基于混合三角變異差分進化算法的平面稀疏陣列約束優化

陳志坤; 杜康; 彭冬亮; 朱新挺

doi:10.11999/JEIT190705

基于混合三角變異差分進化算法的平面稀疏陣列約束優化

doi: 10.11999/JEIT190705

杭州電子科技大學自動化學院杭州 310018

基金項目: 國家自然科學基金(61701148)

詳細信息

作者簡介:
陳志坤：男，1982年生，博士，講師，研究方向為雷達陣列信號處理與電子偵察

杜康：男，1996年生，碩士生，研究方向為陣列優化與波束形成

彭冬亮：男，1977年生，博士，教授，博士生導師，研究方向為信息融合

朱新挺：男，1996年生，碩士生，研究方向為信號檢測技術

通訊作者:
杜康　dk@hdu.edu.cn

中圖分類號: TN957.2
計量
- 文章訪問數: 2810
- HTML全文瀏覽量: 888
- PDF下載量: 74
- 被引次數: 0
出版歷程
- 收稿日期: 2019-09-10
- 修回日期: 2019-11-28
- 網絡出版日期: 2020-01-11
- 刊出日期: 2020-06-04

Planar Sparse Array Constraint Optimization Based on Hybrid Trigonometric Mutation Differential Evolution Algorithm

School of Automation, Hangzhou Dianzi University, Hangzhou 310018, China

Funds: The National Natural Science Foundation of China (61701148)

摘要

摘要:
針對旁瓣零陷凹面約束的稀疏平面陣列優化及算法早熟等問題，該文基于參數自適應的思想，提出一種混合三角變異差分進化算法。通過引入旁瓣零陷凹面約束矩陣，構建自適應懲罰函數，時變權重組合變異策略與交叉策略，提高算法前期全局搜索能力和后期收斂能力，最終實現峰值旁瓣電平和旁瓣零陷凹面的平面陣列約束優化。仿真結果表明，對比混合三角變異策略前的算法，該算法在完成稀疏陣列峰值旁瓣電平優化的同時，能在指定旁瓣區域完成零陷凹面設計，降低有源干擾影響。
- 稀疏陣列優化 /
- 差分進化算法 /
- 自適應懲罰函數 /
- 旁瓣零陷
Abstract:
For the problems of sparse planar array optimization with side-lobe concave nulls constraints and premature algorithm, a Hybrid Trigonometric Mutation Differential Evolution (HTMDE) algorithm is proposed based on the idea of parameter adaptation. By introducing side-lobe concave nulls constraints matrix, adaptive penalty function is constructed. Time-varying weight combination mutation strategy and crossover strategy improve the initial global search ability and late convergence ability of the algorithm. The constrained optimization of the planar array with peak side lobe level and side-lobe concave nulls is finally realized. The simulation results show that, compared with the algorithm before the hybrid trigonometric mutation strategy, the algorithm not only optimizes the peak side-lobe level of sparse array, but also designs concave nulls in specified side-lobe area to reduce the influence of active interference.
- Sparse array optimization /
- Differential Evolution (DE) algorithm /
- Adaptive penalty function /
- Side lobe nulls

HTML全文

圖 1 稀疏陣列3維方向圖

下載: 全尺寸圖片幻燈片

圖 2 算法收斂曲線對比和稀疏陣元分布

下載: 全尺寸圖片幻燈片

圖 3 可行解比例和$u = 0$比平面方向圖

下載: 全尺寸圖片幻燈片

圖 4 稀疏陣列3維方向圖

下載: 全尺寸圖片幻燈片

圖 5 算法收斂曲線和稀疏陣元分布

下載: 全尺寸圖片幻燈片

圖 6 可行解比例和$u = 0$平面方向圖

下載: 全尺寸圖片幻燈片

表 1 最大零陷深度約束為45時旁瓣零陷凹面增益(c = 1)

序號	1	2	3	4	5	6	7	8	9
$p$	50	50	50	51	51	51	52	52	52
$q$	50	51	52	50	51	52	50	51	52
增益(dB)	–41.7232	–47.8437	–43.4869	–41.2586	–53.0450	–44.7019	–43.8560	–46.1852	–46.9309

下載: 導出CSV

表 2 最大零陷深度約束為50時旁瓣零陷凹面增益(c = 1)

序號	1	2	3	4	5	6	7	8	9
$p$	50	50	50	51	51	51	52	52	52
$q$	50	51	52	50	51	52	50	51	52
增益(dB)	–46.6703	–45.7740	–42.0270	–43.5748	–55.1658	–43.9545	–42.9269	–49.6869	–45.4186

下載: 導出CSV

表 3 最大零陷深度約束為55時旁瓣零陷凹面增益(c = 1)

序號	1	2	3	4	5	6	7	8	9
$p$	50	50	50	51	51	51	52	52	52
$q$	50	51	52	50	51	52	50	51	52
增益(dB)	–46.4656	–47.1974	–43.3241	–47.4544	–58.0909	–43.7558	–55.5215	–48.7782	–45.2064

下載: 導出CSV

表 4 最大零陷深度約束為45時旁瓣零陷凹面增益(c = 2)

序號	1	2	3	4	5	6	7	8	9
p	49	49	49	49	49	50	50	50	50
q	49	50	51	52	53	49	50	51	52
增益(dB)	–46.5458	–45.8412	–46.2580	–40.8917	–40.9214	–49.3585	–55.9305	–47.3353	–42.1900
序號	10	11	12	13	14	15	16	17	18
p	50	51	51	51	51	51	52	52	52
q	53	49	50	51	52	53	49	50	51
增益(dB)	–42.6126	–43.5500	–51.2554	–49.3633	–44.1652	–43.3289	–44.5767	–60	–60
序號	19	20	21	22	23	24	25
p	52	52	53	53	53	53	53
q	52	53	49	50	51	52	53
增益(dB)	–45.5003	–42.0649	–46.5876	–45.0475	–48.2879	–44.7265	–41.0207

下載: 導出CSV

表 5 最大零陷深度約束為50時旁瓣零陷凹面增益(c = 2)

序號	1	2	3	4	5	6	7	8	9
p	49	49	49	49	49	50	50	50	50
q	49	50	51	52	53	49	50	51	52
增益(dB)	–37.6175	–40.3846	–45.7498	–48.2500	–43.6255	–36.8799	–41.7660	–49.6858	–45.8806
序號	10	11	12	13	14	15	16	17	18
p	50	51	51	51	51	51	52	52	52
q	53	49	50	51	52	53	49	50	51
增益(dB)	–41.8181	–37.2718	–43.5080	–60	–45.8777	–39.6356	–39.5716	–45.9265	–60
序號	19	20	21	22	23	24	25
$p$	52	52	53	53	53	53	53
$q$	52	53	49	50	51	52	53
增益(dB)	–47.8587	–39.4033	–43.4406	–50.7166	–60	–51.4716	–40.3799

下載: 導出CSV

表 6 最大零陷深度約束為55時旁瓣零陷凹面增益(c = 2)

序號	1	2	3	4	5	6	7	8	9
p	49	49	49	49	49	50	50	50	50
q	49	50	51	52	53	49	50	51	52
增益(dB)	–44.8401	–46.0399	–39.5838	–38.3594	–45.4208	–54.4196	–59.5659	–43.2692	–43.0806
序號	10	11	12	13	14	15	16	17	18
p	50	51	51	51	51	51	52	52	52
q	53	49	50	51	52	53	49	50	51
增益(dB)	–51.9257	–41.3720	–45.5307	–55.5682	–49.6248	–40.8617	–36.9498	–40.1514	–48.4430
序號	19	20	21	22	23	24	25
$p$	52	52	53	53	53	53	53
$q$	52	53	49	50	51	52	53
增益(dB)	–43.0303	–37.3386	–35.2466	–38.9316	–46.3749	–42.4130	–37.3552

下載: 導出CSV

參考文獻(13)

CHEN Kesong, CHEN Hui, WANG Ling, et al. Modified real GA for the synthesis of sparse planar circular arrays[J]. IEEE Antennas and Wireless Propagation Letters, 2016, 15: 274–277. doi: 10.1109/LAWP.2015.2440432

DAI Dingcheng, YAO Minli, MA Hongguang, et al. An effective approach for the synthesis of uniformly excited large linear sparse array[J]. IEEE Antennas and Wireless Propagation Letters, 2018, 17(3): 377–380. doi: 10.1109/LAWP.2018.2790907

LIU Heng, ZHAO Hongwei, LI Weimei, et al. Synthesis of sparse planar arrays using matrix mapping and differential evolution[J]. IEEE Antennas and Wireless Propagation Letters, 2016, 15: 1905–1908. doi: 10.1109/LAWP.2016.2542882

欒曉明, 尚興榮. 稀布同心圓環陣列聯合優化設計[J]. 戰術導彈技術, 2017(3): 92–97. doi: 10.16358/j.issn.1009-1300.2017.03.16

LUAN Xiaoming and SHANG Xingrong. Joint optimization design of sparse concentric ring arrays[J]. Tactical Missile Technology, 2017(3): 92–97. doi: 10.16358/j.issn.1009-1300.2017.03.16

KURUP D G, HIMDI M, and RYDBERG A. Synthesis of uniform amplitude unequally spaced antenna arrays using the differential evolution algorithm[J]. IEEE Transactions on Antennas and Propagation, 2003, 51(9): 2210–2217. doi: 10.1109/TAP.2003.816361

趙光權, 彭喜元, 孫寧. 基于混合優化策略的微分進化改進算法[J]. 電子學報, 2006, 34(12A): 2402–2405.

ZHAO Guangquan, PENG Xiyuan, and SUN Ning. A modified differential evolution algorithm with hybrid optimization strategy[J]. Acta Electronica Sinica, 2006, 34(12A): 2402–2405.

FAN Huiyuan and LAMPINEN J. A trigonometric mutation operation to differential evolution[J]. Journal of Global Optimization, 2003, 27(1): 105–129. doi: 10.1023/A:1024653025686

喬俊飛, 傅嗣鵬, 韓紅桂. 基于混合變異策略的改進差分進化算法及函數優化[J]. 控制工程, 2013, 20(5): 943–947. doi: 10.14107/j.cnki.kzgc.2013.05.030

QIAO Junfei, FU Sipeng, and HAN Honggui. A modified differential evolution algorithm based on hybrid mutation strategy for function optimization[J]. Control Engineering of China, 2013, 20(5): 943–947. doi: 10.14107/j.cnki.kzgc.2013.05.030

SHPAK D J. A method for the optimal pattern synthesis of linear arrays with prescribed nulls[J]. IEEE Transactions on Antennas and Propagation, 1996, 44(3): 286–294. doi: 10.1109/8.486295

FARMANI R and WRIGHT J A. Self-adaptive fitness formulation for constrained optimization[J]. IEEE Transactions on Evolutionary Computation, 2003, 7(5): 445–455. doi: 10.1109/TEVC.2003.817236

劉波, 王凌, 金以慧. 差分進化算法研究進展[J]. 控制與決策, 2007, 22(7): 721–729. doi: 10.13195/j.cd.2007.07.3.liub.001

LIU Bo, WANG Ling, and JIN Yihui. Advances in differential evolution[J]. Control and Decision, 2007, 22(7): 721–729. doi: 10.13195/j.cd.2007.07.3.liub.001

蔡海鸞, 郭學萍. 一種新的自適應懲罰函數在遺傳算法中的應用[J]. 華東師范大學學報: 自然科學版, 2015(6): 36–45, 52.

CAI Hailuan and GUO Xueping. A new adaptive penalty function in the application of genetic algorithm[J]. Journal of East China Normal University:Natural Science, 2015(6): 36–45, 52.

DAS S, KONAR A, and CHAKRABORTY U K. Two improved differential evolution schemes for faster global search[C]. The 7th Annual Conference on Genetic and Evolutionary Computation, Washington, USA, 2005: 991–998. doi: 10.1145/1068009.1068177.
