基于信令數據的軌跡駐留點識別算法研究
doi: 10.11999/JEIT190914
-
1.
重慶郵電大學通信與信息工程學院 重慶 400065
-
2.
重慶郵電大學電子信息與網絡工程研究院 重慶 400065
基金項目: 重慶市自然科學基金 (cstc2018jcyjAX0587)，新型感知技術、信息融合處理及其應用(A2017-10)
Research of Track Resident Point Identification Algorithm Based on Signaling Data
-
1.
Institute of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
-
2.
Electronic Information and Networking Research Institute, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
Funds: The Natural Science Foundation of Chongqing (cstc2018jcyjAX0587), The New Sensing Technology, Information Fusion Processing and its Application (A2017-10)
-
摘要: 針對密度聚類算法只能識別密度相近的簇類且計算復雜度高等問題，該文提出一種基于信令數據中時空軌跡信息的密度峰值快速聚類(ST-CFSFDP)算法。首先對低采樣密度的信令數據進行預處理，消除軌跡震蕩現象；然后基于密度峰值快速聚類(CFSFDP)算法顯式地增加時間維度限制，將局部密度由2維擴展到3維，并提出高密度時間間隔以表征簇中心在時間維度上的數據特征；接著設計篩選策略以選取聚類中心；最后識別用戶出行軌跡中的駐留點，完成出行鏈的劃分。實驗結果表明，所提算法適用于采樣密度低且定位精度差的信令數據，相比CFSFDP算法更適用于時空數據，相比基于密度的時空聚類算法(ST-DBSCAN)召回率提升14%，準確率提升8%，同時降低計算復雜度。
-
關鍵詞:
- 信令數據 /
- 時空聚類 /
- 密度峰值快速聚類算法 /
- 駐留點識別 /
- 出行鏈
Abstract: For the problem that the density-based clustering algorithm can only identify clusters with similar density and high computational complexity, a Clustering by Fast Search and Find of Density Peaks based on Spatio-Temporal trajectory information in mobile phone signaling data, namely ST-CFSFDP, is proposed. Firstly, the low sampling density signaling data are pre-processed to eliminate the trajectory oscillation phenomenon in the data. Then, based on the Clustering by Fast Search and Find of Density Peaks(CFSFDP) algorithm, the time dimension limitation is explicitly increased, and the local density is extended from two-dimension to three-dimension. Moreover, in order to characterize the cluster center point in the time dimension, the concept of high-density time interval is defined. Secondly, the suitable cluster center screening strategy is developed to select automatically the appropriate cluster center. Finally, the resident points are identified in the travel trajectory of individual users over a period of time and the division of the travel chains is completed. The experimental results show that the algorithm is suitable for signaling data with low sampling density and poor positioning accuracy. It is more suitable for spatio-temporal data than CFSFDP algorithm. Compared with Density-Based Spatial Clustering of Applications with Noise based on Spatio-Temporal data (ST-DBSCAN) algorithm, the recall rate is improved by 14%, the accuracy rate is increased by 8%, and the computational complexity is also reduced. -
表 1 信令數據主要字段
字段名稱 字段解釋 字段內容(示例) user ID 用戶身份 0001A LAC_CID 基站位置區域碼與小區識別碼 13119-2056 TimeStamp 用戶接入時間戳 2019-10-23 17:42:09 CoverScene 當前基站的覆蓋場景 道路/學校/火車站等 Lon_Lat 當前基站經度、緯度 (106.59767, 29.40709)
下載: 導出CSV
表 2 震蕩軌跡數據示例
軌跡 位置 時間 距離 (km) 切換速度 (km/h) ${D_0}$ ${L_0}$(106.607617, 29.530807) 08:19:35 / / ${D_1}$ ${L_1}$(106.602659, 29.545336) 08:20:14 1.6 147.6923 ${D_2}$ ${L_2}$(106.607617, 29.530807) 08:20:39 1.6 230.4000
下載: 導出CSV
表 3 基于時間窗的震蕩軌跡檢測方法
輸入：原始軌跡數據${{L} } = \left\{ { {L_1}{\rm{ } }···{\rm{ } }{L_i}{\rm{ } }{L_{i + 1} }{\rm{ } }···{\rm{ } }{L_{i + {N_w} } }{\rm{ } }···} \right\}$，軌跡序列切片中基站位置個數${N_w}$，震蕩數據最大時間閾值${T_{w\_\max }}$； 輸出：檢測到的震蕩軌跡數據${L_{\rm{osc}}}$； (1) 按順序截取原始數據${{L}}$中的前${N_w}$個位置組成序列${L_w}$； (2) 檢測${L_w}$中是否出現循環模式，如果出現則執行步驟(3)，否則序列點向前移1位，重新執行步驟(1)，截取后續${N_w}$個位置的序列片段； (3) 對檢測到的震蕩部分記為(${L_{\rm{beg} } }{\rm{ } }···{\rm{ } }{L_{\rm{end} } }$)，判斷該部分序列的總時間是否小于${T_{w\_\max }}$，如果滿足，那么將該震蕩序列記為${L_{\rm{osc}}}$，同時序
列點向前移1位，返回步驟(1)；如果不滿足，直接返回步驟(1)，直至遍歷完${{L}}$內所有軌跡點。算法結束
下載: 導出CSV
表 4 ST-CFSFDP聚類算法
輸入：原始空間數據$P\left\langle {x\;y\;t\;d} \right\rangle $；截?cái)嗑嚯x${d_{\rm c}}$；截?cái)鄷r(shí)間${t_{\rm c}}$；數據點覆蓋場景的描述$d$ 輸出：該原始數據的聚類集合${C_k}$, $k = 1,2, ··· ,n$； (1) 計算每一個數據點的局部時空密度${\rho _i}$； (2) 依照定義4與定義5計算每個數據點的高密度空間距離${\delta _i}$、高密度時間間隔${\tau _i}$； (3) 計算各個數據點的聚類中心權值，將聚類中心權值的平均值作為閾值，將大于該閾值的數據點放入聚類中心候選點集合${C_{\rm c}}$中； (4) 合并候選點中覆蓋場景相同且空間距離小于${d_{\rm c}}$或時間間隔小于${t_{\rm c}}$的“近鄰數據點”，保留聚類中心權重較高的點； (5) 將剩余的數據點，按照最近鄰思想分配到各個聚類中心所代表的簇中。 算法結束
下載: 導出CSV
表 5 算法距離誤差對比
編號 駐留點坐標(Lon, Lat) CFSFDP算法的距離誤差 ST-DBSCAN算法的距離誤差 ST-CFSFDP算法的距離誤差 1 106.601230, 29.5339600 44.8 42.2 34.6 2 106.602061, 29.5343564 \ 43.5 48.3 3 106.496737, 29.6166844 48.8 35.3 37.4 4 106.496729, 29.6166840 \ \ 50.6 5 106.546322, 29.6203120 52.6 \ 46.4
下載: 導出CSV
-
