基于公式遞推法的可變計算位寬的循環冗余校驗設計與實現

陳容 陳嵐 WAHLAArfan Haider

陳容, 陳嵐, WAHLAArfan Haider. 基于公式遞推法的可變計算位寬的循環冗余校驗設計與實現[J]. 電子與信息學報, 2020, 42(5): 1261-1267. doi: 10.11999/JEIT190503
引用本文: 陳容, 陳嵐, WAHLAArfan Haider. 基于公式遞推法的可變計算位寬的循環冗余校驗設計與實現[J]. 電子與信息學報, 2020, 42(5): 1261-1267. doi: 10.11999/JEIT190503
Rong CHEN, Lan CHEN, Arfan Haider WAHLA. Design and Implementation of Cyclic Redundancy Check with Variable Computing Width Based on Formula Recursive Algorithm[J]. Journal of Electronics & Information Technology, 2020, 42(5): 1261-1267. doi: 10.11999/JEIT190503
Citation: Rong CHEN, Lan CHEN, Arfan Haider WAHLA. Design and Implementation of Cyclic Redundancy Check with Variable Computing Width Based on Formula Recursive Algorithm[J]. Journal of Electronics & Information Technology, 2020, 42(5): 1261-1267. doi: 10.11999/JEIT190503

基于公式遞推法的可變計算位寬的循環冗余校驗設計與實現

doi: 10.11999/JEIT190503
基金項目: 國家科技重大專項(2018ZX03001006-002)
詳細信息
    作者簡介:

    陳容:女,1991年生,博士生,研究方向?yàn)?G通信關鍵技術和物理層基帶芯片設計

    陳嵐:女,1968年生,研究員,主要研究方向?yàn)榧{米及SoC芯片設計方法學、移動通訊系統低功耗技術及物聯網芯片技術等

    WAHLAArfan Haider:男,1988年生,博士生,研究方向?yàn)榛跈C(jī)器學習的智能無線網絡和車載網絡

    通訊作者:

    陳嵐 chenlan@ime.ac.cn

  • 中圖分類號: TN911.72

Design and Implementation of Cyclic Redundancy Check with Variable Computing Width Based on Formula Recursive Algorithm

Funds: The National Science and Technology Major Project (2018ZX03001006-002)
  • 摘要:

    循環冗余校驗(CRC)與信道編碼的級聯使用,可以有效改善譯碼的收斂特性。在新一代無線通信系統,如5G中,碼長和碼率都具有多樣性。為了提高編譯碼分段長度可變的級聯系統的譯碼效率,該文提出一種可變計算位寬的CRC并行算法。該算法在現有固定位寬并行算法的基礎上,合并公式遞推法中反饋數據與輸入數據的并行計算,實現了一種高并行度的CRC校驗架構,并且支持可變位寬的CRC計算。與現有的并行算法相比,合并算法節省了電路資源的開銷,在位寬固定時,資源節約效果明顯,同時在反饋時延上也有將近50%的優化;在位寬可變時,電路資源的使用情況也有相應的優化。

  • 圖  1  LFSR實現的串行編解碼結構

    圖  2  公式遞推法M位并行CRC計算

    圖  3  CRC與信道譯碼的級聯使用

    圖  4  可變計算位寬的CRC級聯系統

    圖  5  M位固定位寬合并計算

    圖  6  1~M位計算位寬可變的CRC計算

    圖  7  1~32位并行度可變的CRC編碼RTL實現

    表  1  硬件資源開銷

    項目
    頂層實體名crc_24
    芯片EP3C5E144C7(Cyclone III)
    邏輯器件數434/5136(8%)
    寄存器數26
    管腳數68/95(72%)
    下載: 導出CSV

    表  2  仿真測試結果

    總長度
    (bit)
    NumMatlab結果仿真結果
    數據1607, 24, 2900111101011011111111011024’h3d6ff6
    數據26523, 32, 1000111000001001101101000124’h3826d1
    數據37024, 15, 3101111110000001111101101124’h7e07db
    下載: 導出CSV

    表  3  選用的生成多項式

    CRC生成多項式
    CRC-12${x^{12}} + {x^{11}} + {x^3} + {x^2} + x + 1$
    CRC-16${x^{16}} + {x^{15}} + {x^2} + 1$
    CRC-32$\begin{array}{l}{x^{32}} + {x^{26}} + {x^{23}} + {x^{22}} + {x^{16}} + {x^{12}} + {x^{11}} + \\{x^{10}} + {x^8} + {x^7} + {x^5} + {x^4} + {x^2} + x + 1\end{array}$
    下載: 導出CSV

    表  4  電路資源和關鍵路徑長度比較

    CRC式子(M=r)算法總計
    1 異或 關鍵路徑
    CRC-12(12)文獻[7]1361129
    文獻[8] 120 66 8
    文獻[10] 103 8
    文獻[9] 77 53 8
    固定 52 43 5
    可變 64 78 9
    CRC-16(16) 文獻[7] 218 186 10
    文獻[8] 188 98 10
    文獻[10] 94 10
    文獻[9] 100 60 9
    固定 72 54 5
    可變 88 101 9
    CRC-32(32) 文獻[7] 1031 967 12
    文獻[8] 928 518 12
    文獻[10] 675 10
    文獻[9] 888 461 12
    固定 452 313 6
    可變 484 408 11
    下載: 導出CSV
  • LI Bin, HUANG Zhiping, SU Shaojing, et al. Implementation of CRC in 10-gigabit Ethernet based on FPGA[J]. Applied Mechanics and Materials, 2014, 599–601: 1548–1552. doi: 10.4028/www.scientific.net/AMM.599-601.1548
    WANG Bingrui, CHEN Pingping, FANG Yi, et al. The design of vertical RS-CRC and LDPC code for ship-based satellite communications on-the-move[J]. IEEE Access, 2019, 7: 44977–44986. doi: 10.1109/ACCESS.2019.2895746
    CAMPOBELLO G, PATANE G, and RUSSO M. Parallel CRC realization[J]. IEEE Transactions on Computers, 2003, 52(10): 1312–1319. doi: 10.1109/TC.2003.1234528
    MUTHIAH D and RAJ A A B. Implementation of high-speed LFSR design with parallel architectures[C]. 2012 International Conference on Computing, Communication and Applications, Dindigul, India, 2012: 1–6.
    HUO Yuanhong, LI Xiaoyang, WANG Wei, et al. High performance table-based architecture for parallel CRC calculation[C]. The 21st IEEE International Workshop on Local and Metropolitan Area Networks, Beijing, 2015: 1–6.
    BAJARANGBALI and ANAND P A. Design of high speed CRC algorithm for ethernet on FPGA using reduced lookup table algorithm[C]. 2016 IEEE Annual India Conference, Bangalore, India, 2016: 1–6.
    DERBY J H. High-speed CRC computation using state-space transformations[C]. GLOBECOM’01. IEEE Global Telecommunications Conference, San Antonio, USA, 2001: 166–170.
    KENNEDY C and REYHANI-MASOLEH A. High-speed CRC computations using improved state-space transformations[C]. 2009 IEEE International Conference on Electro/Information Technology, Windsor, Canada, 2009: 9–14.
    HU Guanghui, SHA Jin, and WANG Zhongfeng. High-speed parallel LFSR architectures based on improved state-space transformations[J]. IEEE Transactions on Very Large Scale Integration (VLSI) Systems, 2017, 25(3): 1159–1163. doi: 10.1109/TVLSI.2016.2608921
    JUNG J, YOO H, LEE Y, et al. Efficient parallel architecture for linear feedback shift registers[J]. IEEE Transactions on Circuits and Systems Ⅱ: Express Briefs, 2015, 62(11): 1068–1072. doi: 10.1109/tcsii.2015.2456294
    CHENG Chao and PARHI K K. High-speed parallel CRC implementation based on unfolding, pipelining, and retiming[J]. IEEE Transactions on Circuits and Systems Ⅱ: Express Briefs, 2006, 53(10): 1017–1021. doi: 10.1109/TCSⅡ.2006.882213
    AYINALA M and PARHI K K. High-speed parallel architectures for linear feedback shift registers[J]. IEEE Transactions on Signal Processing, 2011, 59(9): 4459–4469. doi: 10.1109/TSP.2011.2159495
    李偉華, 焦秉立. 一種基于分段CRC的LDPC譯碼的改進算法[J]. 電子與信息學報, 2008, 30(5): 1167–1170. doi: 10.3724/SP.J.1146.2006.01763

    LI Weihua and JIAO Bingli. Improved method for LDPC decoding algorithm aided by segmented cyclic redundancy checks[J]. Journal of Electronics &Information Technology, 2008, 30(5): 1167–1170. doi: 10.3724/SP.J.1146.2006.01763
    TUSHA A, DO?AN S, and ARSLAN H. IQI mitigation for narrowband IoT systems with OFDM-IM[J]. IEEE Access, 2018, 6: 44626–44634. doi: 10.1109/ACCESS.2018.2864892
    VAN WONTERGHEM J, ALLOUM A, BOUTROS J J, et al. On short-length error-correcting codes for 5G-NR[J]. Ad Hoc Networks, 2018, 79: 53–62. doi: 10.1016/j.adhoc.2018.06.005
    RICHARDSON T and KUDEKAR S. Design of low-density parity check codes for 5G new radio[J]. IEEE Communications Magazine, 2018, 56(3): 28–34. doi: 10.1109/MCOM.2018.1700839
    王瓊, 羅亞潔, 李思舫. 基于分段循環冗余校驗的極化碼自適應連續取消列表譯碼算法[J]. 電子與信息學報, 2019, 41(7): 1572–1578. doi: 10.11999/JEIT180716

    WANG Qiong, LUO Yajie, and LI Sifang. Polar adaptive successive cancellation list decoding based on segmentation cyclic redundancy check[J]. Journal of Electronics &Information Technology, 2019, 41(7): 1572–1578. doi: 10.11999/JEIT180716
