D2D網絡中信道選擇與功率控制策略研究

錢志鴻; 田春生; 王鑫; 王雪

doi:10.11999/JEIT190149

D2D網絡中信道選擇與功率控制策略研究

doi: 10.11999/JEIT190149

錢志鴻¹,
田春生¹,
王鑫^{1, 2},
王雪^1, ,

1.
吉林大學通信工程學院長春 130012
2.
吉林農業大學信息技術學院 ??長春 ??130018

基金項目: 國家自然科學基金(61771219)，吉林大學基礎科研項目(SXGJQY2017-9, 2017TD-19)，吉林大學研究生創新基金(101832018C022)

詳細信息

作者簡介:
錢志鴻：男，1957年生，教授，研究方向?yàn)闊o線網絡通信技術，包括藍牙、RFID, M2M, D2D、無線傳感器網絡及物聯網等

田春生：男，1993年生，博士生，研究方向?yàn)镈2D通信技術與物聯網

王鑫：女，1982年生，博士生，研究方向?yàn)镈2D通信技術

王雪：女，1984年生，副教授，研究方向?yàn)镈2D通信技術與物聯網

通訊作者:
王雪　jluwangxue@163.com

中圖分類號: TN929.5
計量
- 文章訪問數: 2589
- HTML全文瀏覽量: 1309
- PDF下載量: 153
- 被引次數: 0
出版歷程
- 收稿日期: 2019-03-14
- 修回日期: 2019-05-23
- 網絡出版日期: 2019-05-28
- 刊出日期: 2019-10-01

Research on Channel Selection and Power Control Strategy for D2D Networks

Zhihong QIAN¹,
Chunsheng TIAN¹,
Xin WANG^{1, 2},
Xue WANG^{1
, ,}

1.
College of Communication Engineering, Jilin University, Changchun 130012, China
2.
College of Information & Technology, Jilin Agricultural University, Changchun 130018, China

Funds: The National Natural Science Foundation of China (61771219), The Fundamental Research of Jilin University (SXGJQY2017-9, 2017TD-19), The Graduate Innovation Fund of Jilin University (101832018C022)

摘要

摘要: 針對D2D通信的資源分配問題，該文研究了D2D信道選擇與功率控制策略。在保證蜂窩用戶服務質量(QoS)的前提下，提出一種基于啟發式的D2D信道選擇算法，為系統內的D2D用戶找到合適的信道復用資源。同時，利用拉格朗日對偶方法求解得到D2D用戶最優傳輸功率。仿真結果表明當蜂窩用戶與多對D2D用戶共享信道資源時能夠大幅度提升系統平均吞吐量。在相同條件下，該算法的性能要明顯優于現有算法。
- D2D通信 /
- 信道選擇 /
- 功率控制 /
- 拉格朗日對偶
Abstract: Considering the resource allocation problem for Device-to-Device (D2D) communications, a channel selection and power control strategy for D2D communications is investigated. On the premise of guaranteeing the Quality of Service (QoS) of cellular users, a heuristic based D2D channel selection algorithm is proposed to find the suitable channel reusing resources for D2D users in the system. At the same time, the optimal transmission power of D2D users is obtained by using the Lagrange dual method. Simulation results demonstrate that when the cellular user shares channel resources with multiple pairs of D2D users, the system throughput can be dramatically improved. The performance of this algorithm outperforms the exiting algorithms under the same conditions.
- D2D communications /
- Channel selection /
- Power control /
- Lagrange dual

HTML全文

圖 1 系統模型

下載: 全尺寸圖片幻燈片

圖 2 系統平均吞吐量的累積分布函數

下載: 全尺寸圖片幻燈片

圖 3 DUEs最大傳輸功率對系統平均吞吐量的影響

下載: 全尺寸圖片幻燈片

圖 4 DUEs間通信距離對平均吞吐量的影響

下載: 全尺寸圖片幻燈片

圖 5 系統內DUEs數量對DUEs接入概率的影響

下載: 全尺寸圖片幻燈片

表 1 基于啟發式思想的DUEs信道選擇算法

(1)初始化：${D_i} = \varnothing ,\forall i \in C$; ${M_i} = D,\forall i \in C$; $\xi _i^j = 0,\forall i \in C,\forall j \in D$；利用式(11)得到所有DUEs 最優的發射功率$P_{j,i}^{{\rmq7j3ldu95} {\rm{opt}}}$，并求解出與之相對 應的$T(P_{j,i}^{{\rmq7j3ldu95} {\rm{opt}}})$值；
(2) repeat
(3)　$({i^ * },{j^}) = \mathop {\arg \max }\limits_{(i,j):i \in C,j \in {M_i}} T\;(P_{j,i}^{{\rmq7j3ldu95} {\rm{opt}}})$ // 求解得到吞吐量最大值所對應的CUE${i^ }$與DUE${j^}$；　(4)　if $\left[ {{{{P^{\rm{c}}}g_{{i^}}^{\rm{c}}} \Biggr/ {\left( {\sigma _0^2 + \sum\limits_{q \in \left\{ {{D_{{i^}}} \cup {j^}} \right\}} {P_{q,{i^}}^{{\rmq7j3ldu95} {\rm{opt}}}g_{q,{i^}}^{\rmq7j3ldu95}} } \right)}}} \right] \ge {\gamma _{{\rm{th}}}}$ then // 判斷DUE${j^}$復用CUE${i^ }$信道資源時，CUE${i^ * }$的SINR是否滿足系統限制條件，當滿足限制條件時：
(5)　　set $\xi _{{i^}}^{{j^}} = 1$; // 將復用指示因子$\xi _{{i^}}^{{j^}}$的值設置為1；
(6)　　　${M_i} = {M_i}\backslash \left\{ {{j^}} \right\},\forall i \in C$;${D_{{i^}}} = {D_{{i^}}} \cup \left\{ {{j^}} \right\}$; // 將DUE${j^}$從集合${M_i}$中刪除, 同時將DUE${j^}$加入到復用CUE${i^ * }$ 信道資源的DUEs集合 ${D_{{i^*}}}$中；
(7)　else // 當不滿足限制條件時:
(8)　　　${M_{{i^}}} = {M_{{i^}}}\backslash \left\{ {{j^}} \right\}$; // 將DUE${j^}$從集合${M_{{i^*}}}$中刪除；
(9)　end if
(10) until ${M_i} = \varnothing ,\forall i \in C$ // 當集合${M_i}$為空集時停止運行；
(11) return ${D_i},\forall i \in C$; $\xi _i^j,\forall i \in C,\forall j \in D$. // 輸出集合${D_i}$及復用指示因子$\xi _i^j$的值。

下載: 導出CSV

表 2 DUEs功率控制算法

(1) 根據表1對集合${D_i},\forall i \in C$進行初始化；
(2) for all $i \in C$ do
(3)　for all $j \in {D_i}$ do
(4)　　根據式(21)—式(23)計算DUE j傳輸功率$P_{j,i}^{\rmq7j3ldu95}$。
(5)　end for
(6) end for
(7) return $P_{j,i}^d,\forall i \in C,\forall j \in D$. // 輸出DUEs最優傳輸功率。

下載: 導出CSV

表 3 仿真參數

參數	數值
CUEs數量	30, 40
DUEs數量	25～60
DUEs間通信距離	30～100 (m)
CUEs通信路徑損耗	128.1+37.6lg(d(km))
DUEs通信路徑損耗	148+40lg(d(km))
噪聲譜密度	–114 dBm/Hz
DUEs最小吞吐量限制	1.5 Mbps
CUEs傳輸功率	24 dBm

下載: 導出CSV

參考文獻(16)

BENNIS M, DEBBAH M, and POOR H V. Ultrareliable and low-latency wireless communication: Tail, risk, and scale[J]. Proceedings of the IEEE, 2018, 106(10): 1834–1853. doi: 10.1109/JPROC.2018.2867029

錢志鴻, 閻雙葉, 田春生, 等. LTE-A網絡中D2D通信的資源分配算法研究[J]. 電子與信息學報, 2018, 40(10): 2287–2293. doi: 10.11999/JEIT180043

QIAN Zhihong, YAN Shuangye, TIAN Chunsheng, et al. Research on resource allocation algorithm for D2D communications underlaying LTE-A networks[J]. Journal of Electronics &Information Technology, 2018, 40(10): 2287–2293. doi: 10.11999/JEIT180043

王練, 王萌, 任治豪, 等. D2D網絡中基于立即可解網絡編碼的時延最小化重傳方案[J]. 電子與信息學報, 2018, 40(7): 1691–1698. doi: 10.11999/JEIT170976

WANG Lian, WANG Meng, REN Zhihao, et al. Delay minimization retransmission scheme based on instantly decodable network coding for D2D communications[J]. Journal of Electronics &Information Technology, 2018, 40(7): 1691–1698. doi: 10.11999/JEIT170976

錢志鴻, 王雪. 面向5G通信網的D2D技術綜述[J]. 通信學報, 2016, 37(7): 1–14. doi: 10.11959/j.issn.1000-436x.2016129

QIAN Zhihong and WANG Xue. Reviews of D2D technology for 5G communication networks[J]. Journal on Communications, 2016, 37(7): 1–14. doi: 10.11959/j.issn.1000-436x.2016129

XIANG Shangwen, PENG Tao, LIU Ziyang, et al. A distance-dependent mode selection algorithm in heterogeneous D2D and IMT-advanced network[C]. Proceedings of 2012 IEEE Globecom Workshops, Anaheim, USA, 2012: 416–420. doi: 10.1109/GLOCOMW.2012.6477608.

WEN Si, ZHU Xiaoyue, LIN Zhesheng, et al. Distributed resource management for device-to-device (D2D) communication underlay cellular networks[C]. The 24th Annual International Symposium on Personal, Indoor, and Mobile Radio Communications, London, UK, 2013: 1624–1628. doi: 10.1109/PIMRC.2013.6666402.

LEE D H, CHOI K W, JEON W S, et al. Two-stage semi-distributed resource management for device-to-device communication in cellular networks[J]. IEEE Transactions on Wireless Communications, 2014, 13(4): 1908–1920. doi: 10.1109/TWC.2014.022014.130480

ZHANG Wei, HE Wanbing, WU Dan, et al. Joint mode selection, link allocation and power control in underlaying D2D communication[J]. KSⅡ Transactions on Internet and Information Systems, 2016, 10(11): 5209–5228. doi: 10.3837/tiis.2016.11.001

WANG Xianxian, Lü Shaobo, WANG Xing, et al. Greedy heuristic resource allocation algorithm for device-to-device aided cellular systems with system level simulations[J]. KSⅡ Transactions on Internet and Information Systems, 2018, 12(4): 1415–1435. doi: 10.3837/tiis.2018.04.002

AHMAD M, NAEEM M, IQBAL M, et al. Joint user selection, mode assignment, and power allocation in cognitive radio-assisted D2D networks[J]. IET Communications, 2018, 12(10): 1207–1214. doi: 10.1049/iet-com.2017.1206

XU Jun, GUO Chengcheng, and ZHANG Hao. Joint channel allocation and power control based on PSO for cellular networks with D2D communications[J]. Computer Networks, 2018, 133: 104–119. doi: 10.1016/j.comnet.2018.01.017

GJENDEMSJO A, GESBERT D, OIEN G E, et al. Optimal power allocation and scheduling for two-cell capacity maximization[C]. The 4th International Symposium on Modeling and Optimization in Mobile, Ad Hoc and Wireless Networks, Boston, USA, 2006: 1–6. doi: 10.1109/WIOPT.2006.1666517.

ESMAT H H, ELMESALAWY M M, and IBRAHIM I I. Joint channel selection and optimal power allocation for multi-cell D2D communications underlaying cellular networks[J]. IET Communications, 2017, 11(5): 746–755. doi: 10.1049/iet-com.2016.0955

UL HASSAN N, YUEN C, SAEED S, et al. Power control for sum-rate maximization on interference channels under sum power constraint[J]. IEEE Transactions on Vehicular Technology, 2015, 64(2): 593–609. doi: 10.1109/TVT.2014.2324289

ITU-R. Guidelines for evaluation of radio interface technologies for IMT-advanced[R]. Report ITU-R M.2135, 2009.

DINH-VAN S, SHIN Y, and SHIN O S. Resource allocation and power control based on user grouping for underlay device-to-device communications in cellular networks[J]. Transactions on Emerging Telecommunications Technologies, 2017, 28(1): e2920. doi: 10.1002/ett.2920
