基于動態參數差分進化算法的多約束稀布矩形面陣優化

姚敏立; 王旭健; 張峰干; 戴定成

doi:10.11999/JEIT190346

基于動態參數差分進化算法的多約束稀布矩形面陣優化

doi: 10.11999/JEIT190346

火箭軍工程大學 西安 710025

詳細信息

作者簡介:
姚敏立：男，1966年生，教授，研究方向?yàn)閷拵б苿?dòng)衛星通信、陣列信號處理

王旭?。耗?，1994年生，碩士生，研究方向?yàn)殛嚵刑炀€優化設計

張峰干：男，1985年生，博士，研究方向?yàn)殛嚵行盘?hào)處理、陣列天線優化

戴定成：男，1991年生，博士生，研究方向?yàn)殛嚵刑炀€優化設計

通訊作者:
王旭健　wxj_903@163.com

中圖分類號: TN820
計量
- 文章訪問數: 2943
- HTML全文瀏覽量: 1216
- PDF下載量: 67
- 被引次數: 0
出版歷程
- 收稿日期: 2019-05-16
- 修回日期: 2019-09-06
- 網絡出版日期: 2020-01-31
- 刊出日期: 2020-06-04

Synthesis of Sparse Rectangular Planar Arrays with Multiple Constraints Based on Dynamic Parameters Differential Evolution Algorithm

Rocket Force University of Engineering, Xi’an 710025, China

摘要

摘要:
針對多約束條件下稀布矩形平面陣列天線的優化問題，該文提出一種基于動態參數差分進化(DPDE)算法的方向圖綜合方法。首先，對差分進化(DE)算法中的縮放因子和交叉概率引入動態變化控制策略，提高搜索效率和搜索精度。其次，改進矩陣映射方法，重新定義映射法則，改善現有方法隨機性強和搜索精度低的不足。最后，為檢驗所提方法的有效性進行仿真實驗，實驗數據表明，該方法可以提高天線優化性能，有效降低天線的峰值旁瓣電平。
- 陣列天線 /
- 稀布平面陣列 /
- 約束優化 /
- 差分進化算法
Abstract:
For solving the problem of the synthesis of sparse rectangular planar arrays with multiple constraints, this paper proposes a Dynamic Parameters Differential Evolution (DPDE) based algorithm. Firstly, to improve searching efficiency and accuracy of Differential Evolution (DE), the proposed method introduces dynamically changing strategies to the scaling factor and the crossover probability of the traditional Differential Evolution algorithm. Secondly, a modified matrix mapping method and the redefinition of mapping principles are presented to make up the defects of strong randomness and low accuracy in existing methods. Finally, simulation experiments of antenna arrays are performed to validate the effectiveness of the proposed method, and the results demonstrate that the proposed method performs out the existing methods in the respect of reducing peak sidelobe level of antenna arrays.
- Antenna arrays /
- Sparse planar arrays /
- Constrained optimization /
- Differential Evolution (DE) algorithm

HTML全文

圖 1 矩形面陣結構示意圖

下載: 全尺寸圖片幻燈片

圖 2 $\varphi = {0^{\rm{^\circ }}}$和$\varphi = {90^{\rm{^\circ }}}$平面的方向圖

下載: 全尺寸圖片幻燈片

圖 3 實驗1的PSLL實驗結果

下載: 全尺寸圖片幻燈片

圖 4 全平面遠場方向圖

下載: 全尺寸圖片幻燈片

圖 5 實驗2的PSLL實驗結果

下載: 全尺寸圖片幻燈片

圖 6 實驗1陣元分布

下載: 全尺寸圖片幻燈片

圖 7 實驗2陣元分布

下載: 全尺寸圖片幻燈片

表 1 標準測試函數

函數		變量取值范圍	最小值
f₁	$\displaystyle\sum\limits_{i = 1}^n {x_i^2} $	[–100, 100]	0
f₂	$\displaystyle\sum\limits_{i = 1}^n {\left\| {{x_i}} \right\|} + \prod\limits_{i = 1}^n {{x_i}} $	[–10, 10]	0
f₃	${\displaystyle\sum\limits_{i = 1}^n {\left( {\displaystyle\sum\limits_{j = 1}^i {{x_j}} } \right)} ^2}$	[–100, 100]	0
f₄	$\displaystyle\sum\limits_{i = 1}^D {{{\left( {\left\| {{x_i} + 0.5} \right\|} \right)}^2}\quad } $	[–100, 100]	0
f₅	$\displaystyle\sum\limits_{i = 1}^D {\left[ {x_i^2 - 10\cos \left( {2\pi {x_i}} \right) + 10} \right]} $	[–5.12，5.12]	0
f₆	$ - 20{ {\rm{e} }^{ - 0.2\sqrt {\dfrac{1}{D}\displaystyle\sum\limits_{i = 1}^D {x_i^2} } } } - { {\rm{e} }^{\dfrac{1}{D}\displaystyle\sum\limits_{i = 1}^D {\cos \left( {2\pi {x_i} } \right)} } } + 20 + {\rm{e} }$	[–32, 32]	0
f₇	$\dfrac{1}{ {400} }\displaystyle\sum\limits_{i = 1}^D {x_i^2} - \prod\limits_{i = 1}^D {\cos \left( {\frac{ { {x_i} } }{ {\sqrt i } } } \right)} + 1$	[–600, 600]	0

下載: 導出CSV

表 2 實驗參數設置

	縮放因子	交叉概率C_r	種群規模NP	迭代次數NI	變量維度D	縮放因子F	變異概率M_r
DPDE	$1/\sqrt t $	自適應	50	10000	100/200	0.5	0.5
DE	(無)	0.5	50	10000	100/200	0.5	0.5

下載: 導出CSV

表 3 DPDE和DE的實驗結果對比(較好的以*標出)

	DPDE (D=100)			DE (D=100)			DPDE (D=200)			DE (D=200)
	MEAN	SD	PSR(%)	MEAN	SD	PSR(%)	MEAN	SD	PSR(%)	MEAN	SD	PSR(%)
f₁	2.72E-28*	5.23E-56	100	1.86E-14	5.94E-29	100	5.16E-17*	6.17E-34	100	1.87E+01	7.91E+00	0
f₂	1.87E-14*	5.83E-29	100	7.97E-09	2.65E-18	0	1.01E-08*	9.34E-18	0	4.73E+00	3.23E-01	0
f₃	1.41E+00*	3.61E-02	0	3.39E+05	5.07E+08	0	9.04E+00*	1.32E+00	0	1.33E+06	1.02E+10	0
f₄	9.25E-28*	9.62E-55	100	1.99E-14	6.35E-29	100	1.97E-16*	1.01E-32	100	1.92E+01	1.12E+01	0
f₅	3.72E+01*	1.77E+02	0	7.67E+02	3.69E+02	0	2.11E+02*	2.14E+03	0	2.04E+03	8.78E+02	0
f₆	1.54E-14*	3.52E-30	100	2.80E-08	3.13E-17	0	1.68E-09*	2.27E-19	0	2.05E+00	9.44E-01	0
f₇	8.66E-17*	2.16E-33	100	1.08E-14	1.55E-29	100	2.33E-16*	1.64E-33	100	2.74E+00	1.12E-01	0

下載: 導出CSV

表 4 仿真實驗結果對比(dB)

實驗	方法	最優值	均值	最差值	方差
實驗1	本文方法	–62.093	–60.395	–58.141	0.898
	MGA	–45.456	–	–43.864	–
	MMM	–51.499	–	–49.269	–
	AMM	–61.454	–58.922	–	–
實驗2	本文方法	–22.753	–21.287	–19.038	0.363
	MGA	–18.840	–	–	–
	MMM	–20.384	–	–	–
	AMM	–21.886	–20.456	–	–

下載: 導出CSV

參考文獻(16)

OLIVERI G and MASSA A. Genetic algorithm (GA)-enhanced almost difference set (ADS)-based approach for array thinning[J]. IET Microwaves, Antennas & Propagation, 2011, 5(3): 305–315. doi: 10.1049/iet-map.2010.0114

CHEN Kesong, CHEN Hui, WANG Ling, et al. Modified real GA for the synthesis of sparse planar circular arrays[J]. IEEE Antennas and Wireless Propagation Letters, 2016, 15: 274–277. doi: 10.1109/LAWP.2015.2440432

BHATTACHARYA R, BHATTACHARYYA T K, and GARG R. Position mutated hierarchical particle swarm optimization and its application in synthesis of unequally spaced antenna arrays[J]. IEEE Transactions on Antennas and Propagation, 2012, 60(7): 3174–3181. doi: 10.1109/tap.2012.2196917

DAI Dingcheng, YAO Minli, MA Hongguang, et al. An effective approach for the synthesis of uniformly excited large linear sparse array[J]. IEEE Antennas and Wireless Propagation Letters, 2018, 17(3): 377–380. doi: 10.1109/LAWP.2018.2790907

BAI Yanying, XIAO Shaoqiu, LIU Changrong, et al. A hybrid IWO/PSO algorithm for pattern synthesis of conformal phased arrays[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(4): 2328–2332. doi: 10.1109/tap.2012.2231936

SUN Geng, LIU Yanheng, CHEN Zhaoyu, et al. Radiation beam pattern synthesis of concentric circular antenna arrays using hybrid approach based on cuckoo search[J]. IEEE Transactions on Antennas and Propagation, 2018, 66(9): 4563–4576. doi: 10.1109/TAP.2018.2846771

ZHANG Bo, LIU Wei, and GOU Xiaoming. Compressive sensing based sparse antenna array design for directional modulation[J]. IET Microwaves, Antennas & Propagation, 2017, 11(5): 634–641. doi: 10.1049/iet-map.2016.0313

YAN Chuang, YANG Peng, XING Zhiyu, et al. Synthesis of planar sparse arrays with minimum spacing constraint[J]. IEEE Antennas and Wireless Propagation Letters, 2018, 17(6): 1095–1098. doi: 10.1109/LAWP.2018.2833962

GU Pengfei, WANG Gui, FAN Zhenhong, et al. Efficient unitary matrix pencil method for synthesising wideband frequency patterns of sparse linear arrays[J]. IET Microwaves, Antennas & Propagation, 2018, 12(12): 1871–1876. doi: 10.1049/iet-map.2018.0148

LIN Zhiqiang, JIA Weimin, YAO Minli, et al. Synthesis of sparse linear arrays using vector mapping and simultaneous perturbation stochastic approximation[J]. IEEE Antennas and Wireless Propagation Letters, 2012, 11: 220–223. doi: 10.1109/LAWP.2012.2188266

賈維敏, 林志強, 姚敏立, 等. 一種多約束稀布線陣的天線綜合方法[J]. 電子學報, 2013, 41(5): 926–930. doi: 10.3969/j.issn.0372-2112.2013.05.015

JIA Weimin, LIN Zhiqiang, YAO Minli, et al. A synthesis technique for linear sparse arrays with multiple constraints[J]. Acta Electronica Sinica, 2013, 41(5): 926–930. doi: 10.3969/j.issn.0372-2112.2013.05.015

于波, 陳客松, 朱盼, 等. 稀布圓陣的降維優化方法[J]. 電子與信息學報, 2014, 36(2): 476–481. doi: 10.3724/SP.J.1146.2013.00526

YU Bo, CHEN Kesong, ZHU Pan, et al. An optimum method of sparse concentric rings array based on dimensionality reduction[J]. Journal of Electronics &Information Technology, 2014, 36(2): 476–481. doi: 10.3724/SP.J.1146.2013.00526

CHEN Kesong, YUN Xiaohua, HE Zishu, et al. Synthesis of sparse planar arrays using modified real genetic algorithm[J]. IEEE Transactions on Antennas and Propagation, 2007, 55(4): 1067–1073. doi: 10.1109/tap.2007.893375

LIU Heng, ZHAO Hongwei, LI Weimei, et al. Synthesis of sparse planar arrays using matrix mapping and differential evolution[J]. IEEE Antennas and Wireless Propagation Letters, 2016, 15: 1905–1908. doi: 10.1109/LAWP.2016.2542882

DAI Dingcheng, YAO Minli, MA Hongguang, et al. An asymmetric mapping method for the synthesis of sparse planar arrays[J]. IEEE Antennas and Wireless Propagation Letters, 2018, 17(1): 70–73. doi: 10.1109/LAWP.2017.2774498

LI Xiangtao, WANG Jianan, and YIN Minghao. Enhancing the performance of cuckoo search algorithm using orthogonal learning method[J]. Neural Computing and Applications, 2014, 24(6): 1233–1247. doi: 10.1007/s00521-013-1354-6
