基于子孔徑Keystone變換的曲線軌跡大斜視SAR回波模擬

李根; 馬彥恒; 侯建強; 徐公國

doi:10.11999/JEIT190674

基于子孔徑Keystone變換的曲線軌跡大斜視SAR回波模擬

doi: 10.11999/JEIT190674

1.
陸軍工程大學石家莊校區無人機工程系石家莊 050003
2.
陸軍工程大學石家莊校區電子與光學工程系石家莊 050003

詳細信息

作者簡介:
李根：男，1991年生，博士生，主要從事機動平臺大斜視SAR成像和壓縮感知雷達成像研究

馬彥恒：男，1968年生，教授，博士生導師，主要從事機動SAR成像、低小慢目標探測等方向的研究

侯建強：男，1991年生，博士生，主要從事曲線SAR 3維成像研究

徐公國：男，1990年生，博士生，主要從事雷達信號處理與傳感器融合研究

通訊作者:
李根　radarlg@163.com

中圖分類號: TN958
計量
- 文章訪問數: 2355
- HTML全文瀏覽量: 852
- PDF下載量: 76
- 被引次數: 0
出版歷程
- 收稿日期: 2019-09-03
- 修回日期: 2020-05-29
- 網絡出版日期: 2020-06-04
- 刊出日期: 2020-09-27

Sub-aperture Keystone Transform Based Echo Simulation Method for High-squint SAR with a Curve Trajectory

1.
Department of UAV Engineering, Army Engineering University Shijiazhuang Campus, Shijiazhuang 050003, China
2.
Department of Electronic and Optical Engineering, Army Engineering University Shijiazhuang Campus, Shijiazhuang 050003, China

摘要

摘要: 大機動條件下的曲線軌跡大斜視SAR系統傳遞函數具有復雜的多維空變性，現有的高效頻域回波模擬算法均難以實現擴展場景的高精度回波模擬。為此，該文提出一種基于子孔徑Keystone變換的機動SAR回波模擬方法。該方法根據距離徙動校正后的距離壓縮函數對場景的距離壓縮回波進行快速模擬，然后通過高精度的距離向逆處理實現擴展場景的回波模擬。為減少殘余距離徙動對回波模擬精度的影響，距離向處理過程中采用子孔徑Keystone變換的方法實現空變距離徙動的精確校正。理論分析和仿真結果表明，所提方法能夠快速高精度地模擬擴展場景的機動平臺大斜視SAR原始回波數據。
- SAR /
- 回波模擬 /
- 曲線軌跡 /
- 子孔徑Keystone變換
Abstract: The system transfer function of high-squint SAR system with curved trajectory has complex multi-dimensional spatial variability. The existing efficient frequency-domain echo simulation algorithms are difficult to achieve high-precision echo simulation of extended scenes. Therefore, a fast echo simulation method based on sub-aperture Keystone transform is proposed for maneuvering SAR. Based on the time-domain range compression function after range cell migration correction, the method calculates efficiently the range compression echo of scene, and then realizes the echo simulation of extended scene by high precision range inverse processing. In order to reduce the influence of residual range cell migration on the accuracy of echo simulation, the method of the Keystone transform of sub-aperture is used in range processing to achieve accurate correction of space-variant range cell migration in extended scenes. The theoretical analysis and simulation results show that the proposed method can quickly and accurately simulate the original echo data of extended scenes for high-squint SAR mounted on a maneuvering platform.
- SAR /
- Echo simulation /
- Curve trajectory /
- Sub-aperture Keystone transform

HTML全文

圖 1 曲線軌跡SAR成像幾何模型

下載: 全尺寸圖片幻燈片

圖 2 距離向處理流程

下載: 全尺寸圖片幻燈片

圖 3 曲線軌跡大斜視SAR回波模擬流程圖

下載: 全尺寸圖片幻燈片

圖 4 距離壓縮信號的截取對ISLR的影響

下載: 全尺寸圖片幻燈片

圖 5 多倍子孔徑拼接下β對方位向測量指標的影響

下載: 全尺寸圖片幻燈片

圖 6 散射點的分布示意圖和成像結果

下載: 全尺寸圖片幻燈片

圖 7 面目標回波仿真效果分析

下載: 全尺寸圖片幻燈片

圖 8 距離窗長因子對圖像量化指標的影響

下載: 全尺寸圖片幻燈片

表 1 仿真參數

SAR系統參數	數值	運動參數	數值
載頻	15 GHz	斜視角	60°
距離帶寬	300 MHz	平臺高度	4 km
距離過采樣因子	1.2	中心斜距	13 km
合成孔徑時間	3 s	速度	(150, 0, –35) m/s
脈沖寬度	5 μs	加速度	(2.2, 1.2, –0.8) m/s²
脈沖重復頻率	2 kHz	加加速度	(0.2, 0.1, –0.1) m/s³
天線波束寬度	14°

下載: 導出CSV

表 2 點目標的方位向測量指標量化分析結果

點目標	PARE	MWRE	PSLRE(dB)	ISLRE(dB)
1	1.3e-03	1.0e-04	6.1e-03	–2.8e-03
2	5.2e-06	1.0e-06	7.1e-06	8.7e-06
3	1.2e-05	2.1e-06	1.4e-04	3.2e-05
4	1.5e-04	5.2e-06	6.5e-04	6.8e-05

下載: 導出CSV

參考文獻(15)

FRANCESCHETTI G, IODICE A, PERNA S, et al. SAR sensor trajectory deviations: Fourier domain formulation and extended scene simulation of raw signal[J]. IEEE Transactions on Geoscience and Remote Sensing, 2006, 44(9): 2323–2334. doi: 10.1109/tgrs.2006.873206

FRANCESCHETTI G, IODICE A, PERNA S, et al. Efficient simulation of airborne SAR raw data of extended scenes[J]. IEEE Transactions on Geoscience and Remote Sensing, 2006, 44(10): 2851–2860. doi: 10.1109/TGRS.2006.875786

DENG Bin, LI Xiang, WANG Hongqiang, et al. Fast raw-signal simulation of extended scenes for missile-borne SAR with constant acceleration[J]. IEEE Geoscience and Remote Sensing Letters, 2011, 8(1): 44–48. doi: 10.1109/LGRS.2010.2050675

劉昕, 張林讓, 劉楠, 等. 基于級數反演法的變速運動SAR回波二維頻域模擬算法[J]. 宇航學報, 2014, 35(7): 827–833. doi: 10.3873/j.issn.1000-1328.2014.07.012

LIU Xin, ZHANG Linrang, LIU Nan, et al. 2-D fourier domain algorithm for side-looking SAR with variable velocity based on reversion of series[J]. Journal of Astronautics, 2014, 35(7): 827–833. doi: 10.3873/j.issn.1000-1328.2014.07.012

刁桂杰, 許小劍. 大斜視SAR原始數據的快速模擬算法研究[J]. 電子與信息學報, 2011, 33(3): 684–689. doi: 10.3724/SP.J.1146.2010.00498

DIAO Guijie and XU Xiaojian. Fast algorithms for SAR raw data simulation with large squint angles[J]. Journal of Electronics &Information Technology, 2011, 33(3): 684–689. doi: 10.3724/SP.J.1146.2010.00498

DELL’AGLIO D A G, DI MARTINO G, IODICE A, et al. A unified formulation of SAR raw signals from extended scenes for all acquisition modes with application to simulation[J]. IEEE Transactions on Geoscience and Remote Sensing, 2018, 56(8): 4956–4967. doi: 10.1109/TGRS.2018.2844094

汪丙南, 張帆, 向茂生. 基于混合域的SAR回波快速算法[J]. 電子與信息學報, 2011, 33(3): 690–695. doi: 10.3724/SP.J.1146.2010.00555

WANG Bingnan, ZHANG Fan, and XIANG Maosheng. SAR raw signal fast algorithm in mixed domain[J]. Journal of Electronics &Information Technology, 2011, 33(3): 690–695. doi: 10.3724/SP.J.1146.2010.00555

MENG Ziqiang, LI Yachao, LI Chunbiao, et al. A raw data simulator for bistatic forward-looking high-speed maneuvering-platform SAR[J]. Signal Processing, 2015, 117: 151–164. doi: 10.1016/j.sigpro.2015.05.008

HUAI Yuanyuan, LIANG Yi, DING Jinshan, et al. An inverse extended Omega-K algorithm for SAR raw data simulation with trajectory deviations[J]. IEEE Geoscience and Remote Sensing Letters, 2016, 13(6): 826–830. doi: 10.1109/LGRS.2016.2548240

LIAO Yi, ZHOU Song, and YANG Lei. Focusing of SAR with curved trajectory based on improved hyperbolic range equation[J]. IEEE Geoscience and Remote Sensing Letters, 2018, 15(3): 454–458. doi: 10.1109/lgrs.2018.2794471

黨彥鋒, 梁毅, 別博文, 等. 俯沖段大斜視SAR子孔徑成像二維空變校正方法[J]. 電子與信息學報, 2018, 40(11): 2621–2629. doi: 10.11999/JEIT180021

DANG Yanfeng, LIANG Yi, BIE Bowen, et al. Two-dimension space-variance correction approach for diving highly squinted SAR imaging with sub-aperture[J]. Journal of Electronics &Information Technology, 2018, 40(11): 2621–2629. doi: 10.11999/JEIT180021

李寧, 別博文, 邢孟道, 等. 基于多普勒重采樣的恒加速度大斜視SAR成像算法[J]. 電子與信息學報, 2019, 41(12): 2873–2880. doi: 10.11999/JEIT180953

LI Ning, BIE Bowen, XING Mengdao, et al. A doppler resampling based imaging algorithm for high squint SAR with constant acceleration[J]. Journal of Electronics &Information Technology, 2019, 41(12): 2873–2880. doi: 10.11999/JEIT180953

別博文, 孫路, 邢孟道, 等. 基于局部直角坐標和子區域處理的彈載SAR頻域成像算法[J]. 電子與信息學報, 2018, 40(8): 1779–1786. doi: 10.11999/JEIT171107

BIE Bowen, SUN Lu, XING Mengdao, et al. A frequency-domain algorithm based on local Cartesian coordinate and subregion processing for missile-borne SAR imaging[J]. Journal of Electronics &Information Technology, 2018, 40(8): 1779–1786. doi: 10.11999/JEIT171107

鄧歡, 李亞超, 梅海文, 等. 彈載曲線軌跡雙基SAR反向?yàn)V波PFA成像與圖像畸變校正算法[J]. 電子與信息學報, 2018, 40(11): 2638–2644. doi: 10.11999/JEIT170994

DENG Huan, LI Yachao, MEI Haiwen, et al. New back-filtering PFA imaging algorithm and distortion correction method for missile-borne bistatic SAR with curved track[J]. Journal of Electronics &Information Technology, 2018, 40(11): 2638–2644. doi: 10.11999/JEIT170994

DANG Yanfeng, LIANG Yi, BIE Bowen, et al. A range perturbation approach for correcting spatially variant range envelope in diving highly squinted SAR with nonlinear trajectory[J]. IEEE Geoscience and Remote Sensing Letters, 2018, 15(6): 858–862. doi: 10.1109/LGRS.2018.2812158
