一種Alpha穩定分布噪聲下的體積目標長度估計方法

王彬; 侯越圣

doi:10.11999/JEIT190327

一種Alpha穩定分布噪聲下的體積目標長度估計方法

doi: 10.11999/JEIT190327

王彬^,,
侯越圣

戰略支援部隊信息工程大學 鄭州 450001

基金項目: 國家自然科學基金(61572518)

詳細信息

作者簡介:
王彬：女，1971年生，副教授，研究方向為信號分析與處理

侯越圣：男，1995年生，碩士生，研究方向為信號分析與處理

通訊作者:
王彬　commutech@163.com

中圖分類號: TN911
計量
- 文章訪問數: 1699
- HTML全文瀏覽量: 414
- PDF下載量: 41
- 被引次數: 0
出版歷程
- 收稿日期: 2019-05-07
- 修回日期: 2019-12-16
- 網絡出版日期: 2020-07-16
- 刊出日期: 2020-09-27

Estimation of Volume Target Length in Alpha Distribution Noise

Bin WANG^,,
Yuesheng HOU

PLA Strategic Support Force Information Engineering University, Zhengzhou 450001, China

Funds: The National Natural Science Foundation of China (61572518)

摘要

摘要: 為了解決Alpha穩定分布噪聲環境下運動艦船目標的長度估計問題，該文借鑒非線性變換抑制脈沖噪聲以及多普勒目標運動特性估計思想，提出基于廣義時頻分析(G-TFA)和最小二乘估計的運動目標長度估計方法。該方法首先利用G-TFA獲取Alpha穩定分布噪聲環境下運動目標的多普勒頻率，然后利用最小二乘方法估計出目標航速和不同位置的橫正時刻，最后利用上述估計結果計算目標長度。以廣義Winger-Ville分布(G-WVD)為例，從理論上推導了G-TFA在Alpha穩定分布噪聲環境下具有提取目標多普勒特征的能力，并通過仿真實驗驗證了該算法在中低混合信噪比下的穩健性。與現有算法相比，該文所提算法不需要估計噪聲特征指數，算法性能優于基于傳統時頻分析的估計方法。
- 目標長度估計 /
- 橫正時刻估計 /
- Alpha穩定分布噪聲 /
- 廣義時頻分析 /
- 多普勒分析
Abstract: In order to estimate the length of moving ship targets in Alpha stable distribution noise, a moving target length estimation method based on Generalized Time-Frequency Analysis (G-TFA) and least squares estimation is proposed, which utilizes nonlinear transform to suppress impulsive noise and Doppler effect to estimate target motion characteristics. The method uses G-TFA to obtain the Doppler frequency of moving targets in a stable distributed noise environment. Then, the least squares method is used to estimate the target speed and the closest point of approach time of different positions. Finally, the target length is calculated using the above estimation results. Taking Generalized Winger-Ville Distribution (G-WVD) as an example, the ability of G-TFA to extract Doppler features in Alpha stable distributed noise is theoretically derived. The robustness of the proposed method under low-to-medium mixed signal-to-noise ratio is verified by simulation experiments. Compared with the existing methods, the proposed method does not need to estimate the noise characteristic index, and the performance is better than the methods based on the traditional time-frequency analysis.
- Target length estimation /
- Estimating the closest point of approach time /
- Alpha distribution noise /
- Generalized Time-Frequency Analysis (G-TFA) /
- Doppler feature analysis

HTML全文

圖 1 艦船目標與傳感器位置關系

下載: 全尺寸圖片幻燈片

圖 2 多普勒頻移曲線和不同橫正時刻估計結果

下載: 全尺寸圖片幻燈片

圖 3 G-TFA處理流程圖

下載: 全尺寸圖片幻燈片

圖 4 目標特征部位橫正時刻和長度估計算法

下載: 全尺寸圖片幻燈片

圖 5 波形和時頻分析結果

下載: 全尺寸圖片幻燈片

圖 6 不同特征指數下性能對比

下載: 全尺寸圖片幻燈片

圖 7 不同混合信噪比下性能對比

下載: 全尺寸圖片幻燈片

圖 8 實驗場景示意圖

下載: 全尺寸圖片幻燈片

圖 9 接收輻射噪聲時域波形

下載: 全尺寸圖片幻燈片

圖 10 800 Hz線譜時頻分析結果

下載: 全尺寸圖片幻燈片

表 1 實驗條件

被測目標	天和防務TH-B050R型AUV
采集設備	Ocean Sonics公司icListen HF智能水聽器
測試地點	信息工程大學中心校區人工湖，測試區域水深1.5 m左右
測試環境	有雨并伴有4～5級風

下載: 導出CSV

表 2 最小二乘參數估計結果

	橫正距離	橫正時刻	速度(m/s)
記錄值	1.50	12.58	0.795
估計值	1.56	12.52	0.748

下載: 導出CSV

表 3 橫正距離50 m的識別結果

目標類型	識別類型
目標類型	大	中	小	錯誤
大	142	10	0	4
中	11	233	3	2
小	0	6	87	3

下載: 導出CSV

參考文獻(18)

李余興, 李亞安, 陳曉. 基于EEMD的艦船輻射噪聲特征提取方法研究[J]. 振動與沖擊, 2017, 36(5): 114–119. doi: 10.13465/j.cnki.jvs.2017.05.018

LI Yuxing, LI Yaan, and CHEN Xiao. Ships’ radiated noise feature extraction based on EEMD[J]. Journal of Vibration and Shock, 2017, 36(5): 114–119. doi: 10.13465/j.cnki.jvs.2017.05.018

YAN Jiaquan, SUN Haixin, CHEN Hailan, et al. Resonance-based time-frequency manifold for feature extraction of ship-radiated noise[J]. Sensors, 2018, 18(4): 936. doi: 10.3390/s18040936

相敬林, 劉勛. 艦船做為體積聲源的源強度譜縱向分布特性[J]. 探測與控制學報, 2002, 24(2): 5–9, 17. doi: 10.3969/j.issn.1008-1194.2002.02.002

XIANG Jinglin and LIU Xun. The longitudinal distribution of source intensity spectrum of ship-radiated noise[J]. Journal of Detection &Control, 2002, 24(2): 5–9, 17. doi: 10.3969/j.issn.1008-1194.2002.02.002

周有, 韓鵬, 相敬林. 艦船作為體積目標時噪聲通過特性的仿真[J]. 探測與控制學報, 2005, 27(2): 61–64. doi: 10.3969/j.issn.1008-1194.2005.02.017

ZHOU You, HAN Peng, and XIANG Jinglin. Simulation of radiated noise of the ship as a volume target[J]. Journal of Detection &Control, 2005, 27(2): 61–64. doi: 10.3969/j.issn.1008-1194.2005.02.017

陳韶華, 李世智, 陳川. 子帶通過特性分析用于體積目標識別的研究[C]. 中國聲學學會2007年青年學術會議論文集(下), 武漢, 2007: 211–212.

CHEN Shaohua, LI Shizhi, and CHEN Chuan. Volume target recognition with subband passage signature analysis[C]. China Acoustics Society 2007 Youth Conference, Wuhan, China, 2007: 211–212.

劉勛, 相敬林, 張文軍, 等. 自適應艦船被動跟蹤與尺度估計的實驗研究[J]. 兵工學報, 2002, 23(1): 54–58. doi: 10.3321/j.issn:1000-1093.2002.01.013

LIU Xun, XIANG Jinglin, ZHANG Wenjun, et al. Experimental study on the adaptive passive tracking and size estimation of ships[J]. Acta Armamentarii, 2002, 23(1): 54–58. doi: 10.3321/j.issn:1000-1093.2002.01.013

石杰, 相敬林, 陳韶華, 等. 七元非典型聲強向量陣對艦船的被動定向和尺度估計[J]. 電子與信息學報, 2007, 29(6): 1483–1486.

SHI Jie, XIANG Jinglin, CHEN Shaohua, et al. The bearing and size estimation of Volume target based on a vector sound intensity array[J]. Journal of Electronics &Information Technology, 2007, 29(6): 1483–1486.

王笑. 目標艦船尺度特性估計算法研究[D]. [碩士論文], 中國艦船研究院, 2015.

WANG Xiao. Research on the scale estimates algorithm of the Ship target characteristic[D]. [Master dissertation], China Ship Research and Development Academy, 2015.

張攬月, 丁丹丹, 楊德森, 等. 陣元隨機均勻分布球面陣列聯合噪聲源定位方法[J]. 物理學報, 2017, 66(1): 014303. doi: 10.7498/aps.66.014303

ZHANG Lanyue, DING Dandan, YANG Desen, et al. Noise source identification by using near field acoustic holograpy and focused beamforming based on spherical microphone array with random unifrom distribution of elements[J]. Acta Physica Sinica, 2017, 66(1): 014303. doi: 10.7498/aps.66.014303

俞孟薩, 龐業珍. 艦船輻射聲場及聲源特性測量方法研究綜述[J]. 船舶力學, 2017, 21(1): 107–126. doi: 10.3969/j.issn.1007-7294.2017.01.013

YU Mengsa and PANG Yezhen. A review of measurement methods of radiation acoustic field and acoustic source characteristics for ships[J]. Journal of Ship Mechanics, 2017, 21(1): 107–126. doi: 10.3969/j.issn.1007-7294.2017.01.013

CHITRE M, POTTER J, and HENG O S. Underwater acoustic channel characterisation for medium-range shallow water communications[C]. OCEANS '04 MTS/IEEE TECHNO-OCEAN '04, Kobe, Japan, 2004: 40–45.

張安清, 邱天爽, 章新華. α穩定分布的水聲信號處理新方法[J]. 電子與信息學報, 2005, 27(8): 1201–1204.

ZHANG Anqing, QIU Tianshuang, and ZHAND Xinhua. A new underwater acoustic signals processing approach to α-stable distribution[J]. Journal of Electronics &Information Technology, 2005, 27(8): 1201–1204.

FERGUSON B G. Doppler effect for sound emitted by a moving airborne source and received by acoustic sensors located above and below the sea surface[J]. The Journal of the Acoustical Society of America, 1993, 94(6): 3244–3247. doi: 10.1121/1.407230

XU Lingji and YANG Yixin. Parameter estimation of underwater moving sources by using matched Wigner transform[J]. Applied Acoustics, 2016, 101: 5–14. doi: 10.1016/j.apacoust.2015.07.020

GRIFFITH D W, GONZALEZ J G, and ARCE G R. Robust time-frequency representations for signals in α-stable noise using fractional lower-order statistics[C]. 1997 IEEE Signal Processing Workshop on Higher-Order Statistics, Banff, Canada, 1997: 415–419.

張俊林, 王彬, 汪洋, 等. 一種α穩定分布噪聲下OFDM信號調制識別與參數估計算法[J]. 電子學報, 2018, 46(6): 1390–1396. doi: 10.3969/j.issn.0372-2112.2018.06.017

ZHANG Junlin, WANG Bin, WANG Yang, et al. An algorithm for recognition and parameters estimation of OFDM in alpha stable distribution noise[J]. Acta Electronica Sinica, 2018, 46(6): 1390–1396. doi: 10.3969/j.issn.0372-2112.2018.06.017

LI Qin, YUAN Bingchen, and MING Xing. Simulation technique of radiated noise from underwater target and its implement of simulator[C]. The 2nd International Conference on Power Electronics and Intelligent Transportation System, Shenzhen, China, 2009: 357–360.

羅建, 趙亞磊, 黃仁可. 作為體積目標的艦船輻射噪聲建模[J]. 數字海洋與水下攻防, 2018, 1(2): 38–42.

LUO Jian, ZHAO Yalei, and HUANG Renke. Modelling of ship-radiated noise as volume targets[J]. Digital Ocean &Underwater Warfare, 2018, 1(2): 38–42.
