融合區塊鏈與霧計算系統中基于網絡時延和資源管理的優化任務卸載方案

劉通; 唐倫; 何小強; 陳前斌

doi:10.11999/JEIT190654

融合區塊鏈與霧計算系統中基于網絡時延和資源管理的優化任務卸載方案

doi: 10.11999/JEIT190654

劉通^{1, 2, 3, ,},
唐倫^{1, 2},
何小強^{1, 2},
陳前斌^{1, 2}

1.
重慶郵電大學通信與信息工程學院重慶 400065
2.
重慶郵電大學移動通信技術重點實驗室重慶 400065
3.
重慶工程職業技術學院大數據與物聯網學院重慶 402260

基金項目: 國家自然科學基金(61571073)，重慶市教委科學技術研究重大項目(KJZD-M201800601)

詳細信息

作者簡介:
劉通：男，1985年生，博士生，高級工程師，研究方向?yàn)檫吘売嬎恪^(qū)塊鏈等

唐倫：男，1973年生，博士，教授，博士生導師，研究方向?yàn)樾乱淮鸁o線通信網絡、異構蜂窩網絡、軟件定義無線網絡等

何小強：男，1992年生，博士生，研究方向?yàn)?G網絡切片、邊緣計算等

陳前斌：男，1967年生，博士，教授，博士生導師，研究方向?yàn)閭€人通信、多媒體信息處理與傳輸、下一代移動通信網絡等

通訊作者:
劉通　liuyyshiwo@163.com

中圖分類號: TN929.5
計量
- 文章訪問數: 2406
- HTML全文瀏覽量: 980
- PDF下載量: 119
- 被引次數: 0
出版歷程
- 收稿日期: 2019-08-29
- 修回日期: 2019-10-25
- 網絡出版日期: 2020-03-18
- 刊出日期: 2020-09-27

Optimal Task Offloading Scheme Based on Network Delay and Resource Management in Joint Blockchain and Fog Computing System

Tong LIU^{1, 2, 3
, ,},
Lun TANG^{1, 2},
Xiaoqiang HE^{1, 2},
Qianbin CHEN^{1, 2}

1.
Institute of Telecommunication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Key Laboratory of Mobile Communication Technology, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
3.
Department of Big Data and Internet of Things, Chongqing Vocational Institute of Engineering, Chongqing 402260, China

Funds: The National Natural Science Foundation of China (61571073), The Science and Technology Research Program of Chongqing Municipal Education Commission (KJZD-M201800601)

摘要

摘要: 針對如何基于有限的系統剩余資源進行任務優化卸載以增加移動終端的數字貨幣收益問題，該文在融合區塊鏈與霧計算系統中提出一種基于節點剩余資源、網絡時延的任務卸載方案。為了實現任務的優化卸載，首先基于任務量對移動終端的預期收益進行了分析，其次基于網絡節點剩余計算資源、存儲資源、功率資源、網絡時延聯合分析了移動終端的支出。此后以最大化移動終端的數字貨幣收益為優化目標建立了數學優化模型，并利用模擬退火(SA)算法對優化模型進行求解。仿真結果證明上述方案的有效性。
- 區塊鏈 /
- 霧計算 /
- 網絡時延 /
- 資源管理
Abstract: To solve the problem of increasing the digital currency of mobile terminals based on limited residual resources of the system, a task offloading scheme is proposed based on node residual resources and network delay in the joint blockchain and fog computing system. In order to offload the task in an optimal way, the expected revenue of mobile terminals is firstly analyzed based on the amount of tasks. Secondly, based on the remaining computing resources, storage resources, power resources and network delays, the expenditure of mobile terminal is analyzed. Then, a mathematical optimization model is established to maximize the digital currency income of the mobile terminal. The Simulated Annealing (SA) algorithm is employed to deal with the suboptimal model, respectively. Simulation results demonstrate the effectiveness of the proposed scheme.
- Blockchain /
- Fog computing /
- Network delay /
- Resource management

HTML全文

圖 1 系統模型

下載: 全尺寸圖片幻燈片

圖 2 節點數量與時延的關系

下載: 全尺寸圖片幻燈片

圖 3 不同資源類型與定價的關系

下載: 全尺寸圖片幻燈片

圖 4 將任務遷移至不同執行主體的開銷對比

下載: 全尺寸圖片幻燈片

圖 5 將任務遷移至不同執行主體的收益對比

下載: 全尺寸圖片幻燈片

圖 6 使用不同算法時的MUB收益對比

下載: 全尺寸圖片幻燈片

圖 7 數據量大小與收益的關系

下載: 全尺寸圖片幻燈片

表 1 求解優化模型的模擬退火算法流程

　輸入：${Q_{\rm{n}}}$, $\varphi $, ${T_{\max }}$, ${T_{\min }}$, $L$, $\nu $；

　輸出：優化解$\pi^* = \{ \alpha^*,\beta^*\}$；

　(1) 初始化${Q_{\rm{n}}}$, 最高溫度${T_{\max }}$和最低溫度${T_{\min }}$，降溫速度$\nu $，迭代
　　次數$L$；

　(2) for m=1:L do；

　(3) 求解狀態${\pi _m} = \{ {\alpha _m},{\beta _m}\}$, 并計算當前$E_{{\rm{n}}m}^{\rm{T}}$，將
　　 ${\pi _m} = \{ {\alpha _m},{\beta _m}\}$賦值給最佳解$\pi^* = \{ \alpha^*,\beta^*\}$；

　(4) 計算下一狀態解${\pi '} = \{ {\alpha '},{\beta '}\}$，并計算對應的$E_{{\rm{n}}(m + 1)}^{\rm{T}}$；

　(5) 計算增量$\Delta E_{{\rm{n}}m}^{\rm{T}} = E_{{\rm{n}}(m + 1)}^{\rm{T}} - E_{{\rm{n}}m}^{\rm{T}}$；

　(6)　　if $\Delta E_{{\rm{n}}m}^{\rm{T}} < 0$ then；

　(7) 接受當前解為最佳解，并將${\pi _m} = \{ {\alpha _m},{\beta _m}\} $賦值給最佳解
　　 $\pi^* = \{ \alpha^*,\beta^*\}$；

　(8)　　else；

　(9) 以metropolis準則中的概率${p_{{\rm{sol}}}}$接受${\pi _m} = \{ {\alpha _m},{\beta _m}\}$作為當
　　前最佳解；

　(10)　　End if；

　(11)　　if m≠L；

　(12)　　　返回(2)；

　(13)　　else；

　(14)　　　　end for；

　(15) $T(k + 1) = \nu T(k)$；

　(16)　if $T(k + 1) > {T_{\min }}$；

　(17)　　　返回(2)；

　(18)　else；

　(19) end for

下載: 導出CSV

表 2 各種節點的總資源和剩余資源量及其權重的設置

節點類型	資源類型	總資源	剩余資源	權重
BN	存儲資源(GB)	1024	[600, 800]	0.33
	計算資源(MCPS)	1000	[600, 800]	0.33
	功率資源(W)	400	[280, 350]	0.34
FN	存儲資源(GB)	512	[256, 300]	0.33
	計算資源(MCPS)	400	[280, 350]	0.33
	功率資源(W)	40	[28, 30]	0.34
MN	存儲資源(GB)	128	[16, 32]	0.33
	計算資源(MCPS)	200	[100, 160]	0.33
	功率資源(W)	2	[1.2, 1.6]	0.34

下載: 導出CSV

參考文獻(14)

BACCARELLI E, NARANJO P G V, SCARPINITI M, et al. Fog of everything: Energy-efficient networked computing architectures, research challenges, and a case study[J]. IEEE Access, 2017, 5: 9882–9910. doi: 10.1109/ACCESS.2017.2702013

張海波, 李虎, 陳善學, 等. 超密集網絡中基于移動邊緣計算的任務卸載和資源優化[J]. 電子與信息學報, 2019, 41(5): 1194–1201. doi: 10.11999/JEIT180592

ZHANG Haibo, LI Hu, CHEN Shanxue, et al. Computing offloading and resource optimization in ultra-dense networks with mobile edge computation[J]. Journal of Electronics &Information Technology, 2019, 41(5): 1194–1201. doi: 10.11999/JEIT180592

CHEN Lixing, ZHOU Pan, GAO Liang, et al. Adaptive fog configuration for the industrial internet of things[J]. IEEE Transactions on Industrial Informatics, 2018, 14(10): 4656–4664. doi: 10.1109/TⅡ.2018.2846549

SHIRAZI S N, GOUGLIDIS A, FARSHAD A, et al. The extended cloud: review and analysis of mobile edge computing and fog from a security and resilience perspective[J]. IEEE Journal on Selected Areas in Communications, 2017, 35(11): 2586–2595. doi: 10.1109/JSAC.2017.2760478

YU Yong, LI Yannan, TIAN Junfeng, et al. Blockchain-based solutions to security and privacy issues in the internet of things[J]. IEEE Wireless Communications, 2018, 25(6): 12–18. doi: 10.1109/MWC.2017.1800116

CHO H. ASIC-resistance of multi-hash proof-of-work mechanisms for blockchain consensus protocols[J]. IEEE Access, 2018, 6: 66210–66222. doi: 10.1109/ACCESS.2018.2878895

CONTI M, KUMAR E S, LAL C, et al. A survey on security and privacy issues of bitcoin[J]. IEEE Communications Surveys & Tutorials, 2018, 20(4): 3416–3452. doi: 10.1109/COMST.2018.2842460

TSCORSCH F and SCHEUERMANN B. Bitcoin and Beyond: A technical survey on decentralized digital currencies[J]. IEEE Communications Surveys & Tutorials, 2016, 18(3): 2084–2123. doi: 10.1109/COMST.2016.2535718

JANG H and LEE J. An empirical study on modeling and prediction of bitcoin prices with bayesian neural networks based on blockchain information[J]. IEEE Access, 2018, 6: 5427–5437. doi: 10.1109/ACCESS.2017.2779181

VAN DER HORST L, CHOO K K R, and LE-KHAC N A. Process memory investigation of the bitcoin clients electrum and bitcoin core[J]. IEEE Access, 2017, 5: 22385–22398. doi: 10.1109/ACCESS.2017.2759766

LIU Mengting, YU F R, TENG Yinglei, et al. Computation offloading and content caching in wireless blockchain networks with mobile edge computing[J]. IEEE Transactions on Vehicular Technology, 2018, 67(11): 11008–11021. doi: 10.1109/TVT.2018.2866365

XIONG Zehui, ZHANG Yang, NIYATO D, et al. When mobile blockchain meets edge computing[J]. IEEE Communications Magazine, 2018, 56(8): 33–39. doi: 10.1109/MCOM.2018.1701095

YAO Haipeng, MAI Tianle, WANG Jingjing, et al. Resource trading in blockchain-based industrial internet of things[J]. IEEE Transactions on Industrial Informatics, 2019, 15(6): 3602–3609. doi: 10.1109/TⅡ.2019.2902563

WANG Xiaojie, NING Zhaolong, and WANG Lei. Offloading in internet of vehicles: A fog-enabled real-time traffic management system[J]. IEEE Transactions on Industrial Informatics, 2018, 14(10): 4568–4578. doi: 10.1109/TⅡ.2018.2816590
