基于MUSIC算法的二次雷達應答信號分離方法

張海; 陳小龍; 張濤; 張財生

doi:10.11999/JEIT190842

基于MUSIC算法的二次雷達應答信號分離方法

doi: 10.11999/JEIT190842

張海¹,
陳小龍¹,
張濤^{1, 2, ,},
張財生¹

1.
海軍航空大學 煙臺 264001
2.
92337部隊 大連 116023

基金項目: 國家自然科學基金(U1933135, 61871391, 61931021)；山東省重點研發計劃(2019GSF111004)

詳細信息

作者簡介:
張海：男，1976年生，副教授，研究方向?yàn)槔走_(dá)信號處理、雷達目標特性等

陳小龍：男，1985年生，副教授，研究方向?yàn)槔走_(dá)動目標檢測、海雜波抑制、雷達信號精細化處理等

張濤：男，1986年生，工程師，研究方向?yàn)锳DS-B系統設計及信號處理等

張財生：男，1983年生，講師，研究方向?yàn)槔走_(dá)信號處理、ADS-B信號處理等

通訊作者:
張濤　radarads@sina.com

中圖分類號: TN958.96; V19
計量
- 文章訪問數: 4728
- HTML全文瀏覽量: 1336
- PDF下載量: 117
- 被引次數: 0
出版歷程
- 收稿日期: 2019-11-01
- 修回日期: 2020-03-20
- 網絡出版日期: 2020-04-10
- 刊出日期: 2020-12-08

Overlapping Secondary Surveillance Radar Replies Separation Algorithm Based on MUSIC

1.
Naval Aviation University, Yantai 264001, China
2.
92337 Troop, Dalian 116023, China

Funds: The National Nature Science Foundation of China (U1933135, 61871391, 61931021), The Key Research and Development Program of Shandong Province (2019GSF111004)

摘要

摘要: 為了提高在高密度信號環境下對二次監視雷達(SSR)應答信號的接收性能，該文提出一種將信源數估計和信號到達方向(DOA)估計相結合構建分離矩陣實現交疊信號分離的算法。首先根據交疊信號量測的特征值分布來確定交疊信號的個數；然后利用MUSIC算法作譜峰搜索得到各信號的DOA，并重構混合矩陣；最后通過計算混合矩陣的廣義逆得到分離矩陣，并實現對交疊信號的分離。以6陣元均勻線陣為前提進行仿真分析，結果表明所提分離算法可達到90%以上的分離成功率，分離性能和獨立成分分析(ICA)算法相當，優于基于投影技術分離算法(PA)，但計算量遠小于ICA算法，不足ICA算法計算量1/10，更易于工程化應用。
- 交疊信號分離 /
- 陣列天線 /
- SSR應答信號 /
- MUSIC算法 /
- 混合矩陣重構
Abstract: In order to improve the reception performance of Secondary Surveillance Radar (SSR) replies in high-density signal environment, a separation algorithm is proposed, which constructs the separating matrix with estimating the source number and the Direction Of Arrival (DOA) of signal. Firstly, the number of overlapping signals is determined with the eigenvalues distribution of the measurements. Secondly, the mixing matrix with the DOA of signals, which is estimated by peak value searching in MUSIC algorithm. Finally, the separating matrix is estimated by calculating the Moore-Penrose inverse of the reconstructed mixing matrix, achieving separation of overlapping signals. Simulation is done based on uniform linear array with 6 elements. The results show that the proposed separation algorithm can achieve more than 90% success rate to separate two short Mode S replies, and the separating performance is similar to the Independent Component Analysis (ICA) algorithm and is better than Projection Algorithm (PA). The amount of calculation is less than 10 percent of ICA algorithm, thus the proposed separation algorithm is easier to engineering application.
- Overlapping signal Separation /
- Array antenna /
- Secondary Surveillance Radar (SSR) replies /
- MUSIC algorithm /
- Mixing matrix reconstruction

HTML全文

圖 1 SSR應答信號四重交疊

下載: 全尺寸圖片幻燈片

圖 2 特征值分布及信號的空間譜

下載: 全尺寸圖片幻燈片

圖 3 不同測向誤差下的失敗率和誤碼率

下載: 全尺寸圖片幻燈片

圖 4 不同測向誤差下的失敗率和誤碼率(完全交疊)

下載: 全尺寸圖片幻燈片

圖 5 不同交疊程度下的不同算法的分離失敗率

下載: 全尺寸圖片幻燈片

圖 6 不同交疊程度下的不同算法的誤碼率

下載: 全尺寸圖片幻燈片

表 1 交疊信號個數檢測正確概率(%)

DOA	4 dB	8 dB	12 dB	16 dB	20 dB
0°	93.63	95.84	97.51	98.61	99.17
15°	93.07	95.84	96.95	97.78	98.89
30°	92.80	95.29	96.40	97.23	98.61
45°	90.86	93.91	95.84	96.40	98.34
60°	85.87	91.97	95.29	95.29	98.06
75°	72.58	78.95	87.81	93.91	97.51
90°	71.75	77.84	82.55	86.70	90.03

下載: 導出CSV

參考文獻(25)

張軍. 空域監視技術的新進展及應用[J]. 航空學報, 2011, 32(1): 1–14.

ZHANG Jun. New development and application of airspace surveillance technology[J]. Acta Aeronautica et Astronautica Sinica, 2011, 32(1): 1–14.

PETROCHILOS N, GALATI G, and PIRACCI E. Separation of SSR signals by array processing in multilateration systems[J]. IEEE Transactions on Aerospace and Electronic Systems, 2009, 45(3): 965–982. doi: 10.1109/TAES.2009.5259177

王洪, 劉昌忠, 汪學剛. 二次雷達S模式綜述[J]. 電訊技術, 2008, 48(7): 113–118. doi: 10.3969/j.issn.1001-893X.2008.07.029

WANG Hong, LIU Changzhong, and WANG Xuegang. Mode S for secondary surveillance radar (SSR): An introduction and overview[J]. Telecommunication Engineering, 2008, 48(7): 113–118. doi: 10.3969/j.issn.1001-893X.2008.07.029

PETROCHILOS N, GALATI G, MENE L, et al. Separation of multiple secondary surveillance radar sources in a real environment by a novel projection algorithm[C]. The 5th IEEE International Symposium on Signal Processing and Information Technology, Athens, Greece, 2005: 125–130.

PETROCHILOS N, GALATI G, and PIRACCI E. Projection techniques for separation of multiple secondary surveillance radar sources in a real environment[C]. The 4th IEEE Workshop on Sensor Array and Multichannel Processing, Waltham, USA, 2006: 344–348.

PETROCHILOS N, PIRACCI E G, and GALATI G. Separation of multiple secondary surveillance radar sources in a real environment for the near-far case[C]. Antennas and Propagation Society International Symposium, Honolulu, USA, 2007: 3988–3991.

CHEN Xiaolong, CHEN Baoxin, GUAN Jian, et al. Space-range-Doppler focus-based low-observable moving target detection using frequency diverse array MIMO radar[J]. IEEE Access, 2018, 6: 43892–43904. doi: 10.1109/ACCESS.2018.2863745

陳小龍, 關鍵, 黃勇, 等. 雷達低可觀測動目標精細化處理及應用[J]. 科技導報, 2017, 35(20): 19–27.

CHEN Xiaolong, GUAN Jian, HUANG Yong, et al. Radar refined processing and its applications for low-observable moving target[J]. Science &Technology Review, 2017, 35(20): 19–27.

GALATI G, BARTOLINI S, and MENE L. Analysis of SSR signals by super resolution algorithms[C]. The 4th IEEE International Symposium on Signal Processing and Information Technology, Rome, Italy, 2004: 166–170.

王洪, 黃榮順, 徐自勵. 多點定位中A/C模式混疊信號的時域分離算法[J]. 電子科技大學學報, 2013, 42(6): 848–851. doi: 10.3969/j.issn.1001-0548.2013.06.007

WANG Hong, HUANG Rongshun, and XU Zili. Separating algorithm of A/C garbles in time domain for multilateration[J]. Journal of University of Electronic Science and Technology of China, 2013, 42(6): 848–851. doi: 10.3969/j.issn.1001-0548.2013.06.007

王洪, 劉昌忠, 汪學剛, 等. 多點定位混疊信號的盲分離[J]. 電訊技術, 2009, 49(12): 1–4. doi: 10.3969/j.issn.1001-893x.2009.12.001

WANG Hong, LIU Changzhong, WANG Xuegang, et al. Blind Separation of gables in multilateration[J]. Telecommunication Engineering, 2009, 49(12): 1–4. doi: 10.3969/j.issn.1001-893x.2009.12.001

PETROCHILOS N and VAN DER VEEN A J. Algorithms to separate overlapping secondary surveillance radar replies[C]. 2004 IEEE International Conference on Acoustics, Speech, and Signal Processing, Montreal, Canada, 2004: 11–49.

劉松, 龐育才. 基于擴展ESPRIT的隨機陣列高效DoA估計算法[J]. 電子與信息學報, 2019, 41(6): 1324–1329. doi: 10.11999/JEIT180672

LIU Song and PANG Yucai. Efficient augmented ESPRIT-based direction-of-arrival estimation algorithm for random arrays[J]. Journal of Electronics &Information Technology, 2019, 41(6): 1324–1329. doi: 10.11999/JEIT180672

王洪. 1030/1090 MHz頻譜的共享與干擾問題綜述[J]. 電訊技術, 2013, 53(1): 105–109. doi: 10.3969/j.issn.1001-893x.2013.01.021

WANG Hong. Overview of sharing and interference at 1030/1090 MHz[J]. Telecommunication Engineering, 2013, 53(1): 105–109. doi: 10.3969/j.issn.1001-893x.2013.01.021

孫清清, 王洪, 黃忠濤, 等. 1090MHz信號同頻干擾與竄擾概率探究[J]. 通信技術, 2013, 46(2): 8–11. doi: 10.3969/j.issn.1002-0802.2013.02.005

SUN Qingqing, WANG Hong, HUANG Zhongtao, et al. Exploration on 1090MHz co-channel interference and probability of garble[J]. Communications Technology, 2013, 46(2): 8–11. doi: 10.3969/j.issn.1002-0802.2013.02.005

SCHMIDT R O. Multiple emitter location and signal parameter estimation[J]. IEEE Transactions on Antennas and Propagation, 1986, 34(3): 276–280. doi: 10.1109/TAP.1986.1143830

王旭東, 仲倩, 閆賀, 等. 一種二維信號波達方向估計的改進多重信號分類算法[J]. 電子與信息學報, 2019, 41(9): 2137–2142. doi: 10.11999/JEIT181090

WANG Xudong, ZHONG Qian, YAN He, et al. An improved MUSIC algorithm for two dimensional direction of arrival estimation[J]. Journal of Electronics &Information Technology, 2019, 41(9): 2137–2142. doi: 10.11999/JEIT181090

張蔚. 二次雷達原理[M]. 北京: 國防工業出版社, 2009: 144–146.

ZHANG Wei. Secondary Radar Principle[M]. Beijing: National Defense Industry Press, 2009: 144–146.

RTCA D. RTCA DO-260B Minimum operational performance standards for 1090 MHz extended squitter automatic dependent surveillance-broadcast (ADS-B) and traffic information services-broadcast (TIS-B)[S]. Washington, DC: RTCA, Inc., 2011.

ICAO A. 10 (Aeronautical Telecomm.) to the convention on international civil aviation[J]. Volume I, 1996: 52–60.

王永良, 陳輝, 彭應寧, 等. 空間譜估計理論與算法[M]. 北京: 清華大學出版社, 2004: 40–52.

WANG Yongliang, CHEN Hui, PENG Yingning, et al. Spatial Spectrum Estimation Theory and Algorithm[M]. Beijing: Tsinghua University Press, 2004: 40–52.

ROY R and KAILATH T. ESPRIT-estimation of signal parameters via rotational invariance techniques[J]. IEEE Transactions on Acoustics, Speech, and Signal Processing, 1989, 37(7): 984–995. doi: 10.1109/29.32276

王洪, 劉昌忠, 汪學剛, 等. 強干擾背景下S模式解碼方法[J]. 電子與信息學報, 2009, 31(12): 2876–2880.

WANG Hong, LIU Changzhong, WANG Xuegang, et al. Mode S decoding methods in heavy jamming environment[J]. Journal of Electronics &Information Technology, 2009, 31(12): 2876–2880.

張濤, 唐小明, 金林. 基于置信度的S模式信號隨機多位糾錯技術[J]. 電訊技術, 2015, 55(9): 1005–1009. doi: 10.3969/j.issn.1001-893x.2015.09.010

ZHANG Tao, TANG Xiaoming, and JIN Lin. Confidence-based brute force technique with random errors for Mode S reply[J]. Telecommunication Engineering, 2015, 55(9): 1005–1009. doi: 10.3969/j.issn.1001-893x.2015.09.010

孫守宇. 盲信號處理基礎及其應用[M]. 北京: 國防工業出版社, 2010: 50–95.

SUN S Y. Blind Signal Processing Foundation and It’s Applications[M]. Beijing: National Defense Industry Press, 2010: 50–95.
