差異區域平衡法探索時間序列變化的因果關系
doi: 10.11999/JEIT200756
-
1.
福建師范大學數學與信息學院 福州 350117
-
2.
福建師范大學數字福建環境監測物聯網實驗室 福州 350117
基金項目: 國家自然科學基金(61672157)，福建省自然科學基金 (2018J01778)
Different-region Balance Method for Exploring Varying Causal Relations Between Time Series
-
1.
College of Mathematics and Informatics, Fujian Normal University, Fuzhou 350117, China
-
2.
Digit Fujian Internet-of-Things Laboratory of Environmental Monitoring, Fuzhou 350117, China
Funds: The National Natural Science Foundation of China (61672157), The Natural Science Foundation of Fujian Province (2018J01778)
-
摘要: 針對探索時間序列之間隨時間變化的因果關系問題，在每個窗口進行Granger因果檢測的滑動時間窗口方法是求解該問題的常用方法，但其性能對窗寬敏感，不合適的窗寬很可能導致低性能。該文提出一種差異區域平衡方法，首先計算當前滑動窗口W內序列的波動程度Sw并作為波動界，計算窗口W的前向相鄰區域U內序列的波動程度Su。然后，實施前向探索策略：若Su未超過Sw，則實施不同長度區域的平衡檢測方案，即對窗口W、對窗口W與U的合并區域、對窗口W與后向相鄰區域V的合并區域這3種不同長度的差異區域，分別進行時間序列之間因果關系的檢測；若Su超過Sw，則實施上述平衡檢測方案時，其中區域U和V的長度取相同值。最后，將窗口W的多次檢測結果進行綜合后輸出。新方法將不同長度區域的結果進行綜合，能夠降低方法的性能對窗寬的敏感性，保障最終結果的準確性和穩定性。在1個模擬數據集和4個真實數據集上的實驗結果顯示，該文方法能有效地揭示出時間序列之間隨時間變化的因果關系，在正確率高且性能穩定的綜合性能上優于對比方法。
-
關鍵詞:
- 時間序列 /
- 變化的因果關系 /
- Granger因果檢測 /
- 差異區域平衡
Abstract: For discovering time-varying causal relations between time series, a common method is the sliding-window method with Granger causal tests on every window. However, the method performance is sensitive to window sizes, and an unsuitable size probably leads to poor performance. The different-region balance method is proposed. The variation degree of time series in current sliding window W (called variation bound Sw) is first computed, and the degree Su in front neighbor region U of W is computed. Then a forward exploring strategy is adopted: when Su≤Sw, a different-length-region balance test measure is carried out, i.e., causal-relation tests respectively in window W, combined region W and U, and combined window W and back neighbor region V of W; when Su>Sw, it uses the above-mentioned measure where region V has the same length as region U; Finally, in each region, all the test results are synthesized to give a final result. The new method combines the results from different-length regions to reduce its sensitivity to window sizes, and guarantees the accuracy and stability of final results. The experiments on one simulated data set and four real data sets show that, the new method can discover time-varying causal relations between time series effectively, and outperforms the compared methods on the balance performance of high accuracy and stability. -
表 1 不同方法在模擬數據集上發掘因果關系的正確率(%)
窗口寬度 滑動步長 噪聲方差0.01 噪聲方差0.2 噪聲方差0.5 常規 F界 轉折 平衡 常規 F界 轉折 平衡 常規 F界 轉折 平衡 20 5 91.32 88.18 90.99 95.40 80.82 94.56 58 84.13 80.57 91.00 50.29 82.52 10 88.98 88.18 91.91 95.06 80.25 94.56 53.39 83.33 80.15 91.00 46.33 82.54 15 86.78 88.18 90.00 94.43 78.1 94.56 44.86 83.26 78.52 91.00 46.22 82.03 20 83.65 88.18 89.17 92.77 77.05 94.56 45.4 82.15 77.98 91.00 45.48 81.87 30 5 95.85 88.18 90.61 95.87 85.69 94.56 60.4 92.31 83.63 91.00 47.37 87.78 10 94.43 88.18 90.15 95.49 84.95 94.56 53.01 91.95 83.69 91.00 46.4 87.41 15 94.07 88.18 90.85 94.91 83.22 94.56 51.62 91.65 81.93 91.00 45.98 86.84 20 92.96 88.18 90.95 95.57 81.62 94.56 53.21 91.37 81.18 91.00 46.38 86.96 40 5 95.56 88.18 91.83 94.85 92.46 94.56 63.52 94.65 87.62 91.00 46.43 92.17 10 95.31 88.18 90.07 94.87 91.05 94.56 58.89 94.27 87.08 91.00 45.38 92.22 15 94.95 88.18 90.65 94.77 90.62 94.56 58.77 94.55 86.87 91.00 46.39 91.76 20 94.59 88.18 89.9 94.31 89.5 94.56 52.31 93.93 85.86 91.00 45.80 91.03
下載: 導出CSV
表 2 在數據集Dropoff-tweet上發掘因果關系的正確率(%)
窗口
寬度滑動
步長常規滑
動窗F界檢測法 轉折點法 差異平衡法 12 4 91.95 92.62 93.56 93.42 8 90.87 92.62 93.56 93.83 12 89.26 92.62 94.36 90.20 18 4 94.09 92.62 94.90 95.30 8 94.36 92.62 94.36 94.77 12 92.21 92.62 94.36 94.77 24 4 94.36 92.62 94.09 96.51 8 97.05 92.62 96.24 96.78 12 91.95 92.62 91.41 95.70
下載: 導出CSV
表 3 在數據集Tweet-pickup上發掘因果關系的正確率(%)
窗口
寬度滑動
步長常規滑
動窗F界檢測法 轉折點法 差異平衡法 12 4 90.87 94.90 90.87 93.29 8 91.95 94.90 94.09 94.09 12 92.48 94.90 94.09 91.01 18 4 92.48 94.90 88.19 94.90 8 92.48 94.90 93.83 94.90 12 93.02 94.90 94.09 93.02 24 4 92.75 94.90 91.41 95.44 8 93.29 94.90 82.82 95.97 12 92.21 94.90 95.44 95.44
下載: 導出CSV
表 4 在數據集Fish-school上發掘因果關系的正確率(%)
窗口
寬度滑動
步長常規滑動窗 F界檢測法 轉折點法 差異平衡法 140 10 89.60 54.19 69.80 90.1 20 86.24 54.19 69.80 93.29 30 91.28 54.19 69.80 95.64 150 10 89.60 54.19 69.80 84.90 20 83.22 54.19 69.80 91.28 30 89.93 54.19 69.80 99.66 160 10 83.22 54.19 69.80 86.91 20 69.80 54.19 69.80 93.62 30 81.54 54.19 69.80 92.95
下載: 導出CSV
表 5 在數據集Baboon-troop上發掘因果關系的正確率(%)
窗口
寬度滑動
步長常規滑動窗 F界檢測法 轉折點法 差異平衡法 110 10 80.63 35.39 59.10 80.63 20 70.62 35.39 59.10 82.30 30 70.62 35.39 59.10 80.47 120 10 80.63 35.39 59.10 81.64 20 62.27 35.39 59.10 83.31 30 63.94 35.39 59.10 83.97 130 10 80.80 35.39 59.10 82.30 20 75.79 35.39 59.10 83.97 30 82.30 35.39 59.10 82.97
下載: 導出CSV
-
[1] XIE Feng, CAI Ruichu, ZENG Yan, et al. An efficient entropy-based causal discovery method for linear structural equation models with IID noise variables[J]. IEEE Transactions on Neural Networks and Learning Systems, 2020, 31(5): 1667–1680. doi: 10.1109/TNNLS.2019.2921613 [2] YANG Jing, GUO Xiaoxue, AN Ning, et al. Streaming feature-based causal structure learning algorithm with symmetrical uncertainty[J]. Information Sciences, 2018, 467: 708–724. doi: 10.1016/j.ins.2018.04.076 [3] 任偉杰, 韓敏. 多元時間序列因果關系分析研究綜述[J/OL]. 自動化學報, https://doi.org/10.16383/j.aas.c180189, 2019.REN Weijie and HAN Min. Survey on causality analysis of multivariate time series[J/OL]. Acta Automatica Sinica, https://doi.org/10.16383/j.aas.c180189, 2019. [4] HUANG Biwei, ZHANG Kun, GONG Mingming, et al. Causal discovery and forecasting in nonstationary environments with state-space models[C]. The 36th International Conference on Machine Learning, Long Beach, USA, 2019. [5] DU Sizhen, SONG Guojie, HAN Lei, et al. Temporal causal inference with time lag[J]. Neural Computation, 2018, 30(1): 271–291. doi: 10.1162/neco_a_01028 [6] GRANGER C W J. Investigating causal relations by econometric models and cross-spectral methods[J]. Econometrica, 1969, 37(3): 424–438. doi: 10.2307/1912791 [7] ORJUELA-CA?óN A D, CERQUERA A, FREUND J A, et al. Sleep apnea: Tracking effects of a first session of CPAP therapy by means of Granger causality[J]. Computer Methods and Programs in Biomedicine, 2020, 187: 105235. doi: 10.1016/j.cmpb.2019.105235 [8] 范立夫, 趙善學, 張永軍. 信貸結構和產業結構的相互影響研究——基于異質面板數據的格蘭杰因果檢驗[J]. 宏觀經濟研究, 2019(6): 73–82. doi: 10.16304/j.cnki.11-3952/f.2019.06.007FAN Lifu, ZHAO Shanxue, and ZHANG Yongjun. Research on the interaction between credit structure and industrial structure——Granger causality test based on heterogeneous panel data[J]. Scientific Management Research, 2019(6): 73–82. doi: 10.16304/j.cnki.11-3952/f.2019.06.007 [9] 李永立, 吳沖. 基于多變量的Granger因果檢驗方法[J]. 數理統計與管理, 2014, 33(1): 50–58. doi: 10.13860/j.cnki.sltj.2014.01.003LI Yongli and WU Chong. The Granger causality test method based on the multiple variables[J]. Journal of Applied Statistics and Management, 2014, 33(1): 50–58. doi: 10.13860/j.cnki.sltj.2014.01.003 [10] REN Weijie, LI Baisong, and HAN Min. A novel Granger causality method based on HSIC-Lasso for revealing nonlinear relationship between multivariate time series[J]. Physica A: Statistical Mechanics and its Applications, 2020, 541: 123245. doi: 10.1016/j.physa.2019.123245 [11] FINKLE J D, WU J J, and BAGHERI N. Windowed Granger causal inference strategy improves discovery of gene regulatory networks[J]. Proceedings of the National Academy of Sciences of the United States of America, 2018, 115(9): 2252–2257. doi: 10.1073/pnas.1710936115 [12] CHANG T, TSAI S L, and HAGA K Y A. Uncovering the interrelationship between the U. S. stock and housing markets: A bootstrap rolling window Granger causality approach[J]. Applied Economics, 2017, 49(58): 5841–5848. doi: 10.1080/00036846.2017.1346365 [13] LI Zhenhui, ZHENG Guanjie, AGARWAL A, et al. Discovery of causal time intervals[C]. 2017 SIAM International Conference on Data Mining, Houston, USA, 2017: 804–812. [14] MASNADI-SHIRAZI M, MAURYA M R, PAO G, et al. Time varying causal network reconstruction of a mouse cell cycle[J]. BMC Bioinformatics, 2019, 20: 294. doi: 10.1186/s12859-019-2895-1 [15] AMORNBUNCHORNVEJ C, ZHELEVA E, and BERGER-WOLF T Y. Variable-lag granger causality for time series analysis[C]. 2019 IEEE International Conference on Data Science and Advanced Analytics, Washington, USA, 2019. -
