基于流量工程的軟件定義網絡控制資源優化機制

胡宇翔; 李子勇; 胡宗魁; 胡濤

doi:10.11999/JEIT190276

基于流量工程的軟件定義網絡控制資源優化機制

doi: 10.11999/JEIT190276

1.
國家數字交換系統工程技術研究中心 ??鄭州 ??450002
2.
中國人民解放軍第91445部隊 大連 116043

基金項目: 國家自然科學基金(61521003, 61872382)，國家重點研發計劃(2017YFB0803204)，廣東省重點領域研發計劃(2018B010113001)

詳細信息

作者簡介:
胡宇翔：男，1982年生，副研究員，研究方向?yàn)閷拵畔⒕W(wǎng)、軟件定義網絡

李子勇：男，1995年生，碩士生，研究方向?yàn)檐浖x網絡、計算機網絡

胡宗魁：男，1986年生，助理研究員，研究方向?yàn)榭刂谱詣?dòng)化

胡濤：男，1993年生，博士生，研究方向?yàn)檐浖x網絡、網絡空間安全

通訊作者:
李子勇　17629352940@163.com

中圖分類號: TN919.2; TP393.2
計量
- 文章訪問數: 3237
- HTML全文瀏覽量: 1297
- PDF下載量: 125
- 被引次數: 0
出版歷程
- 收稿日期: 2019-04-22
- 修回日期: 2019-06-24
- 網絡出版日期: 2019-08-02
- 刊出日期: 2020-03-19

Control Resource Optimization Mechanism of SDN Based on Traffic Engineering

1.
National Digital Switching System Engineering & Technology Research Center, Zhengzhou 450002, China
2.
Unit 91445 of PLA, Dalian 116043, China

Funds: The National Natural Science Foundation of China (61521003, 61872382), The National Key Research and Development Program of China (2017YFB0803204), The Research and Development Program in Key Areas of Guangdong Province (2018B010113001)

摘要

摘要:
針對軟件定義網絡(SDN)分布式控制平面中由于網絡分域管理所引發的控制擴張問題，該文提出了一種基于流量工程的SDN控制資源優化(TERO)機制。首先基于數據流的路徑特征對流請求的控制資源消耗進行分析，指出通過調整控制器和交換機的關聯關系可以降低控制資源消耗。然后將控制器關聯過程分為兩個階段：先設計了最小集合覆蓋算法來快速求解大規模網絡中控制器關聯問題；在此基礎上，引入聯合博弈策略來優化控制器和交換機的關聯關系以減少控制資源消耗和控制流量開銷。仿真結果表明，與現有的控制器和交換機就近關聯機制相比，該文機制能在保證較低控制流量開銷的前提下，節省約28%的控制資源消耗。
- 軟件定義網絡 /
- 資源優化 /
- 控制器關聯 /
- 分布式控制平面
Abstract:
In Software-Defined Networking (SDN) with distributed control plane, network expansion problems arise due to network domain management. To address this issue, a Traffic Engineering-based control Resource Optimization (TERO) mechanism of SDN is proposed. It analyzes the control resource consumption of flow requests processing with different path characteristics, and points out that the control resource consumption can be reduced by changing the association relationship between controllers and switches. The controller association mechanism is divided into two phases: firstly, a minimum set cover algorithm is designed to solve the controller association problem efficiently in large-scale network. Then, a coalitional game strategy is introduced to optimize the controller association relationship to reduce both control resource consumption and control traffic overhead. The simulation results demonstrate that while keeping control traffic overhead low, mechanism which in this paper can reduce control resource consumption by about 28% in comparison with the controller proximity mechanism.
- Software-Defined Networking (SDN) /
- Resource optimization /
- Controller association /
- Distributed control plane

HTML全文

圖 1 SDN分布式控制平面對流請求處理流程

下載: 全尺寸圖片幻燈片

圖 2 通過交換機遷移可以降低控制資源消耗

下載: 全尺寸圖片幻燈片

圖 3 控制器-交換機備選關系拓?fù)?/p>

下載: 全尺寸圖片幻燈片

圖 4 控制器-交換機關聯后拓?fù)?/p>

下載: 全尺寸圖片幻燈片

圖 5 階段1輸出的控制器-交換機關系

下載: 全尺寸圖片幻燈片

圖 6 控制資源消耗對比

下載: 全尺寸圖片幻燈片

圖 7 控制流量開銷對比

下載: 全尺寸圖片幻燈片

圖 8 MSC算法和TERO控制資源消耗

下載: 全尺寸圖片幻燈片

圖 9 MSC算法和TERO控制流量開銷

下載: 全尺寸圖片幻燈片

圖 10 不同網絡拓?fù)淇刂瀑Y源消耗

下載: 全尺寸圖片幻燈片

圖 11 不同網絡拓?fù)淇刂破髫?fù)載均衡率

下載: 全尺寸圖片幻燈片

表 1 最小集合覆蓋算法執行過程

算法1 最小集合覆蓋算法(Minimum Set Coverage)
輸入： SDN網絡拓?fù)溧徑泳仃?{\text{G}} = [{a_{ij}}]$；網絡中流處理請求矩陣${\text{F}} = [{f_{ij}}]$；控制器所能關聯的備選集合：${C_i} = \{ {S_1},{S_2}, ·\!·\!· ,{S_i}\} $；控制器的容量及冗余因子：${\alpha _m}$, $\beta $
輸出：控制器-交換機之間的映射關系：${\text{X} } = [{x_{ij} }]$
(1) 初始化：控制器-交換機關聯關系SC={·}；已關聯的交換機set_switches={·};
(2) 統計網絡中端到端流量分布Flow_pair=Flow_sort(F)；
(3)　while I in Flow_pair：遍歷網絡中流量
(4)　　Path_switch= Dijkstra(G, i)；計算端到端流量的路徑
(5)　　while Path_switch: 循環4個完備策略
(6)　　　if Path_switch $ \subseteq $${C_i}$：若滿足完備策略1, SC[${C_i}$]={Path_switch }；流經過的所有交換機關聯到${C_i}$
(7)　　　if ${S_i}$$ \in $Path_switch AND ${S_i} \in $${C_j}$滿足完備策略2, ${S_i} \to {C_j}$; ${S_i}$關聯到${C_j}$
(8)　　　if 存在${C_i} \subseteq {C_j}$：滿足完備策略3，則$ \cup {S_i} \to {C_j}$；交換機${S_i}$優先關聯到${C_j}$
(9)　　　if Sn(${S_i}$)$ \subseteq $Sn(${S_j}$)：滿足完備策略4${S_i} \to \cup {\rm{ }}{C_j}$；交換機${S_i}$優先處理
(10)　　　else 如果上述4個完備策略都不能滿足：實行貪婪算法switch = max(Path_switch & ${C_i}$)；尋找關聯交換機較多的控制器SC[${C_i}$]= {switch}；將相應交換機關聯到控制器${C_i}$上
end if; end while;
(11) end while;
(12) SC={${C_j} = \{ {S_j},{S_{j + 1}}, ·\!·\!· {\rm{,}}{S_n}\} $；輸出控制器-交換機映射關系

下載: 導出CSV

表 2 聯合博弈策略執行過程

算法2 聯合博弈策略Coalitional Game
輸入：算法1輸出的控制器-交換機之間的關聯關系${\text{X}} = [{x_{ij} }]$
輸出：控制器-交換機之間的關聯關系$\text{X}' = [{x'_{ij} }]$
(1) 初始化$\text{X} = [{x_{ij} }]$, ${\alpha _m}$, $\beta $
(2) repeat
(3)　　for each ${s_i}$ in $F$：尋找可能存在的交換機遷移
(4)　　　Initial migration pair ${s_i}:{\rm{ }}{c_m} \to {C_n}$；找到滿足兩個條件的交換機遷移對
end for
(5)　　for each $ {c_m}$：對于每一個控制器
(6)　　　${L_{ij}}$=${f_{ij}}{d_{kl}}{x_{ik}}{x_{jl}} + \delta {c_{ik}}$;計算每條數據流的資源消耗
(7)　　　if ${s_i}:{\rm{ }}{c_m} \to {C_n}$ and ${\theta _n} \le \alpha \times \beta $；保證控制器不過載，尋找可能的交換機遷移
(8)　　　　${L'_{ij}}$=${f_{ij}}{d_{kl}}{x'_{ik}}{x'_{jl}} + \delta {c'_{ik}}$；假設遷移，計算新的資源消耗
(9)　　　　if ${L'_{ij}} \le {L_{ij}}$: 若交換機遷移前后，資源消耗減少了，則接受遷移
(10)　　　　　${s_i} \to {c_j}$；實施交換機遷移${L_{ij}} = {L'_{ij}}$；更新的資源消耗
(11)　　　end if; end for；
(12) 直到系統沒有任何交換機要求遷移，則算法收斂

下載: 導出CSV

表 3 實驗拓?fù)鋽?shù)據

網絡拓?fù)?/td>	節點數	鏈路數	控制器數	距離閾值
ARNES	34	47	4	3
ChinaNet	42	66	5	4
Interllifiber	73	93	6	5
Interoute	110	149	7	6

下載: 導出CSV
