自適應調節濾波強度的SAR圖像非局部平均抑斑算法

朱磊; 李敬曼; 潘楊; 劉玉春; 胡曉

doi:10.11999/JEIT200099

自適應調節濾波強度的SAR圖像非局部平均抑斑算法

doi: 10.11999/JEIT200099

朱磊^1, ,,
李敬曼¹,
潘楊¹,
劉玉春^{1, 2},
胡曉¹

1.
西安工程大學電子信息學院西安 710048
2.
周口師范學院機械與電氣工程學院周口 466001

基金項目: 國家自然科學基金(61971339)，陜西省重點研發計劃(2019GY-113)，西安市科技局創新引導計劃(201805030YD8CG14(6))

詳細信息

作者簡介:
朱磊：男，1979年生，教授，碩士生導師，研究方向為圖像處理、嵌入式系統應用

李敬曼：女，1996年生，碩士生，研究方向為圖像處理

潘楊：女，1983年生，講師，研究方向為數字信號處理、聲場仿真與聲信號處理

劉玉春：男，1979年生，副教授，研究方向為信號與信號處理

胡曉：女，1993年生，碩士生，研究方向為圖像處理

通訊作者:
朱磊　zhulei791014@163.com

中圖分類號: TN911.73; TP751
計量
- 文章訪問數: 796
- HTML全文瀏覽量: 460
- PDF下載量: 101
- 被引次數: 0
出版歷程
- 收稿日期: 2020-02-11
- 修回日期: 2020-09-09
- 網絡出版日期: 2020-09-15
- 刊出日期: 2021-05-18

SAR Image Despeckling Algorithm Using Non-Local Means with Adaptive Filtering Strength

Lei ZHU^{1
, ,},
Jingman LI¹,
Yang PAN¹,
Yuchun LIU^{1, 2},
Xiao HU¹

1.
School of Electronics and Information, Xi’an Polytechnic University, Xi’an 710048, China
2.
School of Mechanical and Electrical Engineering, Zhoukou Normal University, Zhoukou 466001, China

Funds: The National Natural Science Foundation of China (61971339), The Shaanxi Provincial Key Research and Development Program (2019GY-113), The Xi’an Science and Technology Bureau Innovation and Guidance Program (201805030YD8CG14(6))

摘要

摘要: 為提升對SAR圖像乘性相干斑的抑制水平與邊緣保護性能，該文提出了一種可自適應調節濾波強度(AFS)的SAR圖像非局部平均(NLM)抑斑新算法(AFS-NLM)。該算法利用Frost濾波圖像計算的局部均值與方差來改善SAR圖像場景參量的估計，形成了一種能更好刻畫SAR圖像同質區與邊緣區的改進Kuan濾波系數。利用局部均值比與改進Kuan濾波系數分別作為新的相似性測量參量與自適應衰減因子，構建了一種更適應SAR圖像乘性噪聲特性的改進NLM濾波。利用偏平滑參數與偏邊緣保護參數控制下的改進NLM濾波，分別替代經典Kuan濾波模型中的像素局部均值與自身灰度值作為加權項，并采用由改進Kuan濾波系數構建的自適應調節因子對二者進行加權平均，從而形成了一種可自適應調節濾波強度的加權濾波新模型。實驗表明，該文算法與近期多種先進算法相比，具有更好的相干斑抑制與邊緣保護性能。
- SAR圖像 /
- 相干斑抑制 /
- 自適應濾波強度 /
- 非局部平均 /
- 改進Kuan濾波
Abstract: A new Non-Local Means (NLM) despeckling algorithm (AFS-NLM) with Adaptive Filtering Strength (AFS) is proposed to improve the performance of reducing multiplicative speckle and preserving the edges in SAR images. A modified Kuan filtering coefficient which can better characterize the homogeneous and edge regions of SAR image is formed by using the local mean and variance calculated in the Frost filtered image to improve the estimation of SAR image scene parameters. An improved NLM which adapts to the multiplicative noise characteristics is constructed by the new similarity measurement parameter estimated by the local mean ratio and the new adaptive decay factor estimated by the improved Kuan filtering coefficient. A new weighted filtering model which can automatically adjust the filtering strength is formed. In the new model, the improved NLM filters controlled by the skew smoothing parameters and the skew edge protection parameters are used to replace the local average value of pixels and the gray value of pixels in the classic Kuan filter model as weighting items, and the adaptive adjustment factor constructed by the improved Kuan filter coefficient is used to weight the two items. Experimental results and comparisons with several advanced despeckling algorithms in recent years show that the proposed algorithm has better speckle suppression and edge preservation performance.
- SAR image /
- Speckle suppression /
- Adaptive Filtering Strength (AFS) /
- Non-Local Means (NLM) /
- Improved Kuan filtering

HTML全文

圖 1 自適應調節NLM濾波強度的SAR圖像抑斑新模型框圖

下載: 全尺寸圖片幻燈片

圖 2 Kuan濾波系數與改進Kuan濾波系數對比

下載: 全尺寸圖片幻燈片

圖 3 兩種方法估計的NLM濾波加權系數圖對比

下載: 全尺寸圖片幻燈片

圖 4 實驗測試用真實SAR圖像

下載: 全尺寸圖片幻燈片

圖 5 各算法對圖4兩幅真實SAR圖像的抑斑圖及其邊緣檢測圖對比

下載: 全尺寸圖片幻燈片

表 1 4種算法對真實SAR圖像抑斑參數比較

抑斑算法	${V_{\rm{ENL}}}$				${V_{\rm{EPI}}}$
抑斑算法	A區	B區	C區	D區	圖4(a)	圖4(b)
SAR-BM3D	755.8	332.0	1610.8	1703.1	0.944	0.771
NL-CV	2070.0	788.9	1001.1	3171.9	0.449	0.400
MR-NLM	2485.4	826.1	1774.1	4100.1	0.958	0.780
AFS-NLM	5064.6	2312.8	3555.3	24115	0.963	0.824

下載: 導出CSV

參考文獻(23)

[1]	魏松杰, 蔣鵬飛, 袁秋壯, 等. 深度神經網絡下的SAR艦船目標檢測與區分模型[J]. 西北工業大學學報, 2019, 37(3): 587–593. doi: 10.1051/jnwpu/20193730587 WEI Songjie, JIANG Pengfei, YUAN Qiuzhuang, et al. Detection and recognition of SAR small ship objects using deep neural network[J]. Journal of Northwestern Polytechnical University, 2019, 37(3): 587–593. doi: 10.1051/jnwpu/20193730587
[2]	LIU Su, ZHANG Gong, and LIU Wenbo. Group sparse representation based dictionary learning for SAR image despeckling[J]. IEEE Access, 2019, 7: 30809–30817. doi: 10.1109/ACCESS.2019.2859825
[3]	李煜, 陳杰, 張淵智. 合成孔徑雷達海面溢油探測研究進展[J]. 電子與信息學報, 2019, 41(3): 751–762. doi: 10.11999/JEIT180468 LI Yu, CHEN Jie, and ZHANG Yuanzhi. Progress in research on marine oil spills detection using synthetic aperture radar[J]. Journal of Electronics &Information Technology, 2019, 41(3): 751–762. doi: 10.11999/JEIT180468
[4]	吳元. 一種基于參數更新的機載SAR圖像目標定位方法[J]. 電子與信息學報, 2019, 41(5): 1063–1068. doi: 10.11999/JEIT180564 WU Yuan. An airborne SAR image target location algorithm based on parameter refining[J]. Journal of Electronics &Information Technology, 2019, 41(5): 1063–1068. doi: 10.11999/JEIT180564
[5]	彭書娟, 曲長文, 李建偉, 等. 基于ROEWA算子局部活動輪廓的SAR圖像分割算法[J]. 系統工程與電子技術, 2019, 41(2): 280–290. doi: 10.3969/j.issn.1001-506X.2019.02.09 PENG Shujuan, QU Changwen, LI Jianwei, et al. Local motion contour segmentation algorithm of SAR image based on ROEWA operator[J]. Systems Engineering and Electronics, 2019, 41(2): 280–290. doi: 10.3969/j.issn.1001-506X.2019.02.09
[6]	韓子碩, 王春平. 基于改進FCM與MRF的SAR圖像分割[J]. 系統工程與電子技術, 2019, 41(8): 1726–1734. doi: 10.3969/j.issn.1001-506X.2019.08.08 HAN Zishuo and WANG Chunping. SAR image segmentation based on improved FCM and MRF[J]. Systems Engineering and Electronics, 2019, 41(8): 1726–1734. doi: 10.3969/j.issn.1001-506X.2019.08.08
[7]	YU Meiting, QUAN Sinong, KUANG Gangyao, et al. SAR target recognition via joint sparse and dense representation of monogenic signal[J]. Remote Sensing, 2019, 11(22): 2676. doi: 10.3390/rs11222676
[8]	LEE J S. Digital image enhancement and noise filtering by use of local statistics[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 1980, PAMI-2(2): 165–168. doi: 10.1109/TPAMI.1980.4766994
[9]	KUAN D T, SAWCHUK A A, STRAND T C, et al. Adaptive noise smoothing filter for images with signal-dependent noise[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 1985, PAMI-7(2): 165–177. doi: 10.1109/TPAMI.1985.4767641
[10]	MA Xiaoshuang and WU Penghai. Multitemporal SAR image despeckling based on a scattering covariance matrix of image patch[J]. Sensors, 2019, 19(14): 3057. doi: 10.3390/s19143057
[11]	BHUIYAN M I H, AHMAD M, and SWAMY M N S. Spatially adaptive wavelet-based method using the cauchy prior for denoising the SAR images[J]. IEEE Transactions on Circuits and Systems for Video Technology, 2007, 17(4): 500–507. doi: 10.1109/TCSVT.2006.888020
[12]	CHOI H and JEONG J. Speckle noise reduction technique for SAR images using statistical characteristics of speckle noise and discrete wavelet transform[J]. Remote Sensing, 2019, 11(10): 1184. doi: 10.3390/rs11101184
[13]	GAO Fei, XUE Xiangshang, SUN Jinping, et al. A SAR image despeckling method based on two-dimensional S transform shrinkage[J]. IEEE Transactions on Geoscience and Remote Sensing, 2016, 54(5): 3025–3034. doi: 10.1109/TGRS.2015.2510161
[14]	YU Yongjian and ACTON S T. Speckle reducing anisotropic diffusion[J]. IEEE Transactions on Image Processing, 2002, 11(11): 1260–1270. doi: 10.1109/TIP.2002.804276
[15]	ZHU Lei, ZHAO Xiaotian, and GU Meihua. SAR image despeckling using improved detail-preserving anisotropic diffusion[J]. Electronics Letters, 2014, 50(15): 1092–1093. doi: 10.1049/el.2014.0293
[16]	MISHRA D, CHAUDHURY S, SARKAR M, et al. Edge probability and pixel relativity-based speckle reducing anisotropic diffusion[J]. IEEE Transactions on Image Processing, 2018, 27(2): 649–664. doi: 10.1109/TIP.2017.2762590
[17]	BUADES A, COLL B, and MOREL J M. A non-local algorithm for image denoising[C]. 2005 IEEE Computer Society Conference on Computer Vision and Pattern Recognition, San Diego, USA, 2005: 60–65. doi: 10.1109/CVPR.2005.38.
[18]	PARRILLI S, PODERICO M, ANGELINO C V, et al. A nonlocal SAR image denoising algorithm based on LLMMSE wavelet shrinkage[J]. IEEE Transactions on Geoscience and Remote Sensing, 2012, 50(2): 606–616. doi: 10.1109/TGRS.2011.2161586
[19]	CHEN Shaobo, HOU Jianhua, ZHANG Hua, et al. De-speckling method based on non-local means and coefficient variation of SAR image[J]. Electronics Letters, 2014, 50(18): 1314–1316. doi: 10.1049/el.2014.0630
[20]	朱磊, 蔡飛飛, 王延年, 等. SAR圖像相干斑的非局部平均濾波算法[J]. 西安交通大學學報, 2018, 52(4): 98–104. doi: 10.7652/xjtuxb201804014 ZHU Lei, CAI Feifei, WANG Yannian, et al. A non-local means filtering algorithm for despeckling of SAR images[J]. Journal of Xi’an Jiaotong University, 2018, 52(4): 98–104. doi: 10.7652/xjtuxb201804014
[21]	FROST V S, STILES J A, SHANMUGAN K S, et al. A model for radar images and its application to adaptive digital filtering of multiplicative noise[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 1982, PAMI-4(2): 157–165. doi: 10.1109/TPAMI.1982.4767223
[22]	TOUZI R, LOPES A, and BOUSQUET P. A statistical and geometrical edge detector for SAR images[J]. IEEE Transactions on Geoscience and Remote Sensing, 1988, 26(6): 764–773. doi: 10.1109/36.7708
[23]	朱磊, 水鵬朗, 章為川, 等. 利用區域劃分的合成孔徑雷達圖像相干斑抑制算法[J]. 西安交通大學學報, 2012, 46(10): 83–88, 100. ZHU Lei, SHUI Penglang, ZHANG Weichuan, et al. A despeckling algorithm for synthetic aperture radar images using region subdivision[J]. Journal of Xi’an Jiaotong University, 2012, 46(10): 83–88, 100.
