基于配置模式匹配和層次化映射結構的高效FPGA碼流生成系統研究

涂開輝; 黃志洪; 侯崢嶸; 楊海鋼

doi:10.11999/JEIT190143

基于配置模式匹配和層次化映射結構的高效FPGA碼流生成系統研究

doi: 10.11999/JEIT190143

涂開輝^{1, 2},
黃志洪¹,
侯崢嶸¹,
楊海鋼^{1, 2, ,}

1.
中國科學院電子學研究所北京 100190
2.
中國科學院大學北京 100049

基金項目: 國家自然科學基金(61876172, 61704173)，北京市科技重大專項課題(Z171100000117019)

詳細信息

作者簡介:
涂開輝：男，1984年生，博士生，助理研究員，研究方向為大規模集成電路設計自動化

黃志洪：男，1984年生，博士，助理研究員，研究方向為可編程邏輯芯片設計技術

侯崢嶸：男，1994年生，研究方向為大規模集成電路設計自動化

楊海鋼：男，1960年生，博士生導師，研究員，研究方向為可編程邏輯芯片設計技術，大規模集成電路設計自動化

通訊作者:
yanghg@mail.ie.ac.cn

中圖分類號: TN402
計量
- 文章訪問數: 3009
- HTML全文瀏覽量: 1590
- PDF下載量: 71
- 被引次數: 0
出版歷程
- 收稿日期: 2019-03-12
- 修回日期: 2019-05-30
- 網絡出版日期: 2019-06-04
- 刊出日期: 2019-11-01

Research on Efficient FPGA Bitstream Generation System Based on Mode Matching and Hierarchical Mapping

1.
Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China

Funds: The National Natural Science Foundation of China (61876172, 61704173), The Major Program of Beijing Science and Technology (Z171100000117019)

摘要

摘要: 碼流生成在FPGA電子設計自動化(EDA)流程中，提供應用電路在芯片上物理實現所需的精準配置信息。現代FPGA的發展一方面呈現出器件規模及碼流容量越來越大的趨勢，另一方面越來越多可變陣列大小的嵌入式應用(例如eFPGA)又要求碼流生成器具備更高的配置效率以及更精簡的可重構數據庫。針對碼流生成時間增加的問題和陣列規模任意縮放的需求，該文提出一種模式匹配和層次映射的碼流生成方法，即對編程單元按配置模式進行分類建模，在配置時按模型進行調用匹配，并采用了層次化的碼流映射策略，使得數據庫可隨陣列排布調整動態生成。該方法可有效應對FPGA嵌入式應用中碼流容量的增大以及陣列規模可變所帶來的挑戰，同時相比平面化的建模及映射方法，碼流配置的時間復雜度由O(n)降低為O(lgn)。
- FPGA /
- 碼流生成 /
- 嵌入式 /
- 配置模式 /
- 層次化
Abstract: Bitstream generator in FPGA Electronic Design Automation(EDA) offers precise configuration information, which enables the application circuits to be implemented on the target device. On one hand, modern FPGAs tend to have larger device scale and more configuration bits, on the other hand, embedded applications (e.g. eFPGAs) require better configuration efficiency and smaller, more adaptive database. In order to meet these new requirements, a bit-stream generation method is proposed which firstly models the configurable resources by configuration modes and matches the netlist with these models, then hierarchical mapping strategy is used to search every bit on a dynamically generated database determined by the array floorplan. This method well meets the challenges that embedded applications may bring-the surge of configuration bit count and the changeable size of the array. Compared to flattened modelling and mapping method, its time complexity is reduced from O(n) to O(lgn).
- FPGA /
- Bitstream generation /
- Embedded /
- Configuration mode /
- Hierarchy

HTML全文

圖 1 配置碼位結構CBS示意

下載: 全尺寸圖片幻燈片

圖 2 碼流生成流程

下載: 全尺寸圖片幻燈片

圖 3 電路設計數據庫-器件結構數據庫層次化對應關系

下載: 全尺寸圖片幻燈片

圖 4 公式配置模型示例

下載: 全尺寸圖片幻燈片

圖 5 DVD測試模型示意

下載: 全尺寸圖片幻燈片

圖 6 DSD測試模型示意

下載: 全尺寸圖片幻燈片

圖 7 碼流配置時間隨器件模型的變化關系(m=5)

下載: 全尺寸圖片幻燈片

表 1 芯片相關數據庫大小(kB)

器件模型*	config_modes	tile/primitive_first_addresses	initial_bitstream	bitstream_format_info	數據庫總大小(kB)
器件a(3 M Gates)	512	10/15	226	2	765
器件b(10 M Gates)	512	32/15	226	2	787
器件c(30 M Gates)	512	99/15	226	2	854
器件d(50 M Gates)	512	158/15	226	2	913
器件e(70 M Gates)	512	210/15	226	2	965
器件f(90 M Gates)	512	268/15	226	2	1023
*注：器件模型均屬一個系列，該系列包含10種復用單元

下載: 導出CSV

表 2 不同電路設計、相同芯片規模(同系列)下的碼流配置時間

電路設計	需要配置的碼位總數(bit)	碼流配置時間
電路1(用滿25 k Gates器件資源)	5.8 k	0.016
電路2(用滿1 M Gates器件資源)	250.4 k	0.682
電路3(用滿10 M Gates器件資源)	2.3 M	6.360
電路4(用滿30 M Gates器件資源)	7.0 M	19.419
電路5(用滿50 M Gates器件資源)	11.5 M	30.334
電路6(用滿80 M Gates器件資源)	18.4 M	50.886

下載: 導出CSV

表 3 相同電路設計、不同芯片規模(同系列)下的碼流配置時間

器件模型	映射層數l	全器件的碼位總數n(bit)	平面化映射碼流(傳統方法) 配置時間t1(s)	層次化映射碼流(本文方法) 配置時間t2(s)
器件1(25.8 k Gates)	3	12.5 k	1.4	0.013
器件2(130 k Gates)	4	62.5 k	7.0	0.013
器件3(645 k Gates)	5	312.5 k	34.1	0.014
器件4(3.1 M Gates)	6	1.5 M	155.2	0.015
器件5(16.1 M Gates)	7	7.8 M	820.2	0.015
器件6(80.6 M Gates)	8	39 M	4066.0	0.016

下載: 導出CSV

表 4 本方法和其他碼流生成工具的特性比較

	Torc^[9]	RapidSmith2^[10]	文獻[18]	本文方法
數據庫通用性	僅針對Xilinx器件	僅針對Xilinx器件	通用	通用
碼流生成層次	Frame級	Frame級	Bit級	Bit級
涵蓋資源	全芯片資源	全芯片資源	僅互連資源	全芯片資源
Bit級映射方法	–	–	平面化	層次化

下載: 導出CSV

參考文獻(18)

王俊, 鄭彤, 雷鵬, 等. 深度學習在雷達中的研究綜述[J]. 雷達學報, 2018, 7(4): 395–411. doi: 10.12000/JR18040

WANG Jun, ZHENG Tong, LEI Peng, et al. Study on deep learning in radar[J]. Journal of Radars, 2018, 7(4): 395–411. doi: 10.12000/JR18040

I?A R and MATOU?EK J. A novel architecture for LZSS compression of configuration bitstreams within FPGA[C]. Proceedings of the IEEE 20th International Symposium on Design and Diagnostics of Electronic Circuits & Systems, Dresden, Germany, 2017: 171–176.

Intel Inc. UGS10CONFIG-Intel stratix 10 configuration user guide[EB/OL]. https://www.intel.com/content/dam/altera-www/global/en_US/pdfs/literature/hb/stratix-10/ug-s10-config.pdf, 2018.

ABDELLATIF K M, CHOTIN-AVOT R, and MEHREZ H. Protecting FPGA bitstreams using authenticated encryption[C]. Proceedings of the IEEE 11th International New Circuits and Systems Conference, Paris, France, 2013: 1–4.

Xilinx Inc. UG909-Vivado design suite user guide partial reconfiguration[OL]. https://www.xilinx.com/support/documentation/sw_manuals/xilinx2016_1/ug909-vivado-partial-reconfiguration.pdf, 2018.

PATTERSON C and GUCCIONE S A. JBits ^TM design abstractions[C]. Proceedings of the 9th Annual IEEE Symposium on Field-Programmable Custom Computing Machines, Rohnert Park, USA, 2001: 251–252.

POETTER A, HUNTER J, PATTERSON C, et al. JHDLBits: The merging of two worlds[C]. Proceedings of the 14th International Conference Field Programmable Logic and Application, Leuven, Belgium, 2004: 414–423.

PHAM K D, HORTA E, and KOCH D. BITMAN: A tool and API for FPGA bitstream manipulations[C]. Proceedings of 2017 Design, Automation & Test in Europe Conference & Exhibition, Lausanne, Switzerland, 2017: 894–897.

STEINER N, WOOD A, SHOJAEI H, et al. Torc: Towards an open-source tool flow[C]. Proceedings of the 19th ACM/SIGDA International Symposium on Field Programmable Gate Arrays, Monterey, USA, 2011: 41–44.

TOWNSEND T and NELSON B. Vivado design interface: An export/import capability for vivado FPGA designs[C]. Proceedings of the 27th International Conference on Field Programmable Logic and Applications, Ghent, Belgium, 2017: 1–7.

NOTE J B and RANNAUD é. From the bitstream to the netlist[C]. Proceedings of the 16th International ACM/SIGDA Symposium on Field Programmable Gate Arrays, Monterey, USA, 2008: 264.

BENZ F, SEFFRIN A, and HUSS S A. Bil: A tool-chain for bitstream reverse-engineering[C]. Proceedings of the 22nd International Conference on Field Programmable Logic and Applications, Oslo, Norway, 2012: 735–738.

DING Zheng, WU Qiang, ZHANG Yizhong, et al. Deriving an NCD file from an FPGA bitstream: Methodology, architecture and evaluation[J]. Microprocessors and Microsystems, 2013, 37(3): 299–312. doi: 10.1016/j.micpro.2012.12.003

ROSE J, LUU J, YU Chiwai, et al. The VTR project: Architecture and CAD for FPGAs from verilog to routing[C]. Proceedings of the ACM/SIGDA International Symposium on Field Programmable Gate Arrays, Monterey, USA, 2012: 77–86.

HUNG E, ESLAMI F, and WILTON S J E. Escaping the academic sandbox: Realizing VPR circuits on Xilinx devices[C]. Proceedings of the IEEE 21st Annual International Symposium on Field-Programmable Custom Computing Machines, Seattle, USA, 2013: 45–52.

HUNG E. Mind the (synthesis) gap: Examining where academic FPGA tools lag behind industry[C]. Proceedings of the 25th International Conference on Field Programmable Logic and Applications, London, UK, 2015: 1–4.

SONI R K, STEINER N, and FRENCH M. Open-source bitstream generation[C]. Proceedings of the IEEE 21st Annual International Symposium on Field-Programmable Custom Computing Machines, Seattle, USA, 2013: 105–112.

李智華, 黃娟, 李威, 等. 一種SRAM型FPGA互連資源的位流碼配置方法[J]. 太赫茲科學與電子信息學報, 2016, 14(1): 136–142. doi: 10.11805/TKYDA201601.0136

LI Zhihua, HUANG Juan, LI Wei, et al. An automatic approach for bitstream configuration of routing resource in SRAM FPGA[J]. Journal of Terahertz Science and Electronic Information Technology, 2016, 14(1): 136–142. doi: 10.11805/TKYDA201601.0136
