D2D輔助的窄帶物聯網中能耗和傳輸成功率的最優折中

裴二榮; 易鑫; 鄧炳光; 李金艷; 張蕾

doi:10.11999/JEIT190786

D2D輔助的窄帶物聯網中能耗和傳輸成功率的最優折中

doi: 10.11999/JEIT190786

1.
重慶郵電大學通信與信息工程學院　重慶　400065
2.
中國電信股份有限公司技術創新中心　北京　102209

基金項目: 國家重大專項(2018zx0301016)，國家自然科學基金(61671096, 61379159)，重慶市基礎研究與前沿探索項目(cstc2018jcyjAX0507, cstc2017jcyjBX0005)

詳細信息

作者簡介:
裴二榮：男，1976年生，副教授，研究方向?yàn)闊o線通信、移動通信

易鑫：男，1996年生，碩士生，研究方向?yàn)檎瓗锫?lián)網、D2D通信

鄧炳光：男，1978年生，副教授，研究方向?yàn)橥ㄐ啪W(wǎng)與測試技術

李金艷：女，1977年生，高級工程師，研究方向?yàn)橐苿?dòng)通信技術標準

張蕾：女，1993年生，初級工程師，研究方向?yàn)榫W(wǎng)移動通信網絡切片

通訊作者:
易鑫　18733653533@163.com

中圖分類號: TN925.1
計量
- 文章訪問數: 1608
- HTML全文瀏覽量: 482
- PDF下載量: 79
- 被引次數: 0
出版歷程
- 收稿日期: 2019-10-16
- 修回日期: 2020-05-24
- 網絡出版日期: 2020-07-15
- 刊出日期: 2020-12-08

The Optimal Tradeoff between Energy Consumption and Transmission Success Probability in D2D Assisted Narrow Band-Internet of Things

1.
Institute of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
China Telecom Technology Innovation Center, Beijing 102209, China

Funds: The National Major Project (2018zx0301016), The National Natural Science Foundation of China (61671096, 61379159), Chongqing Basic Research and Frontier Exploration Project (cstc2018jcyjAX0507, cstc2017jcyjBX0005)

摘要

摘要:
在設備到設備(D2D)通信輔助的窄帶物聯網(NB-IoT)中，為了盡可能提高傳輸成功率，D2D接收端需要預留較多的通信時隙(可以允許多次重傳)。然而，這顯著地增加了用戶設備(UE)的能耗，特別是在信道條件較差或者相鄰D2D鏈路干擾較嚴重的情況下。該文基于中繼和能耗模型構造了一個傳輸成功率和能耗折中的優化問題，進而提出一個基于二分法的通信時隙最優配置算法。數值結果表明較多的預留時隙數量極大地增加了UE的能耗，但是不會顯著提高傳輸成功率，與多中繼傳輸、隨機中繼傳輸和100%成功傳輸?shù)绕渌惴ㄏ啾龋撐奶岢龅念A(yù)留時隙最優配置算法獲得了最小的能耗和幾乎最大的傳輸成功率(只比100%成功傳輸方案低)。
- 窄帶物聯網 /
- 設備到設備通信 /
- 能量消耗 /
- 傳輸成功率
Abstract:
In the Device-to-Device (D2D) communication assisted Narrow Band Internet of Things (NB-IoT), in order to maximize the transmission success probability, the D2D relay device needs to reserve more communication time slots (multiple retransmissions can be allowed to increase the transmission success probability). However, this increases significantly the power consumption of the User Equipment (UE), especially in the case of poor channel conditions or severe interference. An optimization problem based on the relay and energy consumption models is constructed to seek a compromise between transmission success probability and energy consumption, and a communication slot optimal configuration algorithm based on dichotomy is proposed in this paper. The numerical results show that the larger number of reserved time slots can lead to an excessive increase in energy consumption without significantly increasing the transmission success probability. Compared with other algorithms such as multi-relay transmission, random relay transmission and 100% successful transmission, the proposed reserved time slot optimal configuration algorithm can obtain the least energy consumption and almost the highest transmission success probability (it is only lower than that under 100% successful transmission scheme).
- Narrow Band Internet of Things (NB-IoT) /
- D2D communication /
- Power consumption /
- Transmission success probability

HTML全文

圖 1 場景模型

下載: 全尺寸圖片幻燈片

圖 2 DRE通信時間表

下載: 全尺寸圖片幻燈片

圖 3 網絡場景示例

下載: 全尺寸圖片幻燈片

圖 4 不同預留通信時隙數量下的效用值

下載: 全尺寸圖片幻燈片

圖 5 不同傳輸功率下的傳輸成功率($\delta = 0.25$)

下載: 全尺寸圖片幻燈片

圖 6 不同傳輸功率下的總能量消耗($\delta = 0.75$)

下載: 全尺寸圖片幻燈片

圖 7 不同NB-IoT UE傳輸功率下的效用值

下載: 全尺寸圖片幻燈片

表 1 DRE最優預留通信時隙配置搜索算法

輸入：最小時隙數量N₁，最大時隙數量N₂，迭代終止閾值
輸出：最優時隙數量N_opt
初始化：N₁=2, N₂, w_max = 0;
for k=1 : K
根據${E_k} \cdot P_{{\rm{toBS}}}^k/d_{{\rm{toBS}}}^k$得到r_opt;
end
Repeat
mid = $\left\lceil {({N_1} + {N_2})/2} \right\rceil $;
若f((N₁+mid)/2) > f((mid+N₂)/2) 則N₂ = mid;
或f((N₁+mid)/2) < f((mid+N₂)/2) 則N₁ = mid;
Until
(N₂-N₁)/2 <$\varepsilon $;
N_opt = $\arg \max (f({N_{{\rm{ts}}}}))$, N_ts = N₁, N₂, (N₁+N₂)/2。

下載: 導出CSV

參考文獻(17)

NING Zhaolong, HU Xiping, CHEN Zhikui, et al. A cooperative quality-aware service access system for social internet of vehicles[J]. IEEE Internet of Things Journal, 2018, 5(4): 2506–2517. doi: 10.1109/JIOT.2017.2764259

劉素艷, 劉元安, 吳帆, 等. 物聯網中基于相似性計算的傳感器搜索[J]. 電子與信息學報, 2018, 40(12): 3020–3027. doi: 10.11999/JEIT171085

LIU Suyan, LIU Yuanan, WU Fan, et al. Sensor search based on sensor similarity computing in the internet of things[J]. Journal of Electronics &Information Technology, 2018, 40(12): 3020–3027. doi: 10.11999/JEIT171085

彭建華, 張帥, 許曉明, 等. 物聯網中一種抗大規模天線陣列竊聽者的噪聲注入方案[J]. 電子與信息學報, 2019, 41(1): 67–73. doi: 10.11999/JEIT180342

PENG Jianhua, ZHANG Shuai, XU Xiaoming, et al. A noise injection scheme resistant to massive MIMO eavesdropper in IoT[J]. Journal of Electronics &Information Technology, 2019, 41(1): 67–73. doi: 10.11999/JEIT180342

YAQOOB I, AHMED E, HASHEM I A T, et al. Internet of things architecture: Recent advances, taxonomy, requirements, and open challenges[J]. IEEE Wireless Communications, 2017, 24(3): 10–16. doi: 10.1109/MWC.2017.1600421

NING Zhaolong, XIA Feng, ULLAH N, et al. Vehicular social networks: Enabling smart mobility[J]. IEEE Communications Magazine, 2017, 55(5): 16–55. doi: 10.1109/MCOM.2017.1600263

YU Changsheng, LI Yu, WU Yuan, et al. Uplink scheduling and link adaptation for narrowband internet of things systems[J]. IEEE Access, 2017, 5: 1724–1734. doi: 10.1109/ACCESS.2017.2664418

CHEN Min, MIAO Yiming, JIAN Xin, et al. Cognitive-LPWAN: Towards intelligent wireless services in hybrid low power wide area networks[J]. IEEE Transactions on Green Communications and Networking, 2019, 3(2): 409–417. doi: 10.1109/TGCN.2018.2873783

KONG Xiangjie, XIA Feng, WANG Jinzhong, et al. Time-location-relationship combined service recommendation based on taxi trajectory data[J]. IEEE Transactions on Industrial Informatics, 2017, 13(3): 1202–1212. doi: 10.1109/TII.2017.2684163

LIU Jiajia and KATO N. Device-to-Device communication overlaying two-hop multi-channel uplink cellular networks[C]. The 16th ACM International Symposium on Mobile Ad Hoc Networking and Computing, Hangzhou, China, 2015: 307–316. doi: 10.1145/2746285.2746311.

MILITANO L, ORSINO A, ARANITI G, et al. A constrained coalition formation game for multihop D2D content uploading[J]. IEEE Transactions on Wireless Communications, 2016, 15(3): 2012–2024. doi: 10.1109/TWC.2015.2497682

GAO Chuhan, ZHANG Haoming, CHEN Xinlei, et al. Impact of selfishness in device-to-device communication underlying cellular networks[J]. IEEE Transactions on Vehicular Technology, 2017, 66(10): 9338–9349. doi: 10.1109/TVT.2017.2699862

YANG H H, LEE J, and QUEK T Q S. Heterogeneous cellular network with energy harvesting-based D2D communication[J]. IEEE Transactions on Wireless Communications, 2016, 15(2): 1406–1419. doi: 10.1109/TWC.2015.2489651

CHEN Gaojie, TANG Jinchuan, and COON J P. Optimal routing for multihop social-based D2D communications in the internet of things[J]. IEEE Internet of Things Journal, 2018, 5(3): 1880–1889. doi: 10.1109/JIOT.2018.2817024

MILITANO L, ORSINO A, ARANITI G, et al. Trusted D2D-based data uploading in in-band narrowband-IoT with social awareness[C]. The IEEE 27th Annual International Symposium on Personal, Indoor, and Mobile Radio Communications, Valencia, Spain, 2016: 1–6. doi: 10.1109/PIMRC.2016.7794568.

PETROV V, SAMUYLOV A, BEGISHEV V, et al. Vehicle-based relay assistance for opportunistic crowdsensing over narrowband IoT (NB-IoT)[J]. IEEE Internet of Things Journal, 2018, 5(5): 3710–3723. doi: 10.1109/JIOT.2017.2670363

LI Yanjun, CHI Kaikai, CHEN Honglong, et al. Narrowband internet of things systems with opportunistic D2D communication[J]. IEEE Internet of Things Journal, 2018, 5(3): 1474–1484. doi: 10.1109/JIOT.2017.2782323

NING Zhaolong, WANG Xiaojie, KONG Xiangjie, et al. A social-aware group formation framework for information diffusion in narrowband internet of things[J]. IEEE Internet of Things Journal, 2018, 5(3): 1527–1538. doi: 10.1109/JIOT.2017.2777480
