正交多用戶短參考差分混沌移位鍵控通信系統性能分析
doi: 10.11999/JEIT190778
-
重慶郵電大學通信與信息工程學院 重慶 400065
基金項目: 國家自然科學基金(61771085, 61371164),重慶市教育委員會科研項目(KJQN201900601, KJ1600407)
Performance Analysis of Orthogonal Multiuser Short Reference Differential Chaos Shift Keying Communication System
-
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
Funds: The National Natural Science Foundation of China (61771085, 61371164), The Research Project of Chongqing Educational Commission (KJQN201900601, KJ1600407)
-
摘要: 針對差分混沌移位鍵控系統傳輸速率和能量效率低的缺點,該文提出一種正交多用戶短參考差分混沌移位鍵控(OMU-SR-DCSK)通信系統。系統將參考信號長度縮短為每個信息承載信號長度的1/P,并在參考時隙后增加了兩路連續的信息時隙,每個信息時隙內,N個用戶信息在Walsh碼正交特性作用下同時傳輸,利用Walsh碼的正交特性可完全消除用戶間干擾,從而改善系統誤碼性能。推導了OMU-SR-DCSK在加性高斯白噪聲(AWGN)信道和Rayleigh衰落信道下的理論比特誤碼率(BER)公式并進行了仿真。仿真結果和理論推導的吻合證明了理論推導的正確性,從而為OMU-SR-DCSK應用于多用戶串行傳輸系統提供了理論依據。Abstract: An Orthogonal MultiUser Short Reference Differential Chaos Shift Keying (OMU-SR-DCSK) communication system is proposed to overcome the dominant drawbacks of DCSK system relating to low transmission rate and energy efficiency. The proposed system shortens the reference signal to 1/P of information bearing signal. Two consecutive information time slots are added after the reference time slot. Due to the excellent features of Walsh codes, the system sends information from N users in one information time slot. Meanwhile, the use of orthogonality of the Walsh code eliminates completely intra-signal interference and enhances the performance of Bit Error Rate (BER) better. The theoretical BER formula of OMU-SR-DCSK over Additive White Gaussian Noise (AWGN) channel and Rayleigh fading channel are derived and simulations are carried out respectively. The coincidence between the simulation results and the theoretical derivations proves the correctness of the theoretical derivation, providing a theoretical basis for the application of OMU-SR-DCSK to multiuser serial transmission system.
-
表 1 OMU-SR-DCSK, SRMR-DCSK, VHE-DCSK和MC-DCSK系統的能量效率及傳輸速率
系統名稱 傳輸速率(${R_B}$) 能量效率(${E_\eta }$) OMU-SR-DCSK ${{2N} / {(R + 2\beta )}}$ ${{2N\beta } / {(R + 2N\beta )}}$ SRMR-DCSK ${N / {(R + \beta )}}$ ${{N\beta } / {(R + N\beta )}}$ VHE-DCSK ${N / {(2\beta }})$ ${N / {(1 + N)}}$ MC-DCSK ${N / \beta }$ ${N / {(1 + N)}}$ 下載: 導出CSV
-
?ICEK S, KOCAMAZ U E, and UYARO?LU Y. Secure chaotic communication with Jerk chaotic system using sliding mode control method and its real circuit implementation[J]. Iranian Journal of Science and Technology, Transactions of Electrical Engineering, 2019, 43(3): 687–698. doi: 10.1007/s40998-019-00184-9 ESCRIBANO F J, KADDOUM G, WAGEMAKERS A, et al. Design of a new differential chaos-shift-keying system for continuous mobility[J]. IEEE Transactions on Communications, 2016, 64(5): 2066–2078. doi: 10.1109/TCOMM.2016.2538236 CAI Guofa, FANG Yi, HAN Guojun, et al. A new hierarchical M-ary DCSK communication system: Design and analysis[J]. IEEE Access, 2017, 5: 17414–17424. doi: 10.1109/ACCESS.2017.2740973 KADDOUM G, TRAN H V, KONG Long, et al. Design of simultaneous wireless information and power transfer scheme for short reference DCSK communication systems[J]. IEEE Transactions on Communications, 2017, 65(1): 431–433. doi: 10.1109/TCOMM.2016.2619707 HU Wei, WANG Lin, and KADDOUM G. Design and performance analysis of a differentially spatial modulated chaos shift keying modulation system[J]. IEEE Transactions on Circuits and Systems II: Express Briefs, 2017, 64(11): 1302–1306. doi: 10.1109/TCSII.2017.2697456 張琳, 徐位凱, 王琳, 等. 碼復用差分混沌鍵控性能分析與同步算法[J]. 重慶郵電大學學報: 自然科學版, 2016, 28(3): 330–336.ZHANG Lin, XU Weikai, WANG Lin, et al. Performance analysis and synchronization algorithm for CS-DCSK system[J]. Journal of Chongqing University of Posts and Telecommunications (Natural Science Edition) , 2016, 28(3): 330–336. YANG Hua and JIANG Guoping. High-efficiency differential-chaos-shift-keying scheme for chaos-based noncoherent communication[J]. IEEE Transactions on Circuits and Systems II: Express Briefs, 2012, 59(5): 312–316. doi: 10.1109/TCSII.2012.2190859 KOLUMBAN G and KIS G. Multipath performance of FM-DCSK chaotic communications system[C]. 2000 IEEE International Symposium on Circuits and Systems, Geneva, Switzerland, 2000: 433–436. doi: 10.1109/ISCAS.2000.858781. BAO Jiyu, XU Weikai, WANG Lin, et al. Performance analysis and sub-carriers power allocation for MC-QCSK[C]. 2015 International Conference on Wireless Communications & Signal Processing, Nanjing, China, 2015: 1–5. doi: 10.1109/WCSP.2015.7341173. 張剛, 許嘉平, 張?zhí)祢U. 基于希爾伯特變換的多用戶DCSK通信系統性能分析[J]. 電子與信息學報, 2018, 40(11): 2744–2751. doi: 10.11999/JEIT180110ZHANG Gang, XU Jiaping, and ZHAGN Tianqi. Performance analyze for multiuser-DCSK communication system based on hilbert transform[J]. Journal of Electronics &Information Technology, 2018, 40(11): 2744–2751. doi: 10.11999/JEIT180110 YANG Hua, JIANG Guoping, TANG W K S, et al. Multi-carrier differential chaos shift keying system with subcarriers allocation for noise reduction[J]. IEEE Transactions on Circuits and Systems II: Express Briefs, 2018, 65(11): 1733–1777. doi: 10.1109/TCSII.2017.2752754 張剛, 趙暢暢, 張?zhí)祢U. 短參考正交多用戶差分混沌鍵控方案的性能分析[J]. 電子與信息學報, 2019, 41(9): 2055–2062. doi: 10.11999/JEIT181038ZHANG Gang, ZHAO Changchang, and ZHANG Tianqi. Performance analysis of short reference orthogonal multiuser differential chaotic shift keying scheme[J]. Journal of Electronics &Information Technology, 2019, 41(9): 2055–2062. doi: 10.11999/JEIT181038 TALEB F, BENDIMERAD F T, and ROVIRAS D. Very high efficiency differential chaos shift keying system[J]. IET Communications, 2016, 10(17): 2300–2307. doi: 10.1049/iet-com.2016.0411 KADDOUM G, RICHARDSON F D, and GAGNON F. Design and analysis of a multi-carrier differential chaos shift keying communication system[J]. IEEE Transactions on Communications, 2013, 61(8): 3281–3291. doi: 10.1109/TCOMM.2013.071013.130225 張剛, 郝怡曼, 張?zhí)祢U. 短參倍速差分混沌鍵控系統[J]. 系統工程與電子技術, 2018, 40(1): 184–190. doi: 10.3969/j.issn.1001-506X.2018.01.27ZHANG Gang, HAO Yiman, and ZHANG Tianqi. Short reference multifold rate differential chaos shift keying[J]. Systems Engineering and Electronics, 2018, 40(1): 184–190. doi: 10.3969/j.issn.1001-506X.2018.01.27 CAI Guofa, WANG Lin, and CHEN Guanrong. Capacity of the non-coherent DCSK system over Rayleigh fading channel[J]. IET Communications, 2016, 10(18): 2663–2669. doi: 10.1049/iet-com.2016.0487 -
