全負載蜂窩網絡下多復用D2D通信功率分配算法研究

錢志鴻; 蒙武杰; 王雪; 胡良帥; 王鑫

doi:10.11999/JEIT190974

全負載蜂窩網絡下多復用D2D通信功率分配算法研究

doi: 10.11999/JEIT190974

吉林大學通信工程學院長春 130012

基金項目: 國家自然科學基金(61771219)，吉林大學基礎科研項目(SXGJQY2017-9，2017TD-19)

詳細信息

作者簡介:
錢志鴻：男，1957年生，教授，研究方向?yàn)闊o線網絡通信技術，包括藍牙，RFID，M2M，D2D，無線傳感器網絡及物聯網等

蒙武杰：男，1995年生，碩士生，研究方向?yàn)镈2D通信技術

王雪：女，1984年生，副教授，研究方向?yàn)?G通信中的關鍵技術，包括D2D通信的模式選擇、同步技術，以及物聯網技術

胡良帥：男，1995年生，碩士生，研究方向?yàn)镈2D通信技術

王鑫：女，1982年生，博士生，研究方向?yàn)镈2D通信技術與物聯網

通訊作者:
王雪　jluwangxue@163.com

中圖分類號: TN929.5
計量
- 文章訪問數: 1969
- HTML全文瀏覽量: 534
- PDF下載量: 96
- 被引次數: 0
出版歷程
- 收稿日期: 2019-12-03
- 修回日期: 2020-05-22
- 網絡出版日期: 2020-07-14
- 刊出日期: 2020-12-08

Research on Power Allocation Algorithm of Multi-to-One Multiplexing D2D Communication Underlaying Full Load Cellular Networks

College of Communication Engineering, Jilin University, Changchun 130012, China

Funds: The National Natural Science Foundation of China (61771219), The Fundamental Research of Jilin University (SXGJQY2017-9, 2017TD-19)

摘要

摘要:
針對全負載蜂窩網絡中D2D通信的功率分配問題，該文提出了一種基于非合作完全信息博弈納什均衡解的多復用D2D通信功率分配算法。以優先保證蜂窩用戶通信質量與D2D用戶接入率為前提，設置D2D通信系統上行鏈路幀結構，之后建立非合作完全信息博弈系統模型，引入定價機制到功率分配博弈模型中并分析納什均衡解的存在性與唯一性，最后給出該模型的分布式迭代求解算法。仿真結果表明，隨著D2D用戶復用數量的增加，該算法在提升系統吞吐量的同時，能有效地控制系統內部干擾，大幅度降低系統總能耗。
- 無線通信 /
- D2D通信 /
- 功率分配 /
- 博弈論
Abstract:
Considering power allocation of D2D (Device to Device) communication in fully loaded cellular networks, a multi-to-one multiplexing D2D communication power allocation algorithm based on the Nash equilibrium solution of non-cooperative complete information game is proposed. The communication quality of cellular users and the access rate of D2D users are guaranteed first, and the uplink frame structure of D2D communication system is given. Then, the non-cooperative complete information game model is established. After that, the pricing mechanism is introduced into the power distribution game model, and the existence and uniqueness of the Nash equilibrium solution are analyzed. Finally, the paper gives a distributed iterative algorithm for the model. The simulation results show that with the increase of the number of D2D pairs, the algorithm not only improves the system throughput, but also controls the internal interference of the system effectively, reduces the total energy consumption of the system greatly.
- Wireless communications /
- D2D communications /
- Power distribution /
- Game theory

HTML全文

圖 1 系統模型

下載: 全尺寸圖片幻燈片

圖 2 系統通信幀結構

下載: 全尺寸圖片幻燈片

圖 3 不同復用模式下系統總功率

下載: 全尺寸圖片幻燈片

圖 4 不同復用模式下D2D通信系統吞吐量

下載: 全尺寸圖片幻燈片

圖 5 不同復用模式下D2D通信系統吞吐量累積分布函數

下載: 全尺寸圖片幻燈片

圖 6 $n = 7$時D2D通信系統吞吐量CDF對比曲線

下載: 全尺寸圖片幻燈片

表 1 多復用D2D通信功率分配算法

算法1：功率分配算法
輸入：$S_{{\rm{max}}}^{D_q},\;\lambda _j^D,\;\varepsilon ,\;\alpha ,\;\chi ,\;{N_0},\;{{{Z}}_{p,q}},\;{{{Y}}_{p,q}}$
輸出：$S_1^{D_q},\;S_2^{D_q},\;S_3^{D_q},\; ··· ,\;S_q^{D_q},\;{ {{T} }_{{\rm{sum}}} }$
(1) for $i = 1$ to $p$ do
(2)　　calculate ${{{Y}}_{i,i}} = S_i^{C_p}$
(3)　if $S_i^{C_p} \ge S_{\max }^{C_p}$ then $S_i^{C_p} = S_{\max }^{C_p}$
(4)　end for
(5) $t = 0 , {\xi _{i,j}} = 1 , S_j^{D_q}(0) = S_{\max }^{D_q}$
(6) for $i = 1$ to $p$ do
(7)　for $j = 1$ to $n$ do
(8)　　　$t = t + 1$ 　(9)　$S_j^{D_q}(t) = \frac{B}{ {\lambda _j^D\ln 2} } - \dfrac{ {\mu \left[ {\sigma _N^2 \!+\! \displaystyle\sum\limits_{k = 1,k \ne j}^n { {\xi _{i,j} }S_k^{D_q}(t \!-\! 1){H_{j,k} } } } \right]} }{ { {g_j} } }$
(10)　　if $S_j^{D_q}(t) < S_{\min }^{D_q}$ then $S_j^{D_q}(t) = S_{\min }^{D_q}$
(11)　　if $S_j^{D_q}(t) > S_{\max }^{D_q}$ then $S_j^{D_q}(t) = S_{{\rm{max}}}^{D_q}$
(12)　end for
(13)　if $\left\| {S_j^{D_q}(t) - S_j^{D_q}(t - 1)} \right\| < \varepsilon ,j \in \left[ {1,n} \right]$ then
(14)　　calculate ${ {{Z} }_{i,j} } , { {{T} }_{{\rm{sum}}} }$
(15)　else go to step (8)
(16) end for

下載: 導出CSV

表 2 仿真參數

參數	數值
小區半徑	1000 m
路徑損耗常數($\alpha $)	0.01
路徑損耗指數($\chi $)	4
${N_0}$	–114 dBm/Hz
蜂窩用戶最大發射功率	48 dBm
D2D用戶的最大發射功率	24 dBm
系統帶寬	180 kHz
多徑衰落	單位均值的指數分布
陰影衰落	均值為0，標準差為8的正態分布
蜂窩用戶數	20
D2D用戶對數量	60～140
D2D用戶之間最大距離	50 m
系統誤碼率BER	${10^{ - 4}}$

下載: 導出CSV

參考文獻(13)

DOPPLER K, RINNE M, WIJTING C, et al. Device-to-device communication as an underlay to LTE-advanced networks[J]. IEEE Communications Magazine, 2009, 47(12): 42–49. doi: 10.1109/MCOM.2009.5350367

錢志鴻, 王雪. 面向5G通信網的D2D技術綜述[J]. 通信學報, 2016, 37(7): 1–14. doi: 10.11959/j.issn.1000-436x.2016129

QIAN Zhihong and WANG Xue. Reviews of D2D technology for 5G communication networks[J]. Journal on Communications, 2016, 37(7): 1–14. doi: 10.11959/j.issn.1000-436x.2016129

代海波, 陸忞, 黃永明, 等. D2D通信系統中節能功率控制算法[J]. 電子與信息學報, 2017, 39(4): 997–1001. doi: 10.11999/JEIT160553

DAI Haibo, LU Wen, HUANG Yongming, et al. Energy-efficient power control algorithm for D2D communication[J]. Journal of Electronics &Information Technology, 2017, 39(4): 997–1001. doi: 10.11999/JEIT160553

錢志鴻, 田春生, 王鑫, 等. D2D網絡中信道選擇與功率控制策略研究[J]. 電子與信息學報, 2019, 41(10): 2287–2293. doi: 10.11999/JEIT190149

QIAN Zhihong, TIAN Chunsheng, WANG Xin, et al. Research on channel selection and power control strategy for D2D networks[J]. Journal of Electronics &Information Technology, 2019, 41(10): 2287–2293. doi: 10.11999/JEIT190149

AHMAD M, AZAM M, NAEEM M, et al. Resource management in D2D communication: An optimization perspective[J]. Journal of Network and Computer Applications, 2017, 93: 51–75. doi: 10.1016/j.jnca.2017.03.017

NGUYEN H H, HASEGAWA M, and HWANG W J. Distributed resource allocation for D2D communications underlay cellular networks[J]. IEEE Communications Letters, 2016, 20(5): 942–945. doi: 10.1109/LCOMM.2015.2498925

FENG Daquan, LU Lu, YUAN-WU Y, et al. Device-to-Device communications underlaying cellular networks[J]. IEEE Transactions on Communications, 2013, 61(8): 3541–3551. doi: 10.1109/TCOMM.2013.071013.120787

ZHOU Hao, JI Yusheng, LI Jie, et al. Joint mode selection, MCS assignment, resource allocation and power control for D2D communication underlaying cellular networks[C]. 2014 IEEE Wireless Communications and Networking Conference (WCNC), Istanbul, Turkey, 2014: 1667–1672. doi: 10.1109/WCNC.2014.6952480.

YIN Rui, ZHONG Caijun, YU Guanding, et al. Joint spectrum and power allocation for D2D communications underlaying cellular networks[J]. IEEE Transactions on Vehicular Technology, 2016, 65(4): 2182–2195. doi: 10.1109/TVT.2015.2424395

ZHANG Lin, XIAO Ming, WU Gang, et al. Efficient scheduling and power allocation for D2D-assisted wireless caching networks[J]. IEEE Transactions on Communications, 2016, 64(6): 2438–2452. doi: 10.1109/TCOMM.2016.2552164

PARK S, CHOI S, and LEE B G. Game theory-based power allocation strategy for D2D communication in multi-cell environment[C]. 2015 International Conference on Information and Communication Technology Convergence (ICTC), Jeju, South Korea, 2015: 356–359.

錢志鴻, 閻雙葉, 田春生, 等. LTE-A網絡中D2D通信的資源分配算法研究[J]. 電子與信息學報, 2018, 40(10): 2287–2293. doi: 10.11999/JEIT180043

QIAN Zhihong, YAN Shuangye, TIAN Chunsheng, et al. Research on resource allocation algorithm for D2D communications underlaying LTE-A networks[J]. Journal of Electronics &Information Technology, 2018, 40(10): 2287–2293. doi: 10.11999/JEIT180043

LUO Xiantian, LI Hui, BAI Yaorong, et al. Research on power allocation algorithm in non-orthogonal multiple access systems[C]. 2019 14th IEEE Conference on Industrial Electronics and Applications (ICIEA), Xi'an, China, 2019: 1084–1089. doi: 10.1109/ICIEA.2019.8834152.
