一種軟判決下的RS碼識別算法

吳昭軍; 張立民; 鐘兆根; 劉傳輝

doi:10.11999/JEIT190690

一種軟判決下的RS碼識別算法

doi: 10.11999/JEIT190690

1.
海軍航空大學信息融合研究所煙臺 264001
2.
海軍航空大學航空基礎學院煙臺 264001

基金項目: 國家自然科學基金(61179016)；泰山學者工程專項(ts201511020)

詳細信息

作者簡介:
吳昭軍：男，1992年生，博士生，研究方向?yàn)樾诺谰幋a識別

張立民：男，1966年生，教授，博士生導師，研究方向?yàn)樾l(wèi)星信號處理及應用

鐘兆根：男，1984年生，博士，講師，研究方向?yàn)閿U(kuò)頻信號處理

劉傳輝：男，1984年生，博士，講師，研究方向?yàn)楹娇胀ㄐ畔到y(tǒng)與網絡

通訊作者:
張立民　iamzlm@163.com

中圖分類號: TN911.7
計量
- 文章訪問數: 3162
- HTML全文瀏覽量: 867
- PDF下載量: 64
- 被引次數: 0
出版歷程
- 收稿日期: 2019-09-05
- 修回日期: 2020-04-16
- 網絡出版日期: 2020-04-23
- 刊出日期: 2020-09-27

Blind Recognition of RS Codes Based on Soft Decision

1.
Department of Information Fusion, Naval Aviation University, Yantai 264001, China
2.
School of Aviation Basis, Naval Aviation University, Yantai 264001, China

Funds: The National Natural Science Foundation of China (61179016), The Taishan Scholar Special Foundation (ts201511020)

摘要

摘要: 針對現有RS碼識別算法需要對碼字符號在不同域之間進行轉化，且容錯性能較差的問題，該文提出一種直接利用軟判決序列完成RS碼識別算法。算法首先從RS碼定義出發，給出了RS碼校驗關系從GF(2^m)到GF(2)上的等價轉換方式，從而避免了不同域下復雜的符號轉化；其次引入了能夠衡量校驗關系成立大小的平均校驗符合度概念，然后基于其統計特性以及極大極小判決準則，遍歷可能的碼長以及對應的m級本原多項式，進行初始碼根校驗匹配，從而完成碼長以及本原多項式識別；最后利用識別出的碼長以及本原多項式，構建本原多項式下GF(2^m)，進行連續碼根匹配判決，最終完成碼生成多項式識別。仿真結果表明：推導的平均校驗符合度統計特性與實際情況一致，算法能在低信噪比下有效完成參數識別；同時該算法具有較好的低信噪比適應能力，在信噪比為6 dB條件下，工程中常見的RS碼識別率均能達到90%以上。與現有算法相比，該文算法性能明顯好于硬判決算法，且比傳統算法提升1 dB以上性能。
- RS碼 /
- 軟判決 /
- 平均校驗符合度 /
- 極大極小準則 /
- 碼根匹配
Abstract: To solve the problem that the existing algorithms for recognition of RS codes need to transform the code characters among different domains and poor performance, a new algorithm based on soft decision is proposed. Firstly, starting from the definition of RS codes, the equivalent conversion mode of the check relation of RS code from GF (2^m) to GF (2) is given, which avoids the complex symbol transformation in different domains. Secondly, the average check conformity which can measure the validity of the check relationship is introduced and based on its statistical characteristics and minimax decision criteria, the possible code length and corresponding m-level primitive polynomials are traversed to match the initial code root, as the results, the code length and primitive polynomial are recognized. Finally, under the identified code length and the primitive polynomial, the GF (2^m) is constructed, and the continuous code root matching decision is made, then the generation polynomial is recognized. The simulation results show that the derived statistical characteristics of the average check conformity are consistent with the actual situation, and the proposed algorithm can effectively recognize parameter under low Signal-to-Noise Ratio (SNR). At the same time, the proposed algorithm has good adaptability to low SNR. At SNR of 6 dB, the recognition rate of common RS codes in engineering can reach more than 90%. Compared with the existing methods, the performance of this algorithm is better than hard-decision algorithm, besides, it is improved by more than 1 dB compared by traditional algorithms.
- RS code /
- Soft decision /
- Average check conformity /
- Minimax criterion /
- Code root matching

HTML全文

圖 1 校驗符合度統計特性對比

下載: 全尺寸圖片幻燈片

圖 2 碼長對算法識別性能影響

下載: 全尺寸圖片幻燈片

圖 3 碼塊數目對算法影響

下載: 全尺寸圖片幻燈片

圖 4 5種算法對比

下載: 全尺寸圖片幻燈片

表 1 RS碼編碼器參數設定

m	碼長	本原多項式	生成多項式	H₁下測試元素	H₀下測試元素
4	15	x⁴+x+1	${\alpha ^3}{x^4} + {\alpha ^{11}}{x^3} + {\alpha ^{14}}{x^2} + {\alpha ^6}x + {\alpha ^8}$	${\alpha ^2}$	${\alpha ^5}$
5	31	x⁵+x²+1	${\alpha ^4}{x^2} + {\alpha ^{20}}x + \alpha $	$\alpha $	${\alpha ^3}$
6	63	x⁶+x+1	${\alpha ^5}{x^4} + {\alpha ^{19}}{x^3} + {\alpha ^{36}}{x^2} + {\alpha ^{14}}x + {\alpha ^{58}}$	${\alpha ^3}$	${\alpha ^6}$

下載: 導出CSV

表 2 不同碼長的RS碼編碼器參數

m	碼長	本原多項式	生成多項式	糾錯能力
4	15	x⁴+x+1	${\alpha ^3}{x^4} + {\alpha ^{11}}{x^3} + {\alpha ^{14}}{x^2} + {\alpha ^6}x + {\alpha ^8}$	2
5	31	x⁵+x²+1	${\alpha ^4}{x^4} + {\alpha ^{23}}{x^3} + {\alpha ^{13}}{x^2} + {\alpha ^{18}}x + {\alpha ^{25}}$	2
6	63	x⁶+x+1	${\alpha ^5}{x^4} + {\alpha ^{19}}{x^3} + {\alpha ^{36}}{x^2} + {\alpha ^{14}}x + {\alpha ^{58}}$	2
7	127	x⁷+x+1	${\alpha ^6}{x^4} + {\alpha ^{23}}{x^3} + {\alpha ^{69}}{x^2} + {\alpha ^{18}}x + {\alpha ^{123}}$	2
8	255	x⁸+x⁴+x³+x²+1	${\alpha ^7}{x^4} + {\alpha ^{78}}{x^3} + {\alpha ^{248}}{x^2} + {\alpha ^{73}}x + {\alpha ^{252}}$	2

下載: 導出CSV
