基于ICA和特征提取的MIMO信號調制識別算法

張?zhí)祢U; 范聰聰; 葛宛營; 張?zhí)?/>
	<meta name=

doi:10.11999/JEIT190320

基于ICA和特征提取的MIMO信號調制識別算法

doi: 10.11999/JEIT190320

重慶郵電大學通信與信息工程學院重慶 400065

基金項目: 國家自然科學基金(61671095, 61702065, 61701067, 61771085)，信號與信息處理重慶市市級重點實驗室建設項目(CSTC2009CA2003)，重慶市研究生科研創新項目(CYS17219)，重慶市教育委員會科研項目(KJ1600427, KJ1600429)

詳細信息

作者簡介:
張?zhí)祢U：男，1971年生，博士后，教授，主要研究方向?yàn)檎Z(yǔ)音信號處理、通信信號的調制解調、盲處理、神經網絡實現以及FPGA, VLSI 實現

范聰聰：男，1995年生，碩士生，研究方向?yàn)橥ㄐ判盘?hào)的盲處理

葛宛營：男，1994年生，碩士生，研究方向?yàn)檎Z(yǔ)音增強與盲分離

張?zhí)欤耗校?993年生，碩士生，研究方向?yàn)檎Z(yǔ)音信號處理，聲樂分離

通訊作者:
范聰聰　2669432120@qq.com

中圖分類號: TN911.7
計量
- 文章訪問數: 2341
- HTML全文瀏覽量: 966
- PDF下載量: 120
- 被引次數: 0
出版歷程
- 收稿日期: 2019-05-06
- 修回日期: 2020-03-18
- 網絡出版日期: 2020-06-26
- 刊出日期: 2020-09-27

MIMO Signal Modulation Recognition Algorithm Based on ICA and Feature Extraction

School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (61671095, 61702065, 61701067, 61771085), The Project of Key Laboratory of Signal and Information Processing of Chongqing (CSTC2009CA2003), The Chongqing Graduate Research and Innovation Project (CYS17219), The Research Project of Chongqing Educational Commission (KJ1600427, KJ1600429)

摘要

摘要: 針對非協作通信中多輸入多輸出(MIMO)信號的盲調制識別，該文提出一種基于獨立分量分析(ICA)和特征提取的調制識別算法。根據空分復用MIMO系統各發送天線上信號的獨立性，利用ICA算法從接收的混合信號中分離出發射信號。為實現全盲條件下的調制識別，在進行ICA分離前，利用最小描述長度(MDL)準則估計發射天線數。在得到發射信號之后，首先利用6階累積量、循環譜和4次方譜算法構造4個特征參數，然后利用分層結構的神經網絡分類器識別信號的調制類型。仿真結果表明，所提方法可在較低信噪比下對{2PSK, 2ASK, 2FSK, 4PSK, 4ASK, MSK, 8PSK, 16QAM}8種MIMO信號進行有效識別，當發送天線數為2、接收天線數為5、信噪比為2 dB時，識別率可達到98%以上。
- 信號處理 /
- 多輸入多輸出信號 /
- 獨立分量分析 /
- 6階累積量 /
- 循環譜 /
- 神經網絡
Abstract: For blind modulation recognition of Multiple Input Multiple Output (MIMO) signals in non-cooperative communication, a modulation recognition method based on Independent Component Analysis (ICA) and feature extraction is proposed. According to the signal independence of each transmitting antenna in space division multiplexing MIMO system, the ICA algorithm is used to separate the transmitting signal from the received mixed signal. In order to realize modulation recognition under completely blind condition, the Minimum Description Length (MDL) criterion is used to estimate the number of transmitting antennas before ICA separation. After obtaining the transmitted signal, four characteristic parameters are constructed by using six-order cumulant, cyclic spectrum and fourth-power spectrum algorithm, and then the modulation type of the signal is identified by using hierarchical neural network classifier. The simulation results show that the proposed method can effectively recognize {2PSK, 2ASK, 2FSK, 4PSK, 4ASK, MSK, 8PSK, 16QAM} eight MIMO signals at low SNR. When the number of transmitting antennas is 2, the number of receiving antennas is 5 and the SNR is 2dB, the recognition rate can reach more than 98%.
- Signal processing /
- Multiple Input Multiple Output (MIMO) signals /
- Independent Component Analysis (ICA) /
- Sixth-order cumulant /
- Cyclic spectrum /
- Neural network

HTML全文

圖 1 分層結構的神經網絡分類器

下載: 全尺寸圖片幻燈片

圖 2 調制識別流程圖

下載: 全尺寸圖片幻燈片

圖 3 不同 ${N_{\rm{t}}} \times {N_{\rm{r}}}$ 下的估計性能

下載: 全尺寸圖片幻燈片

圖 4 不同調制方式下 ${N_{\rm{t}}}$ 的估計性能

下載: 全尺寸圖片幻燈片

圖 5 特征參數T₁隨SNR的變化曲線

下載: 全尺寸圖片幻燈片

圖 6 特征參數T₂隨SNR的變化曲線

下載: 全尺寸圖片幻燈片

圖 7 特征參數T₃隨SNR的變化曲線

下載: 全尺寸圖片幻燈片

圖 8 特征參數T₄隨SNR的變化曲線

下載: 全尺寸圖片幻燈片

表 1 各調制信號的高階累積量

累積量	2PSK	4PSK	8PSK	2ASK	4ASK	2FSK	MSK	16QAM
$\left\| {{C_{21}}} \right\|$	1	1	1	1	1	1	1	1
$\left\| {{C_{42}}} \right\|$	2	1	1	2	1.36	1	1	0.68
$\left\| {{C_{63}}} \right\|$	13	4	4	13	9.16	4	4	2.08

下載: 導出CSV

表 2 ${N_{\rm{t}}} \times {N_{\rm{r}}} = 4 \times 5$ 時的識別率(%)

調制類型	–2 dB	0 dB	2 dB	4 dB	6 dB	8 dB	10 dB
2PSK	80.6	85.7	89.5	94.0	97.0	98.8	100
2ASK	82.4	87.3	92.0	95.2	97.0	99.3	100
2FSK	89.0	93.0	94.8	97.3	100	100	100
4PSK	89.4	93.0	96.9	98.2	98.8	100	100
4ASK	85.0	87.0	90.2	96.0	100	100	100
MSK	88.5	92.4	96.0	98.3	99.5	100	100
8PSK	91.0	95.0	97.8	99.0	100	100	100
16QAM	87.0	92.3	95.6	98.2	100	100	100

下載: 導出CSV

表 3 ${N_{\rm{t}}} \times {N_{\rm{r}}} = 4 \times 6$ 時的識別率(%)

調制類型	-2 dB	0 dB	2 dB	4 dB	6 dB	8 dB	10 dB
2PSK	83.7	88.0	95.0	98.2	99.4	100	100
2ASK	84.5	90.3	96.0	98.4	100	100	100
2FSK	91.3	96.0	98.2	99.5	100	100	100
4PSK	91.6	96.4	97.5	100	100	100	100
4ASK	89.0	94.4	98.0	99.2	100	100	100
MSK	91.0	95.0	97.3	100	100	100	100
8PSK	93.0	97.2	99.3	100	100	100	100
16QAM	91.0	95.3	98.4	100	100	100	100

下載: 導出CSV

表 4 ${N_{\rm{t}}} \times {N_{\rm{r}}}{\rm{ = 2}} \times {\rm{5}}$ 時的識別率(%)

調制類型	-2 dB	0 dB	2 dB	4 dB	6 dB	8 dB	10 dB
2PSK	89.0	93.1	98.3	99.0	100	100	100
2ASK	91.6	95.0	98.2	99.0	100	100	100
2FSK	93.4	98.3	99.5	100	100	100	100
4PSK	95.8	98.3	100	100	100	100	100
4ASK	92.0	97.0	99.6	100	100	100	100
MSK	94.0	97.6	98.8	100	100	100	100
8PSK	96.8	99.3	100	100	100	100	100
16QAM	94.3	98.0	100	100	100	100	100

下載: 導出CSV

參考文獻(16)

ZHAO Yong, XU Yitao, JIANG Han, et al. Recognition of digital modulation signals based on high-order cumulants[C]. 2015 International Conference on Wireless Communications & Signal Processing, Nanjing, China, 2015: 1–5. doi: 10.1109/WCSP.2015.7341279.

郭立民, 寇韻涵, 陳濤, 等. 基于棧式稀疏自編碼器的低信噪比下低截獲概率雷達信號調制類型識別[J]. 電子與信息學報, 2018, 40(4): 875–881. doi: 10.11999/JEIT170588

GUO Limin, KOU Yunhan, CHEN Tao, et al. Low probability of intercept radar signal recognition based on stacked sparse auto-encoder[J]. Journal of Electronics &Information Technology, 2018, 40(4): 875–881. doi: 10.11999/JEIT170588

陳濤, 柳立志, 郭立民. 基于MWC壓縮采樣寬帶接收機的雷達信號脈內調制識別[J]. 電子與信息學報, 2018, 40(4): 867–874. doi: 10.11999/JEIT170612

CHEN Tao, LIU Lizhi, and GUO Limin. Intra-pulse modulation recognition of radar signals based on MWC compressed sampling wideband receiver[J]. Journal of Electronics &Information Technology, 2018, 40(4): 867–874. doi: 10.11999/JEIT170612

張利, 李青. 基于高階累積量的調制識別算法的研究[J]. 信息工程大學學報, 2017, 18(4): 403–408. doi: 10.3969/j.issn.1671-0673.2017.04.005

ZHANG Li and LI Qing. Research on modulation recognition algorithm based on higher-order cumulant[J]. Journal of Information Engineering University, 2017, 18(4): 403–408. doi: 10.3969/j.issn.1671-0673.2017.04.005

譚曉衡, 褚國星, 張雪靜, 等. 基于高階累積量和小波變換的調制識別算法[J]. 系統工程與電子技術, 2018, 40(1): 171–177. doi: 10.3969/j.issn.1001-506X.2018.01.25

TAN Xiaoheng, CHU Guoxing, ZHANG Xuejing, et al. Modulation recognition algorithm based on high - order cumulants and wavelet transform[J]. Systems Engineering and Electronics, 2018, 40(1): 171–177. doi: 10.3969/j.issn.1001-506X.2018.01.25

趙雄文, 郭春霞, 李景春. 基于高階累積量和循環譜的信號調制方式混合識別算法[J]. 電子與信息學報, 2016, 38(3): 674–680. doi: 10.11999/JEIT150747

ZHAO Xiongwen, GUO Chunxia, and LI Jingchun. Mixed recognition algorithm for signal modulation schemes by high-order cumulants and cyclic spectrum[J]. Journal of Electronics &Information Technology, 2016, 38(3): 674–680. doi: 10.11999/JEIT150747

CHOQUEUSE V, AZOU S, YAO K, et al. Blind modulation recognition for MIMO systems[J]. MTA Review, 2009, 19(2): 183–196.

張路平, 王建新. MIMO信號調制方式盲識別[J]. 應用科學學報, 2012, 30(2): 135–140. doi: 10.3969/j.issn.0255-8297.2012.02.005

ZHANG Luping and WANG Jianxin. Blind modulation recognition for MIMO signals[J]. Journal of Applied Sciences, 2012, 30(2): 135–140. doi: 10.3969/j.issn.0255-8297.2012.02.005

DAS D, BORA P K, and BHATTACHARJEE R. Blind modulation recognition of the lower order PSK signals under the MIMO Keyhole channel[J]. IEEE Communications Letters, 2018, 22(9): 1834–1837. doi: 10.1109/LCOMM.2018.2853638

WEI Mengchuan, WEI Zaixue, YANG Jianyi, et al. Automatic modulation recognition of digital signal based on auto-encoding network in MIMO System[C]. The 18th IEEE International Conference on Communication Technology, Chongqing, China, 2018: 1017–1021. doi: 10.1109/ICCT.2018.8600148.

LIU Xiaokai, ZHAO Chenglin, WANG Pengbiao, et al. Blind modulation classification algorithm based on machine learning for spatially correlated MIMO system[J]. IET Communications, 2017, 11(7): 1000–1007. doi: 10.1049/iet-com.2015.1222

COMON P and JUTTEN C. Handbook of Blind Source Separation: Independent Component Analysis and Applications[M]. Oxford: Academic Press, 2010: 147–153.

許宏吉, 劉琚, 谷波, 等. 空時分組碼通信中的一類ICA盲檢測方案[J]. 通信學報, 2007, 28(6): 12–19. doi: 10.3321/j.issn:1000-436X.2007.06.003

XU Hongji, LIU Ju, GU Bo, et al. ICA based blind detection scheme in space-time block coding communications[J]. Journal on Communications, 2007, 28(6): 12–19. doi: 10.3321/j.issn:1000-436X.2007.06.003

WANG Rui. Research on digital signal modulation recognition and parameter estimation based on cyclostationarity[D]. [Master dissertation], University of Electronic Science and Technology, 2012: 20–24.

REYNALDI A, LUKAS S, and MARGARETHA H. Backpropagation and Levenberg-Marquardt algorithm for training finite element neural network[C]. The 6th UKSim/AMSS European Symposium on Computer Modeling and Simulation, Valetta, Malta, 2012: 89–94. doi: 10.1109/EMS.2012.56.

KHOSRAVIANI M, KALBKHANI H, and SHAYESTEH M G. Digital modulation recognition in MIMO systems based on segmentation of received data[C]. 2017 Iranian Conference on Electrical Engineering, Tehran, Iran, 2017: 1998–2002. doi: 10.1109/IranianCEE.2017.7985384.
