地磁背景下基于傳感器陣列的磁偶極子目標跟蹤方法

陳路昭; 馮永強; 郭瑞杰; 朱萬華; 方廣有

doi:10.11999/JEIT190236

地磁背景下基于傳感器陣列的磁偶極子目標跟蹤方法

doi: 10.11999/JEIT190236

陳路昭^{1, 2, 3},
馮永強^{1, 2},
郭瑞杰³,
朱萬華^1, ,,
方廣有¹

1.
中國科學院電磁輻射與探測技術重點實驗室北京 100190
2.
中國科學院大學 北京 100049
3.
北京自動化控制設備研究所北京 100074

基金項目: 國家自然科學基金青年基金(41704177)和國家重點研發計劃“深地資源勘查開采”重點專項(2018YFC0603201)

詳細信息

作者簡介:
陳路昭：男，1992年生，博士，研究方向為傳感器陣列的磁信號處理方法、運動平臺磁干擾補償技術

馮永強：男，1985年生，博士生，研究方向為航磁系統硬件設計與航磁數據處理方法

郭瑞杰：女，1992年生，碩士，研究方向為組合導航與系統控制技術

朱萬華：男，1982年生，副研究員，主要研究方向為高靈敏度磁場傳感器關鍵技術、高性能磁屏蔽關鍵技術

方廣有：男，1963年生，研究員，主要研究方向為超寬帶電磁場理論及工程應用、超寬帶雷達成像技術、微波成像新方法和新技術

通訊作者:
朱萬華　whzhu@mail.ie.ac.cn

中圖分類號: O411.5; TN911.73
計量
- 文章訪問數: 3673
- HTML全文瀏覽量: 1216
- PDF下載量: 131
- 被引次數: 0
出版歷程
- 收稿日期: 2019-04-10
- 修回日期: 2019-12-01
- 網絡出版日期: 2019-12-09
- 刊出日期: 2020-03-19

Magnetic Dipole Object Tracking Algorithm Based on Magnetometer Array in Geomagnetic Background

Luzhao CHEN^{1, 2, 3},
Yongqiang FENG^{1, 2},
Ruijie GUO³,
Wanhua ZHU^{1
, ,},
Guangyou FANG¹

1.
Key Laboratory of Electromagnetic Radiation and Sensing Technology, Chinese Academy of Sciences, Beijing 100190, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China
3.
Beijing Automation Control Equipment Institute, Beijing 100074, China

Funds: The Youth Program of National Natural Science Foundation of China (41704177), The National Key R&D Program of China (2018YFC0603201)

摘要

摘要:
針對地磁背景下磁偶極子目標跟蹤過程中存在的地磁干擾與模型非線性的問題，該文提出一種基于差量磁異常的蒙特卡洛卡爾曼濾波(MCKF)跟蹤方法。新的跟蹤方法以傳感器陣列測量磁場的差量作為觀測信號，并利用蒙特卡洛卡爾曼濾波算法解決模型的非線性問題，實現磁偶極子目標的實時跟蹤。通過仿真跟蹤實驗，結果表明該文算法較傳統的擴展或無跡卡爾曼濾波算法在穩定跟蹤過程中對目標特征參數的估計更精確；通過地磁背景跟蹤實驗，結果驗證了該文算法較傳統算法在低信噪比下的性能優勢。
- 磁偶極子 /
- 蒙特卡洛卡爾曼濾波 /
- 傳感器陣列 /
- 地磁背景
Abstract:
In order to solve the problem of geomagnetic interference and model nonlinearity in the tracking process of magnetic dipole under geomagnetic background, Monte Carlo Kalman Filter (MCKF) tracking method based on differential magnetic anomaly is proposed in this paper. The new tracking method takes the difference of magnetic field measured by sensor array as the observation signal, and uses Monte Carlo Kalman Filtering (MCKF) algorithm to solve the nonlinear problem of the model to realize the real-time tracking of magnetic dipole targets. The simulation results show that the proposed method is more accurate than the traditional Extended Kalman Filter (EKF) or Untracked Kalman Filter (UKF) in the stable tracking process. The results of real geomagnetic background tracking experiments show that the proposed algorithm has better tracking performance under low SNR.
- Magnetic dipole /
- Monte Carlo Kalman Filter (MCKF) /
- Sensor array /
- Geomagnetic background

HTML全文

圖 1 仿真磁偶極子運動軌跡與傳感器分布位置

下載: 全尺寸圖片幻燈片

圖 2 傳感器測量結果

下載: 全尺寸圖片幻燈片

圖 3 基于MCKF跟蹤算法的流程圖

下載: 全尺寸圖片幻燈片

圖 4 仿真磁偶極子跟蹤結果對比

下載: 全尺寸圖片幻燈片

圖 5 真實目標跟蹤實驗

下載: 全尺寸圖片幻燈片

圖 6 跟蹤實驗?zāi)M磁性目標體

下載: 全尺寸圖片幻燈片

圖 7 陣列傳感器測量磁場與差量磁場

下載: 全尺寸圖片幻燈片

圖 8 模擬磁性目標的位置跟蹤結果

下載: 全尺寸圖片幻燈片

圖 9 模擬磁性目標的磁矩跟蹤結果

下載: 全尺寸圖片幻燈片

表 1 不同跟蹤算法各方向投影軌跡跟蹤誤差

	跟蹤算法	時間區間
	跟蹤算法	1～40點	41～80點	81～120點	120～160點	160～200點
x方向	EKF	0.0651	0.0127	0.0023	0.0057	0.0409
	UKF	0.0689	0.0127	0.0024	0.0057	0.0410
	MCKF	0.2143	0.0153	0.0024	0.0039	0.0218
y方向	EKF	0.0491	0.0113	0.0059	0.0100	0.0319
	UKF	0.0512	0.0112	0.0061	0.0096	0.0318
	MCKF	0.1237	0.0115	0.0042	0.0061	0.0158
z方向	EKF	0.0430	0.0089	0.0021	0.0042	0.0163
	UKF	0.0436	0.0088	0.0022	0.0041	0.0164
	MCKF	0.0456	0.0086	0.0022	0.0043	0.0198

下載: 導出CSV

表 2 不同蒙特卡洛樣本點數的算法各方向投影軌跡跟蹤誤差

表2(a) x方向
蒙特卡洛樣本點數	時間區間
蒙特卡洛樣本點數	1～40	41～80	81～120	120～160	160～200
50	0.2817	0.0242	0.0035	0.0052	0.0264
100	0.2481	0.0194	0.0030	0.0046	0.0231
200	0.2143	0.0153	0.0024	0.0039	0.0218
400	0.2316	0.0159	0.0023	0.0039	0.0212
表2(b) y方向
蒙特卡洛樣本點數	時間區間
蒙特卡洛樣本點數	1～40	41～80	81～120	120～160	160～200
50	0.1658	0.0168	0.0049	0.0069	0.0192
100	0.1442	0.0141	0.0047	0.0063	0.0166
200	0.1237	0.0115	0.0042	0.0061	0.0158
400	0.1346	0.0118	0.0043	0.0059	0.0151
表2(c) z方向
蒙特卡洛樣本點數	時間區間
蒙特卡洛樣本點數	1～40	41～80	81～120	120～160	160～200
50	0.0569	0.0124	0.0031	0.0053	0.0242
100	0.0496	0.0105	0.0026	0.0046	0.0202
200	0.0456	0.0086	0.0022	0.0043	0.0198
400	0.0466	0.0090	0.0021	0.0042	0.0195

下載: 導出CSV

參考文獻(23)

IOANNIDIS G. Identification of a ship or submarine from its magnetic signature[J]. IEEE Transactions on Aerospace and Electronic Systems, 1977, AES-13(3): 327–329. doi: 10.1109/TAES.1977.308404

FAGGIONI O, SOLDANI M, GABELLONE A, et al. Undersea harbour defence: A new choice in magnetic networks[J]. Journal of Applied Geophysics, 2010, 72(1): 46–56. doi: 10.1016/j.jappgeo.2010.07.001

ZHANG Mengying, WANG Hua, GE Lin, et al. Automatic search algorithms for near-field ferromagnetic targets based on magnetic anomaly detection[J]. Mathematical Problems in Engineering, 2018, 2018: 2130236. doi: 10.1155/2018/2130236

SHEINKER A, LERNER B, SALOMONSKI N, et al. Localization and magnetic moment estimation of a ferromagnetic target by simulated annealing[J]. Measurement Science and Technology, 2007, 18(11): 3451–3457. doi: 10.1088/0957-0233/18/11/027

SHEINKER A, SALOMONSKI N, GINZBURG B, et al. Remote sensing of a magnetic target utilizing population based incremental learning[J]. Sensors and Actuators A: Physical, 2008, 143(2): 215–223. doi: 10.1016/j.sna.2007.10.064

YANG Wan’an, HU Chao, LI Mao, et al. A new tracking system for three magnetic objectives[J]. IEEE Transactions on Magnetics, 2010, 46(12): 4023–4029. doi: 10.1109/tmag.2010.2076823

GAO Xiang, YAN Shenggang, and LI Bi. A novel method of localization for moving objects with an alternating magnetic field[J]. Sensors, 2017, 17(4): 923(1–12). doi: 10.3390/s17040923

WANG Chen, QU Xiaodong, ZHANG Xiaojuan, et al. A fast calibration method for magnetometer array and the application of ferromagnetic target localization[J]. IEEE Transactions on Instrumentation and Measurement, 2017, 66(7): 1743–1750. doi: 10.1109/TIM.2017.2668558

賈文抖, 林春生, 陳春行, 等. 針對磁目標定位失效的改進歐拉定位方法[J]. 海軍工程大學學報, 2018, 30(3): 37–42.

JIA Wendou, LIN Chunsheng, CHEN Chunxing, et al. Improved Euler method for preventing failure of positioning magnetic target[J]. Journal of Naval University of Engineering, 2018, 30(3): 37–42.

WIEGERT R and OESCHGER J. Generalized magnetic gradient contraction based method for detection, localization and discrimination of underwater mines and unexploded ordnance[C]. The OCEANS 2005 MTS/IEEE, Washington, USA, 2005: 1325–1332.

BIRSAN M. Non-linear Kalman filters for tracking a magnetic dipole[R]. Defence R&D Canada, Atlantic, 2005.

BIRSAN M. Unscented particle filter for tracking a magnetic dipole target[C]. The OCEANS 2005 MTS/IEEE, Washington, USA, 2005, 1656–1659.

KOZICK R J and SADLER B M. Algorithms for tracking with an array of magnetic sensors[C]. The 5th IEEE Sensor Array and Multichannel Signal Processing Workshop, Darmstadt, Germany, 2008: 423–427.

ALHMIEDAT T, ABU TALEB A, and BSOUL M. A study on threads detection and tracking systems for military applications using WSNs[J]. International Journal of Computer Applications, 2012, 40(15): 12–18. doi: 10.5120/5055-7347

張朝陽, 肖昌漢, 高俊吉, 等. 磁性物體磁偶極子模型適用性的試驗研究[J]. 應用基礎與工程科學學報, 2010, 18(5): 862–868. doi: 10.3969/j.issn.1005-0930.2010.05.016

ZHANG Zhaoyang, XIAO Changhan, GAO Junji, et al. Experiment research of magnetic dipole model applicability for a magnetic object[J]. Journal of Basic Science and Engineering, 2010, 18(5): 862–868. doi: 10.3969/j.issn.1005-0930.2010.05.016

于振濤, 呂俊偉, 張本濤. 基于海底磁力儀陣列的磁性目標定位方法[J]. 武漢理工大學學報, 2012, 34(6): 131–135. doi: 10.3963/j.issn.1671-4431.2012.06.028

YU Zhentao, Lü Junwei, and ZHANG Bentao. A method to localize magnetic target based on a seabed array of magnetometers[J]. Journal of Wuhan University of Technology, 2012, 34(6): 131–135. doi: 10.3963/j.issn.1671-4431.2012.06.028

吳志東, 周穗華, 陳志毅. 基于非線性濾波算法的磁偶極子跟蹤[J]. 魚雷技術, 2013, 21(4): 262–267. doi: 10.3969/j.issn.1673-1948.2013.04.006

WU Zhidong, ZHOU Suihua, and CHEN Zhiyi. Magnetic dipole tracking based on nonlinear filtering algorithm[J]. Torpedo Technology, 2013, 21(4): 262–267. doi: 10.3969/j.issn.1673-1948.2013.04.006

高俊吉, 劉大明, 周國華. 水中非合作運動磁性目標跟蹤及參數估計[J]. 哈爾濱工程大學學報, 2013, 34(9): 1124–1130. doi: 10.3969/j.issn.1006-7043.201209033

GAO Junji, LIU Daming, and ZHOU Guohua. Study on the tracking and parameter estimating of unknown moving magnetism objects[J]. Journal of Harbin Engineering University, 2013, 34(9): 1124–1130. doi: 10.3969/j.issn.1006-7043.201209033

張宏欣, 周穗華, 吳志東, 等. 基于改進粗糙化粒子濾波的磁偶極子跟蹤[J]. 華中科技大學學報: 自然科學版, 2014, 42(9): 76–80. doi: 10.13245/j.hust.140917

ZHANG Hongxin, ZHOU Suihua, WU Zhidong, et al. Magnetic dipole localization based on improved roughening particle filter[J]. Journal of Huazhong University of Science and Technology:Natural Science Edition, 2014, 42(9): 76–80. doi: 10.13245/j.hust.140917

周穗華, 張文成, 張宏欣. 基于混合卡爾曼濾波的磁偶極子目標跟蹤[J]. 水雷戰與艦船防護, 2015, 23(4): 7–11.

ZHOU Suihua, ZHANG Wencheng, and ZHANG Hongxin. Magnetic dipole target tracking based on mixed kalman filter[J]. Mine Warfare &Ship Self-defence, 2015, 23(4): 7–11.

吳垣甫, 孫躍. 基于遞推更新卡爾曼濾波的磁偶極子目標跟蹤[J]. 北京航空航天大學學報, 2017, 43(9): 1805–1812. doi: 10.13700/j.bh.1001-5965.2016.0694

WU Yuanfu and SUN Yue. Magnetic dipole target tracking based on recursive update Kalman filter[J]. Journal of Beijing University of Aeronautics and Astronautics, 2017, 43(9): 1805–1812. doi: 10.13700/j.bh.1001-5965.2016.0694

張宏欣, 周穗華, 張伽偉. 磁偶極子跟蹤的漸進貝葉斯濾波方法[J]. 自動化學報, 2017, 43(5): 822–834. doi: 10.16383/j.aas.2017.c160052

ZHANG Hongxin, ZHOU Suihua, and ZHANG Jiawei. A progressive bayesian filtering approach to magnetic dipole tracking[J]. Acta Automatica Sinica, 2017, 43(5): 822–834. doi: 10.16383/j.aas.2017.c160052

張宏欣. 磁性目標跟蹤的多模型自適應濾波方法[J]. 數字海洋與水下攻防, 2018, 1(2): 57–62.

ZHANG Hongxin. Multiple-model adaptive filtering method for magnetic target tracking[J]. Digital Ocean &Underwater Warfare, 2018, 1(2): 57–62.
