面向時延與可靠性優化的服務功能鏈部署方法

翟東; 孟相如; 康巧燕; 胡航; 韓曉陽

doi:10.11999/JEIT200023

面向時延與可靠性優化的服務功能鏈部署方法

doi: 10.11999/JEIT200023

1.
空軍工程大學研究生院西安 710077
2.
空軍工程大學信息與導航學院西安 710077

基金項目: 國家自然科學基金(61871313, 61901509)，陜西省自然科學基金青年項目(2018JQ6042)

詳細信息

作者簡介:
翟東：男，1993年生，博士生，研究方向?yàn)榫W(wǎng)絡功能虛擬化

孟相如：男，1963年生，教授，博士生導師，研究方向?yàn)橄乱淮W(wǎng)絡、網絡安全

康巧燕：女，1980年生，副教授，研究方向?yàn)橄乱淮W(wǎng)絡

胡航：男，1989年生，講師，研究方向?yàn)檎J(rèn)知無線電、網絡安全

韓曉陽：男，1986年生，博士生，研究方向?yàn)橄乱淮W(wǎng)絡、網絡功能虛擬化

通訊作者:
翟東　zhaidongwzwdl@163.com

中圖分類號: TN915; TP393
計量
- 文章訪問數: 1338
- HTML全文瀏覽量: 789
- PDF下載量: 77
- 被引次數: 0
出版歷程
- 收稿日期: 2020-01-06
- 修回日期: 2020-08-23
- 網絡出版日期: 2020-09-03
- 刊出日期: 2020-10-13

Service Function Chain Deployment Method for Delay and Reliability Optimization

1.
Graduate School, Aire Force Engineering University, Xi’an 710077, China
2.
Information and Navigation College, Aire Force Engineering University, Xi’an 710077, China

Funds: The National Natural Science Foundation of China (61871313, 61901509), The Natural Science Foundation of Shaanxi Province (2018JQ6042)

摘要

摘要: 針對5G網絡高可靠性、低時延的服務需求，該文提出一種面向時延與可靠性優化的服務功能鏈(SFC)部署(DROSD)方法。在不預留冗余資源的情況下，首先通過功能互斥約束來確定SFC中相鄰虛擬網絡功能(VNF)是否可聚合；其次通過功能性約束、資源約束選擇可聚合物理節點集合，實現負載均衡，提高SFC可靠性；然后通過跳數約束進行優化，進一步篩選可聚合物理節點集合以降低SFC的端到端時延；最后通過節點可用資源、節點度以及與原節點跳數指標進行降序排列，取最大值物理節點部署VNF。SFC的路由選擇，采用K-最短路徑算法。仿真實驗表明，該文所提算法提高了請求接受率、長期平均收益開銷比，增強了SFC可靠性，降低了端到端時延，減小了平均帶寬開銷。
- 網絡功能虛擬化 /
- 服務功能鏈 /
- 虛擬網絡功能部署 /
- 可靠性 /
- 時延
Abstract: For the high reliability and low delay service requirements of 5G network, a Delay and Reliability Optimization of Service Function Chain (SFC) Deployment (DROSD) method is proposed. Without reservation of redundant resources, firstly, the function mutually exclusive constraints are used to determine whether the adjacent Virtual Network Function (VNF) in SFC can be combined; Secondly, functional constraints and resource constraints are used to select combinatorial physical node set to achieve load balancing and improve the reliability of SFC; Thirdly, the end-to-end delay of SFC is reduced by hop number constraints, and finally the VNF is deployed by the physical node with the maximum value, which is arranged in descending order through the available resources, node degree and hops from the original node. The routing of SFC adopts K-shortest path algorithm. The simulation results show that the proposed algorithm improves the request acceptance rate and the long-term average ratio of revenue to cost, enhances the reliability of SFC, reduces the end-to-end delay, and reduces the average bandwidth cost.
- Network function virtualization /
- Service Function Chain (SFC) /
- Virtual Network Function (VNF) deployment /
- Reliability /
- Delay

HTML全文

圖 1 系統場景

下載: 全尺寸圖片幻燈片

圖 2 聚合與未聚合狀態對比

下載: 全尺寸圖片幻燈片

圖 3 請求接受率

下載: 全尺寸圖片幻燈片

圖 4 長期平均收益開銷比

下載: 全尺寸圖片幻燈片

圖 5 平均可靠性

下載: 全尺寸圖片幻燈片

圖 6 平均時延

下載: 全尺寸圖片幻燈片

圖 7 平均帶寬開銷

下載: 全尺寸圖片幻燈片

表 1 算法1：DROSD算法VNF部署流程

輸入：${G^{\rm{s}}}$, $G_{\rm{v}}^g$
輸出：VNF_Embedding_List
對于$G_{\rm{v}}^g$中的${\rm{SF}}{{\rm{C}}_g}$，
(1) 獲取${\rm{SF}}{{\rm{C}}_g}$的VNF數目K
for k=1:K-1
利用深度優先，對可靠性進行優化，判斷相鄰VNF是否滿　　　足功能互斥約束
if $P_{k,k + 1}^g = 0$
對時延進行優化，利用算法2選取可部署物理節點集合　　　　${M_1}$, ${M_2}$
(2) 　　　　if ${M_1}{\rm{ = } }\varnothing$
部署失敗
else
if ${M_2}{\rm{ = } }\varnothing$
部署失敗
else
計算節點$Im$值，取最大值節點部署${f_k}$
end
end
else
對可靠性和時延進行優化，利用算法3選取可聚合物理節點集合$M_1'$, $M_2'$
if $M_1'{\rm{ = } }\varnothing$
聚合失敗
返回步驟(2)
else
if $M_2'{\rm{ = } }\varnothing$
聚合失敗
返回步驟(2)
else
計算節點$Im$值，取最大值節點部署${f_k}$, ${f_{k{\rm{ + }}1}}$
end
end
end

下載: 導出CSV

表 2 算法2：可部署物理節點選取流程

任意 ${f_k}$, ${w_i}$
for 未部署${\rm{SF}}{{\rm{C}}_g}$中VNF的所有物理節點$N_1^{\rm{s}}$
選擇滿足功能性約束的物理節點
if $F_n^{{f_k},{w_i}}{\rm{ = }}1$
選擇滿足資源約束的物理節點，實現負載均衡。
if $C_{n,{\rm{ava} } }^{\rm{s}} \ge C_{g,k}^{\rm{v}}{\rm{\& \& } }F_{n,{\rm{ava} } }^s \ge F_{g,k}^{\rm{v}}{\rm{\& \& } }{h_{ {S_1},n} } \le {h_0}$
$n \in {M_1}$
利用與目的節點的跳數約束進一步優化時延
if ${h_{ {S_1},{D_g} } } \ge {h_{n,{D_g} } }$
$n \in {M_2}$
end
end
end
end

下載: 導出CSV

表 3 算法3：可聚合物理節點選取流程

任意${f_k}$, ${w_i}$和${f_{k{\rm{ + }}1}},{w_j}$
for 未部署${\rm{SF}}{{\rm{C}}_g}$中VNF的所有物理節點$N_1^{\rm{s}}$
對可靠性進行優化，選擇滿足${f_k}$，${f_{k{\rm{ + }}1}}$功能性約束的物理節點
if $F_n^{{f_k},{w_i}}{\rm{ = }}1{\rm{\& \& }}F_n^{{f_{k{\rm{ + }}1}},{w_j}}{\rm{ = }}1$
選擇滿足資源約束的物理節點，實現負載均衡。
if $C_{n,{\rm{ava} } }^{\rm{s} } \ge (C_{g,k}^{\rm{v} } \!+\! C_{g,k{\rm{ + } }1}^{\rm{v} }){\rm{\& \& } }F_{n,{\rm{ava} } }^{\rm{s} } \ge (F_{g,k}^{\rm{v}} \!+\! F_{g,k + 1}^{\rm{v} }){\rm{\& \& } }$ 　$ {h_{ {S_1},n} } \le {h_1} $
$n \in M_1'$
利用與目的節點的跳數約束進一步優化時延
if ${h_{ {S_1},D} } \ge {h_{n,D} }$
$n \in M_2'$
end
end
end
end

下載: 導出CSV

表 4 算法描述

算法名稱	部署準則
DROSD	本文所提算法，VNF部署：依據功能互斥約束、功能性約束、跳數約束、資源約束，聚合VNF；路由選擇：k-最短路徑。
NLRE	文獻[11]所提算法，VNF部署：根據節點位置、可靠性采用PageRank思想排序，進行相應部署；路由選擇：k-最短路徑。
QARE	文獻[14]所提算法，VNF部署：根據節點隊列信息排序，部署VNF；路由選擇：選擇可靠性最高鏈路。

下載: 導出CSV

參考文獻(15)

QI Dandan, SHEN Subin, WANG Guanghui, et al. Towards an efficient VNF placement in network function virtualization[J]. Computer Communications, 2019, 138: 81–89. doi: 10.1016/j.comcom.2019.03.005

YI Bo, WANG Xingwei, LI Keqin, et al. A comprehensive survey of network function virtualization[J]. Computer Networks, 2018, 133: 212–262. doi: 10.1016/j.comnet.2018.01.021

MIAO Wang, MIN Geyong, WU Yulei, et al. Stochastic performance analysis of network function virtualization in future internet[J]. IEEE Journal on Selected Areas in Communications, 2019, 37(3): 613–626. doi: 10.1109/JSAC.2019.2894304

SUN Gang, LIAO Dan, ZHAO Dongcheng, et al. Towards provisioning hybrid virtual networks in federated cloud data centers[J]. Future Generation Computer Systems, 2018, 87: 457–469. doi: 10.1016/j.future.2017.09.065

湯紅波, 邱航, 游偉, 等. 基于聯合備份的服務功能鏈可靠性保障的部署方法[J]. 電子與信息學報, 2019, 41(12): 3006–3013. doi: 10.11999/JEIT190013

TANG Hongbo, QIU Hang, YOU Wei, et al. A reliability-guarantee method for service function chain deployment based on joint backup[J]. Journal of Electronics &Information Technology, 2019, 41(12): 3006–3013. doi: 10.11999/JEIT190013

SUN Gang, CHEN Zhenrong, YU Hongfang, et al. Online parallelized service function chain orchestration in data center networks[J]. IEEE Access, 2019, 7: 100147–100161. doi: 10.1109/ACCESS.2019.2930295

唐倫, 楊恒, 馬潤琳, 等. 基于5G接入網絡的多優先級虛擬網絡功能遷移開銷與網絡能耗聯合優化算法[J]. 電子與信息學報, 2019, 41(9): 2079–2086. doi: 10.11999/JEIT180906

TANG Lun, YANG Heng, MA Runlin, et al. Multi-priority based joint optimization algorithm of virtual network function migration cost and network energy consumption[J]. Journal of Electronics &Information Technology, 2019, 41(9): 2079–2086. doi: 10.11999/JEIT180906

CHENG Xiangle, WU Yulei, Min Geyong, et al. Network function virtualization in dynamic networks: A stochastic perspective[J]. IEEE Journal on Selected Areas in Communications, 2018, 36(10): 2218–2232. doi: 10.1109/JSAC.2018.2869958

ERAMO V, MIUCCI E, AMMAR M, et al. An approach for service function chain routing and virtual function network instance migration in network function virtualization architectures[J]. IEEE/ACM Transactions on Networking, 2017, 25(4): 2008–2025. doi: 10.1109/TNET.2017.2668470

RAAYATPANAH M A and WEISE T. Virtual network function placement for service function chaining with minimum energy consumption[C]. 2018 IEEE International Conference on Computer and Communication Engineering Technology (CCET), Beijing, China, 2018: 198–202.

唐倫, 趙培培, 趙國繁, 等. 基于QoS保障的服務功能鏈動態部署算法[J]. 北京郵電大學學報, 2018, 41(6): 90–96. doi: 10.13190/j.jbupt.2018-013

TANG Lun, ZHAO Peipei, ZHAO Guofan, et al. Dynamic deployment algorithm for service function chaining with QoS guarantee[J]. Journal of Beijing University of Posts and Telecommunications, 2018, 41(6): 90–96. doi: 10.13190/j.jbupt.2018-013

HERKER S, AN Xueli, KIESS W, et al. Data-center architecture impacts on virtualized network functions service chain embedding with high availability requirements[C]. 2015 IEEE Globecom Workshops (GC Wkshps), San Diego, USA, 2015: 1–7.

QU Long, KHABBAZ M, and ASSI C. Reliability-aware service chaining in carrier-grade softwarized networks[J]. IEEE Journal on Selected Areas in Communications, 2018, 36(3): 558–573. doi: 10.1109/JSAC.2018.2815338

TANG Lun, ZHAO Guofan, WANG Chenmeng, et al. Queue-aware reliable embedding algorithm for 5G network slicing[J]. Computer Networks, 2018, 146: 138–150. doi: 10.1016/j.comnet.2018.09.014

ZHAO Dongcheng, REN Jing, LIN Rongping, et al. On orchestrating service function Chains in 5G mobile network[J]. IEEE Access, 2019, 7: 39402–39416. doi: 10.1109/ACCESS.2019.2895316
