一種高性能硬件加密引擎陣列架構

駱建軍; 沈一凡; 周迪; 馮春陽; 鄧江峽

doi:10.11999/JEIT200855

一種高性能硬件加密引擎陣列架構

doi: 10.11999/JEIT200855

1.
杭州電子科技大學微電子研究中心杭州 310018
2.
浙江宇視科技有限公司杭州 310051

基金項目: 國家基礎科研項目(JCKY2018415C001)，浙江省固態硬盤和數據安全技術重點實驗室(2015E10003)

詳細信息

作者簡介:
駱建軍：男，1970年生，教授，博士生導師，研究方向?yàn)榧呻娐?、?shù)字存儲和數據安全系統

沈一凡：女，1996年生，碩士，研究方向?yàn)榧呻娐?/p>
周迪：男，1975年生，正高級工程師，研究方向?yàn)槲锫?lián)網、視頻安全

馮春陽：男，1966年生，高級工程師，研究方向?yàn)榧呻娐吩O(shè)計、功率半導體

鄧江峽：女，1983年生，副教授、碩士生導師，研究方向?yàn)樽孕娮訉W(xué)、集成電路設計與驗證

通訊作者:
鄧江峽　dengjiangxia@hdu.edu.cn

中圖分類號: TN492; TN918.4
計量
- 文章訪問數: 842
- HTML全文瀏覽量: 390
- PDF下載量: 55
- 被引次數: 0
出版歷程
- 收稿日期: 2020-10-04
- 修回日期: 2021-09-30
- 網絡出版日期: 2021-10-25
- 刊出日期: 2021-12-21

High Performance Crypto Module with Array of Hardware Engines

1.
Microelectronics Research Institute of Hangzhou Dianzi University, Hangzhou 310018, China
2.
Uniview Research Institute, Hangzhou 310051, China

Funds: The National Basic Research Program (JCKY2018415C001), Zhejiang Key Laboratory Foundation of Solid State Drive and Data Security (2015E10003)

摘要

摘要: 該文提出一種高性能硬件加密引擎陣列架構，為大數據應用提供了先進的安全解決方案。該模塊架構包括一個高速接口、一個中央管理和監視模塊(CMMM)、一組多通道驅動加密引擎陣列，其中CMMM將任務分配給加密引擎，經由專用算法處理后再將數據傳回主機。由于接口吞吐量和加密引擎陣列規模會限制模塊性能，針對PCIe高速接口，采用MMC/eMMC總線連接構建陣列，發現更多加密引擎集成到系統后，模塊性能將會得到提升。為驗證該架構，使用55 nm制程工藝完成了一個PCIe Gen2×4接口的ASIC加密卡，測試結果顯示其平均吞吐量高達419.23 MB。
- 專用集成電路 /
- 安全 /
- 加密 /
- PCIe /
- eMMC
Abstract: A high-performance crypto module prescribed in this paper offers advanced security solutions in big data applications. A module architecture, which consists of a high throughput interface, Central Manage & Monitor Module (CMMM) and multiple channels driving a group of crypto engines, is discussed here. CMMM distributes the tasks to the crypto engines and guides the data back to the host after processing by the dedicated algorithm. Since the module's performance is limited by the interface throughput and the scale of the crypto engines, an array with MMC/eMMC bus connections is built for PCIe high-speed interfaces. The more crypto engines are integrated into a system, the higher performance of this system can reach. To verify this architecture, an ASIC encryption card with PCIe Gen2×4 interface is made under semiconductor manufacturing process technology of 55 nm, and tested. The average throughput of this card can achieve up to 419.23 MB.
- ASIC /
- Security /
- Crypto /
- PCIe /
- eMMC
