浮點數比較分支的混淆方法研究

耿普,  祝躍飛

耿普, 祝躍飛. 浮點數比較分支的混淆方法研究[J]. 電子與信息學報, 2020, 42(12): 2857-2864. doi: 10.11999/JEIT190743
引用本文: 耿普, 祝躍飛. 浮點數比較分支的混淆方法研究[J]. 電子與信息學報, 2020, 42(12): 2857-2864. doi: 10.11999/JEIT190743
Pu GENG, Yuefei ZHU. An Branch Obfuscation Research on Path Branch Which Formed by Floating-point Comparison[J]. Journal of Electronics & Information Technology, 2020, 42(12): 2857-2864. doi: 10.11999/JEIT190743
Citation: Pu GENG, Yuefei ZHU. An Branch Obfuscation Research on Path Branch Which Formed by Floating-point Comparison[J]. Journal of Electronics & Information Technology, 2020, 42(12): 2857-2864. doi: 10.11999/JEIT190743

浮點數比較分支的混淆方法研究

doi: 10.11999/JEIT190743

  • 信息工程大學 鄭州 450002

基金項目: 國家重點研發計劃(2016YFB0801601, 2016YFB0801505)
詳細信息
    作者簡介:

    耿普：男，1982年生，博士生，研究方向為信息安全

    祝躍飛：男，1962年生，教授、博士生導師，研究方向為網絡空間安全

    通訊作者:

    耿普　23015636@qq.com

  • 中圖分類號: TP311

An Branch Obfuscation Research on Path Branch Which Formed by Floating-point Comparison

  • Information Engineering University, Zhengzhou 450002, China

Funds: The National Key R&D Program of China (2016YFB0801601, 2016YFB0801505)
  • 摘要:

    針對當前分支混淆方法僅對整數比較分支有效的缺陷，該文分析浮點數二進制表示與大小比較的關系，證明了浮點數二進制區間的前綴集合與浮點數區間內數據之間具有前綴匹配關系。使用哈希函數對前綴集合進行保護，利用哈希函數的單向性實現對抗符號執行，通過哈希值比對替換浮點數比較，提出一種基于前綴哈希值比較的分支條件混淆技術，實現了一種在符號執行對抗和混淆還原對抗上具有較強對抗性的混淆方法。最后，通過實驗證和分析，證實了該文提出的混淆方法有消耗小、能夠有效對抗符號執行和混淆還原的優點，具備較好的實用性。

    Abstract:

    For the faultiness that the recent branch obfuscation method is only efficient on branch condition formed by integer comparison. The relations between the binary representation and big or small comparison of floats are analyzed. The idea that the floats in float interval has prefix matching relation with the prefix set which comes from the binary representation interval of the floats is proved. By protecting the prefix set with Hash function, and based on the comparison of prefix-Hash, a new branch obfuscation method which works well on the branch formed by float number comparison is proposed. The new obfuscation method is powerful on symbolic execution combating and obfuscation recovery combating. At last, the obfuscation proposed in this paper is confirmed to be practical, and is useful to be against symbolic execution and obfuscation recovery.

    • HTML全文

  • 圖  1  浮點數IEEE 754標準存儲示意圖

    圖  2  浮點數比較分支的混淆示意圖

    　算法1 前綴算法
    　輸入：a1a2···an//起始值a的二進制表示
    　　　　b1b2···bn//結束值b的二進制表示
    　輸出：PrefixSet//區間的前綴集合
    　PrefixSet Get_Prefix(a1a2···an，b1b2···bn)
    　{
    　　for (int k=1; (k<=n) && (ak==bk); k++)
    　　{
    　　　if (k==(n+1))
    　　　　return { a1a2···an};
    　　}
    　　if ((akak+1···an == 00···0) && (bkbk+1···bn == 11···1))
    　　{
    　　　if (k== 1)
    　　　　return {*};
    　　　else
    　　　　return {a1a2···ak-1};
    　　}
    　　PrefixSet1 = Get_Prefix(ak+1ak+2···an, 11···1);
    　　PrefixSet2 = Get_Prefix(00···0, bk+1bk+2···bn);
    　　Return {a1a2···ak-10+PrefixSet1, a1a2···ak－11+PrefixSet2};
    　}
    下載: 導出CSV
    　算法2：isMatch(x, HS) //判斷輸入為x時，分支條件的取值，算
    　法返回值為true或者false
    　輸入：浮點數x，浮點數區間[a, b]對應二進制前綴集合的sha1集
    　合HS1和HS2
    　輸出：x是否屬于浮點數區間[a,b]
    　bool isMatch(x,HS1,HS2)
    　{ char tmp[32] = {‘*’,‘*’,···,‘*’};
    　　　int Ix= *((int *)&x); char sha1out[32][24];
    　　　char sign = (Ix>>(31-i))&1; tmp[0] = sign;
    　　　for(int i=1; i<32; i++){
    　　　　tmp[i]=(Ix>>(31-i))&1; sha1out[i]=sha1(tmp,32);
    　　　　char sign = tmp[0];
    　　　　if(sign == 0)
    　　　　{for(int j=0; j<hashNumofHS1;j++)
    　　　　{ if(sha1out[i]==HS1[j]) return true; }
    　　　　}
    　　　　else if(sign == 1)
    　　　　{for(int j=0; j<hashNumofHS2;j++)
    　　　　　{ if(sha1out[i]==HS2[j]) return true; }
    　　　　}
    　　　}
    　　　return false;}
    下載: 導出CSV

    表  1  單分支混淆的消耗數據表

    分支條件空間消耗(Byte)時間消耗
    解密后前綴數據空間Sha1算法代碼空間isMatch算法代碼空間
    if(1.0≤x ≤10.0)混淆后變?yōu)椋篿f(isMatch(x, HS1))4×20=8026844680.033
    if((x ≤1.0)||((y>10.0)&&(1.0≤z ≤10.0))) 混淆后變?yōu)椋篿f(isMatch(x,HS2)||(isMatch (y,HS3) && isMatch(z,HS4)))(9+8+4)×20=44026844680.102
    注釋：(1) 空間消耗中，只有前綴數據占用空間是每個分支混淆需要獨占的，其余空間是所有分支混淆共享的空間。(2) HS1, HS2, HS3和HS4表示前綴數據的哈希值集合。
    下載: 導出CSV

    表  2  分支混淆前后程序占用空間和執行時間數據表

    混淆前的數據處理程序混淆后的數據處理程序
    占用空間(Byte)3737641472
    執行時間235.6
    被混淆分支數(個)1
    分支執行次數(次)1000
    下載: 導出CSV

    表  3  混淆方法執行效率比較

    混淆方法單分支單次執行平均時間消耗單分支混淆空間消耗(Byte)實驗主機分支類型
    本文方法0.0334×103CPU為Intel I5的主機浮點數比較
    王志方法0.0314×103CPU為Intel I5的主機整數大小比較
    王志方法(11312-1442.7)/(3×10000)=0.3294×103CPU為Intel Core2 Q9400的主機整數大小比較
    陳喆方法2209.8×104CPU為Intel Core2 Q9400的主機整數大小比較
    Ma方法7507×103CPU為Intel Core2 Q9400的主機整數大小比較
    下載: 導出CSV

    表  4  混淆分支的符號執行測試結果

    利用符號執行的程序分析工具執行時間結果
    Angr80求解出使得isMatch返回值為真的分支輸入值的解個數為0
    KLEE360共執行593906條指令和 118個分支執行，但求解出使得isMatch返回值為真的分支輸入值的解個數為0
    下載: 導出CSV
  • Software Management: Security imperative, business opportunity —2018 BSA global software survey. Washington[OL]. https://ww2.bsa.org/-/media/Files/StudiesDownload/2018_BSA_GSS_Report_cn.pdf. 2018.
    梁光輝, 龐建民, 單征. 基于代碼進化的惡意代碼沙箱規避檢測技術研究[J]. 電子與信息學報, 2019, 41(2): 341–347. doi: 10.11999/JEIT180257

    LIANG Guanghu, PANG Jianmin, and SHAN Zheng. Malware sandbox evasion detection based on code evolution[J]. Journal of Electronics &Information Technology, 2019, 41(2): 341–347. doi: 10.11999/JEIT180257
    COLLBERG C, THOMBORSON C, and LOW D. A taxonomy of obfuscating transformations[R]. Technical Report 148, 1997.
    張躍軍, 潘釗, 汪鵬君, 等. 基于狀態映射的AES算法硬件混淆設計[J]. 電子與信息學報, 2018, 40(3): 750–757. doi: 10.11999/JEIT170556

    ZHANG Yuejun, PAN Zhao, WANG Pengjun, et al. Design of hardware obfuscation AES based on state deflection strategy[J]. Journal of Electronics &Information Technology, 2018, 40(3): 750–757. doi: 10.11999/JEIT170556
    POPOV I V, DEBRAY S K, and ANDREWS G R. Binary obfuscation using signals[C]. The 16th USENIX Security Symposium, Boston, USA, 2007: 275–290.
    賈春福, 王志, 劉昕, 等. 路徑模糊: 一種有效抵抗符號執行的二進制混淆技術[J]. 計算機研究與發展, 2011, 48(11): 2111–2119.

    JIA Chunfu, WANG Zhi, LIU Xin, et al. Branch obfuscation: An efficient binary code obfuscation to impede symbolic execution[J]. Journal of Computer Research and Development, 2011, 48(11): 2111–2119.
    SHARIF M, LANZI A, GIFFIN J, et al. Impeding malware analysis using conditional code obfuscation[C]. Network and Distributed System Security Symposium, San Diego, USA, 2008: 321–333.
    WANG Zhi, MING Jiang, JIA Chunfu, et al. Linear obfuscation to combat symbolic execution[C]. The 16th European Symposium on Research in Computer Security, Leuven, Belgium, 2011: 210–226. doi: 10.1007/978-3-642-23822-2_12.
    ZONG Nan and JIA Chunfu. Branch obfuscation using "Black Boxes"[C]. 2014 Theoretical Aspects of Software Engineering Conference, Changsha, China, 2014: 114–121. doi: 10.1109/TASE.2014.19.
    MA Haoyu, MA Xinjie, LIU Weijie, et al. Control flow obfuscation using neural network to fight concolic testing[C]. The 10th International Conference on Security and Privacy in Communication Networks, Beijing, China, 2014: 287–304.
    王志, 賈春福, 劉偉杰, 等. 一種抵抗符號執行的路徑分支混淆技術[J]. 電子學報, 2015, 43(5): 870–878. doi: 10.3969/j.issn.0372-2112.2015.05.006

    WANG Zhi, JIA Chunfu, LIU Weijie, et al. Branch obfuscation to combat symbolic execution[J]. Acta Electronica Sinica, 2015, 43(5): 870–878. doi: 10.3969/j.issn.0372-2112.2015.05.006
    陳喆, 王志, 王曉初, 等. 基于代碼移動的二進制程序控制流混淆方法[J]. 計算機研究與發展, 2015, 52(8): 1902–1909. doi: 10.7544/issn1000-1239.2015.20140607

    CHEN Zhe, WANG Zhi, WANG Xiaochu, et al. Using code mobility to obfuscate control flow in binary codes[J]. Journal of Computer Research and Development, 2015, 52(8): 1902–1909. doi: 10.7544/issn1000-1239.2015.20140607
    陳喆, 賈春福, 宗楠, 等. 隨機森林在程序分支混淆中的應用[J]. 電子學報, 2018, 46(10): 2458–2466. doi: 10.3969/j.issn.0372-2112.2018.10.020

    CHEN Zhe, JIA Chunfu, ZONG Nan, et al. Branch obfuscation using random forest[J]. Acta Electronica Sinica, 2018, 46(10): 2458–2466. doi: 10.3969/j.issn.0372-2112.2018.10.020
    KING J C. Symbolic execution and program testing[J]. Communications of the ACM, 1976, 19(7): 385–394. doi: 10.1145/360248.360252
    崔寶江, 梁曉兵, 王禹, 等. 基于回溯與引導的關鍵代碼區域覆蓋的二進制程序測試技術研究[J]. 電子與信息學報, 2012, 34(1): 108–114. doi: 10.3724/SP.J.1146.2011.00532

    CUI Baojiang, LIANG Xiaobing, WANG Yu, et al. The study of binary program test techniques based on backtracking and leading for covering key code area[J]. Journal of Electronics &Information Technology, 2012, 34(1): 108–114. doi: 10.3724/SP.J.1146.2011.00532
    BANESCU S, COLLBERG C, GANESH V, et al. Code obfuscation against symbolic execution attacks[C]. The 32nd Annual Conference on Computer Security Applications, Los Angeles, USA, 2016: 189–200. doi: 10.1145/2991079.2991114.
    BANESCU S, COLLBERG C, and PRETSCHNER A. Predicting the resilience of obfuscated code against symbolic execution attacks via machine learning[C]. The 26th USENIX Security Symposium, Vancouver, Canada, 2017: 661–678.
    FAN Jinliang, XU Jun, AMMAR M H, et al. Prefix-preserving IP address anonymization: measurement-based security evaluation and a new cryptography-based scheme[J]. Computer Networks, 2004, 46(2): 253–272. doi: 10.1016/j.comnet.2004.03.033
    魏凌波, 馮曉兵, 張馳, 等. 基于前綴保持加密的網絡功能外包系統[J]. 通信學報, 2018, 39(4): 159–166. doi: 10.11959/j.issn.1000-436x.2018057

    WEI Lingbo, FENG Xiaobing, ZHANG Chi, et al. Network function outsourcing system based on prefix-preserving encryption[J]. Journal on Communications, 2018, 39(4): 159–166. doi: 10.11959/j.issn.1000-436x.2018057
