基于格拉布斯準則和改進粒子濾波算法的水下傳感網目標跟蹤

張穎; 高靈君

doi:10.11999/JEIT190079

基于格拉布斯準則和改進粒子濾波算法的水下傳感網目標跟蹤

doi: 10.11999/JEIT190079

張穎^,,
高靈君

上海海事大學信息工程學院上海 201306

基金項目: 國家自然科學基金(61673259)

詳細信息

作者簡介:
張穎：男，1968年生，博士，教授，博士生導師，研究方向為物聯網、海事無線通信、無線自組織網絡

高靈君：女，1994年生，碩士生，研究方向為物聯網信息融合，無線傳感網絡目標跟蹤、預測

通訊作者:
張穎　yingzhang@shmtu.edu.cn

中圖分類號: TP393
計量
- 文章訪問數: 1770
- HTML全文瀏覽量: 681
- PDF下載量: 96
- 被引次數: 0
出版歷程
- 收稿日期: 2019-01-28
- 修回日期: 2019-08-29
- 網絡出版日期: 2019-09-03
- 刊出日期: 2019-10-01

Target Tracking with Underwater Sensor Networks Based on Grubbs Criterion and Improved Particle Filter Algorithm

Ying ZHANG^,,
Lingjun GAO

College of Information Engineering, Shanghai Maritime University, Shanghai 201306, China

Funds: The National Natural Science Foundation of China (61673259)

摘要

摘要: 水下無線傳感網絡(UWSN)執行目標跟蹤時，因為各個傳感器節點測量值對目標狀態估計的貢獻不一樣以及節點能量有限，所以探索一種好的節點融合權重方法和節點規劃機制能夠獲得更好的跟蹤性能。針對上述問題，該文提出一種基于Grubbs準則和互信息熵加權融合的分布式粒子濾波(PF)目標跟蹤算法(GMIEW)。首先利用Grubbs準則對傳感器節點所獲得的信息進行分析檢驗，去除干擾信息和錯誤信息。其次，在粒子濾波的重要性權值計算的過程中，引入動態加權因子，采用傳感器節點的測量值與目標狀態之間的互信息熵，來反映傳感器節點提供的目標信息量，從而獲得各個節點相應的加權因子。最后，采用3維場景下的簇-樹型網絡拓撲結構，跟蹤監測區域內的目標。實驗結果顯示，該算法可有效提高水下傳感器網絡測量數據對目標跟蹤預測的準確度，降低跟蹤誤差。
- 水下無線傳感器網絡 /
- 目標跟蹤 /
- Grubbs準則 /
- 互信息熵 /
- 粒子濾波
Abstract: When the Underwater Wireless Sensor Network (UWSN) performs target tracking, the contributions of the measured values of the nodes are different, and the battery energy carried by the sensor node is limited. Therefore, a good node fusion weight method and node planning mechanism can obtain better tracking performance. A distributed particle filter target tracking algorithm based on Grubbs criterion and Mutual Information Entropy Weighted (GMIEW) fusion is proposed to solve the above problem in this paper. Firstly, the Grubbs criterion is used to analyze and verify the information obtained by the sensor nodes before the information fusion, and the interference information and error information are removed. Secondly, in the process of calculating the importance weight of particle filter, the dynamic weighting factor is introduced. The mutual information entropy between the measured value of the sensor node and the target state is used to reflect the amount of target information provided by the sensor node, so as to obtain the corresponding weighting factor of each node. Finally, the improved cluster-tree network topology is used to track the target in three-dimensional space. Simulation results show that the proposed algorithm improves greatly the accuracy of underwater sensor measurement data for target tracking prediction and reduces the tracking error.
- Underwater Wireless Sensor Network (UWSN) /
- Target tracking /
- Grubbs criterion /
- Mutual information entropy /
- Particle Filtering (PF)

HTML全文

圖 1 水下傳感器網絡模型

下載: 全尺寸圖片幻燈片

圖 2 3維網絡仿真場景

下載: 全尺寸圖片幻燈片

圖 3 觀測噪聲為0.36, 3種算法的不同跟蹤軌跡

下載: 全尺寸圖片幻燈片

圖 5 觀測噪聲為2.00, 3種算法的不同跟蹤軌跡

下載: 全尺寸圖片幻燈片

圖 7 觀測噪聲為5.00, 3種算法的不同跟蹤軌跡

下載: 全尺寸圖片幻燈片

圖 4 觀測噪聲為0.36, 3種不同算法的平均位置RMSE

下載: 全尺寸圖片幻燈片

圖 6 觀測噪聲為2.00, 3種不同算法的平均位置RMSE

下載: 全尺寸圖片幻燈片

圖 8 觀測噪聲為5.00, 3種不同算法的平均位置RMSE

下載: 全尺寸圖片幻燈片

圖 9 小區域數量為4, 3種不同算法的平均位置RMSE

下載: 全尺寸圖片幻燈片

圖 11 小區域數量為16, 3種不同算法的平均位置RMSE

下載: 全尺寸圖片幻燈片

圖 12 不同小區域數量下3種不同算法的能量損耗

下載: 全尺寸圖片幻燈片

圖 10 小區域數量為8, 3種不同算法的平均位置RMSE

下載: 全尺寸圖片幻燈片

表 1 目標跟蹤算法仿真中的參數設置

仿真參數	數值
目標初始位置	(0, 60, 80)
目標初始加速度(m/s²)	(5, 6, –1)
粒子數(個)	2000
聲音傳感器密度ρ(個/m³)	0.00008
仿真次數(次)	50
目標初始速度(m/s)	(15, –20, 4)
采樣間隔	1
監測時長	20
過程噪聲方差	0.1
目標信號能量S	5000

下載: 導出CSV

表 2 3種算法的平均跟蹤反應時間

跟蹤算法	平均跟蹤反應時間
AW	0.1451
AHPW	0.3857
GMIEW	0.5046

下載: 導出CSV

表 3 3D仿真場景中不同傳感器密度ρ下3種算法的平均位置RMSE(個/m³)

算法	0.00006	0.00008	0.00010
AW	3.6452	1.0442	0.9236
AHPW	2.6235	0.8940	0.5024
GMIEW	1.5261	0.5023	0.3026

下載: 導出CSV

參考文獻(24)

HEIDEMANN J, STOJANOVIC M, and ZORZI M. Underwater sensor networks: Applications, advances and challenges[J]. Philosophical Transactions of the Royal Society A: Mathematical, Physical and Engineering Sciences, 2012, 370(1958): 158–175. doi: 10.1098/rsta.2011.0214

SOUZA é L, NAKAMURA E F, and PAZZI R W. Target tracking for sensor networks: A survey[J]. ACM Computing Surveys (CSUR) , 2016, 49(2): 31. doi: 10.1145/2938639

HAN Guangjie, JIANG Jinfang, ZHANG Chenyu, et al. A survey on mobile anchor node assisted localization in wireless sensor networks[J]. IEEE Communications Surveys & Tutorials, 2016, 18(3): 2220–2243. doi: 10.1109/COMST.2016.2544751

周偉, 石為人, 張洪德, 等. 無線傳感器網絡的分布式目標跟蹤研究[J]. 儀器儀表學報, 2013, 34(7): 1485–1491. doi: 10.19650/j.cnki.cjsi.2013.07.007

ZHOU Wei, SHI Weiren, ZHANG Hongde, et al. Study on distributed target tracking in wireless sensor networks[J]. Chinese Journal of Scientific Instrument, 2013, 34(7): 1485–1491. doi: 10.19650/j.cnki.cjsi.2013.07.007

AKYILDIZ I F, POMPILI D, and MELODIA T. Underwater acoustic sensor networks: Research challenges[J]. Ad Hoc Networks, 2005, 3(3): 257–279. doi: 10.1016/j.adhoc.2005.01.004

WANG Xin, XU Mengxi, WANG Huibin, et al. Combination of interacting multiple models with the particle filter for three-dimensional target tracking in underwater wireless sensor networks[J]. Mathematical Problems in Engineering, 2012, 2012: 829451. doi: 10.1155/2012/829451

DEHNAVI S M, AYATI M, and ZAKERZADEH M R. Three dimensional target tracking via underwater acoustic wireless sensor network[C]. 2017 Artificial Intelligence and Robotics, Qazvin, Iran, 2017: 153–157. doi: 10.1109/RIOS.2017.7956459.

ZHANG Qiang, ZHANG Chaojie, LIU Meiqin, et al. Local node selection for target tracking based on underwater wireless sensor networks[J]. International Journal of Systems Science, 2015, 46(16): 2918–2927. doi: 10.1080/00207721.2014.880199

POOSTPASAND M and JAVIDAN R. An adaptive target tracking method for 3D underwater wireless sensor networks[J]. Wireless Networks, 2018, 24(8): 2797–2810. doi: 10.1007/s11276-017-1506-1

ISBITIREN G and AKAN O B. Three-dimensional underwater target tracking with acoustic sensor networks[J]. IEEE Transactions on Vehicular Technology, 2011, 60(8): 3897–3906. doi: 10.1109/TVT.2011.2163538

TISDALE J, RYAN A, KIM Z, et al. A multiple UAV system for vision-based search and localization[C]. 2008 American Control Conference, Seattle, USA, 2008: 1985–1990. doi: 10.1109/ACC.2008.4586784.

RYAN A and HEDRICK J K. Particle filter based information-theoretic active sensing[J]. Robotics and Autonomous Systems, 2010, 58(5): 574–584. doi: 10.1016/j.robot.2010.01.001

HOFFMANN G M and TOMLIN C J. Mobile sensor network control using mutual information methods and particle filters[J]. IEEE Transactions on Automatic Control, 2010, 55(1): 32–47. doi: 10.1109/TAC.2009.2034206

AHMADI H, VIANI F, and BOUALLEGUE R. An accurate prediction method for moving target localization and tracking in wireless sensor networks[J]. Ad Hoc Networks, 2018, 70: 14–22. doi: 10.1016/j.adhoc.2017.11.008

ORACEVIC A, AKBAS S, and OZDEMIR S. Secure and reliable object tracking in wireless sensor networks[J]. Computers & Security, 2017, 70: 307–318. doi: 10.1016/j.cose.2017.06.009

LIU Meiqin, ZHANG Duo, ZHANG Senlin, et al. Node depth adjustment based target tracking in UWSNs using improved harmony search[J]. Sensors, 2017, 17(12): 2807. doi: 10.3390/s17122807

HUANG Yan, LIANG Wei, YU Haibin, et al. Target tracking based on a distributed particle filter in underwater sensor networks[J]. Wireless Communications & Mobile Computing, 2008, 8(8): 1023–1033. doi: 10.1002/wcm.660

胡玲, 侍洪波. 基于分簇的動態協同算法在無線傳感器網絡中的應用[J]. 華東理工大學學報: 自然科學版, 2012, 38(3): 356–359, 390.

HU Ling and SHI Hongbo. Dynamic collaborative algorithms based on clustering routing protocol applied in wireless sensor network[J]. Journal of East China University of Science and Technology:Natural Science Edition, 2012, 38(3): 356–359, 390.

PILLUTLA L S. Network coding based distributed indoor target tracking using wireless sensor networks[J]. Wireless Personal Communications, 2017, 96(3): 3673–3691. doi: 10.1007/s11277-017-4069-7

黃艷, 梁韋, 于海斌. 基于粒子濾波的無線傳感器網絡目標跟蹤算法[J]. 控制與決策, 2008, 23(12): 1389–1394. doi: 10.3321/j.issn:1001-0920.2008.12.014

HUANG Yan, LIANG Wei, YU Haibin, et al. Tracking algorithms based on particle filter for wireless sensor networks[J]. Control and Decision, 2008, 23(12): 1389–1394. doi: 10.3321/j.issn:1001-0920.2008.12.014

SOZER E M, STOJANOVIC M, and PROAKIS J G. Underwater acoustic networks[J]. IEEE Journal of Oceanic Engineering, 2000, 25(1): 72–83. doi: 10.1109/48.820738

ZHANG Bingbing, WANG Yiyin, WANG Hongyi, et al. Tracking a duty-cycled autonomous underwater vehicle by underwater wireless sensor networks[J]. IEEE Access, 2017, 5: 18016–18032. doi: 10.1109/ACCESS.2017.2750322

郭忠文, 羅漢江, 洪鋒, 等. 水下無線傳感器網絡的研究進展[J]. 計算機研究與發展, 2010, 47(3): 377–389.

GUO Zhongwen, LUO Hanjiang, HONG Feng, et al. Current progress and research issues in underwater sensor networks[J]. Journal of Computer Research and Development, 2010, 47(3): 377–389.

柴毅, 屈劍鋒, 郭茂耘, 等. 分布式傳感器網絡在線自適應數據融合算法研究[J]. 儀器儀表學報, 2007, 28(8): 129–134.

CHAI Yi, QU Jianfeng, GUO Maoyun, et al. Distributed online adaptive data fusion algorithm for wireless sensor networks[J]. Chinese Journal of Scientific Instrument, 2007, 28(8): 129–134.
