基于Keystone變換和擾動重采樣的機動平臺大斜視SAR成像方法

李根,  馬彥恒,  侯建強,  徐公國

李根, 馬彥恒, 侯建強, 徐公國. 基于Keystone變換和擾動重采樣的機動平臺大斜視SAR成像方法[J]. 電子與信息學報, 2020, 42(10): 2485-2492. doi: 10.11999/JEIT190831
引用本文: 李根, 馬彥恒, 侯建強, 徐公國. 基于Keystone變換和擾動重采樣的機動平臺大斜視SAR成像方法[J]. 電子與信息學報, 2020, 42(10): 2485-2492. doi: 10.11999/JEIT190831
Gen LI, Yanheng MA, Jianqiang HOU, Gongguo XU. Maneuvering Platform High-squint SAR Imaging Method Based on Keystone Transform and Perturbation Resampling[J]. Journal of Electronics & Information Technology, 2020, 42(10): 2485-2492. doi: 10.11999/JEIT190831
Citation: Gen LI, Yanheng MA, Jianqiang HOU, Gongguo XU. Maneuvering Platform High-squint SAR Imaging Method Based on Keystone Transform and Perturbation Resampling[J]. Journal of Electronics & Information Technology, 2020, 42(10): 2485-2492. doi: 10.11999/JEIT190831

基于Keystone變換和擾動重采樣的機動平臺大斜視SAR成像方法

doi: 10.11999/JEIT190831
  • 1.

    陸軍工程大學石家莊校區無人機工程系 石家莊 050003

  • 2.

    陸軍工程大學石家莊校區電子與光學工程系 石家莊 050003

詳細信息
    作者簡介:

    李根：男，1991年生，博士生，主要從事機動平臺大斜視SAR成像和壓縮感知雷達成像研究

    馬彥恒：男，1968年生，教授，博士生導師，主要從事機動SAR成像、低小慢目標探測等方向的研究

    侯建強：男，1991年生，博士生，主要從事曲線SAR 3維成像研究

    徐公國：男，1990年生，博士生，主要從事雷達信號處理與傳感器融合研究

    通訊作者:

    李根　radarlg@163.com

  • 中圖分類號: TN957.52

Maneuvering Platform High-squint SAR Imaging Method Based on Keystone Transform and Perturbation Resampling

  • 1.

    Department of UAV Engineering, Army Engineering University Shijiazhuang Campus, Shijiazhuang 050003, China

  • 2.

    Department of Electronic and Optical Engineering, Army Engineering University Shijiazhuang Campus, Shijiazhuang 050003, China

  • 摘要: 加速度和下降速度的存在使機動平臺大斜視SAR的成像參數存在明顯的2維空變性，嚴重影響場景的聚焦深度。針對這個問題，該文提出了一種基于Keystone變換和擾動重采樣的機動SAR成像方法。首先，通過距離走動校正和去加速處理實現距離方位解耦以及方位頻譜去混疊，然后采用方位時域的Keystone變換校正空變的距離徙動；在方位壓縮過程中，通過引入時域的高階擾動因子去除多普勒參數的2階及3階方位空變性，然后通過方位頻域的重采樣處理去除多普勒參數的方位1階空變性。所提方法能夠有效校正距離徙動軌跡和方位聚焦參數的2維空變性，實現機動平臺大斜SAR的大場景成像，仿真分析驗證了所提方法的有效性。
    Abstract: The existence of acceleration and descent velocity makes the imaging parameters of high-squint SAR mounted on maneuvering platform have obvious two-dimensional spatial variability, which affects seriously the focus depth of the scene. To solve this problem, a maneuvering SAR imaging method based on Keystone transform and azimuth perturbation resampling is proposed. First of all, the range azimuth decoupling and the azimuth spectrum de Aliasing are realized by the range walk correction and de-acceleration processing. Then the spatial-variant range cell migration is corrected by the Keystone transform in the azimuth time domain; In the process of azimuth compression, the second- and third-order spatial variabilities of Doppler parameters are removed by introducing the high-order perturbation factor in the time domain, and then the first-order spatial variability of the Doppler parameters is removed by the azimuth resampling processing in the azimuth frequency domain. The proposed method can effectively correct the two-dimensional spatial variability of range cell migration trajectory and azimuth focus parameters, and realize the large scene imaging of high-squint maneuvering SAR. Simulation analysis verifies the effectiveness of the proposed method.
    • HTML全文

  • 圖  1  機動平臺大斜視SAR成像模型

    圖  2  成像算法流程

    圖  3  有效成像區域分析

    圖  4  機動SAR成像目標分布示意圖

    圖  5  空變距離徙動校正結果

    圖  6  點目標聚焦結果方位剖面圖

    表  1  仿真參數

    參數數值參數數值
    載頻15 GHz地面斜視角60°
    距離帶寬300 MHz平臺高度4 km
    合成孔徑時間3 s中心斜距12 km
    脈沖寬度5 μs速度(150, 0, –30) m/s
    脈沖重復頻率1.5 kHz加速度(2.4, 0.8, –2.2) m/s2
    下載: 導出CSV

    表  2  點目標方位向測量指標

    測量指標FDPF方法[13]本文擾動重采樣方法
    點1點2點3點1點2點3
    PSLR(dB)–3.98–13.26–4.78–12.68–13.27–13.39
    ISLR(dB)–7.11–9.83–6.78–9.37–9.81–10.28
    MW20.6715.6028.3515.6215.6115.62
    下載: 導出CSV
  • ZENG Tao, LI Yinghe, DING Zegang, et al. Subaperture approach based on azimuth-dependent range cell migration correction and azimuth focusing parameter equalization for maneuvering high-squint-mode SAR[J]. IEEE Transactions on Geoscience and Remote Sensing, 2015, 53(12): 6718–6734. doi: 10.1109/TGRS.2015.2447393
    DANG Yanfeng, LIANG Yi, BIE Bowen, et al. A range perturbation approach for correcting spatially variant range envelope in diving highly squinted SAR with nonlinear trajectory[J]. IEEE Geoscience and Remote Sensing Letters, 2018, 15(6): 858–862. doi: 10.1109/LGRS.2018.2812158
    LIAO Yi, ZHOU Song, and YANG Lei. Focusing of SAR with curved trajectory based on improved hyperbolic range equation[J]. IEEE Geoscience and Remote Sensing Letters, 2018, 15(3): 454–458. doi: 10.1109/LGRS.2018.2794471
    李寧, 別博文, 邢孟道, 等. 基于多普勒重采樣的恒加速度大斜視SAR成像算法[J]. 電子與信息學報, 2019, 41(12): 2873–2880. doi: 10.11999/JEIT180953

    LI Ning, BIE Bowen, XING Mengdao, et al. A doppler resampling based imaging algorithm for high squint SAR with constant acceleration[J]. Journal of Electronics &Information Technology, 2019, 41(12): 2873–2880. doi: 10.11999/JEIT180953
    LI Zhenyu, LIANG Yi, XING Mengdao, et al. An improved range model and Omega-k-based imaging algorithm for high-squint SAR with curved trajectory and constant acceleration[J]. IEEE Geoscience and Remote Sensing Letters, 2016, 13(5): 656–660. doi: 10.1109/LGRS.2016.2533631
    鄧歡, 李亞超, 梅海文, 等. 彈載曲線軌跡雙基SAR反向濾波PFA成像與圖像畸變校正算法[J]. 電子與信息學報, 2018, 40(11): 2638–2644. doi: 10.11999/JEIT170994

    DENG Huan, LI Yachao, MEI Haiwen, et al. New back-filtering PFA imaging algorithm and distortion correction method for missile-borne bistatic SAR with curved track[J]. Journal of Electronics &Information Technology, 2018, 40(11): 2638–2644. doi: 10.11999/JEIT170994
    江淮, 趙惠昌, 漢敏, 等. 基于變量解耦的俯沖加速段彈載SAR大場景成像算法[J]. 物理學報, 2014, 63(7): 078403. doi: 10.7498/aps.63.078403

    JIANG Huai, ZHAO Huichang, HAN Min, et al. An imaging algorithm for missile-borne SAR with downward movement based on variable decoupling[J]. Acta Physica Sinica, 2014, 63(7): 078403. doi: 10.7498/aps.63.078403
    LI Zhenyu, XING Mengdao, LIANG Yi, et al. A frequency-domain imaging algorithm for highly squinted SAR mounted on maneuvering platforms with nonlinear trajectory[J]. IEEE Transactions on Geoscience and Remote Sensing, 2016, 54(7): 4023–4038. doi: 10.1109/TGRS.2016.2535391
    江淮, 陳思, 趙惠昌, 等. 一種彈載SAR子孔徑成像算法[J]. 電子與信息學報, 2017, 39(10): 2526–2530. doi: 10.11999/JEIT161337

    JIANG Huai, CHEN Si, ZHAO Huichang, et al. Subaperture imaging algorithm for missile-borne SAR[J]. Journal of Electronics &Information Technology, 2017, 39(10): 2526–2530. doi: 10.11999/JEIT161337
    劉文康, 景國彬, 孫光才, 等. 基于兩步方位重采樣的中軌SAR聚焦方法[J]. 電子與信息學報, 2019, 41(1): 136–142. doi: 10.11999/JEIT180238

    LIU Wenkang, JING Guobin, SUN Guangcai, et al. Medium-earth-orbit SAR data focusing method based on two-step azimuth resampling[J]. Journal of Electronics &Information Technology, 2019, 41(1): 136–142. doi: 10.11999/JEIT180238
    TANG Shiyang, LIN Chunhui, ZHOU Yu, et al. Processing of long integration time spaceborne SAR data with curved orbit[J]. IEEE Transactions on Geoscience and Remote Sensing, 2018, 56(2): 888–904. doi: 10.1109/TGRS.2017.2756109
    別博文, 梁毅, 黨彥鋒, 等. 曲線軌跡SAR大斜視子孔徑成像算法[J]. 系統工程與電子技術, 2017, 39(3): 500–505. doi: 10.3969/j.issn.1001-506X.2017.03.07

    BIE Bowen, LIANG Yi, DANG Yanfeng, et al. Sub-aperture imaging algorithm for high squint SAR with curvilinear flight tracks[J]. Systems Engineering and Electronics, 2017, 39(3): 500–505. doi: 10.3969/j.issn.1001-506X.2017.03.07
    黨彥鋒, 梁毅, 別博文, 等. 俯沖段大斜視SAR子孔徑成像二維空變校正方法[J]. 電子與信息學報, 2018, 40(11): 2621–2629. doi: 10.11999/JEIT180021

    DANG Yanfeng, LIANG Yi, BIE Bowen, et al. Two-dimension space-variance correction approach for diving highly squinted SAR imaging with sub-aperture[J]. Journal of Electronics &Information Technology, 2018, 40(11): 2621–2629. doi: 10.11999/JEIT180021
    NEO Y L, WONG F, and CUMMING I G. A two-dimensional spectrum for bistatic SAR processing using series reversion[J]. IEEE Geoscience and Remote Sensing Letters, 2007, 4(1): 93–96. doi: 10.1109/LGRS.2006.885862
    LI Dong, LIN Huan, LIU Hongqing, et al. Focus improvement for high-resolution highly squinted SAR imaging based on 2-D spatial-variant linear and quadratic RCMs correction and azimuth-dependent doppler equalization[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2017, 10(1): 168–183. doi: 10.1109/jstars.2016.2569561
    TANG Shiyang, ZHANG Linrang, GUO Ping, et al. Processing of monostatic SAR data with general configurations[J]. IEEE Transactions on Geoscience and Remote Sensing, 2015, 53(12): 6529–6546. doi: 10.1109/TGRS.2015.2443835
