節點中介性和頻譜離散度感知虛擬光網絡生存性協同映射

劉煥淋; 胡會霞; 陳勇; 溫濛; 王展鵬

doi:10.11999/JEIT190543

節點中介性和頻譜離散度感知虛擬光網絡生存性協同映射

doi: 10.11999/JEIT190543

1.
重慶郵電大學通信與信息工程學院重慶 400065
2.
重慶郵電大學自動化學院重慶 400065

基金項目: 國家自然科學基金(51977021)；重慶市科技局自然科學基金 (CSTC2019jcyj-msxmX0613)

詳細信息

作者簡介:
劉煥淋：女，1970年生，教授，研究方向?yàn)楣馔ㄐ偶夹g(shù)與未來網絡

胡會霞：女，1997年生，碩士生，研究方向?yàn)樯婀饩W(wǎng)絡頻譜路由

陳勇：男，1963年生，教授，研究方向?yàn)楣馔ㄐ排c傳感檢測技術

溫濛：女，1996年生，碩士生，研究方向?yàn)楣馔ㄐ藕凸饩W(wǎng)絡

王展鵬：男，1996年生，碩士生，研究方向?yàn)楣饩W(wǎng)絡資源分配

通訊作者:
劉煥淋　liuhl2@sina.com

中圖分類號: TN929.11
計量
- 文章訪問數: 1676
- HTML全文瀏覽量: 566
- PDF下載量: 36
- 被引次數: 0
出版歷程
- 收稿日期: 2019-07-18
- 修回日期: 2020-07-08
- 網絡出版日期: 2020-07-22
- 刊出日期: 2020-09-27

Survivability Coordinated Mapping Based on Node Centrality and Spectrum Dispersion Awareness for Virtual Optical Networks

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
School of Automation, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China(51977021), The Natural Science Foundation Project of Chongqing Science and Technology Commission (CSTC2019 jcyj-msxmX0613)

摘要

摘要: 虛擬網絡的映射策略影響彈性光網絡(EON)資源可用性和網絡生存性。該文提出一種基于節點間距離和頻譜離散度感知的虛擬光網絡生存性協同映射(CM-DSDA)算法，研究節點計算資源和拓?fù)湮恢弥薪樾缘墓夤?jié)點排序策略，設計頻譜離散度方法評價鏈路頻譜碎片化程度。在虛擬鏈路的生存性映射中，選擇鄰接已映射節點中消耗頻隙數少且頻譜離散度低的工作光路和保護光路協同映射虛擬網絡。仿真結果表明所提算法能有效地提高EON的頻譜占用率和減少帶寬阻塞率。
- 虛擬光網絡 /
- 生存性協同映射 /
- 節點中介性 /
- 頻譜離散度 /
- 頻譜占用率
Abstract: The mapping strategy of virtual network has important effect on the resource availability and survivability of the Elastic Optical Network (EON). A survivable virtual optical network Coordinated Mapping based on the Distance and Spectrum Dispersion Awareness (CM-DSDA) between nodes is proposed in the paper. A physical node weighted sorting strategy is studied, which not only considers the number of physical node computing resources, but also considers the location centrality of the physical nodes in the EON topology. And a method of spectrum dispersion is designed to evaluate the link’s spectrum fragmentation. During the virtual link’s survivability mapping, the working and protection optical paths adjacent the position of the mapped physical nodes with the minimum number of spectrum usage and the lowest frequency spectrum dispersion are selected to coordinated mapping the virtual optical networks. Simulation results show that the CM-DSDA can effectively increase the EON’s spectrum utilization and reduce bandwidth blocking probability.
- Virtual optical network /
- Survivable coordinated mapping /
- Node centrality /
- Spectrum dispersion /
- Spectrum usage ratio

HTML全文

圖 1 網絡拓?fù)涫疽鈭D

下載: 全尺寸圖片幻燈片

圖 2 光虛擬網絡映射示意圖

下載: 全尺寸圖片幻燈片

圖 3 仿真網絡拓?fù)?/p>

下載: 全尺寸圖片幻燈片

圖 4 不同α和負載下兩種算法的帶寬阻塞率

下載: 全尺寸圖片幻燈片

圖 5 不同負載下4種算法的帶寬阻塞率

下載: 全尺寸圖片幻燈片

圖 6 不同負載下4種算法的頻譜利用率

下載: 全尺寸圖片幻燈片

表 1 CM-DSDA算法

輸入：EON拓?fù)?{G^{\rm{S}}} = \left( {{N^{\rm{S}}},{E^{\rm{S}}},C_{}^{\rm{S}},A_{}^{\rm{S}}} \right)$，虛擬網絡請求${G^{\rm{V}}} = \left( {{N^{\rm{V}}},{E^{\rm{V}}},C_{}^{\rm{V}},A_{}^{\rm{V}}} \right)$。
輸出：虛擬網絡生存性映射的節點、工作光路、保護光路和頻譜分配結果。
步驟1 ?根據式(5)計算虛擬節點權值，根據式(6)計算光節點的權值，降序排序虛擬節點和光節點在虛擬節點集合VNR{v₁, v₂, ···, v_N}和光　節點集SNR{s₁, s₂, ···, s_M}中。虛擬節點數N，光節點數M，若N>M，阻塞該虛擬網絡請求，否則，設n=1；
步驟2 ?根據約束式(1)和式(2)，根據首選即中原則判斷光節點s_i的剩余計算資源數是否滿足虛擬節點v_n需求，s_i∈SNR，i=1, 2, ···, M，若　滿足，將v_n映射在s_i上，并在SNR集合中刪除已映射的光節點s_i。若N=1，輸出虛擬網絡映射結果，否則，n=n+1，轉步驟3；
步驟3 ?在EON中，計算所有候選光節點與已經映射光節點之間滿足式(3)約束的虛擬鏈路映射的最短跳光路，判斷每條最短光路是否滿足　虛擬網絡需求和光路上個鏈路頻譜一致性和連續性的可用頻譜塊，若滿足，光路加入候選映射的光路集合P中；
步驟4 ?在集合P中，對每條最短光路p_k，采用首次命中的頻譜分配方式進行光路的滿足頻譜一致性和連續性的頻譜預分配；根據式(7)計算　該光路的頻譜離散度并確定光路的重載鏈路${\rm{max\{ F}}_l^{{p_k}}\} $，加入重載鏈路集合{$l_{\max }^1$, $l_{\max }^2$, ···, $l_{\max }^k$}中，根據頻譜離散度大小升序排列重載鏈　路集合；
步驟5 ?選擇集合{$l_{\max }^1$, $l_{\max }^2$, ···,$l_{\max }^k$}中的第1條鏈路所對應光路${p_k}$，將其作為虛擬鏈路的映射光路，則該映射光路的另一端點即是虛擬節 　點v_n映射的光節點，并在SNR集合中刪除已映射光節點s_i；
步驟6 ?在EON中，通過邊分離的最短光路算法確定滿足式(4)約束的映射光路的生存性保護光路，判斷保護光路是否有滿足虛擬網絡資源　需求和滿足光路上各鏈路的頻譜一致性和連續性的可用頻譜塊，若有，轉至步驟7；若無，則阻塞該虛擬網絡請求；
步驟7 ?分別用首次命中與頻譜最大共享度的頻譜分配方式，為工作光路和保護光路分配滿足頻譜一致性和連續性的頻譜資源，更新映射　后光節點剩余計算資源，若n < N，轉步驟2；
步驟8　輸出虛擬網絡映射結果。

下載: 導出CSV

參考文獻(19)

劉韻潔, 張嬌, 黃韜, 等. 面向服務定制的未來網絡架構[J]. 重慶郵電大學學報: 自然科學版, 2018, 30(1): 1–8. doi: 10.3979/j.issn.1673-825X.2018.01.001

LIU Yunjie, ZHANG Jiao, HUANG Tao, et al. Service customized future network architecture[J]. Journal of Chongqing University of Posts and Telecommunications:Natural Science Edition, 2018, 30(1): 1–8. doi: 10.3979/j.issn.1673-825X.2018.01.001

HADI M and PAKRAVAN M R. Energy-efficient fast configuration of flexible transponders and grooming switches in OFDM-based elastic optical networks[J]. Journal of Optical Communications and Networking, 2018, 10(2): 90–103. doi: 10.1364/JOCN.10.000090

LIU Huanlin, DU Jundan, CHEN Yong, et al. A coordinated virtual optical network embedding algorithm based on resources availability-aware over elastic optical networks[J]. Optical Fiber Technology, 2018, 45: 391–398. doi: 10.1016/j.yofte.2018.08.021

IYER S. Retracted article: Performance benefits of regeneration flexibility and modulation convertibility in elastic optical networks[J]. Telecommunication Systems, 2018, 69(1): 167. doi: 10.1007/s11235-017-0378-0

GUO Xiaojin, HUANG Jun, LIU Huanlin, et al. Efficient P-cycle combination protection strategy based on improved genetic algorithm in elastic optical networks[J]. IET Optoelectronics, 2018, 12(2): 73–79. doi: 10.1049/iet-opt.2016.0177

施穎潔, 陳前斌, 楊希希, 等. 基于拍賣的網絡切片虛擬資源分配算法研究[J]. 重慶郵電大學學報: 自然科學版, 2018, 30(2): 159–166. doi: 10.3979/j.issn.1673-825X.2018.02.002

SHI Yingjie, CHEN Qianbin, YANG Xixi, et al. Virtual resource allocation algorithm of network slice based on auction[J]. Journal of Chongqing University of Posts and Telecommunications:Natural Science Edition, 2018, 30(2): 159–166. doi: 10.3979/j.issn.1673-825X.2018.02.002

LIU Huanlin, XIONG Cuilian, CHEN Yong, et al. An optimization method of VON mapping for energy efficiency and routing in elastic optical networks[J]. Optical Fiber Technology, 2018, 41: 173–181. doi: 10.1016/j.yofte.2018.01.004

WANG Wei, ZHAO Yongli, HE Ruiying, et al. Continuity aware spectrum allocation schemes for virtual optical network embedding in elastic optical networks[J]. Optical Fiber Technology, 2016, 29: 28–33. doi: 10.1016/j.yofte.2016.01.008

劉煥淋, 呂磊, 陳勇, 等. 節點重要性感知的透明虛擬光網絡協同映射策略[J]. 電子與信息學報, 2018, 40(8): 1978–1984. doi: 10.11999/JEIT171096

LIU Huanlin, Lü Lei, CHEN Yong, et al. Node-importance aware coordinated embedding strategy for transparent virtual optical network[J]. Journal of Electronics &Information Technology, 2018, 40(8): 1978–1984. doi: 10.11999/JEIT171096

鮑寧海, 蘇國慶, 陳靜波. 恢復時間敏感的光網絡混合通路保護算法[J]. 重慶郵電大學學報: 自然科學版, 2017, 29(3): 313–319. doi: 10.3979/j.issn.1673-825X.2017.03.005

BAO Ninghai, SU Goqing, and CHEN Jingbo. Recovery-time aware hybrid path protection algorithm in optical networks[J]. Journal of Chongqing University of Posts and Telecommunications:Natural Science Edition, 2017, 29(3): 313–319. doi: 10.3979/j.issn.1673-825X.2017.03.005

XIAO Xiancui and ZHENG Xiangwei. A proposal of survivable virtual network embedding algorithm[J]. Journal of High Speed Networks, 2016, 22(3): 241–251. doi: 10.3233/JHS-160546

RAHMAN M R and BOUTABA R. SVNE: Survivable virtual network embedding algorithms for network virtualization[J]. IEEE Transactions on Network and Service Management, 2013, 10(2): 105–118. doi: 10.1109/TNSM.2013.013013.110202

SOUALAH O, AITSAADI N, and FAJJARI I. A novel reactive survivable virtual network embedding scheme based on game theory[J]. IEEE Transactions on Network and Service Management, 2017, 14(3): 569–585. doi: 10.1109/TNSM.2017.2717019

CHOWDHURY S R, AHMED R, KHAN M M A, et al. Dedicated protection for survivable virtual network embedding[J]. IEEE Transactions on Network and Service Management, 2016, 13(4): 913–926. doi: 10.1109/tnsm.2016.2574239

WANG Yuyu, LI Xin, GUO Bingli, et al. Survivable virtual optical network mapping in elastic optical networks with shared backup path protection[C]. The 25th IEEE Wireless and Optical Communication Conference, Chengdu, China, 2016: 1–4. doi: 10.1109/WOCC.2016.7506633.

劉煥淋, 林振宇, 王欣, 等. 彈性光網絡中基于安全性感知的差異化虛擬光網絡的映射策略[J]. 電子與信息學報, 2019, 41(2): 424–432. doi: 10.11999/JEIT180335

LIU Huanlin, LIN Zhenyu, WANG Xin, et al. A diverse virtual optical network mapping strategy based on security awareness in elastic optical networks[J]. Journal of Electronics &Information Technology, 2019, 41(2): 424–432. doi: 10.11999/JEIT180335

CHEN Bowen, ZHANG Jie, XIE Weisheng, et al. Cost-effective survivable virtual optical network mapping in flexible bandwidth optical networks[J]. Journal of Lightwave Technology, 2016, 34(10): 2398–2412. doi: 10.1109/JLT.2016.2530846

YANG Hui, CHENG Lei, LUO Guangjun, et al. Survivable virtual optical network embedding with probabilistic network-element failures in elastic optical networks[J]. Optical Fiber Technology, 2015, 23: 90–94. doi: 10.1016/j.yofte.2015.02.006

LIU Huanlin, XIONG Qile, and CHEN Yong. Routing core and spectrum allocation algorithm for inter-core crosstalk and energy efficiency in space division multiplexing elastic optical networks[J]. IEEE Access, 2020, 8: 70453–70464. doi: 10.1109/ACCESS.2020.2985422
