基于深度生成對抗網絡的海雜波數據增強方法

丁斌; 夏雪; 梁雪峰

doi:10.11999/JEIT200447

基于深度生成對抗網絡的海雜波數據增強方法

doi: 10.11999/JEIT200447

丁斌^1, ,,
夏雪²,
梁雪峰^{1, 3}

1.
西安文理學院西安 710065
2.
西安石油大學 西安 710065
3.
西安電子科技大學 西安 710071

基金項目: 西安市科技計劃(2019KJWL30)

詳細信息

作者簡介:
丁斌：男，1980年生，博士，高級工程師，研究方向?yàn)橹悄苄畔⑻幚?、圖像解譯與智慧遙感

夏雪：女，1985年生，博士，研究方向?yàn)樾盘?hào)與信息處理

梁雪峰：男，1973年生，博士，教授，博士生導師，研究方向?yàn)橐曈X(jué)認知計算(心理學)、計算機視覺、視覺大數據挖掘、智能算法

通訊作者:
丁斌　xadb2005@163.com

中圖分類號: TN959.72; TP391
計量
- 文章訪問數: 2236
- HTML全文瀏覽量: 1350
- PDF下載量: 292
- 被引次數: 0
出版歷程
- 收稿日期: 2020-06-02
- 修回日期: 2021-02-27
- 網絡出版日期: 2021-03-04
- 刊出日期: 2021-07-10

Sea Clutter Data Augmentation Method Based on Deep Generative Adversarial Network

Bin DING^{1
, ,},
Xue XIA²,
Xuefeng LIANG^{1, 3}

1.
Xi’an University, Xi’an 710065, China
2.
Xi’an Shiyou University, Xi’an 710065, China
3.
Xidian University, Xi’an 710071, China

Funds: Xi’an Science and Technology Plan (2019KJWL30)

摘要

摘要: 海雜波數據稀缺，獲取海雜波數據成本高、周期長，極大地限制了海雜波特性研究及海洋遙感應用。該文主要研究了基于深度生成性對抗網絡(GAN)的海雜波數據生成方法，通過擴展傳統的GAN框架，形成了1維海雜波數據生成和鑒別模型，基于實測海雜波數據集，進行對抗網絡生成和鑒別模型訓練，分析了生成模型所生成的海雜波數據的幅度分布特性和時間、空間相關性?；趯?shí)測數據驗證了該方法能夠生成更多、更多樣、與真實海雜波數據分布相近的海雜波數據。
- 生成性對抗網絡 /
- 海雜波 /
- 幅度分布特性 /
- 時間相關性
Abstract: Due to the scarcity of sea clutter data, the high cost and long period of obtaining sea clutter data greatly limit the research of sea clutter characteristics and the application of ocean remote sensing. The method of sea clutter data generation based on the Generative Adversarial Networks (GAN) is studied. By extending the traditional GAN framework, a one-dimensional sea clutter data generation and identification model is formed. Based on the radar measured sea clutter data set, the generation and identification model training in the adversarial network is carried out. The amplitude distribution characteristics and time and spatial correlation of the sea clutter data generated by the model are analyzed. Based on the measured data, it is verified that the method can generate more sea clutter data with more variety, and similar distribution to the real sea clutter data.
- Generative Adversarial Networks(GAN) /
- Sea clutter /
- Amplitude distribution characteristics /
- Temporal correlation

HTML全文

圖 1 GAN結構示意圖

下載: 全尺寸圖片幻燈片

圖 2 海雜波數據對抗生成網絡結構

下載: 全尺寸圖片幻燈片

圖 3 單載頻發射信號，海雜波時域波形

下載: 全尺寸圖片幻燈片

圖 4 實測海雜波數據實部&生成海雜波數據實部

下載: 全尺寸圖片幻燈片

圖 5 實測海雜波數據虛部&生成海雜波數據虛部

下載: 全尺寸圖片幻燈片

圖 6 第100采樣點10000幀海雜波幅度

下載: 全尺寸圖片幻燈片

圖 7 生成海雜波數據(10000幀)雜波幅度圖

下載: 全尺寸圖片幻燈片

圖 8 第100采樣點10000幀海雜波幅度直方圖

下載: 全尺寸圖片幻燈片

圖 9 生成海雜波數據(10000幀)幅度直方圖

下載: 全尺寸圖片幻燈片

圖 10 直接生成回波幅度(模值)(10000幀)直方圖

下載: 全尺寸圖片幻燈片

圖 11 幅度分布擬合曲線

下載: 全尺寸圖片幻燈片

圖 12 實測海雜波數據&生成海雜波數據功率譜密度

下載: 全尺寸圖片幻燈片

圖 13 實測&生成海雜波數據時間相關系數

下載: 全尺寸圖片幻燈片

圖 14 實測海雜波&生成海雜波距離向第100采樣點處距離維空間相關系數

下載: 全尺寸圖片幻燈片

表 1 生成器、辨別器網絡參數

生成器網絡			判別器網絡
Layer	Act./Norm	Output shape	Layer	Act./Norm	Output shape
Fully Linear	ReLU		Conv1d	Leaky ReLU	64×2048
	BatchNorm1d	1×256	Conv1d	Leaky ReLU	128×512
Conv1d	ReLU	512×512	Conv1d	Leaky ReLU	256×128
Conv1d	ReLU	256×1024	Conv1d	Leaky ReLU	512×128
Conv1d	ReLU	128×1024	Conv1d	Leaky ReLU	1024×16
Conv1d	ReLU	64×4096	Fully Linear	sigmoid	1×1
Conv1d	Tanh	1×8192

下載: 導出CSV
