基于非局部操作的深度卷積神經網絡車位占用檢測算法

申鉉京; 沈哲; 黃永平; 王玉

doi:10.11999/JEIT190349

基于非局部操作的深度卷積神經網絡車位占用檢測算法

doi: 10.11999/JEIT190349

申鉉京¹,
沈哲¹,
黃永平¹,
王玉^2, ,

1.
吉林大學計算機科學與技術學院長春 130012
2.
吉林大學應用技術學院長春 130012

基金項目: 智慧法院智能化服務技術研究及支撐平臺開發(2018YFC0830100)，國家自然科學基金(61672259, 61876070)，國家自然科學基金青年科學基金(61602203)，吉林省科技發展計劃重點科技研發項目(20180201064SF)，吉林省優秀青年人才基金(20180520020JH)

詳細信息

作者簡介:
申鉉京：男，1958年生，博士，教授，研究方向?yàn)閳D像處理與模式識別、多媒體信息安全、智能控制技術

沈哲：男，1995年生，碩士生，研究方向?yàn)閳D像處理與模式識別

黃永平：男，1964年生，博士，副教授，研究方向?yàn)閳D像處理與模式識別、智能控制與嵌入式系統

王玉：男，1983年生，博士，副教授，研究方向?yàn)閳D像處理與模式識別、多媒體信息技術

通訊作者:
王玉　wangyu001@jlu.edu.cn

中圖分類號: TN911.73; TP391
計量
- 文章訪問數: 2020
- HTML全文瀏覽量: 805
- PDF下載量: 101
- 被引次數: 0
出版歷程
- 收稿日期: 2019-05-17
- 修回日期: 2020-01-04
- 網絡出版日期: 2020-07-01
- 刊出日期: 2020-09-27

Deep Convolutional Neural Network for Parking Space Occupancy Detection Based on Non-local Operation

1.
College of Computer Science and Technology, Jilin University, Changchun 130012, China
2.
College of Applied Technology, Jilin University, Changchun 130012, China

Funds: The Intelligent Court Intelligent Service Technology Research and Support Platform Development (2018YFC0830100), The National Natural Science Foundation of China (61672259, 61876070), The National Natural Science Foundation of China Youth Science Foundation (61602203), The Key Scientific and Technological R & D Projects of Jilin Province Science and Technology Development Plan(20180201064SF), Jilin Province Outstanding Young Talent Fund Project (20180520020JH)

摘要

摘要: 隨著城市交通智能化發展，準確高效地獲取可用車位對于解決日益嚴峻的停車難問題至關重要。該文提出一種基于非局部操作的深度卷積神經網絡車位占用檢測算法。針對停車位圖像特性，引入非局部操作，度量遠距離像素間的相似性，直接獲取邊緣高頻特征；使用小卷積核獲取局部細節特征；以端到端的方式訓練網絡。實驗中，通過設置不同卷積核尺寸和非局部模塊層數，優化網絡結構。實驗結果表明，該文所提算法與傳統的基于紋理特征的車位占用檢測算法相比，無論在預測精度還是模型的泛化性能，均具有顯著的優勢。與當前廣泛應用的基于局部特征提取的卷積神經網絡相比，該算法具有較大的優勢。在真實場景中，該算法同樣具有較高精度，具備實際應用價值。
- 車位占用檢測 /
- 紋理特征 /
- 卷積神經網絡 /
- 非局部操作
Abstract: With the intelligent development of urban traffic, accurate and efficient access to available parking spaces is essential to solve the increasingly difficult problem of parking difficulties. Therefore, this paper proposes a deep convolutional neural network parking occupancy detection algorithm based on non-local operation. For the image characteristics of parking spaces, non-local operations are introduced, the similarity between distant pixels is measured, and the high-frequency features of the edges are directly obtained. The local details are obtained by using small convolution kernels, and the network is trained in an end-to-end manner. In the experiment, the network structure is optimized by setting different convolution kernel sizes and non-local module layers. The experimental results show that compared with the traditional texture feature-based parking space occupancy detection algorithm, the proposed algorithm has significant advantages in both prediction accuracy and generalization performance of the model. At the same time, compared with the currently widely used convolutional neural network based on local feature extraction, the algorithm also has great advantages. In real scenes, the algorithm also has high precision and has practical application value.
- Parking space occupancy detection /
- Texture feature /
- Convolutional neural network /
- Non-local operation

HTML全文

圖 1 非局部模塊

下載: 全尺寸圖片幻燈片

圖 2 停車位圖像

下載: 全尺寸圖片幻燈片

圖 3 模型結構圖

下載: 全尺寸圖片幻燈片

圖 4 不同卷積核尺寸的準確率曲線圖

下載: 全尺寸圖片幻燈片

圖 5 不同層數非局部模塊的準確率曲線圖

下載: 全尺寸圖片幻燈片

圖 6 可視化的特征圖

下載: 全尺寸圖片幻燈片

圖 7 PKLot, CNRPark數據集間實驗準確率對比柱狀圖

下載: 全尺寸圖片幻燈片

圖 8 匡亞明樓停車場車位占用情況檢測結果

下載: 全尺寸圖片幻燈片

表 1 不同卷積核尺寸的準確率詳細對比(%)

卷積核尺寸	訓練精度	測試精度
卷積核尺寸	訓練精度	UFPR04	UFPR05	PUCPR
3	99.97	99.74	96.40	97.48
5	99.90	99.78	97.67	97.85
7	99.56	99.72	96.00	96.78
9	99.44	99.41	94.81	96.38
11	99.41	99.25	92.18	95.39

下載: 導出CSV

表 2 不同層數非局部模塊的準確率詳細對比(%)

非局部模塊層數	訓練精度	測試精度
非局部模塊層數	訓練精度	UFPR04	UFPR05	PUCPR
1	99.90	99.78	97.67	97.85
2	99.96	99.81	97.65	97.55
3	99.95	99.85	98.55	98.35

下載: 導出CSV

表 3 不同方法的PKLot子數據集內測試準確率(%)

訓練集	UFPR04	UFPR05	PUCPR
測試集	UFPR04	UFPR05	PUCPR
本文方法	99.85	99.62	99.92
mAlexnet	99.54	99.49	99.90
LPQu	99.50	98.90	99.58
Mean	99.64	99.30	99.61

下載: 導出CSV

表 4 不同方法的PKLot子數據集間測試準確率(%)

訓練集	測試集	方法	精度
UFPR04	UFPR05	本文方法	98.55
		mAlexnet^[14]	93.29
		LPQg^[18]	84.92
		Max	88.33
	PUCPR	本文方法	98.31
		mAlexnet^[14]	98.27
		LPQg^[18]	84.25
		Mean	88.40
UFPR05	UFPR04	本文方法	94.45
		mAlexnet^[14]	93.69
		LPQg^[18]	85.76
		Mean	85.53
	PUCPR	本文方法	95.87
		mAlexnet^[14]	92.72
		LPQu^[17]	87.74
		Mean	89.83
PUCPR	UFPR04	本文方法	99.24
		mAlexnet^[14]	98.03
		LPQg^[18]	87.15
		Mean	88.88
	UFPR05	本文方法	98.89
		mAlexnet^[14]	96.00
		LBPri^[19]	82.78
		Mean	84.20

下載: 導出CSV

參考文獻(19)

CAICEDO F, BLAZQUEZ C, and MIRANDA P. Prediction of parking space availability in real time[J]. Expert Systems with Applications, 2012, 39(8): 7281–7290. doi: 10.1016/j.eswa.2012.01.091

DEL POSTIGO C G, TORRES J, and MENéNDEZ J M. Vacant parking area estimation through background subtraction and transience map analysis[J]. IET Intelligent Transport Systems, 2015, 9(9): 835–841. doi: 10.1049/iet-its.2014.0090

DAN N. Parking management system and method[P]. US, 20030144890, 2003.

TSAI L W, HSIEH J W, and FAN K C. Vehicle detection using normalized color and edge map[J]. IEEE Transactions on Image Processing, 2007, 16(3): 850–864. doi: 10.1109/tip.2007.891147

HUANG C C, TAI Yushu, and WANG S J. Vacant parking space detection based on plane-based Bayesian hierarchical framework[J]. IEEE Transactions on Circuits and Systems for Video Technology, 2013, 23(9): 1598–1610. doi: 10.1109/tcsvt.2013.2254961

DELIBALTOV D, WU Wencheng, LOCE R P, et al. Parking lot occupancy determination from lamp-post camera images[C]. The 16th International IEEE Conference on Intelligent Transportation Systems, The Hague, Netherlands, 2013: 2387–2392. doi: 10.1109/itsc.2013.6728584.

LECUN Y, BENGIO Y, and HINTON G E. Deep learning[J]. Nature, 2015, 521(7553): 436–444. doi: 10.1038/nature14539

DE ALMEID P R L, OLIVEIRA L S, BRITTO JR A S, et al. PKLot–a robust dataset for parking lot classification[J]. Expert Systems with Applications, 2015, 42(11): 4937–4949. doi: 10.1016/j.eswa.2015.02.009

AMATO G, CARRARA F, FALCHI F, et al. Car parking occupancy detection using smart camera networks and deep learning[C]. 2016 IEEE Symposium on Computers and Communication, Messina, Italy, 2016: 1212–1217. doi: 10.1109/iscc.2016.7543901.

BUADES A, COLL B, and MOREL J M. A non-local algorithm for image denoising[C]. 2005 IEEE Computer Society Conference on Computer Vision and Pattern Recognition, San Diego, USA, 2005: 60–65. doi: 10.1109/cvpr.2005.38.

VASWANI A, SHAZEER N, PARMAR N, et al. Attention is all you need[C]. The 31st Conference on Neural Information Processing Systems, Long Beach, USA, 2017: 5998–6008.

WANG Xiaolong, GIRSHICK R, GUPTA A, et al. Non-local neural networks[C]. 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Salt Lake City, USA, 2018: 7794–7803. doi: 10.1109/cvpr.2018.00813.

HE Kaiming, ZHANG Xiangyu, REN Shaoqing, et al. Deep residual learning for image recognition[C]. 2016 IEEE Conference on Computer Vision and Pattern Recognition, Las Vegas, USA, 2016: 770–778. doi: 10.1109/cvpr.2016.90.

AMATO G, CARRARA F, FALCHI F, et al. Deep learning for decentralized parking lot occupancy detection[J]. Expert Systems with Applications, 2017, 72: 327–334. doi: 10.1016/j.eswa.2016.10.055

KRIZHEVSKY A, SUTSKEVER I, and HINTON G E. ImageNet classification with deep convolutional neural networks[C]. The 25th International Conference on Neural Information Processing Systems, Red Hook, USA, 2012: 1097–1105.

NURULLAYEV S and LEE S W. Generalized parking occupancy analysis based on dilated convolutional neural network[J]. Sensors, 2019, 19(2): 277. doi: 10.3390/s19020277

OJANSIVU V and HEIKKIL? J. Blur insensitive texture classification using local phase quantization[C]. The 3rd International Conference on Image and Signal Processing, Cherbourg-Octeville, France, 2008: 236–243. doi: 10.1007/978-3-540-69905-7_27.

RAHTU E, HEIKKILA J, OJANSIVU V, et al. Local phase quantization for blur-insensitive image analysis[J]. Image and Vision Computing, 2012, 30(8): 501–512. doi: 10.1016/j.imavis.2012.04.001

OJALA T, PIETIKAINEN M, and MAENPAA T. Multiresolution gray-scale and rotation invariant texture classification with local binary patterns[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2002, 24(7): 971–987. doi: 10.1109/tpami.2002.1017623
