下載: 全尺寸圖片幻燈片

圖 7 上下文融合模塊特征可視化

下載: 全尺寸圖片幻燈片

圖 8 不同方法的P-R曲線圖

下載: 全尺寸圖片幻燈片

表 1 艦船數據集的基本信息

數據集	傳感器來源	空間分辨率	極化方式	輸入圖像大小	場景
SSDD	RadarSat-2, TerraSAR-X, Sentinel-1	1～15	VV, HH, VH, HV	500×500	近海、近岸區域
SAR-Ship Dataset	GF-3, Sentinel-1	3, 5, 8, 10等	VV, HH, VH, HV	256×256	遠海區域

下載: 導出CSV

表 2 模型實驗結果

方法	上下文融合(CF)	分支交互(IB)	召回率(%)	準確率(%)	平均精度(%)	F₁(%)	fps
FCOS^[14]	×	×	88.64	88.44	86.27	88.54	23
本文	√	×	92.23	86.60	90.69	89.32	29
FCOS^[14]	×	√	90.31	93.41	88.42	91.83	22
本文	√	√	94.27	92.04	92.56	93.14	28
注：“×”表示沒有采用該模塊。“√”表示采用該模塊。加粗值為每列最優結果。

下載: 導出CSV

表 3 不同方法在SSDD數據集上檢測性能對比

方法	單階段	無錨框	召回率(%)	準確率(%)	平均精度(%)	F₁(%)	fps
Faster R-CNN	×	×	85.39	84.18	83.07	84.78	11
RetinaNet	√	×	89.40	90.43	87.94	89.91	16
DCMSNN	×	×	91.59	88.33	89.34	89.93	8
本文CI-Net	√	√	94.27	92.04	92.56	93.14	28

下載: 導出CSV

表 4 不同方法在SAR-Ship-Dataset上檢測性能對比

方法	單階段	無錨框	召回率(%)	準確率(%)	平均精度(%)	F₁(%)	fps
Faster R-CNN	×	×	84.30	84.47	81.77	84.39	13
RetinaNet	√	×	84.60	85.83	82.02	85.21	21
DCMSNN	×	×	86.64	88.07	84.36	87.35	9
本文CI-Net	√	√	90.28	88.14	88.32	89.20	34

下載: 導出CSV

參考文獻(23)

[1]	楊國錚, 禹晶, 肖創柏, 等. 基于形態字典學習的復雜背景SAR圖像艦船尾跡檢測[J]. 自動化學報, 2017, 43(10): 1713–1725. doi: 10.16383/j.aas.2017.c160274 YANG Guozheng, YU Jing, XIAO Chuangbai, et al. Ship Wake detection in SAR images with complex background using morphological dictionary learning[J]. Acta Automatica Sinica, 2017, 43(10): 1713–1725. doi: 10.16383/j.aas.2017.c160274
[2]	李健偉, 曲長文, 彭書娟, 等. 基于生成對抗網絡和線上難例挖掘的SAR圖像艦船目標檢測[J]. 電子與信息學報, 2019, 41(1): 143–149. doi: 10.11999/JEIT180050 LI Jianwei, QU Changwen, PENG Shujuan, et al. Ship detection in SAR images based on generative adversarial network and online hard examples mining[J]. Journal of Electronics &Information Technology, 2019, 41(1): 143–149. doi: 10.11999/JEIT180050
[3]	HOU Biao, CHEN Xingzhong, and JIAO Licheng. Multilayer CFAR detection of ship targets in very high resolution SAR images[J]. IEEE Geoscience and Remote Sensing Letters, 2015, 12(4): 811–815. doi: 10.1109/LGRS.2014.2362955
[4]	LI Jianwei, QU Changwen, and SHAO Jiaqi. Ship detection in SAR images based on an improved faster R-CNN[C]. 2017 SAR in Big Data Era: Models, Methods and Applications, Beijing, China, 2017: 1–6. doi: 10.1109/BIGSARDATA.2017.8124934.
[5]	REN Shaoqing, HE Kaiming, GIRSHICK R, et al. Faster R-CNN: Towards real-time object detection with region proposal networks[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2017, 39(6): 1137–1149. doi: 10.1109/TPAMI.2016.2577031
[6]	JIAO Jiao, ZHANG Yue, SUN Hao, et al. A densely connected end-to-end neural network for multiscale and multiscene SAR ship detection[J]. IEEE Access, 2018, 6: 20881–20892. doi: 10.1109/ACCESS.2018.2825376
[7]	胡昌華, 陳辰, 何川, 等. 基于深度卷積神經網絡的SAR圖像艦船小目標檢測[J]. 中國慣性技術學報, 2019, 27(3): 397–405, 414. doi: 10.13695/j.cnki.12-1222/o3.2019.03.018 HU Changhua, CHEN Chen, HE Chuan, et al. SAR detection for small target ship based on deep convolutional neural network[J]. Journal of Chinese Inertial Technology, 2019, 27(3): 397–405, 414. doi: 10.13695/j.cnki.12-1222/o3.2019.03.018
[8]	LIN T Y, DOLLáR P, GIRSHICK R, et al. Feature pyramid networks for object detection[C]. 2017 IEEE Conference on Computer Vision and Pattern Recognition (CVPR), Honolulu, USA, 2017: 936–944. doi: 10.1109/CVPR.2017.106.
[9]	CUI Zongyong, LI Qi, CAO Zongjie, et al. Dense attention pyramid networks for multi-scale ship detection in SAR images[J]. IEEE Transactions on Geoscience and Remote Sensing, 2019, 57(11): 8983–8997. doi: 10.1109/TGRS.2019.2923988
[10]	LIU Wei, ANGUELOV D, ERHAN D, et al. SSD: Single shot multibox detector[C]. The 14th European Conference on Computer Vision, Amsterdam, Netherlands, 2016: 21–37. doi: 10.1007/978-3-319-46448-0_2.
[11]	REDMON J, DIVVALA S, GIRSHICK R, et al. You only look once: Unified, real-time object detection[C]. 2016 IEEE Conference on Computer Vision and Pattern Recognition (CVPR), Las Vegas, USA, 2016: 779–788. doi: 10.1109/CVPR.2016.91.
[12]	SHRIVASTAVA A, GUPTA A, and GIRSHICK R. Training region-based object detectors with online hard example mining[C]. 2016 IEEE Conference on Computer Vision and Pattern Recognition (CVPR), Las Vegas, USA, 2016: 761–769. doi: 10.1109/CVPR.2016.89.
[13]	DUAN Kaiwen, BAI Song, XIE Lingxi, et al. CenterNet: Keypoint triplets for object detection[C]. 2019 IEEE/CVF International Conference on Computer Vision (ICCV), Seoul, South Korea, 2019: 6568–6577. doi: 10.1109/ICCV.2019.00667.
[14]	TIAN Zhi, SHEN Chunhua, CHEN Hao, et al. FCOS: Fully convolutional one-stage object detection[C]. 2019 IEEE/CVF International Conference on Computer Vision (ICCV), Seoul, South Korea, 2019: 9626–9635. doi: 10.1109/ICCV.2019.00972.
[15]	PANG Jiangmiao, CHEN Kai, SHI Jianping, et al. Libra R-CNN: Towards balanced learning for object detection[C]. 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR), Long Beach, USA, 2019: 821–830. doi: 10.1109/CVPR.2019.00091.
[16]	CAO Yue, XU Jiarui, LIN S, et al. GCNet: Non-local networks meet squeeze-excitation networks and beyond[C]. 2019 IEEE/CVF International Conference on Computer Vision Workshop (ICCVW), Seoul, South Korea,2019: 1971–1980. doi: 10.1109/ICCVW.2019.00246.
[17]	WANG Xiaolong, GIRSHICK R, GUPTA A, et al. Non-local neural networks[C]. 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Salt Lake City, USA, 2018: 7794–7803. doi: 10.1109/CVPR.2018.00813.
[18]	HU Jie, SHEN Li, and SUN Gang. Squeeze-and-excitation networks[C]. 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Salt Lake City, USA, 2018: 7132–7141. doi: 10.1109/CVPR.2018.00745.
[19]	LI Huan and TANG Jinglei. Dairy goat image generation based on improved-self-attention generative adversarial networks[J]. IEEE Access, 2020, 8: 62448–62457. doi: 10.1109/ACCESS.2020.2981496
[20]	LIN T Y, GOYAL P, GIRSHICK R, et al. Focal loss for dense object detection[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2020, 42(2): 318–327. doi: 10.1109/TPAMI.2018.2858826
[21]	WANG Yuanyuan, WANG Chao, ZHANG Hong, et al. A SAR dataset of ship detection for deep learning under complex backgrounds[J]. Remote Sensing, 2019, 11(7): 765. doi: 10.3390/rs11070765
[22]	HUANG Lanqing, LIU Bin, LI Boying, et al. OpenSARShip: A dataset dedicated to Sentinel-1 ship interpretation[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2018, 11(1): 195–208. doi: 10.1109/JSTARS.2017.2755672
[23]	KANG Miao, JI Kefeng, LENG Xiangguang, et al. Contextual region-based convolutional neural network with multilayer fusion for SAR ship detection[J]. Remote Sensing, 2017, 9(8): 860. doi: 10.3390/rs9080860
