高效寬帶包絡跟蹤系統電路性能優化及非線性行為校正

曹韜; 劉友江; 楊春; 周劼

doi:10.11999/JEIT190275

高效寬帶包絡跟蹤系統電路性能優化及非線性行為校正

doi: 10.11999/JEIT190275

中國工程物理研究院電子工程研究所綿陽 621900

基金項目: 國家自然科學基金(61601425)

詳細信息

作者簡介:
曹韜：男，1985年生，副研究員，研究方向為無線測控通信系統設計技術

劉友江：男，1986年生，特聘研究員，研究方向為無線測控通信系統設計技術

楊春：男，1972年生，研究員，研究方向為無線測控通信系統設計技術

周劼：男，1972年生，研究員，研究方向為無線測控通信系統設計技術

通訊作者:
曹韜　caotaog@gmail.com

中圖分類號: TN919
計量
- 文章訪問數: 1701
- HTML全文瀏覽量: 1039
- PDF下載量: 52
- 被引次數: 0
出版歷程
- 收稿日期: 2019-04-22
- 修回日期: 2019-11-24
- 網絡出版日期: 2019-11-30
- 刊出日期: 2020-03-19

Circuits Optimization and System Linearization for High Efficiency and Wideband Envelope Tracking Architecture

Institute of Electronic Engineering, China Academy of Engineering Physics, Mianyang 621900, China

Funds: The National Natural Science Foundation of China (61601425)

摘要

摘要:
為改善包絡跟蹤(ET)發射機帶寬、效率、線性度等指標，需優化其關鍵電路性能并校正系統非線性行為。針對該問題，該文構建電源調制器等效模型，推導其效率極值并闡述效率優化方法；引入頻率補償網絡來提升電路帶寬及線性性能；基于系統非線性行為特征，提出包絡增強型數字預失真模型及線性化方案；設計實際電路并搭建包絡跟蹤系統。對于S頻段5/10/20 MHz帶寬6.7 dB峰均比測試信號，該系統功放平均效率分別為61%, 54%, 44%，且矢量幅度誤差(EVM)均優于1%，具有較好的帶寬、效率、線性度等性能，驗證了電路優化方法及非線性行為校正方案的可行性。
- 包絡調制器 /
- 包絡跟蹤 /
- 數字預失真 /
- 高效率
Abstract:
To improve bandwidth, efficiency and linearity of Envelope Tracking (ET) architecture, it is necessary to optimize the performance of envelope supply modulator and linearize nonlinear behavior of the ET system. The optimization procedure of the supply modulator is proposed based on the equivalent circuit model. The frequency compensation network is used to improve the bandwidth and linearity of the modulator circuit. An envelope enhanced memory polynomial digital pre-distortion model is introduced to address the nonlinear distortion of the ET system. The practical circuit mentioned above is fabricated and the overall experimental system is set up. Measurement results show that the ET PA at S-band obtains measured efficiency 61%, 54%, 44% and Error Vector Magnitude (EVM) 1% for 6.7 dB PAPR signals with 5 MHz/10 MHz/20 MHz modulation bandwidths, respectively. The ET system exhibits competitive bandwidth, efficiency and linearity, which verifies the proposed optimization and linearization methodology.
- Envelope modulator /
- Envelope Tracking(ET) /
- Digital Pre-Distortion(DPD) /
- High-efficiency

HTML全文

圖 1 混合型EA電路結構

下載: 全尺寸圖片幻燈片

圖 2 電流采樣信號與開關波形示意圖

下載: 全尺寸圖片幻燈片

圖 3 參數β與h的關系曲線及不同調制信號包絡幅度概率分布

下載: 全尺寸圖片幻燈片

圖 4 EA平均效率曲面3維視圖及俯視圖

下載: 全尺寸圖片幻燈片

圖 5 EA線性級反饋網絡結構圖

下載: 全尺寸圖片幻燈片

圖 6 頻率補償前后線性級幅頻特性

下載: 全尺寸圖片幻燈片

圖 7 EA電路實物圖及其平均效率特性

下載: 全尺寸圖片幻燈片

圖 8 EA電路輸入、輸出包絡及誤差信號歸一化功率譜

下載: 全尺寸圖片幻燈片

圖 9 ET測試系統框圖

下載: 全尺寸圖片幻燈片

圖 10 ET系統關鍵波形實測圖(局部)

下載: 全尺寸圖片幻燈片

圖 11 DPD前后ET系統輸出頻譜測試圖(局部)

下載: 全尺寸圖片幻燈片

表 1 本文EA電路測試結果與近年文獻結果對比

文獻/年份	帶寬(MHz)	負載(Ω)	輸出范圍(V)	輸出功率(W)	效率(%)
文獻[9]/2016	5	—	12.0～27.0	4.0	76.0
文獻[10]/2017	5	—	0～22.5	4.8	73.6
文獻[11]/2017	10	17.5	9.6～26.4	19.4	77.0
文獻[12]/2017	10	6	1.0～2.5	1.0	83.0
文獻[13]/2019	10	8	7.0～27.0	42.5	77.1
本文	40	7.5	2.5～28.0	18.2	81.7

下載: 導出CSV

表 2 ET系統測試結果

信號帶寬(MHz)	DPD	功率(dBm)	增益(dB)	效率(%)	ACPR1(dBc)	EVM(%)
5	無	34.4	11.0	61.3	-26.7	7.50
5	有	34.4	11.0	60.8	-49.7	0.32
10	無	34.6	11.1	56.7	-26.8	8.10
10	有	34.2	10.7	53.7	-46.3	0.60
20	無	34.3	11.3	46.4	-26.4	8.90
20	有	34.1	11.1	44.1	-46.0	0.67

下載: 導出CSV

參考文獻(16)

BALTEANU F, MODI H, ZHU Yu, et al. Envelope tracking system for high power applications in uplink 4G/5G LTE advanced[C]. 2018 Asia-Pacific Microwave Conference, Kyoto, Japan, 2018: 863–865. doi: 10.23919/APMC.2018.8617571.

SHI Weimin, HE Songbai, ZHU Xiaoyu, et al. Broadband continuous-mode doherty power amplifiers with noninfinity peaking impedance[J]. IEEE Transactions on Microwave Theory and Techniques, 2018, 66(2): 1034–1046. doi: 10.1109/TMTT.2017.2749224

HOLZER K D, YUAN Wen, and WALLING J S. Wideband techniques for outphasing power amplifiers[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2018, 65(9): 2715–2725. doi: 10.1109/TCSI.2018.2800041

LIU Youjiang, YOO C S, FAIRBANKS J, et al. A 53% PAE envelope tracking GaN power amplifier for 20 MHz bandwidth LTE signals at 880 MHz[C]. 2016 IEEE Topical Conference on Power Amplifiers for Wireless and Radio Applications, Austin, USA, 2016: 30–32. doi: 10.1109/PAWR.2016.7440155.

HASSAN M, ASBECK P M, and LARSON L E. A CMOS dual-switching power-supply modulator with 8% efficiency improvement for 20 MHz LTE envelope tracking RF power amplifier[C]. 2013 IEEE International Solid-State Circuits Conference Digest of Technical Papers, San Francisco, USA, 2013: 366–368. doi: 10.1109/ISSCC.2013.6487772.

KOMATSUZAKI Y, LANFRANCO S, KOLMONEN T, et al. A high efficiency 3.6–4.0 GHz envelope-tracking power amplifier using GaN soft-switching buck-converter[C]. 2018 IEEE/MTT-S International Microwave Symposium, Philadelphia, USA, 2018: 465–468. doi: 10.1109/MWSYM.2018.8439225.

HASSAN M, LARSON L E, LEUNG V W, et al. A wideband CMOS/GaAs HBT envelope tracking power amplifier for 4G LTE mobile terminal applications[J]. IEEE Transactions on Microwave Theory and Techniques, 2012, 60(5): 1321–1330. doi: 10.1109/TMTT.2012.2187537

KIM J, KIM D, CHO Y, et al. Highly efficient RF transmitter over broad average power range using multilevel envelope-tracking power amplifier[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2015, 62(6): 1648–1657. doi: 10.1109/TCSI.2015.2423771

WANG Yazhou, JIN Qian, and RUAN Xinbo. Optimized design of the multilevel converter in series-form switch-linear hybrid envelope-tracking power supply[J]. IEEE Transactions on Industrial Electronics, 2016, 63(9): 5451–5460. doi: 10.1109/TIE.2016.2565459

JIN Qian, RUAN Xinbo, REN Xiaoyong, et al. Step-wave switched capacitor converter for compact design of envelope tracking power supply[J]. IEEE Transactions on Industrial Electronics, 2017, 64(12): 9587–9591. doi: 10.1109/TIE.2017.2716900

LENG Yang, RUAN Xinbo, JIN Qian, et al. High-efficiency high-bandwidth switch-linear hybrid envelope-tracking power supply with slew rate split-band method[C]. 2017 IEEE Energy Conversion Congress and Exposition, Cincinnati, USA, 2017: 2246–2252. doi: 10.1109/ECCE.2017.8096438.

JING Yue and BAKKALOGLU B. A high slew-rate adaptive biasing hybrid envelope tracking supply modulator for LTE applications[J]. IEEE Transactions on Microwave Theory and Techniques, 2017, 65(9): 3245–3256. doi: 10.1109/TMTT.2017.2678476

XI Huan, CAO Juan, LIU Ning, et al. High bandwidth envelope tracking power supply with pulse edge independent distribution method[J]. IEEE Transactions on Industrial Electronics, 2019, 66(8): 5907–5917. doi: 10.1109/TIE.2018.2874580

KIM D, KANG D, CHOI J, et al. Optimization for envelope shaped operation of envelope tracking power amplifier[J]. IEEE Transactions on Microwave Theory and Techniques, 2011, 59(7): 1787–1795. doi: 10.1109/TMTT.2011.2140124

LEACH W M. Feedforward compensation of the amplifier output stage for improved stability with capacitive loads[J]. IEEE Transactions on Consumer Electronics, 1988, 34(2): 334–338. doi: 10.1109/30.2950

MKADEM F, ISLAM A, and BOUMAIZA S. Multi-band complexity reduced generalized-memory-polynomial power-amplifier digital pre-distortion[J]. IEEE Transactions on Microwave Theory and Techniques, 2016, 64(6): 1763–1774. doi: 10.1109/TMTT.2016.2561279
