基于快速貝葉斯匹配追蹤優化的海上稀疏信道估計方法

張穎; 姚雨豐

doi:10.11999/JEIT190102

基于快速貝葉斯匹配追蹤優化的海上稀疏信道估計方法

doi: 10.11999/JEIT190102

張穎^,,
姚雨豐

上海海事大學信息工程學院上海 201306

基金項目: 國家自然科學基金(61673259)

詳細信息

作者簡介:
張穎：男，1968年生，博士，教授，博士生導師，研究方向?yàn)槲锫?lián)網、海事無線通信、無線自組織網絡

姚雨豐：男，1995年生，碩士生，研究方向?yàn)楹Ｊ聼o線通信信道估計、無線信號傳輸技術

通訊作者:
張穎　yingzhang@shmtu.edu.cn

中圖分類號: TN911
計量
- 文章訪問數: 3557
- HTML全文瀏覽量: 896
- PDF下載量: 112
- 被引次數: 0
出版歷程
- 收稿日期: 2019-02-21
- 修回日期: 2019-09-01
- 網絡出版日期: 2019-09-06
- 刊出日期: 2020-02-19

Channel Estimation Algorithm of Maritime Sparse Channel Based on Fast Bayesian Matching Pursuit Optimization

Ying ZHANG^,,
Yufeng YAO

College of Information Engineering, Shanghai Maritime University, Shanghai 201306, China

Funds: The National Natural Science Foundation of China (61673259)

摘要

摘要:
正交頻分復用(OFDM)系統中，由于頻率發生選擇性衰落會導致信道在數據傳輸中產生符號間干擾，因此接收機往往需要知道信道狀態信息。而在海上通信的情況下，信道傳輸會受到多種外界因素的干擾，往往需要預先進行信道探測估計。為了提高估計性能，該文提出一種基于奇異值分解優化觀測矩陣的快速貝葉斯匹配追蹤稀疏信道估計優化算法(FBMPO)，該算法不僅能夠充分考慮海上通信的信道稀疏性，也能夠降低信道的不確定性帶來的影響。計算機仿真實驗表明，與傳統的信道估計算法相比，該算法能夠提高信道估計的精確度。
- 信道估計 /
- 貝葉斯準則 /
- 稀疏信道 /
- 匹配追蹤
Abstract:
In the Orthogonal Frequency Division Multiplexing (OFDM) system, the receiver often needs to know the channel state information, because the frequency selective fading channel will generate inter-symbol interference in the data transmission. In the case of maritime communication, the method of channel estimation is often needed to detect the channel subjected to the interference of various external factors. In order to improve the estimation performance, the Fast Bayesian Matching Pursuit based on singular-value-decomposition for Optimizing observation matrix (FBMPO) is proposed, which fully considers not only the sparse channel of maritime communication, but also reduces the influence of uncertainty of the unpredictable channel. Computer simulation shows, compared with traditional channel estimation algorithms, the proposed algorithm can effectively improve the accuracy of channel estimation.
- Channel estimation /
- Bayesian criterion /
- Sparse channel /
- Matching pursuit

HTML全文

圖 1 海上通信損耗模型

下載: 全尺寸圖片幻燈片

圖 2 N為32時，p₁為0.04時，3種算法的AMSE對比

下載: 全尺寸圖片幻燈片

圖 4 N為64時，p₁為0.04時，3種算法的AMSE對比

下載: 全尺寸圖片幻燈片

圖 5 N為32時，p₁為0.01時，3種算法的AMSE對比

下載: 全尺寸圖片幻燈片

圖 3 N為48時，p₁為0.04時，3種算法的AMSE對比

下載: 全尺寸圖片幻燈片

圖 6 N為32時，p₁為0.04時，3種算法的BER對比

下載: 全尺寸圖片幻燈片

圖 8 N為64時，p₁為0.04時，3種算法的BER對比

下載: 全尺寸圖片幻燈片

圖 9 N為32時，p₁為0.01時，3種算法的BER對比

下載: 全尺寸圖片幻燈片

圖 7 N為48時，p₁為0.04時，3種算法的BER對比

下載: 全尺寸圖片幻燈片

表 1 FBMPO算法的偽代碼

FBMPO算法
輸入：參數向量s, 觀測矩陣${{\varphi } }_i$，迭代閾值K, R and L；
輸出：${\tilde h_{ {\rm{MMSE} } } }$;
(1) Initialize ${\mu _{0,1}}$ by式(20)
(2) for i ← 1 to L:
(3) 　　${{}_i} \leftarrow {{{\varphi}} ^{ - 1}}{{{\phi}} _i};\;{{{\beta }}_i} \leftarrow {\left( {1 + {\sigma _1}^2{{\phi}} _i^{\rm{T}}{{}_i}} \right)^{ - 1}}$;
(4) 　　${\mu _{1,i} }^* \leftarrow {\mu _{0,1} } + \dfrac{1}{2}\lg \left( {\frac{ { { {{\beta} } _i} } }{ { {\sigma _1}^2} } } \right) + \dfrac{1}{2}{ {{\beta} } _i}{\left\| { { {{y} }^{\rm{T} } }{ { }_i} } \right\|^2}$ 　　　　　　　 $ + {\rm{lg} }\dfrac{ { {p_1} } }{ {1 - {p_1} } }$;
(5) end for
(6) for q ← 1 to K:
(7) 　　${\mu _{1,q}} \leftarrow {\mu _{1,i}}^$; ${\rm{}}{b_{1,q}}^{\left( 1 \right)} \leftarrow {\mu _{1,i}}^$; ${\rm{}}{c_{1,q}}^{\left( 1 \right)} \leftarrow {c_{1,i}}^$; 　　　　　　${\beta _{1,q}}^{\left( 1 \right)} \leftarrow {\beta _{1,i}}^$;
(8) end for
(9) ${{{\phi}}_i} \leftarrow {{{U}}_1} {{W}_2} {{{V}}_1}^{\rm T}$; ${{{\phi}} _i}' \leftarrow {{{U}}_1}{{{W}}_2}'{{{V}}_1}^{\rm{T}}$;
(10) for l ← 1 to R:
(11) 　　${{{\beta}} _i} \leftarrow {\left( {1 + {\sigma _1}^2{{{\phi}} _i}{{'}^{\rm{T}}}{{}_i}} \right)^{ - 1}}$;
(12) 　　${{{\mu}} _i} \leftarrow {\mu ^{\left( {l - 1} \right)}} + \dfrac{1}{2}{\rm{lg}}{{{\beta}} _i} + \dfrac{1}{2}{{{\beta}} _i}{\left( {{{{s}}^{\rm{T}}}c_i^{\left( l \right)}} \right)^2} $ 　　　　　　 $ + {\rm{lg}}\frac{{{p_1}}}{{1 - {p_1}}}$;
(13) 　　$i_*^{\left( l \right)} \leftarrow {\rm{argma}}{{\rm{x}}_i}{\mu _i}$;
(14)　　 ${G^{\left( l \right)}} \leftarrow {G^{\left( {l - 1} \right)}} \cup ^{\{i_{}^{(l)}\}} $; 　　　　　　 $c_i^{\left( {l + 1} \right)} \leftarrow c_i^{\left( l \right)} - {{i}}_{i_^{\left( l \right)}}^{\left( l \right)}{{{\beta }}_{i_^{\left( l \right)}}}{{i}}_{i_^{\left( l \right)}}^{{{\left( l \right)}^{\rm{T}}}}{{{\phi}} _i}$;
(15) end for
(16) 計算${\tilde h_{ {\rm{MMSE} } } }$ by式(30)

下載: 導出CSV

表 2 系統仿真參數設置

參數仿真	參數值
信道抽頭數系統信道帶寬	6410 MHz
采樣頻率循環前綴長度	10 MHz16
調制方式	BPSK
非零抽頭概率 p₁	{0.04,0.01}
FFT/IFFT點數	1024
訓練序列長度	{32,48,64}

下載: 導出CSV

表 3 不同算法在不同訓練序列時的運算時間

	N=32	N=48	N=64
OMP	6.4284	8.0413	11.4591
BCS	18.2541	20.8931	24.5212
FBMPO	11.4618	13.7194	15.0951

下載: 導出CSV

參考文獻(20)

XIAO Liping, LIANG Zhibo, and LIU Kai. A novel compressed sensing-based channel estimation method for OFDM system[J]. IEICE Transactions on Fundamentals of Electronics, Communications and Computer Sciences, 2017, E100.A(1): 322–326. doi: 10.1587/transfun.E100.A.322

DAI Linglong, WANG Zhaocheng, and YANG Zhixing. Compressive sensing based time domain synchronous OFDM transmission for vehicular communications[J]. IEEE Journal on Selected Areas in Communications, 2013, 31(9): 460–469. doi: 10.1109/JSAC.2013.SUP.0513041

DAI Linglong, WANG Zhaocheng, and YANG Zhixing. Next-generation digital television terrestrial broadcasting systems: Key technologies and research trends[J]. IEEE Communications Magazine, 2012, 50(6): 150–158. doi: 10.1109/MCOM.2012.6211500

LI Weichang and PREISIG J C. Estimation of rapidly time-varying sparse channels[J]. IEEE Journal of Oceanic Engineering, 2007, 32(4): 927–939. doi: 10.1109/JOE.2007.906409

GE Lijun, CHENG Yitai, XU Wei, et al. Sparsity adaptive channel estimation based on compressed sensing for OFDM systems[J]. Journal of the Chinese Institute of Engineers, 2017, 40(2): 146–148. doi: 10.1080/02533839.2017.1287597

TAUBOCK G, HLAWATSCH F, EIWEN D, et al. Compressive estimation of doubly selective channels in multicarrier systems: Leakage effects and sparsity-enhancing processing[J]. IEEE Journal of Selected Topics in Signal Processing, 2010, 4(2): 255–271. doi: 10.1109/JSTSP.2010.2042410

GUI Guan, WAN Qun, PENG Wei, et al. Sparse multipath channel estimation using compressive sampling matching pursuit algorithm[C]. The 7th IEEE VTS Asia Pacific Wireless Communications Symposium, Kaohsiung, China, 2010: 10–14.

GUI Guan, WAN Qun, and PENG Wei. Fast compressed sensing-based sparse multipath channel estimation with smooth L0 algorithm[C]. The 3rd International Conference on Communications and Mobile Computing, Qingdao, China, 2011: 242–245.

KARABULUT G Z and YONGACOGLU A. Sparse channel estimation using orthogonal matching pursuit algorithm[C]. The 60th IEEE Vehicular Technology Conference, Los Angeles, USA, 2004: 3880–3884.

ZHANG Yi, VENKATESAN R, DOBRE O A, et al. Novel compressed sensing-based channel estimation algorithm and near-optimal pilot placement scheme[J]. IEEE Transactions on Wireless Communications, 2016, 15(4): 2590–2603. doi: 10.1109/TWC.2015.2505315

CHEN Guorui. Channel estimation with Bayesian framework based on compressed sensing algorithm in multimedia transmission system[J]. Multimedia Tools and Applications, 2019, 78(7): 8813–8825. doi: 10.1007/s11042-018-6443-1

JOSE R, PAVITHRAN G, and ASWATHI C. Sparse channel estimation in OFDM systems using compressed sensing techniques in a Bayesian framework[J]. Computers & Electrical Engineering, 2017, 61: 173–183. doi: 10.1016/j.compeleceng.2017.03.014

BARBU O E, MANCHóN C N, ROM C, et al. OFDM receiver for fast time-varying channels using block-sparse Bayesian learning[J]. IEEE Transactions on Vehicular Technology, 2016, 65(12): 10053–10057. doi: 10.1109/TVT.2016.2554611

PRASAD R, MURTHY C R, RAO B D. Joint channel estimation and data detection in MIMO-OFDM systems: A sparse Bayesian learning approach[J]. IEEE Transactions on Signal Processing, 2015, 63(20): 5369–5382. doi: 10.1109/TSP.2015.2451071

SCHNITER P, POTTER L C, and ZINIEL J. Fast Bayesian matching pursuit[C]. 2008 Information Theory and Applications Workshop, San Diego, USA, 2008: 326–333.

WEI Zhuangkun, HU Wenxiu, HAN Dahai, et al. Simultaneous channel estimation and signal detection in wireless ultraviolet communications combating inter-symbol-interference[J]. Optics Express, 2018, 26(3): 3260–3270. doi: 10.1364/OE.26.003260

HE Chengbing, HUANG Jianguo, ZHANG Qunfei, et al. Single carrier frequency domain equalizer for underwater wireless communication[C]. 2009 WRI International Conference on Communications and Mobile Computing, Kunming, China, 2009: 186–190.

QI Chenhao, YUE Guosen, WU Lenan, et al. Pilot design schemes for sparse channel estimation in OFDM systems[J]. IEEE Transactions on Vehicular Technology, 2015, 64(4): 1493–1505. doi: 10.1109/TVT.2014.2331085

胡強, 林云. 基于觀測矩陣優化的自適應壓縮感知算法[J]. 計算機應用, 2017, 37(12): 3381–3385. doi: 10.11772/j.issn.1001-9081.2017.12.3381

HU Qiang and LIN Yun. Adaptive compressed sensing algorithm based on observation matrix optimization[J]. Journal of Computer Applications, 2017, 37(12): 3381–3385. doi: 10.11772/j.issn.1001-9081.2017.12.3381

CANDèS E J. The restricted isometry property and its implications for compressed sensing[J]. Comptes Rendus Mathematique, 2008, 346(9–10): 589–592. doi: 10.1016/j.crma.2008.03.014
