分?jǐn)?shù)階憶阻退化Jerk系統的特性分析與DSP實現
doi: 10.11999/JEIT190904
-
中南大學物理與電子學院 長沙 410006
Characteristics Analysis and DSP Implementation of Fractional-order Memristive Hypogenetic Jerk System
-
School of Physics and Electronics, Central South University, Changsha 410006, China
-
摘要: 為了探究分?jǐn)?shù)階形式下該類系統的動力學特性,該文將分?jǐn)?shù)階微積分引入到憶阻退化Jerk系統中,增加了一個自由度,提升了系統性能。通過相圖、分岔圖、李雅普諾夫指數譜、復雜度混沌圖等分析了系統的動力學特性,并采用DSP技術,實現了該系統的數字電路。研究結果表明,系統拓展到分?jǐn)?shù)階后有兩種不同的單渦卷吸引子,系統隨初值變化呈現倍周期分岔路徑,在某些特定初值處系統演化路徑出現躍變。系統具有無限多個吸引子共存。
-
關鍵詞:
- 憶阻器 /
- 混沌 /
- 分?jǐn)?shù)階微積分 /
- 吸引子共存 /
- 多穩態
Abstract: To investigate the dynamic characteristics of this type of system in the fractional-order case, fractional-order calculus is introduced into memristive hypogenetic Jerk system, which adds one degree of freedom and improves system performance. The dynamical characteristics of the system are analyzed by phase diagram, bifurcation diagram, Lyapunov exponent spectrum, complexity chaotic diagram, etc., and the digital circuit of the system is realized by employing DSP technology. The research results show that when the system is extended to the fractional order, the system presents a period doubling bifurcation path with the initial value, and the evolution path of the system changes abruptly at some specific initial values, showing infinite coexistence of attractors.-
Key words:
- Memristor /
- Chaos /
- Fractional calculus /
- Coexistence attractors /
- Multistability
-
