基于二階統計量盲源分離算法的無源雷達同頻干擾抑制研究

呂曉德; 孫正豪; 劉忠勝; 張漢良; 劉平羽

doi:10.11999/JEIT190178

基于二階統計量盲源分離算法的無源雷達同頻干擾抑制研究

doi: 10.11999/JEIT190178

呂曉德^{1, 2},
孫正豪^{1, 2, 3, ,},
劉忠勝^{1, 2},
張漢良^{1, 2, 3},
劉平羽^{1, 2, 3}

1.
中國科學院空天信息創新研究院北京 100094
2.
微波成像技術國家級重點實驗室北京 100190
3.
中國科學院大學 北京 100049

詳細信息

作者簡介:
呂曉德：男，1969年生，研究員，研究方向?yàn)榛陉嚵屑夹g(shù)的的新體制雷達系統及其應用

孫正豪：男，1995年生，碩士生，研究方向?yàn)闊o源雷達信號處理

劉忠勝：男，1977年生，副研究員，研究方向?yàn)楦缮鍿AR信號處理

張漢良：男，1993年生，碩士生，研究方向?yàn)榛贚TE信號的無源雷達信號處理

劉平羽：男，1994年生，碩士生，研究方向?yàn)闊o源雷達信號處理

通訊作者:
孫正豪　sunzhenghao17@mails.ucas.ac.cn

中圖分類號: TN958.97
計量
- 文章訪問數: 3272
- HTML全文瀏覽量: 1339
- PDF下載量: 124
- 被引次數: 0
出版歷程
- 收稿日期: 2019-03-25
- 修回日期: 2019-11-25
- 網絡出版日期: 2019-12-14
- 刊出日期: 2020-06-04

Research on Suppressing Co-channel Interference of Passive Radar Based on Blind Source Separation Using Second Order Statistics

Xiaode Lü^{1, 2},
Zhenghao SUN^{1, 2, 3
, ,},
Zhongsheng LIU^{1, 2},
Hanliang ZHANG^{1, 2, 3},
Pingyu LIU^{1, 2, 3}

1.
Aerospace Information Research Institute, Chinese Academy of Sciences, Beijing 100094, China
2.
National Key Lab of Microwave Imaging Technology, Beijing 100190, China
3.
University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要:
針對基于長期演進(LTE)信號的無源雷達存在同頻基站干擾的問題，該文提出一種基于2階統計量的盲源分離算法，該算法是在卷積混合模型下，通過多通道最小均方(LMS)算法實現分離信號之間的相關性最小。由于各發射基站信號之間統計不相關，當分離信號之間的相關性達到最小時，完成觀測信號的分離。在此基礎上，改進了傳統無源雷達信號處理的流程，增加了分離同頻干擾基站直達波和多徑雜波的步驟，實現了對同頻干擾基站雜波的抑制。通過仿真分析，驗證了算法的有效性，為基于LTE信號的無源雷達數據處理提供了參考。
- 無源雷達 /
- 長期演進信號 /
- 同頻干擾抑制 /
- 盲源分離 /
- 2階統計量
Abstract:
For the problem of co-frequency base station interference in passive radar based on Long Term Evolution (LTE) signal, an algorithm based on blind source separation using second order statistics is proposed. The presented algorithm is based on convolution mixed model, and achieves the minimum correlation among separated signals through multi-channel Least-Mean-Square (LMS) algorithm. Without statistical correlation among the signals of each transmitting base station, the separation of the observed signals is completed when the separated signals achieve the minimum correlation. On this basis, the traditional signal processing for passive radar is improved. The steps of separating co-frequency interference clutter consisting of both direct-path and multipath clutter are added, which can suppress the clutter interference of co-channel base station. Simulation and analysis verify the effectiveness of the algorithm. The algorithm provides a reference for data processing of passive radar based on LTE signal.
- Passive radar /
- Long Term Evolution (LTE) signal /
- Co-channel interference suppression /
- Blind source separation /
- Second order statistics

HTML全文

圖 1 盲源分離模型結構圖

下載: 全尺寸圖片幻燈片

圖 2 信號卷積混合濾波器模型

下載: 全尺寸圖片幻燈片

圖 3 信號后向分離濾波器模型

下載: 全尺寸圖片幻燈片

圖 4 第i個通道的分離系統示意圖

下載: 全尺寸圖片幻燈片

圖 5 無源雷達信號處理流程圖

下載: 全尺寸圖片幻燈片

圖 6 傳統無源雷達雜波對消能量對比圖

下載: 全尺寸圖片幻燈片

圖 7 觀測信號與源信號的散點圖

下載: 全尺寸圖片幻燈片

圖 8 傳統處理流程后的互模糊距離剖面圖

下載: 全尺寸圖片幻燈片

圖 9 分離信號與源信號散點圖

下載: 全尺寸圖片幻燈片

圖 10 對消能量比較圖

下載: 全尺寸圖片幻燈片

圖 11 改進的處理流程后的互模糊距離剖面圖

下載: 全尺寸圖片幻燈片

圖 12 噪聲對雜波對消比的影響

下載: 全尺寸圖片幻燈片

表 1 多通道LMS算法總結

參數：$N$= 源數目，$M$= 觀測信號數目　　　一般假設$N = M$ 　　　 ${K_i}$= 分離濾波器階數，$i = 1,2, ··· ,N$ 　　　 ${\mu _{ij}}$= 步長，$i,j = 1,2, ··· ,N$，且$i \ne j$
輸入：${x_i}\left( t \right) = $觀測信號，$i = 1,2, ··· ,N$
初始化：${ {{W} }_{ {{ij} } } }\left( 0 \right) = { {{{\textit{0}}} }_{ {{Kj} } } }$, $i,j = 1,2, ··· ,N$，且$i \ne j$ 　　　　 ${ {{Y} }_i}\left( t \right) = { {{{\textit{0}}} }_{Ki} }$, $i = 1,2, ··· ,N$ 　　　　 ${K_i}$選取$K \ge \max \left\{ {{K_i},i = 1,2, ··· ,N} \right\}$ 　　　　 ${\mu _{ij}}$根據輸入數據進行調整
計算：對$t = 1,2, ··· $，迭代計算：　　　 ${y_i}\left( t \right) = {x_i}\left( t \right) - \displaystyle\sum\nolimits_{j \ne i,j = 1}^N { {{W} }_{ij}^{\rm{T} }\left( {t - 1} \right){ {{Y} }_j}\left( t \right)} $ 　　　 ${{{W}}_{ij}}\left( t \right) = {{{W}}_{ij}}\left( {t - 1} \right) + {\mu _{ij}}{y_i}\left( t \right){{{Y}}_j}\left( t \right)$ 　　　 ${{{Y}}_i}\left( t \right) = {\left[ {{y_i}\left( {t - 1} \right),{y_i}\left( {t - 2} \right), ··· ,{y_i}\left( {t - {K_i}} \right)} \right]^{\rm{T}}}$ 　　　 $i,j = 1,2, ··· ,N,i \ne j$
終止條件：前后兩次分離信號之間相關性系數的變化量小于所設 　　　　　的誤差門限
輸出：${y_i}\left( t \right) = $分離信號，$i = 1,2, ··· ,N$

下載: 導出CSV

表 2 回波通道1仿真參數

	主基站信號		同頻干擾基站信號
	時延(μs)	衰減(dB)	時延(μs)	衰減(dB)
直達波	0	0	0.07	–1
多徑1	0.13	–8	0.20	–9
多徑2	0.29	–11	0.36	–12
多徑3	0.42	–15	0.59	–15
弱多徑	0.16～1.95	–20～>–30	0.16～1.95	–20～>–30
目標1	11.39	–30
目標2	17.15	–37

下載: 導出CSV

表 3 回波通道2仿真參數

	主基站信號		同頻干擾基站信號
	時延(μs)	衰減(dB)	時延(μs)	衰減(dB)
直達波	0.03	–2	0	–1
多徑1	0.19	–8	0.16	–9
多徑2	0.35	–14	0.36	–13
多徑3	0.46	–19	0.49	–14
弱多徑	0.16～1.95	–20～–30	0.16～1.95	–20～–30

下載: 導出CSV

參考文獻(26)

GRIFFITHS H D and BAKER C J. Passive coherent location radar systems. Part 1: Performance prediction[J]. IEE Proceedings-Radar, Sonar and Navigation, 2005, 152(3): 153–159. doi: 10.1049/ip-rsn:20045082

OLSEN K E and ASEN W. Bridging the gap between civilian and military passive radar[J]. IEEE Aerospace and Electronic Systems Magazine, 2017, 32(2): 4–12. doi: 10.1109/MAES.2017.160030

CUI Haixia, LEUNG V C M, LI Shaoqian, et al. LTE in the unlicensed band: Overview, challenges, and opportunities[J]. IEEE Wireless Communications, 2017, 24(4): 99–105. doi: 10.1109/MWC.2016.1600031WC

SALAH A A, ABDULLAH R S A R, ISMAIL A, et al. Feasibility study of LTE signal as a new illuminators of opportunity for passive radar applications[C]. 2013 IEEE International RF and Microwave Conference, Penang, Malaysia, 2013: 258–262.

SALAH A A, Abdullah R S A R, ISMAIL A, et al. Experimental study of LTE signals as illuminators of opportunity for passive bistatic radar applications[J]. Electronics Letters, 2014, 50(7): 545–547. doi: 10.1049/el.2014.0237

ABDULLAH R S A R, AZIZ N H A, RASHID N E A, et al. Analysis on target detection and classification in LTE based passive forward scattering radar[J]. Sensors, 2016, 16(10): 1607. doi: 10.3390/s16101607

DAN Yangpeng, WAN Xianrong, YI Jianxin, et al. Ambiguity function analysis of Long Term Evolution transmission for passive radar[C]. The 12th International Symposium on Antennas, Propagation and EM theory, Hangzhou, China, 2018: 1–4.

王本靜, 易建新, 萬顯榮, 等. LTE外輻射源雷達幀間模糊帶分析與抑制[J]. 雷達學報, 2018, 7(4): 514–522. doi: 10.12000/JR18025

WANG Benjing, YI Jianxin, WAN Xianrong, et al. Inter-frame ambiguity analysis and suppression of LTE signal for passive radar[J]. Journal of Radars, 2018, 7(4): 514–522. doi: 10.12000/JR18025

呂曉德, 張漢良, 楊璟茂, 等. 基于LTE信號的外輻射源雷達副峰特性及抑制方法研究[J]. 電子與信息學報, 2018, 40(10): 2498–2505. doi: 10.11999/JEIT180019

Lü Xiaode, ZHANG Hanliang, YANG Jingmao, et al. Research on characteristics and suppression methods of side peaks of passive radar based on LTE signal[J]. Journal of Electronics &Information Technology, 2018, 40(10): 2498–2505. doi: 10.11999/JEIT180019

王海濤. 外輻射源雷達信號處理若干問題研究[D]. [博士論文], 西安電子科技大學, 2013.

WANG Haitao. Study on some issues of signal processing for passive bistatic radar[D]. [Ph.D. dissertation], Xidian University, 2013.

張良俊, 楊杰, 盧開旺. GSM輻射源雷達干擾抑制技術[J]. 電子學報, 2014, 42(9): 1852–1856.

ZHANG Liangjun, YANG Jie, and LU Kaiwang. Clutter suppression technique in GSM based passive bistatic radar[J]. Acta Electronica Sinica, 2014, 42(9): 1852–1856.

陳剛, 王俊, 王玨, 等. GSM信號外輻射源雷達同頻干擾抑制方法[J]. 西安電子科技大學學報: 自然科學版, 2017, 44(6): 37–42.

CHEN Gang, WANG Jun, WANG Jue, et al. Method of co-channel interference cancellation for the GSM based PBR[J]. Journal of Xidian University:Natural Science, 2017, 44(6): 37–42.

WANG Shuzhao, JIN Guibin, JIN Guimei, et al. Method to remove the interference in reflected wave of passive radar based on the improved FastICA[C]. The 2009 9th International Conference on Electronic Measurement & Instruments, Beijing, China, 2009: 4-24–4-30.

YOU Hong, YU Wenzhen, and YOU Hong. Co-channel interference restraining for passive radar with illuminators of opportunity based on ICA[C]. 2011 IEEE International Conference on Signal Processing, Communications and Computing, Xi'an, China, 2011: 1–3.

陳希信, 王峰, 龍偉軍. 基于獨立成分分析的外輻射源雷達同頻干擾抑制[J]. 中國電子科學研究院學報, 2015, 10(1): 75–77.

CHEN Xixin, WANG Feng, and LONG Weijun. Co-channel interference suppression for passive radar based on independent component analysis[J]. Journal of China Academy of Electronics and Information Technology, 2015, 10(1): 75–77.

GUO Shuai, WANG Jun, CHEN Gang, et al. Mainlobe interference suppression based on independent component analysis in passive bistatic radar[J]. IET Signal Processing, 2018, 12(9): 1193–1201. doi: 10.1049/iet-spr.2018.5198

梅鐵民. 盲源分離理論與算法[M]. 西安: 西安電子科技大學出版社, 2013: 105–116.

MEI Tiemin. Theory and Algorithms of Blind Source Separation[M]. Beijing: Xidian University Press, 2013: 105–116.

CHENG Guanghui, WANG Leijie, and WANG Zhuande. A nonorthogonal joint block diagonalization algorithm avoiding degenerate solutions[J]. Chinese Journal of Electronics, 2017, 26(2): 331–335. doi: 10.1049/cje.2016.11.009

YANG Liu, XIANG Yong, and PENG Dezhong. Precoding-based blind separation of MIMO FIR mixtures[J]. IEEE Access, 2017, 5: 12417–12427. doi: 10.1109/ACCESS.2017.2720578

JARBOUI L, DEVILLE Y, HOSSEINI S, et al. A second-order blind source separation method for bilinear mixtures[J]. Multidimensional Systems and Signal Processing, 2018, 29(3): 153–1172.

LI Jichuan, ZHAO Yaodong, ZHAO Yongke, et al. Direct path wave purification for passive radar with normalized least mean square algorithm[C]. 2013 IEEE International Conference on Signal Processing, Communication and Computing, Kunming, China, 2013: 1–4.

陳剛, 王俊, 王玨, 等. 外輻射源雷達參考信號提純方法[J]. 系統工程與電子技術, 2018, 40(1): 45–49. doi: 10.3969/j.issn.1001-506X.2018.01.07

CHEN Gang, WANG Jun, WANG Jue, et al. Reference signal purifying method in passive bistatic radar[J]. Systems Engineering and Electronics, 2018, 40(1): 45–49. doi: 10.3969/j.issn.1001-506X.2018.01.07

趙耀東, 呂曉德, 李紀傳, 等. 基于插值理論的分?jǐn)?shù)延遲雜波自適應對消算法[J]. 系統工程與電子技術, 2013, 35(7): 1409–1414.

ZHAO Yaodong, Lü Xiaode, LI Jichuan, et al. Adaptive fractional-delay clutter cancellation algorithm based on interpolation theory[J]. Systems Engineering and Electronics, 2013, 35(7): 1409–1414.

劉宇, 呂曉德, 楊鵬程. 一種無源雷達頻域擴展相消批處理雜波對消算法[J]. 雷達學報, 2016, 5(3): 293–301. doi: 10.12000/JR15098

LIU Yu, LV Xiaode, and YANG Pengcheng. Batch version of extensive cancellation algorithm for clutter mitigation in frequency domain of passive radar[J]. Journal of Radars, 2016, 5(3): 293–301. doi: 10.12000/JR15098

柴致海, 呂曉德, 楊鵬程, 等. 一種單頻網模式下無源雷達時域雜波對消算法[J]. 雷達科學與技術, 2018, 16(1): 6–13.

CHAI Zhihai, LYU Xiaode, YANG Pengcheng, et al. A time-domain clutter cancellation algorithm for passive radar in SFN[J]. Radar Science and Technology, 2018, 16(1): 6–13.

YI Jianxin, WAN Xianrong, LI Deshi, et al. Robust clutter rejection in passive radar via generalized subband cancellation[J]. IEEE Transactions on Aerospace and Electronic Systems, 2018, 54(4): 1931–1946. doi: 10.1109/TAES.2018.2805228
