多操作系統異構網絡的病毒傳播模型和安全性能優化策略

王剛; 馮云; 陸世偉; 馬潤年

doi:10.11999/JEIT190360

多操作系統異構網絡的病毒傳播模型和安全性能優化策略

doi: 10.11999/JEIT190360

空軍工程大學信息與導航學院西安 710077

基金項目: 國家自然科學基金(61573017)

詳細信息

作者簡介:
王剛：男，1976年生，教授，博士，碩士生導師，主要研究方向?yàn)榫W(wǎng)絡空間安全和復雜網絡

馮云：男，1996年生，碩士生，研究方向?yàn)榫W(wǎng)絡空間安全

陸世偉：男，1995年生，碩士生，研究方向?yàn)榫W(wǎng)絡空間安全

馬潤年：男，1963年生，教授，博士，碩士生導師，主要研究方向?yàn)榫W(wǎng)絡空間安全和復雜網絡

通訊作者:
王剛　wglxl@nudt.edu.cn

中圖分類號: TP393.08
計量
- 文章訪問數: 2085
- HTML全文瀏覽量: 893
- PDF下載量: 84
- 被引次數: 0
出版歷程
- 收稿日期: 2019-05-22
- 修回日期: 2019-12-09
- 網絡出版日期: 2019-12-20
- 刊出日期: 2020-06-04

Virus Propagation Model and Security Performance Optimization Strategy of Multi-operating System Heterogeneous Network

Information and Navigation Institute, Air Force Engineering University, Xi’an 710077, China

Funds: The National Nature Science Foundation of China (61573017)

摘要

摘要:
針對蠕蟲病毒通常只能感染特定操作系統的特點，該文研究了多操作系統異構網絡中的病毒傳播規律及安全性能優化策略。首先，考慮多數病毒僅限在同種操作系統之間的鏈路中傳播，在SIRS病毒傳播模型中引入異構邊比例參數，通過系統平衡點求解和基本再生數分析，研究異構邊對單系統病毒傳播和網絡安全性能的影響。其次，按照動態目標防御思想和技術，設計了非異構邊隨機中斷、非異構邊隨機重連和單操作系統節點隨機跳變3種網絡安全優化策略，分析了3種策略下異構邊比例和基本再生數的變化及其對網絡安全性能的影響。最后仿真驗證了病毒傳播模型的正確性和3種策略的網絡安全性能優化效果，同隨機中斷和隨機隔離策略對比，分析其對網絡安全性能和網絡業務承載能力的影響。
- 病毒傳播 /
- SIRS模型 /
- 異構邊比例 /
- 網絡安全性能
Abstract:
In view of the fact that worm viruses can only infect specific operating systems, the virus propagation rule and security performance optimization strategy in multi-operating system heterogeneous network are studied in this paper. First, considering that most viruses can only spread in link between the same operation system, the parameters of heterogeneous edges ratio are introduced into the Susceptible Infected Remove Susceptible (SIRS) virus transmission model, and the influence of heterogeneous edges and network security performance on the single system virus transmission is studied through system equilibrium solution and basic regeneration number analysis. Secondly, according to the moving target defense thought and technology, the network security optimization strategies is designed for non-isomeric random interrupt, non-isomeric random reconnecting and single operating system random node migration, and the variation of the same ratio and the basic number of regenerated numbers in the three strategies and the impact on the safety of the network are anaylrzed. Finally, the correctness of the virus propagation model is verified by simulation, and the network security performance optimization effects of the three strategies are analyzed.
- Virus transmission /
- Susceptible Infected Remove Susceptible (SIRS) model /
- Heterogeneous edge ratio /
- Network security performance

HTML全文

圖 1 多操作系統異構網絡及其子網絡

下載: 全尺寸圖片幻燈片

圖 2 多操作系統異構網絡中病毒傳播的SIRS模型

下載: 全尺寸圖片幻燈片

圖 3 β=0.01時不同網絡中病毒傳播情況

下載: 全尺寸圖片幻燈片

圖 4 鏈路調整前后網絡中病毒傳播情況

下載: 全尺寸圖片幻燈片

圖 5 非異構邊隨機中斷、非異構邊隨機重連和隨機中斷效果對比

下載: 全尺寸圖片幻燈片

圖 6 單操作系統節點隨機跳變策略對網絡中病毒傳播的影響

下載: 全尺寸圖片幻燈片

圖 7 隨機隔離、單操作系統節點隨機跳變效果對比

下載: 全尺寸圖片幻燈片

圖 8 100次重復試驗中節點跳變優化前后網絡平均度變化

下載: 全尺寸圖片幻燈片

表 1 非異構邊隨機中斷表

輸入：初始網絡G，斷開邊的比例${p_{\rmq7j3ldu95}}$；
輸出：優化后的網絡${{G}}'$；
(1) 為網絡中的邊加權，其中異構邊權重為1，非異構邊權重為2；
(2) 采用Prime表以網絡中度最大的節點為起點生成網絡G的最　　小生成樹G₁及其子圖G₂；
(3) 隨機刪除G₂中數量為${p_{\rmq7j3ldu95}}({M_1} + {M_2})$的連接相應操作系統的邊；
(4) 將G₁和G₂整合得到優化后的網絡${{G}}'$。

下載: 導出CSV

表 2 非異構邊隨機重連表

輸入：初始網絡G，重連邊的比例${p_{\rmq7j3ldu95}}$；
輸出：優化后的網絡${{G}}'$；
(1) 為網絡中的邊加權，其中異構邊權重為1，非異構邊權重為2；
(2) 采用Prime表以網絡中度最大節點為起點生成網絡G的最小　　生成樹G₁及其補圖G₂；
(3) 隨機刪除G₂中數量為${p_{\rmq7j3ldu95}}({M_1} + {M_2})$的連接相應操作系統的邊；
(4) 在網絡G₂中增添數量為${p_{\rmq7j3ldu95}}({M_1} + {M_2})$的邊，用于連接網絡中　　不同操作系統類型的節點；
(5) 將G₁和G₂整合得到優化后的網絡${{G}}'$。

下載: 導出CSV

表 3 單操作系統節點隨機跳變算法

輸入：初始網絡G，目標比例${p_j}$；
輸出：優化后的網絡G；
(1) 隨機選取網絡中的相應操作系統節點N_i，改變其操作系統類型；
(2) 統計網絡中相應操作系統比例${p_1}$，若${p_1} < {p_j}$，則進行步驟(3)，　　否則重復步驟(1)、步驟(2)；
(3) 輸出網絡G。

下載: 導出CSV

表 4 數學模型及網絡演化結果對比

	數學模型平衡點位置	網絡演化穩態均值	方差
無標度網絡	${P_0}(333.1,0,666.9)$	337.1,0,662.9	18.10,0,18.10
小世界網絡	${P_0}(333.1,0,666.9)$	332.9,0,667.1	14.50,0,14.50
P2P網絡	${P_0}(1816,0,3624)$	1834.1,0,3603.9	22.41,0,22.40

下載: 導出CSV

參考文獻(18)

PEI Yongzhen, LIU Shaoying, LI Changguo, et al. The dynamics of an impulsive delay SI model with variable coefficients[J]. Applied Mathematical Modelling, 2009, 33(6): 2766–2776. doi: 10.1016/j.apm.2008.08.011

VAN MIEGHEM P. Epidemic phase transition of the SIS type in networks[J]. Europhysics Letters, 2012, 97(4): 48004. doi: 10.1209/0295-5075/97/48004

MARTINEZ J S V, LOPEZ G P, GONZALEZ A J, et al. Numerical approaching of SIR epidemic model for propagation of computer worms[J]. IEEE Latin America Transactions, 2015, 13(10): 3452–3460. doi: 10.1109/TLA.2015.7387254

王剛, 胡鑫, 陸世偉. 節點增減機制下的病毒傳播模型及穩定性[J]. 電子科技大學學報, 2019, 48(1): 74–79. doi: 10.3969/j.issn.1001-0548.2019.01.013

WANG Gang, HU Xin, and LU Shiwei. Virus spreading model and its stability based on the mechanism of node increasing and decreasing[J]. Journal of University of Electronic Science and Technology of China, 2019, 48(1): 74–79. doi: 10.3969/j.issn.1001-0548.2019.01.013

顧?？? 蔣國平, 夏玲玲. 基于狀態概率轉移的SIRS病毒傳播模型及其臨界值分析[J]. 計算機科學, 2016, 43(6A): 64–67. doi: 10.11896/j.issn.1002-137X.2016.6A.014

GU Haijun, JIANG Guoping, and XIA Lingling. SIRS epidemic model and its threshold based on state transition probability[J]. Computer Science, 2016, 43(6A): 64–67. doi: 10.11896/j.issn.1002-137X.2016.6A.014

王剛, 陸世偉, 胡鑫, 等. “去二存一”混合機制下的病毒擴散模型及穩定性分析[J]. 電子與信息學報, 2019, 41(3): 709–716. doi: 10.11999/JEIT180381

WANG Gang, LU Shiwei, HU Xin, et al. Virus propagation model and stability under the hybrid mechanism of “Two-go and One-live”[J]. Journal of Electronics &Information Technology, 2019, 41(3): 709–716. doi: 10.11999/JEIT180381

王剛, 陸世偉, 胡鑫, 等. 潛伏機制下網絡病毒傳播SEIQRS模型及穩定性分析[J]. 哈爾濱工業大學學報, 2019, 51(5): 131–137. doi: 10.11918/j.issn.0367-6234.201805136

WANG Gang, LU Shiwei, HU Xin, et al. Network virus spreading SEIQRS model and its stability under escape mechanism[J]. Journal of Harbin Institute of Technology, 2019, 51(5): 131–137. doi: 10.11918/j.issn.0367-6234.201805136

EL-SAYED A M A, ARAFA A A M, KHALI M, et al. A mathematical model with memory for propagation of computer virus under human intervention[J]. Progress in Fractional Differentiation and Applications, 2016, 2(2): 105–113. doi: 10.18576/pfda/020203

WANG Lei, YAO Changhua, YANG Yuqi, et al. Research on a dynamic virus propagation model to improve smart campus security[J]. IEEE Access, 2018, 6: 20663–20672. doi: 10.1109/ACCESS.2018.2817508

HEYDARI V, KIM S I, and YOO S M. Scalable anti-censorship framework using moving target defense for web servers[J]. IEEE Transactions on Information Forensics and Security, 2017, 12(5): 1113–1124. doi: 10.1109/TIFS.2016.2647218

LEI Cheng, MA Duohe, and ZHANG Hongqi. Optimal strategy selection for moving target defense based on Markov game[J]. IEEE Access, 2017, 5: 156–169. doi: 10.1109/ACCESS.2016.2633983

熊鑫立, 趙光勝, 徐偉光, 等. 基于系統攻擊面的動態目標防御有效性評估方法[J]. 清華大學學報: 自然科學版, 2019, 59(4): 276–283. doi: 10.16511/j.cnki.qhdxxb.2018.26.056

XIONG Xinli, ZHAO Guangsheng, XU Weiguang, et al. System attack surface based MTD effectiveness assessment model[J]. Journal of Tsinghua University:Science and Technology, 2019, 59(4): 276–283. doi: 10.16511/j.cnki.qhdxxb.2018.26.056

周余陽, 程光, 郭春生, 等. 移動目標防御的攻擊面動態轉移技術研究綜述[J]. 軟件學報, 2018, 29(9): 2799–2820. doi: 10.13328/j.cnki.jos.005597

ZHOU Yuyang, CHENG Guang, GUO Chunsheng, et al. Survey on attack surface dynamic transfer technology based on moving target defense[J]. Journal of Software, 2018, 29(9): 2799–2820. doi: 10.13328/j.cnki.jos.005597

劉江, 張紅旗, 楊英杰, 等. 基于主機安全狀態遷移模型的動態網絡防御有效性評估[J]. 電子與信息學報, 2017, 39(3): 509–517. doi: 10.11999/JEIT160513

LIU Jiang, ZHANG Hongqi, YANG Yingjie, et al. Effectiveness evaluation of moving network defense based on host security state transition model[J]. Journal of Electronics &Information Technology, 2017, 39(3): 509–517. doi: 10.11999/JEIT160513

HONG J B and KIM D S. Assessing the effectiveness of moving target defenses using security models[J]. IEEE Transactions on Dependable and Secure Computing, 2016, 13(2): 163–177. doi: 10.1109/TDSC.2015.2443790

JIANG Jiaojiao, WEN Sheng, YU Shui, et al. K-center: An approach on the multi-source identification of information diffusion[J]. IEEE Transactions on Information Forensics and Security, 2015, 10(12): 2616–2626. doi: 10.1109/TIFS.2015.2469256

CAI Jun, WANG Yu, LIU Yan, et al. Enhancing network capacity by weakening community structure in scale-free network[J]. Future Generation Computer Systems, 2018, 87: 765–771. doi: 10.1016/j.future.2017.08.014

LESKOVEC J, KLEINBERG J, and KREVL A. SNAP Datasets: Stanford Large Network Dataset Collection[EB/OL]. http://snap.stanford.edu/data/p2p-Gnutella04.html, 2004.
