簡潔無電感憶阻混沌電路及其特性

曾以成; 成德武; 譚其威

doi:10.11999/JEIT190859

簡潔無電感憶阻混沌電路及其特性

doi: 10.11999/JEIT190859

湘潭大學物理與光電工程學院湘潭 411105

基金項目: 國家自然科學基金(61471310)

詳細信息

作者簡介:
曾以成：男，1962年生，教授，博士生導師，主要研究方向?yàn)榉蔷€(xiàn)性電路、混沌信號處理、語音信號處理

成德武：男，1994年生，碩士生，研究方向?yàn)榉蔷€(xiàn)性系統、混沌信號處理

譚其威：女，1993年生，碩士，研究方向?yàn)榉蔷€(xiàn)性系統、混沌信號處理

通訊作者:
曾以成　yichengz@xtu.edu.cn

中圖分類號: TN601
計量
- 文章訪問數: 2374
- HTML全文瀏覽量: 876
- PDF下載量: 135
- 被引次數: 0
出版歷程
- 收稿日期: 2019-11-01
- 修回日期: 2019-11-26
- 網絡出版日期: 2019-12-20
- 刊出日期: 2020-06-04

A Simple Inductor-free Memristive Chaotic Circuit and Its Characteristics

School of Physics and Photoelectric Engineering, Xiangtan University, Xiangtan, 411105, China

Funds: The National Natural Science Foundation of China (61471310)

摘要

摘要: 采用非理想有源電壓控制憶阻器和磁通控制型光滑3次非線性憶阻器，該文設計了一種不含電感的簡單(只含5個電子元器件)雙憶阻混沌電路。采用常規的非線性分析手段詳細研究了電路參數變化時系統的基本動力學行為，例如平衡點穩定性分析，相軌圖以及李雅普諾夫指數譜和分岔圖等。通過調節系統控制參數，該系統可產生多渦卷、多翼以及暫態混沌等十分豐富的動力學現象。此外，還研究了系統依賴于憶阻器初始狀態的多穩態，得到了一些有意義的結果。為驗證電路的可行性及穩定性，通過對憶阻器的模擬等效電路的搭建，并將該等效電路應用于所提出的混沌電路中，硬件電路實驗結果以及Multisim電路仿真結果與理論分析一致。
- 憶阻器 /
- 混沌電路 /
- 多穩態 /
- 暫態混沌
Abstract: A simple two-memristor chaotic circuit without inductance (only five electronic components) is designed by using a non-ideal active voltage control memristor and a flux-controlled smooth cubic nonlinear memristor. When the circuit parameters change, the basic dynamic behaviors of the system are studied in detail by the means of conventional nonlinear analysis, such as the analysis of equilibrium stability, phase diagram, Lyapunov exponent spectrum and bifurcation diagram. With the parameters changing, the proposed system can produce various phenomena of dynamics such as multi-scrolls, multi-wings and transient transition behaviors. Furthermore, the multistability characteristics of the system are also studied in the condition of changing the initial state of two memristors in system respectively, and some meaningful results are obtained. In order to verify the feasibility and stability of the circuit, the analog equivalent circuit of each memristor is constructed, and it is applied to the proposed chaotic circuit. The experimental results of the hardware circuit and the circuit simulation results of the Multisim are in good agreement with the theoretical analysis.
- Memristor /
- Chaotic circuit /
- Multistability /
- Transient transition behaviors

HTML全文

圖 1 無電感雙憶阻型混沌電路

下載: 全尺寸圖片幻燈片

圖 2 憶阻器W₃等效電路

下載: 全尺寸圖片幻燈片

圖 3 憶阻器W₄等效電路

下載: 全尺寸圖片幻燈片

圖 4 系統隨c變化時李雅普諾夫指數譜和分岔圖

下載: 全尺寸圖片幻燈片

圖 5 隨參數c變化的z-w相圖

下載: 全尺寸圖片幻燈片

圖 6 暫態混沌現象

下載: 全尺寸圖片幻燈片

圖 7 系統隨初始值w(0)變化時李雅普諾夫指數譜和分岔圖

下載: 全尺寸圖片幻燈片

圖 8 憶阻器W₄隨初始值w(0)變化的x-w相圖

下載: 全尺寸圖片幻燈片

圖 9 Multisim仿真電路原理圖

下載: 全尺寸圖片幻燈片

圖 10 Multisim仿真結果與硬件等效電路結果比較

下載: 全尺寸圖片幻燈片

表 1 憶阻器W₃隨初始狀態變化所產生的多穩態舉例

z(0)取值	LE李雅普諾夫指數	系統狀態
4.0	(+, 0, –, –)	2翼混沌吸引子
6.5	(+, 0, –, –)	4翼混沌吸引子
13.5	(+, 0, –, –)	6翼混沌吸引子
17.5	(+, 0, –, –)	8翼混沌吸引子

下載: 導出CSV

表 2 簡潔無電感憶阻混沌電路的參數取值

參數	名稱	參值
$ {C_a},{C_1},{C_3}$	電容	1 nF
C₂	電容	25 nF
$ {g_a},{\rm{ }}{g_b},{\rm{ }}{g_{3,}}{g_4}$	增益	1
$ {g_1},{\rm{ }}{g_2}$	增益	0.1
R₁	電阻	0.25 kΩ
R₂	電阻	50.00 kΩ
R₃	電阻	25.00 kΩ
$ {R_4},{\rm{ }}{R_c}$	電阻	10.00 kΩ
R_b	電阻	16.70 kΩ
$ {R_d},{R_e}_,{R_5}{,}{R_6}$	電阻	2.00 kΩ

下載: 導出CSV

參考文獻(26)

鄭利京, 王光義, 張娜. 基于憶阻器的混合CMOS乘法器設計[J]. 杭州電子科技大學學報: 自然科學版, 2019, 39(2): 1–5. doi: 10.13954/j.cnki.hdu.2019.02.001

ZHENG Lijing, WANG Guangyi, and ZHANG Na. A multiplier design based on hybrid memristor-CMOS[J]. Journal of Hangzhou Dianzi University:Natural Sciences, 2019, 39(2): 1–5. doi: 10.13954/j.cnki.hdu.2019.02.001

WANG Xingyuan and ZHANG Huili. A novel image encryption algorithm based on genetic recombination and hyper-chaotic systems[J]. Nonlinear Dynamics, 2016, 83(1/2): 333–346. doi: 10.1007/s11071-015-2330-8

DUAN Shukai, HU Xiaofang, DONG Zhekang, et al. Memristor-based cellular nonlinear/neural network: Design, analysis, and applications[J]. IEEE Transactions on Neural Networks and Learning Systems, 2015, 26(6): 1202–1213. doi: 10.1109/TNNLS.2014.2334701

劉軍, 段書凱, 李天舒, 等. 機械臂的自旋憶阻RBF神經網絡控制系統設計[J]. 儀器儀表學報, 2018, 39(8): 212–219. doi: 10.19650/j.cnki.cjsi.J1803068

LIU Jun, DUAN Shukai, LI Tianshu, et al. Design of RBF neural network control system based on spintronic memristor for robotic manipulator[J]. Chinese Journal of Scientific Instrument, 2018, 39(8): 212–219. doi: 10.19650/j.cnki.cjsi.J1803068

WANG Chunni, Lü Mi, ALSAEDI A, et al. Synchronization stability and pattern selection in a memristive neuronal network[J]. Chaos, 2017, 27(11): 113108. doi: 10.1063/1.5004234

吳杰, 王光義, 丘嶸, 等. 憶阻器數字化仿真器的設計與實現[J]. 杭州電子科技大學學報: 自然科學版, 2018, 38(5): 1–6. doi: 10.13954/j.cnki.hdu.2018.05.001

WU Jie, WANG Guangyi, QIU Rong, et al. Design and implementation of digital simulator for memristor[J]. Journal of Hangzhou Dianzi University:Natural Sciences, 2018, 38(5): 1–6. doi: 10.13954/j.cnki.hdu.2018.05.001

WU Xiangjun, FU Zhengye, and KURTHS J. A secure communication scheme based generalized function projective synchronization of a new 5D hyperchaotic system[J]. Physica Scripta, 2015, 90(4): 045210. doi: 10.1088/0031-8949/90/4/045210

ALJAFAR M J, PERKOWSKI M A, ACKEN J M, et al. A time-efficient CMOS-memristive programmable circuit realizing logic functions in generalized AND-XOR structures[J]. IEEE Transactions on Very Large Scale Integration (VLSI) Systems, 2018, 26(1): 23–36. doi: 10.1109/TVLSI.2017.2750074

阮靜雅, 孫克輝, 牟俊. 基于憶阻器反饋的Lorenz超混沌系統及其電路實現[J]. 物理學報, 2016, 65(19): 190502. doi: 10.7498/aps.65.190502

RUAN Jingya, SUN Kehui, and MOU Jun. Memristor-based Lorenz hyper-chaotic system and its circuit implementation[J]. Acta Physica Sinica, 2016, 65(19): 190502. doi: 10.7498/aps.65.190502

BAO Bocheng, JIANG Tao, XU Quan, et al. Coexisting infinitely many attractors in active band-pass filter-based memristive circuit[J]. Nonlinear Dynamics, 2016, 86(3): 1711–1723. doi: 10.1007/s11071-016-2988-6

RUAN Jingya, SUN Kehui, MOU Jun, et al. Fractional-order simplest memristor-based chaotic circuit with new derivative[J]. The European Physical Journal Plus, 2018, 133(1): No. 3, 1–12. doi: 10.1140/epjp/i2018-11828-0

MUTHUSWAMY B and CHUA L O. Simplest chaotic circuit[J]. International Journal of Bifurcation and Chaos, 2010, 20(5): 1567–1580. doi: 10.1142/S0218127410027076

MUTHUSWAMY B. Implementing memristor based chaotic circuits[J]. International Journal of Bifurcation and Chaos, 2010, 20(5): 1335–1350. doi: 10.1142/S0218127410026514

ITOH M and CHUA L O. Memristor oscillators[J]. International Journal of Bifurcation and Chaos, 2008, 18(11): 3183–3206. doi: 10.1142/S0218127408022354

YUAN Fang and LI Yuxia. A chaotic circuit constructed by a memristor, a memcapacitor and a meminductor[J]. An Interdisciplinary Journal of Nonlinear Science, 2019, 29(10): 101101. doi: 10.1063/1.5125673

LI Chuang, MIN Fuhong, and LI Chunbiao. Multiple coexisting attractors of the serial-parallel memristor-based chaotic system and its adaptive generalized synchronization[J]. Nonlinear Dynamics, 2018, 94(4): 2785–2806. doi: 10.1007/s11071-018-4524-3

RAJAGOPAL K, LI Chunbiao, NAZARIMEHR F, et al. Chaotic dynamics of modified Wien bridge oscillator with fractional order memristor[J]. Radioengineering, 2019, 28(1): 165–174.

洪慶輝, 曾以成, 李志軍. 含磁控和荷控兩種憶阻器的混沌電路設計與仿真[J]. 物理學報, 2013, 63(23): 230502. doi: 10.7498/aps.62.230502

HONG Qinghui, ZENG Yicheng, and LI Zhijun. Design and simulation of chaotic circuit for flux-controlled memristor and charge-controlled memristor[J]. Acta Physica Sinica, 2013, 63(23): 230502. doi: 10.7498/aps.62.230502

BAO Bocheng, ZHANG Xi, BAO Han, et al. Dynamical effects of memristive load on peak current mode buck-boost switching converter[J]. Chaos, Solitons & Fractals, 2019, 122: 69–79.

CHEN Chengjie, CHEN Jingqi, BAO Han, et al. Coexisting multi-stable patterns in memristor synapse-coupled Hopfield neural network with two neurons[J]. Nonlinear Dynamics, 2019, 95(4): 3385–3399. doi: 10.1007/s11071-019-04762-8

BAO Bocheng, MA Zhenghua, XU Jianping, et al. A simple memristor chaotic circuit with complex dynamics[J]. International Journal of Bifurcation and Chaos, 2011, 21(9): 2629–2645. doi: 10.1142/S0218127411029999

WANG Chunhua, LIU Xiaoming, and XIA Hu. Multi-piecewise quadratic nonlinearity memristor and its 2N-scroll and 2N+1-scroll chaotic attractors system[J]. An Interdisciplinary Journal of Nonlinear Science, 2017, 27(3): 033114. doi: 10.1063/1.4979039

譚志平, 曾以成, 李志軍, 等. 浮地型憶阻器混沌電路的分析與實現[J]. 儀器儀表學報, 2014, 35(9): 2123–2129.

TAN Zhiping, ZENG Yicheng, and LI Zhijun. Analysis and implementation of a floating memristor chaotic circuit[J]. Chinese Journal of Scientific Instrument, 2014, 35(9): 2123–2129.

BAO Bocheng, JIANG Tao, WANG Guangyi, et al. Two-memristor-based Chua’s hyperchaotic circuit with plane equilibrium and its extreme multistability[J]. Nonlinear Dynamics, 2017, 89(2): 1157–1171. doi: 10.1007/s11071-017-3507-0

CHEN Mo, SUN Mengxia, BAO Bocheng, et al. Controlling extreme multistability of memristor emulator-based dynamical circuit in flux-charge domain[J]. Nonlinear Dynamics, 2018, 91(2): 1395–1412. doi: 10.1007/s11071-017-3952-9

TAN Qiwei, ZENG Yicheng, and LI Zhijun. A simple inductor-free memristive circuit with three line equilibria[J]. Nonlinear Dynamics, 2018, 94(3): 1585–1602. doi: 10.1007/s11071-018-4443-3
