基于干擾信號帶外分量卷積反演的鄰道干擾抑制

霍曉磊; 趙宏志; 劉穎; 李曉輝; 王欣; 唐友喜

doi:10.11999/JEIT190704

基于干擾信號帶外分量卷積反演的鄰道干擾抑制

doi: 10.11999/JEIT190704

霍曉磊^{1, 2},
趙宏志^1, ,,
劉穎¹,
李曉輝²,
王欣²,
唐友喜¹

1.
電子科技大學通信抗干擾技術國家級重點實驗室成都 611731
2.
陸軍工程大學石家莊校區電子與光學工程系石家莊 050003

基金項目: 國家自然科學基金(61771107, 61701075, 61601064, 61531009)，國家重點研發計劃(2018YFB1801903)，四川科技計劃(2019JDRC0006)

詳細信息

作者簡介:
霍曉磊：男，1980年生，博士生，主要研究方向?yàn)闊o線信號處理、通信抗干擾技術

趙宏志：男，1978年生，教授，博士生導師，主要研究方向?yàn)橥ㄐ趴垢蓴_技術、并行化信號處理

劉穎：男，1985年生，講師，主要研究方向?yàn)閿?shù)字預失真、無線信號處理

李曉輝：男，1978年生，講師，主要研究方向?yàn)闊o線通信技術、指揮控制系統

王欣：女，1983年生，講師，主要研究方向?yàn)橹笓]控制系統、通信抗干擾技術

唐友喜：男，1964年生，教授，博士生導師，主要研究方向?yàn)樾盘柼幚?、傳感器網絡

通訊作者:
趙宏志　lyn@uestc.edu.cn

中圖分類號: TN92
計量
- 文章訪問數: 3512
- HTML全文瀏覽量: 970
- PDF下載量: 99
- 被引次數: 0
出版歷程
- 收稿日期: 2019-09-10
- 修回日期: 2020-02-28
- 網絡出版日期: 2020-04-07
- 刊出日期: 2020-10-13

Adjacent Channel Interference Suppression Based on Deconvolution of Interference Signal’s Out-of-band Component

1.
National key Laboratory of Science and Technology on Communications, University of Electronic Science and Technology of China, Chengdu 611731, China
2.
Department of Electronic and Optical Engineering, Shijiazhuang Campus of Army Engineering University, Shijiazhuang 050003, China

Funds: The National Natural Science Foundation of China (61771107, 61701075, 61601064, 61531009), The National Key R&D Program of China (2018YFB1801903), Sichuan Science and Technology Program (2019JDRC0006)

摘要

摘要: 鄰道干擾(ACI)抑制中需要獲取干擾信號非線性特征進行信號重建與抵消，因此接收機需使用高速率寬帶模數轉換器(ADC)采集干擾信號，這將大幅增加接收機成本。針對上述問題，該文提出一種采用干擾信號帶外分量卷積反演的鄰道干擾抑制方法，利用接收的干擾信號帶外非線性分量，計算并消除相鄰幀之間的影響，由窄帶部分卷積信號幀構造出線性卷積信號幀，然后用正則化最小二乘方法恢復原始非線性寬帶干擾信號，從而降低ADC采樣率。仿真驗證結果表明當采樣率僅為傳統方案1/3，所提方法帶來的殘余干擾不高于底噪6 dB。
- 無線通信 /
- 鄰道干擾 /
- 干擾抑制 /
- 卷積反演 /
- 信號恢復
Abstract: In Adjacent Channel Interference (ACI) suppression, in order to obtain the nonlinear characteristics of interference signal for reconstruction and cancellation, the receiver needs to use high-sampling-rate wideband Analog-to-Digital Converter (ADC) to sample interference signal, which will greatly increase the cost of the receiver. To solve the problem, a ACI suppression method based on deconvolution of interference signal’s out-of-band component is proposed in this paper. By using the known out-of-band nonlinear component, the influence between adjacent frames is calculated and eliminated, and then the narrow band linear convolution frame is constructed from the partial convolution frame. Finally, the original wide band signal is recovered by regularized least square method, thus reducing the ADC sampling rate. The simulation results show that when the sampling rate is only 1/3 of the traditional scheme, the residual interference brought by the proposed method is not higher than the noise floor of 6 dB.
- Wireless communication /
- Adjacent Channel Interference (ACI) /
- Interference suppression /
- Deconvolution /
- Signal recovery

HTML全文

圖 1 卷積反演架構鄰道干擾抑制接收機

下載: 全尺寸圖片幻燈片

圖 2 卷積反演電路框圖

下載: 全尺寸圖片幻燈片

圖 3 卷積反演信號頻譜示意圖

下載: 全尺寸圖片幻燈片

圖 4 輸入鄰道干擾INR同信號恢復誤差的關系

下載: 全尺寸圖片幻燈片

圖 5 INR為40 dB時反演信號及殘余干擾頻譜

下載: 全尺寸圖片幻燈片

圖 6 INR為60 dB時反演信號及殘余干擾頻譜

下載: 全尺寸圖片幻燈片

圖 7 接收信號INR同鄰道干擾抑制能力關系

下載: 全尺寸圖片幻燈片

表 1 仿真實驗參數設置

項目指標	參數值
信號幀長	2.56 ms
信號帶寬	25 kHz
濾波器階數	60
采樣頻率	125 kHz
阻帶頻率1/通帶頻率1	20/30 kHz
通帶頻率2/阻帶頻率2	50/60 kHz
阻帶衰減	50 dB

下載: 導出CSV

表 2 仿真系統參數設置

項目指標	參數值
信號帶寬	25 kHz
信道帶寬	50 kHz
發射功率	18 dBm
干擾信號SNR	70～110 dB
鄰道干擾INR	40～80 dB

下載: 導出CSV

參考文獻(20)

ZHOU Ping, LU Yinghua, TAO Yong, et al. Simulation analysis on co-site interference of vehicular digital communication system based on IM prediction method by BER[J]. The Journal of China Universities of Posts and Telecommunications, 2016, 23(1): 31–41. doi: 10.1016/S1005-8885(16)60005-5

HAN Ting, HAN Bingjun, ZHANG Lin, et al. Coexistence study for wifi and zigbee under smart home scenarios[C]. IEEE International Conference on Network Infrastructure and Digital Content, Beijing, China, 2012: 669-674. doi: 10.1109/ICNIDC.2012.6418840.

IEEE. IEEE 802.11-2007 Wireless LAN medium access control (MAC) and physical layer (PHY) specifications[S]. IEEE, 2007.

NIKITIN A V, DAVIDCHACK R L, and SMITH J E. Out-of-band and adjacent-channel interference reduction by analog nonlinear filters[J]. EURASIP Journal on Advances in Signal Processing, 2015, 2015(1): 12. doi: 10.1186/s13634-015-0202-5

劉建成, 全厚德, 孫慧賢, 等. 近距離無線電臺鄰道干擾的功率譜解析[J]. 電訊技術, 2017, 57(3): 306–310. doi: 10.3969/j.issn.1001-893x.2017.03.010

LIU Jiancheng, QUAN Houde, SUN Huixian, et al. Power spectrum resolution of adjacent channel interference for collocated wireless radios[J]. Telecommunication Engineering, 2017, 57(3): 306–310. doi: 10.3969/j.issn.1001-893x.2017.03.010

武南開, 蘇東林, 何洪濤, 等. 機載超短波電臺鄰道干擾減敏特性建模與評估[J]. 北京航空航天大學學報, 2017, 43(3): 481–487. doi: 10.13700/j.bh.1001-5965.2016.0230

WU Nankai, SU Donglin, HE Hongtao, et al. Adjacent channel interference modeling and assessment on reduction of airborne VHF radio sensitivity[J]. Journal of Beijing University of Aeronautics and Astronautics, 2017, 43(3): 481–487. doi: 10.13700/j.bh.1001-5965.2016.0230

XUE Zhen, WANG Jinlong, SHI Qingjiang, et al. Time-frequency scheduling and power optimization for reliable multiple UAV communications[J]. IEEE Access, 2018, 6: 3992–4005. doi: 10.1109/ACCESS.2018.2790933

霍曉磊, 趙宏志, 劉穎, 等. 基于抵消技術的鄰道干擾抑制[J]. 系統工程與電子技術, 2019, 41(11): 2611–2618.

HUO Xiaolei, ZHAO Hongzhi, LIU Ying, et al. Adjacent channel interference suppression based on cancellation technology[J]. Systems Engineering and Electronics, 2019, 41(11): 2611–2618.

ROBLIN P, QUINDROIT C, NARAHARISETTI N, et al. Concurrent linearization: The state of the art for modeling and linearization of multiband power amplifiers[J]. IEEE Microwave Magazine, 2013, 14(7): 75–91. doi: 10.1109/MMM.2013.2281297

LIU Ying, HUANG Chuang, QUAN Xin, et al. Novel linearization architecture with limited ADC dynamic range for green power amplifiers[J]. IEEE Journal on Selected Areas in Communications, 2016, 34(12): 3902–3914. doi: 10.1109/JSAC.2016.2600415

LIU Ying, PAN Wensheng, SHAO Shihai, et al. A new digital predistortion for wideband power amplifiers with constrained feedback bandwidth[J]. IEEE Microwave and Wireless Components Letters, 2013, 23(12): 683–685. doi: 10.1109/LMWC.2013.2284786

MA Yuelin, YAMAO Y, AKAIWA Y, et al. Wideband digital predistortion using spectral extrapolation of band-limited feedback signal[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2014, 61(7): 2088–2097. doi: 10.1109/TCSI.2013.2295897

PAN Wensheng, LIU Ying, SHAO Shihai, et al. A method to reduce sampling rate of the ADC in feedback channel for wideband digital predistortion[J]. Circuits, Systems, and Signal Processing, 2014, 33(8): 2655–2665. doi: 10.1007/s00034-014-9751-3

LIU Ying, PAN Wensheng, SHAO Shihai, et al. A general digital predistortion architecture using constrained feedback bandwidth for wideband power amplifiers[J]. IEEE Transactions on Microwave Theory and Techniques, 2015, 63(5): 1544–1555. doi: 10.1109/TMTT.2015.2416184

YU Xin. Digital predistortion using feedback signal with incomplete spectral information[C]. 2012 Asia Pacific Microwave Conference, Kaohsiung, China, 2012: 950–952. doi: 10.1109/APMC.2012.6421788.

鄒謀炎. 反卷積和信號復原[M]. 北京: 國防工業出版社, 2001: 10-160.

ZOU Mouyan. Deconvolution and Signal Recovery[M]. Beijing: National Defense Industry Press, 2001: 10-160.

HANSEN P C. Analysis of discrete ill-posed problems by means of the L-curve[J]. SIAM Review, 1992, 34(4): 561–580. doi: 10.1137/1034115

GOLUB G H, HEATH M, and WAHBA H G. Generalized cross-validation as a method for choosing a good ridge parameter[J]. Technometrics, 1979, 21(2): 215–223. doi: 10.1080/00401706.1979.10489751

HANSEN P C. REGULARIZATION TOOLS: A matlab package for analysis and solution of discrete ill-posed problems[J]. Numerical Algorithms, 1994, 6(1): 1–35. doi: 10.1007/BF02149761

DING Lei, ZHOU G T, MORGAN D R, et al. A robust digital baseband predistorter constructed using memory polynomials[J]. IEEE Transactions on Communications, 2004, 52(1): 159–165. doi: 10.1109/TCOMM.2003.822188
